X9S-PT1000THE PROXTAG COMMUNICATES W/THE BEACON & SENSORS

Note: Instal llation must b P be performed roxTa by a Proxens ag Ins se authorized stallat professional tion G installer. Guide MODEL NUMBER: PT1000 Page i MODEL NUMBER: PT1000 INSTALLATION: This product MUST be installed by a Proxense authorized professional installer. FCC STATEMENTS: THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. © 2010 Proxense, LLC. All rights reserved. Proxense, the Proxense logo, and other Proxense marks are owned by Proxense, LLC and may be registered. All other trademarks are the property of their respective owners. Proxense assumes no responsibility for any errors that may appear in this guide. Information contained herein is subject to change without notice. Corporate Office: Proxense, LLC 689 NW Stonepine Drive Bend, OR 97701 541.382.5745 DOCUMENT NUMBER: PX-9000-0001-00 Revision Log: This log identifies those portions of this document, which have been revised since the initial release and the date of each revision. Date Version Revisions 08/16/10 00 Initial Release ProxTag Installation Guide MODEL NUMBER: PT1000 Page 2 Introduction This Installation Guide is written for a Proxense authorized installation professional. Only a Proxense authorized installation professional may configure and provisioning this product. There are three steps to the installation: • Before you start • Configuring the ProxTag • Provisioning the ProxTag Step 1: Before you start To ensure that you have the most recent version of this guide, be sure to check our FTP site before you start the installation. Package Contents Your package includes the following items: • This Guide (Your package maybe part of a master pack where only one copy of this guide will be provided.) • One ProxTag Minimum Requirements • ProxNet installation site survey which lists the following: a. Asset information b. Asset type ProxT MODE Ste a. P b. R c. C Ste Pleas If yo Telep Email Tag Installatio EL NUMBER p 2: Con ower On the Run the ProxA Click the Prox p 3: Pro se contact the ou need t phone: 561.79 : support@pr on Guide : PT1000 nfigurin ProxTag by p Admin executa x tags tab. ovisioni e system adm technical 98.6166 roxense.com g the Pr pressing the p able from eith ng the P inistrator who assistan roxTag power button. her a network d. C th ProxTag o must now pr nce share or loc a Click the Add he Prox tag ID g rovision the P al drive of the tag button to D number. P ProxTag. P e client. o add new tag ress OK butto Page 3 g. Enter on.

August 16th, 2010 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification – Product Name: ProxTag Model No: PT1000 P/N: PX-7100-0004-00 FCC ID: X9S-PT1000 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request long term confidential treatment of information accompanying this application as listed below: 1. Schematic Diagram PT1000 (P1) – Schematic_FCC_1.0.pdf 2. Parts List PT1000 (P1) – Parts List_FCC_1.0.pdf 3. Block Diagram PT1000 (P1) – Block Diagram_FCC_1.0.pdf 4. Theory of Operation PT1000 (P1) – Theory of Operation_FCC_1.0.pdf The above documents contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these documents may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Further, the applicant understands that the documents listed above as requiring long term confidential treatment will remain undisclosed indefinitely. Sincerely, Wayne Becker Sr. Engineer Proxense, LLC Florida Office (Engineering): 1013 N State Road 7 Royal Palm Beach, FL 33411 561.798.6166 Ext 124

External Photos Proxense, LLC Front Rear Sides Production SWF RF switch connector exposed (plastic housing drilled) for conducted measurements. Page 1 of 1Rev 1.0 Product Name: ProxTagModel No: PT1000P/N: PX-7100-0004-00HW Build: P1FCC ID: X9S-PT1000

Product Name: ProxTagModel No: PT1000P/N: PX-7100-0004-00HW Build: P1FCC ID: X9S-PT1000 FCC ID Label Artwor k & Label Location Proxense, LLC Scale: 1:1 Page 1 of 1Rev 1.0 3V xxmA S/N: 1234567890123456789 PROXENSE Model No: PT1000 P/N: PX-7100-0004-00 L/C: ZZZZZZ-ZZ Made in the USA FCC ID: X9S-PT1000IC: 9282A-PT1000 12345678901234567890 EZZZZZZ Dimensions: 1.25” x 0.5” RC 0.060”

Internal Photos Proxense, LLC Front Page 1 of 1Rev 1.0 Back Product Name: ProxTagModel No: PT1000P/N: PX-7100-0004-00HW Build: P1FCC ID: X9S-PT1000

Integrated Omni (x2) RX / TX ANT1 ANT2 Antenna Technical Description Page 1 of 3Rev 1.1 Proxense, LLC Product Name: ProxTagModel No: PT1000P/N: PX-7100-0004-00HW Build: P1FCC ID: X9S-PT1000

FCC PART 15.247 AND IC RSS-210 TEST REPORT DIGITAL SPREAD SPECTRUM Applicant PROXENSE, LLC. Address 1013 N. State Road 7 Royal Palm Beach, Fl. 33411 USA FCC ID X9S-PT1000 Model Number PT1000 Product Description Tag Date Sample Received 7/29/2010 Date Tested 7/29/2010 Tested By Richard Block Approved By Mario R. de Aranzeta Report Number 1796AT10TestReport.doc Test Results PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, FL 32669 USA Ph: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com Testing Certificate # 0955-01 APPLICANT: PROXENSE, LLC. FCC ID: X9S-PT1000 IC: 9282A-PT1000 REPORT: P\PROXENSE\1796AT10\1796AT10TestReport.doc Page 2 of 24 Mdea 3.14.2008 TABLE OF CONTENT GENERAL REMARKS ............................................................................................................................... 3 GENERAL INFORMATION ........................................................................................................................ 4 EMC EQUIPMENT LIST............................................................................................................................ 5 TEST PROCEDURES ................................................................................................................................ 6 CALCULATION OF DUTY CYCLE ............................................................................................................. 7 RADIATION INTERFERENCE ................................................................................................................. 10 POWER LINE CONDUCTED INTERFERENCE ........................................................................................ 13 OCCUPIED BANDWIDTH ....................................................................................................................... 14 POWER OUTPUT .................................................................................................................................... 16 SPURIOUS EMISSIONS AT ANTENNA TERMINALS ............................................................................... 17 RADIATED SPURIOUS EMISSIONS INTO ADJACENT RESTRICTED BAND .......................................... 19 POWER SPECTRAL DENSITY ................................................................................................................ 23 RADIATED EMISSIONS TEST SETUP PHOTO ....................................................................................... 24 APPLICANT: PROXENSE, LLC. FCC ID: X9S-PT1000 IC: 9282A-PT1000 REPORT: P\PROXENSE\1796AT10\1796AT10TestReport.doc Page 3 of 24 Mdea 3.14.2008 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 11/16/2010 APPLICANT: PROXENSE, LLC. FCC ID: X9S-PT1000 IC: 9282A-PT1000 REPORT: P\PROXENSE\1796AT10\1796AT10TestReport.doc Page 4 of 24 Mdea 3.14.2008 GENERAL INFORMATION DUT Specification Applicable Standard Part 15.247, RSS-210, RSS-GEN DUT Description Tag FCC ID X9S-PT1000 IC 9282A-PT1000 Operating Frequency TX: 2405-2480 MHz DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Antenna Connector N/A Antenna internal Test Facility Timco Engineering Inc. located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Conditions Temperature: 26ºC Relative humidity: 50% Test Exercise The DUT was placed in continuous transmit mode of operation. Test Supporting Equipment Supporting Device Manufacturer Model / FCC ID Serial Number N/A APPLICANT: PROXENSE, LLC. FCC ID: X9S-PT1000 IC: 9282A-PT1000 REPORT: P\PROXENSE\1796AT10\1796AT10TestReport.doc Page 5 of 24 Mdea 3.14.2008 EMC EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 3/10/10 3/10/12 AC Voltmeter HP 400FL 2213A14499 CAL 3/23/09 3/23/11 Antenna: Dipole Kit Electro- Metrics TDA-30/1-4 153 CHAR 6/10/09 6/10/11 Frequency Counter HP 5385A 3242A07460 CAL 5/26/09 5/26/11 Hygro- Thermometer Extech 445703 0602 CAL 1/30/09 1/30/11 Modulation Analyzer HP 8901A 3435A06868 CAL 5/26/09 5/26/11 Digital Multimeter Fluke FLUKE-77-3 79510405 CAL 5/18/09 5/18/11 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 11/21/09 11/21/11 Analyzer Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 CAL 11/22/09 11/22/11 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 11/21/09 11/21/11 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 11/24/09 11/24/11 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 4/25/10 4/25/12 APPLICANT: PROXENSE, LLC. FCC ID: X9S-PT1000 IC: 9282A-PT1000 REPORT: P\PROXENSE\1796AT10\1796AT10TestReport.doc Page 6 of 24 Mdea 3.14.2008 TEST PROCEDURES Radiation Interference: ANSI C63.4-2003 using a spectrum analyzer, a preselector, a quasi-peak adapter, and an appropriate antenna. The …
