X9S-BS1000THE BIOSENSOR COMMUNICATES W/THE BEACON & PROX DEV

Note: Installation must be performed by a Proxense authorized professional installer. BioSensor Installation Guide MODEL NUMBER: BS1000 Page i MODEL NUMBER: BS1000 INSTALLATION: This product MUST be installed by a Proxense authorized professional installer. FCC STATEMENTS: THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. © 2010 Proxense, LLC. All rights reserved. Proxense, the Proxense logo, and other Proxense marks are owned by Proxense, LLC and may be registered. All other trademarks are the property of their respective owners. Proxense assumes no responsibility for any errors that may appear in this guide. Information contained herein is subject to change without notice. Corporate Office: Proxense, LLC 689 NW Stonepine Drive Bend, OR 97701 541.382.5745 DOCUMENT NUMBER: PX-9000-0002-00 Revision Log: This log identifies those portions of this document, which have been revised since the initial release and the date of each revision. Date Version Revisions 08/16/10 00 Initial Release BIOSENSOR Installation Guide MODEL NUMBER: BS1000 Page 2 Introduction This Installation Guide is written for a Proxense authorized installation professional. Only a Proxense authorized installation professional may install this product. There are four steps to the installation: • Before you start • Connecting the BioSensor to the client • Installing the ProxAccess client software • Provisioning the BioSensor Step 1: Before you start To ensure that you have the most recent version of this guide, be sure to check our FTP site before you start the installation. Package Contents Your package includes the following items: • This Guide (Your package maybe part of a master pack where only one copy of this guide will be provided.) • One BioSensor • One USB 2.0 cable, Type A to Mini-B Minimum Requirements • A Microsoft Windows ® Client PC with a minimum 1GHZ processor and 1GB RAM equipped with: ƒ Windows XP Pro or later 32 / 64-bit OS with current service packs installed ƒ 10/100/1000BaseT Ethernet Network Interface Card; TCP/IP Protocol ƒ USB 2.0 port ƒ Hard drive with 50MB of free space • Proxense FTP account for downloading ProxAccess client. (Proxense DOES NOT provided any software on media (i.e. CD / DVD). Software is available only by FTP download. • Broadband Internet access Step 2: Connecting the BioSensor to the client There are two connectors located on the rear panel of the BioSensor: a. Mini USB-B: Connect the Type A end of the supplied USB cable to an available USB port on the client PC. Connect the other end of the USB cable to the Mini USB-B port of the BioSensor. b. SMA: If the site survey determined that the BioSensor requires an external RX antenna. Then connect the SMA RF cable from the external antenna to the BioSensor. BIOSENSOR Installation Guide MODEL NUMBER: BS1000 Page 3 Step 3: Installing the ProxAccess Client software a. Run the ProxAccess client setup executable from either a network share or local drive of the client. The Welcome screen will appear. b. Click the Next button to continue with the installation or Click the Cancel button to quit the setup program. c. Select the default destination folder by clicking Next or click the browse button and select another folder. d. Click the Next button to start the installation. e. The Installing ProxAccess Client dialog screen will appear as the system is being updated and files are being copied to the hard drive. BIOSENSOR Installation Guide MODEL NUMBER: BS1000 Page 4 f. When the Successfully Installed dialog screen appears click the Close button. g. The ProxAccess client icon will now be displayed in the system tray. h. Verify that the blue LED (power LED) is ON. Step 4: Provisioning the BioSensor You have completed the client installation. Please contact the system administrator who must now provision the BioSensor. If you need technical assistance Telephone: 561.798.6166 Email: [email protected]

August 16 Federal C Authoriza Confiden t Product N Model No P/N: PX-7 FCC ID: X Pursuant confidenti 1. S 2. P 3. B 4. T The abov e public. Th benefits to The appli c all accom Further, t h treatment Sincerely , Wayne B e Sr. Engine Proxense Florida O f 1013 N St Royal Pal 561.798. 6 6th, 2010 Communicatio tion and Eval tiality Reques Name: BioSen o: BS1000 7100-0001-00 X9S-BS1000 to Sections 0 al treatment o chematic Dia arts List lock Diagra m heory of Ope e documents he public disc o its competit cant understa panying docu he applicant u will remain u , ecker eer , LLC ffice (Enginee tate Road 7 m Beach, FL 6166 Ext 124 ons Commissi uation Divisio st regarding a nsor 0 0.457 and 0.45 of information agram BS BS m BS ration BS contain trad e closure of thes ors. ands that purs umentation wi understands t undisclosed in ering): 33411 4 ion on pplication for 59 of the Com n accompanyi 1000 (P1) – S 1000 (P1) – P 1000 (P1) – B 1000 (P1) – T e secrets and se documents suant to Secti ill not be mad that the docum ndefinitely. certification – mmission’s Ru ing this applic Schematic_FC Parts List_FC Block Diagram Theory of Ope proprietary in s may be har ion 0.457 of t de before the ments listed a – ules, we here cation as liste CC_1.0.pdf CC_1.0.pdf m_FCC_1.1.p eration_FCC_ nformation no rmful to the ap he rules, disc date of the G above as requ eby request lo ed below: pdf _1.1.pdf ot customarily pplicant and p closure of this Grant for this a uiring long ter ong term y released to t provide unjus s application a application. rm confidentia the tified and al

External Photos Proxense, LLC Front Rear Sides Page 1 of 1Rev 1.0 USB 2.0 Mini-B Jack SMA Jack Product Name: BioSensorModel No: BS1000P/N: PX-7100-0001-00HW Build: P1FCC ID: X9S-BS1000

Product Name: BioSensorModel No: BS1000P/N: PX-7100-0001-00HW Build: P1FCC ID: X9S-BS1000 FCC ID Label Artwor k & Label Location Proxense, LLC Scale: 1:1 Page 1 of 1Rev 1.0 5V xxxmA S/N: 1234567890123456789 PROXENSE Model No: BS1000 P/N: PX-7100-0001-00 L/C: ZZZZZZ-ZZ Made in the USA FCC ID: X9S-BS1000 IC: 9282A-BS1000 12345678901234567890 EZZZZZ Dimensions: 1.5 x 0.8” RC 0.062”

Internal Photos Proxense, LLC Front Page 1 of 1Rev 1.0 Back Product Name: BioSensorModel No: BS1000P/N: PX-7100-0001-00HW Build: P1FCC ID: X9S-BS1000

DESIGN ADVANTAGES Best in Class Performance—Smallest Occupied Volume • Powerful combination of 81% peak efficiency and simple implementation guidelines. • Minimal ground clearance and component “keep out” areas. Very low component height. • High selectivity eliminates the cost for additional filters and frees up board space High Tolerance to Frequency Shifts • IMD’s high RF isolation resists antenna detuning that otherwise can impair reception. • Single part works for various PCB sizes and layouts. Quicker Time-to-Market • Fewer design modifications required to pass RF test suite. • Simpler implementation—no matching networks. RoHS Compliant • Antennas comply with appropriate RoHS Directives. SERVICE AND SUPPORT Extensive RF Experience • Our Savvi ceramic antennas are supported by exten- sive application notes, and when needed, by the expertise of RF engineers who have integrated hundreds of antenna designs into wireless devices. Global Operations & Design Support • Ethertronics’ global operations encompass an integrated network of design centers that provide local customer support. Ethertronics’ Savvi series of Isolated Magnetic Dipole™ (IMD) antennas deliver on the key needs of device designers for higher functionality and performance in smaller/thinner designs. These innovative antennas provide compelling advantages for Bluetooth enabled cell phones, media players and other mobile devices. PRODUCT: BLUETOOTH ® Savvi TM Embedded Bluetooth Antennas 2.4—2.5 GHz END USER ADVANTAGES Superior Range • Greater antenna efficiency means longer range and a better end user experience. Exceptional Coverage • Better coverage delivers more reliable wireless connections for mobile phones, laptops, stereo headsets, cars, media players, audio systems and more. ETHERTRONICS 9605 Scranton Road, Suite 300 | San Diego, CA 92121 - USA | www.ethertronics.com tel +(1) 858.550.3820 | fax +(1) 858.550.3821 | contact: [email protected] TECHNOLOGY ADVANTAGES KEY BENEFITS Part No. M830310 Real-World Performance and Implementation Ceramic antennas may look alike on the outside, but the important difference is inside. Other antennas may contain simple PiFA or monopole designs that interact with their surroundings, complicating layout or changing performance with use position. Ethertronics’ antennas utilize patented IMD technology to deliver a unique size and performance combination. Stays in Tune High RF isolation means IMD antennas resist de- tuning regardless of usage position. And one standardized part can typically be placed in a variety of locations. Smallest Effective Size IMD antennas require a smaller keep-out area for surrounding components, leading to a smaller effective size. High Performance IMD’s high efficiency and simple design rules lower development risk and speed time-to-market without sacrificing performance. Plus, high RF selectivity eliminates the cost and space for band-pass circuitry. More information is available on our Website at www.ethertronics.com/resources/. Ethertronics’ Savvi TM Bluetooth Embedded Antenna Specifications Ethertronics produces a wide variety of standard and custom antennas to meet user needs. Below are the typical specs for a Bluetooth application. PRODUCT: Bluetooth ® Antenna Electrical Specifications Typical Characteristics (inside an enclosure) Size 8x3x1.3mm Mounting Surface mount Packaging Tape & Reel Mechanical Specifications Typical Efficiency, Return Loss Antenna Radiation Patterns Typical Performance Ethertronics’ Test Board PCB: 40x80mm BT Antenna 2.4—2.5 GHz Peak Gain 1.39 dBi Average Efficiency 78% VSWR Match 2.0:1 max Feed Point Impedance 50 ohms unbalanced Power Handling .5 Watt cw Polarization Linear 2.4 GHz Band Phi = 0 o Plane Theta = 90 o Plane Phi = 90 o Plane © 2009 Ethertronics. All rights reserved. Ethertronics, the Ethertronics logo, shaping antenna technology, Savvi, Isolated Magnetic Dipole and the iMD logo are trademarks of Ethertronics. All other trademarks are the property of their respective owners. Specifications subject to change and are dependent upon actual implementation. BT 03/27/09 z x z y x y

ANT ARX only Integrated Omni (x2) RX / TX ANT1 ANT2 ANT A (RX only):Various Proxense custom directional antennas with a 0 dBi gain Product Name: BioSensorModel No: BS1000P/N: PX-7100-0001-00HW Build: P1FCC ID: X9S-BS1000 Antenna Technical Description Page 1 of 3Rev 1.1 Proxense, LLC MINI USB-BSMA BIO T TruProxG GatewayM Module

FCC PART 15.247 AND IC RSS-210 TEST REPORT DIGITAL SPREAD SPECTRUM Applicant PROXENSE, LLC. Address 1013 N. State Road 7 Royal Palm Beach, Fl. 33411 USA FCC ID X9S-BS1000 IC 9282A-BS1000 Model Number BS1000 Product Description Bio Sensor with internal antenna Date Sample Received 7/22/2010 Date Tested 7/22/2010 Tested By Richard Block Approved By Mario R. de Aranzeta Report Number 1756AT10TestReport_Ant 1.doc Test Results PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, FL 32669 USA Ph: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com Testing Certificate # 0955-01 APPLICANT: PROXENSE, LLC. FCC ID: X9S-BS1000 IC: 9282A-BS1000 REPORT: Y:\P\PROXENSE\1756AT10\1756AT10TestReport_Ant 1.doc Page 32 of 32 Mdea 3.14.2008 TABLE OF CONTENT GENERAL REMARKS ............................................................................................................................... 4 GENERAL INFORMATION ........................................................................................................................ 5 EMC EQUIPMENT LIST............................................................................................................................ 6 TEST PROCEDURES ................................................................................................................................ 7 CALCULATION OF DUTY CYCLE ............................................................................................................. 8 RADIATION INTERFERENCE ................................................................................................................. 12 POWER LINE CONDUCTED INTERFERENCE ........................................................................................ 16 OCCUPIED BANDWIDTH ....................................................................................................................... 19 POWER OUTPUT .................................................................................................................................... 21 SPURIOUS EMISSIONS AT ANTENNA TERMINALS ............................................................................... 22 RADIATED SPURIOUS EMISSIONS INTO ADJACENT RESTRICTED BAND .......................................... 24 POWER SPECTRAL DENSITY ................................................................................................................ 30 RADIATED EMISSIONS TEST SETUP PHOTO ....................................................................................... 31 POWERLINE CONDUCTED TEST SETUP PHOTO .................................................................................. 32 APPLICANT: PROXENSE, LLC. FCC ID: X9S-BS1000 IC: 9282A-BS1000 REPORT: Y:\P\PROXENSE\1756AT10\1756AT10TestReport_Ant 1.doc Page 32 of 32 Mdea 3.14.2008 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 11/15/2010 APPLICANT: PROXENSE, LLC. FCC ID: X9S-BS1000 IC: 9282A-BS1000 REPORT: Y:\P\PROXENSE\1756AT10\1756AT10TestReport_Ant 1.doc Page 32 of 32 Mdea 3.14.2008 GENERAL INFORMATION DUT Specification Applicable Standard Part 15.247, RSS-210, RSS-GEN DUT Description Bio Sensor with internal antenna FCC ID X9S-BS1000 IC 9282A-BS1000 Operating Frequency TX: 2405-2480 MHz DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Antenna Connector N/A Antenna internal Test Facility Timco Engineering Inc. located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Conditions Temperature: 26ºC Relative humidity: 50% Test Exercise The DUT was placed in continuous transmit mode of operation. Test Supporting Equipment Supporting Device Manufacturer Model / FCC ID Serial Number Netbook Acer Aspire One LUS680B06691915E101601 APPLICANT: PROXENSE, LLC. FCC ID: X9S-BS1000 IC: 9282A-BS1000 REPORT: Y:\P\PROXENSE\1756AT10\1756AT10TestReport_Ant 1.doc Page 32 of 32 Mdea 3.14.2008 EMC EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 3/10/10 3/10/12 AC Voltmeter HP 400FL 2213A14499 CAL 3/23/09 3/23/11 Antenna: Dipole Kit Electro- Metrics TDA-30/1-4 153 CHAR 6/10/09 6/10/11 Frequency Counter HP 5385A 3242A07460 CAL 5/26/09 5/26/11 Hygro- Thermometer Extech 445703 0602 CAL 1/30/09 1/30/11 Modulation Analyzer HP 8901A 3435A06868 CAL 5/26/09 5/26/11 Digital Multimeter Fluke FLUKE-77-3 79510405 CAL 5/18/09 5/18/11 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 11/21/09 11/21/11 Analyzer Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 CAL 11/22/09 11/22/11 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 11/21/09 11/21/11 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 11/24/09 11/24/11 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 4/25/10 4/25/12 APPLICA…

Text truncated - open the document above for the full version.

FCC PART 15.247 AND IC RSS-210 TEST REPORT DIGITAL SPREAD SPECTRUM Applicant PROXENSE, LLC. Address 1013 N. State Road 7 Royal Palm Beach, Fl. 33411 USA FCC ID X9S-BS1000 IC 9282A-BS1000 Model Number BS1000 Product Description Bio Sensor with external antenna Date Sample Received 7/22/2010 Date Tested 7/22/2010 Tested By Richard Block Approved By Mario R. de Aranzeta Report Number 1756AT10TestReport_Ant 2.doc Test Results PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, FL 32669 USA Ph: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com Testing Certificate # 0955-01 APPLICANT: PROXENSE, LLC. FCC ID: X9S-BS1000 IC: 9282A-BS1000 REPORT: Y:\P\PROXENSE\1756AT10\1756AT10TestReport_Ant 2.doc Page 2 of 31 Mdea 3.14.2008 TABLE OF CONTENT GENERAL REMARKS ............................................................................................................................... 3 GENERAL INFORMATION ........................................................................................................................ 4 EMC EQUIPMENT LIST............................................................................................................................ 5 TEST PROCEDURES ................................................................................................................................ 6 CALCULATION OF DUTY CYCLE ............................................................................................................. 7 RADIATION INTERFERENCE ................................................................................................................. 11 POWER LINE CONDUCTED INTERFERENCE ........................................................................................ 15 OCCUPIED BANDWIDTH ....................................................................................................................... 18 POWER OUTPUT .................................................................................................................................... 20 SPURIOUS EMISSIONS AT ANTENNA TERMINALS ............................................................................... 21 RADIATED SPURIOUS EMISSIONS INTO ADJACENT RESTRICTED BAND .......................................... 23 POWER SPECTRAL DENSITY ................................................................................................................ 29 RADIATED EMISSIONS TEST SETUP PHOTO ....................................................................................... 30 POWERLINE CONDUCTED TEST SETUP PHOTO .................................................................................. 31 APPLICANT: PROXENSE, LLC. FCC ID: X9S-BS1000 IC: 9282A-BS1000 REPORT: Y:\P\PROXENSE\1756AT10\1756AT10TestReport_Ant 2.doc Page 3 of 31 Mdea 3.14.2008 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 11/15/2010 APPLICANT: PROXENSE, LLC. FCC ID: X9S-BS1000 IC: 9282A-BS1000 REPORT: Y:\P\PROXENSE\1756AT10\1756AT10TestReport_Ant 2.doc Page 4 of 31 Mdea 3.14.2008 GENERAL INFORMATION DUT Specification Applicable Standard Part 15.247, RSS-210, RSS-GEN DUT Description Bio Sensor with external antenna FCC ID X9S-BS1000 IC 9282A-BS1000 Operating Frequency TX: 2405-2480 MHz DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Antenna external Test Facility Timco Engineering Inc. located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Conditions Temperature: 26ºC Relative humidity: 50% Test Exercise The DUT was placed in continuous transmit mode of operation. Test Supporting Equipment Supporting Device Manufacturer Model / FCC ID Serial Number Netbook Acer Aspire One LUS680B06691915E101601 APPLICANT: PROXENSE, LLC. FCC ID: X9S-BS1000 IC: 9282A-BS1000 REPORT: Y:\P\PROXENSE\1756AT10\1756AT10TestReport_Ant 2.doc Page 5 of 31 Mdea 3.14.2008 EMC EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 3/10/10 3/10/12 AC Voltmeter HP 400FL 2213A14499 CAL 3/23/09 3/23/11 Antenna: Dipole Kit Electro- Metrics TDA-30/1-4 153 CHAR 6/10/09 6/10/11 Frequency Counter HP 5385A 3242A07460 CAL 5/26/09 5/26/11 Hygro- Thermometer Extech 445703 0602 CAL 1/30/09 1/30/11 Modulation Analyzer HP 8901A 3435A06868 CAL 5/26/09 5/26/11 Digital Multimeter Fluke FLUKE-77-3 79510405 CAL 5/18/09 5/18/11 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 11/21/09 11/21/11 Analyzer Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 CAL 11/22/09 11/22/11 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 11/21/09 11/21/11 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 11/24/09 11/24/11 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 4/25/10 4/25/12 APPLICANT: PROXENSE, LLC. FCC ID:…

Text truncated - open the document above for the full version.

APPLICANT: PROXENSE, LLC. FCC ID: X9S-BS1000 TEST SET UP PHOTOS EXTERNAL ANTENNA INTERNAL ANTENNA POWERLINE CONDUCTED EMISSIONS
