XCNC210400ABCM3380Z D3.0 Wireless eMTA

1 U S E R ’ S M A N U A L DVW3201B 2 Content 1. Introduction.............................................................................................................................3 1.1 Scope..................................................................................................................................4 1.2 Function..............................................................................................................................4 2 Product Specification............................................................................................................4 2.1 Hardware Specification.................................................................................................4 3. Product Requirements..........................................................................................................5 3.1 Hardware Requirements................................................................................................5 3.2 Hardware Architecture..................................................................................................6 4 FCC Notice...............................................................................................................................8 3 Section One: Introduction 1. Introduction Project Name: 802.11 a/b/g/n (2x2) card based on IC BCM43224 with BGA package. Product name:BCM3380Z D3.0 Wireless eMTA The typical use model for this embedded device is to allow the client device to be connected to an 802.11a/b/g/n 2x2 wireless network with infrastructure 4 mode or to serve as an ad-hoc (peer-to-peer) data path. 1.1 Scope The Wireless BCM43224 is an available 11n solution in the 2.4/5GHz band, compatible with the IEEE802.11a/b/g/n. The 802.11 a/g data rate provides for 54, 48, 36, 24, 18, 12, 9, 6Mbps, and 802.11b data rate provides for 11, 5.5, 2, 1Mbps. In addition, 11n provide MCS8~MCS15 for HT20 which PHY data rate up to 150Mbps; also provide MCS8~MCS15 for HT40 with data rate up to 300Mbps. 1.2 Function • RoHS and Green Compliant. • 802.11a/b/g/n 2x2 based on BCM43224. • PCI-E Half Mini Supported. • Module is powered by the host with a 3.3V +/- 10% supply (55mVpp ripple). • Module’s clock source is provided by the on board XTAL Oscillator of 20 MHz (+/- 10ppm). • JTAG connector will be provided for FA and debug. 2 Product Specification 2.1 Hardware Specification Wireless LAN Standards IEEE 802.11 a/b/g/n Operating Frequency 2400~2483.5MHz, 5150~5250MHz, 5725~5850MHz WLAN Data Rate 802.11a/g: 54Mbps with fall back of 48, 36, 24, 18, 12, 9, 6Mbps. 802.11b: 11Mbps with fall back rates of 5.5, 2, and 1Mbps 802.11n: MCS8~MCS15 Transmitter Output Power Typical 10.0dBm(AV) for 11a Typical 15.5dBm(AV) for 11b 5 Typical 15.5dBm(AV) for 11g Typical 14.5dBm(AV) for HT20 Typical 13.5dBm(AV) for HT40 Receiver Sensitivity Typical –65dBm for MCS15 (HT40) @ 10% PER Typical –67dBm for MCS14 (HT40) @ 10% PER Typical –68dBm for MCS13 (HT40) @ 10% PER Typical –71dBm for MCS12 (HT40) @ 10% PER Typical –73dBm for MCS11 (HT40) @ 10% PER Typical –76dBm for MCS10 (HT40) @ 10% PER Typical –79dBm for MCS9 (HT40) @ 10% PER Typical –82dBm for MCS8 (HT40) @ 10% PER Typical –70dBm for MCS15 (HT20) @ 10% PER Typical –72dBm for MCS14 (HT20) @ 10% PER Typical –73dBm for MCS13 (HT20) @ 10% PER Typical –76dBm for MCS12 (HT20) @ 10% PER Typical –79dBm for MCS11 (HT20) @ 10% PER Typical –82dBm for MCS10 (HT20) @ 10% PER Typical –83dBm for MCS9 (HT20) @ 10% PER Typical –85dBm for MCS8 (HT20) @ 10% PER Typical –74dBm for 54Mbps @ 10% PER Typical –76dBm for 48Mbps @ 10% PER Typical –86dBm for 18Mbps @ 10% PER Typical –89dBm for 6Mbps @ 10% PER Typical –89dBm for 11Mbps @ 8% PER Typical –94dBm for 1Mbps @ 8% PER 3. Product Requirements 3.1 Hardware Requirements Host Interface PCI-E 6 3.2 Hardware Architecture This specification describes an embedded 802.11a/b/g/n WiFi interface PCA ‘module’ for embedded device products. The module has two antennae. This module is powered from the host (3.3V) and interfaces to the host with PCIE-half signals. No switches, indicators or related user interface signals are provided on this module. An on-board 20 MHz XTAL is included. I/O PIN DEFINE 7 8 4 FCC Notice Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. I MPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Project No.: 1009C165 Page 14 of 16 1009C165 1009C165 Neutron Engineering Inc. Project No.: 1009C165 Page 14 of 16 1009C165 1009C165 Neutron Engineering Inc. Project No.: 1009C165 Page 15 of 16 1009C165 1009C165 Neutron Engineering Inc. Project No.: 1009C165 Page 15 of 16 1009C165 1009C165 Neutron Engineering Inc. Project No.: 1009C165 Page 16 of 16 1009C165

Neutron Engineering Inc. Project No.: 1009C165 Page 14 of 16 1009C165 1009C165 Neutron Engineering Inc. Project No.: 1009C165 Page 14 of 16 1009C165 1009C165 Neutron Engineering Inc. Project No.: 1009C165 Page 15 of 16 1009C165 1009C165 Neutron Engineering Inc. Project No.: 1009C165 Page 15 of 16 1009C165 1009C165 Neutron Engineering Inc. Project No.: 1009C165 Page 16 of 16 1009C165

1.1. Test Result of RF Exposure Evaluation . Product: BCM3380Z D3.0 Wireless eMTA Test Item: RF Exposure Evaluation Data .Test Mode: Normal Operation 1.1.1. Antenna Gain Ant. Brand Model Name Antenna TypeConnector Gain (dBi) 1 WHA YU C107-510733-AMetal PIFA U.FL [email protected] 4.1dB@5G 2 WHA YU C107-510734-AMetal PIFA U.FL [email protected] 4.4dB@5G 1.1.2. EUT Operation condition Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.1.3. Output Power into Antenna & RF Exposure Evaluation Distance 1.1.4 Modulation Type: OFDM: BPSK, QPSK, 16QAM and 64QAM MIMO: HT20 and HT40 802.11a CH36, CH40, CH 48 (ANT.2) Test Date: Oct 20, 2010 Temperature:24°C Humidity: 60％ Frequency (MHz) Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) 5180 4.4 2.7542 8.96 7.8705 0.004315 1 5200 4.4 2.7542 8.53 7.1285 0.003908 1 5240 4.4 2.7542 9.03 7.9983 0.004385 1 802.11n HT20 CH36, CH40, CH 48 (WITH COMBINER) Test Date: Oct 20, 2010 Temperature:24°C Humidity: 60％ Frequency (MHz) Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) 5180 7.26 5.3211 12.06 16.0694 0.017020 1 5200 7.26 5.3211 11.74 14.9279 0.015811 1 5240 7.26 5.3211 11.59 14.4212 0.015274 1 802.11n HT40 CH38, CH46 (WITH COMBINER) Test Date: Oct 20, 2010 Temperature:24°C Humidity: 60％ Frequency (MHz) Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) 5190 7.26 5.3211 12.03 15.9588 0.016902 1 5230 7.26 5.3211 12.14 16.3682 0.017336 1 The worst data is calculated as 0.017336 mW/cm 2 < limit 1 mW/cm 2 . So, RF exposure limit warning or SAR test are not required. The EUT will only be used with a separation of 20cm or greater between the antenna and nearby persons and can therefore be considered a mobile transmitter per 47CFR2.1091 (b). The RF Exposure Information page from the manual is included here for reference.

Report No.: NEI-FCCP-2-1009C165 Page 2 of 111 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedu res as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences or generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: NEI-FCCP-2-1009C165 Page 3 of 111 Neutron Engineering Inc. Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.4 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION 15 4.1.2 MEASUREMENT INSTRUMENTS LIST 15 4.1.3 TEST PROCEDURE 16 4.1.4 DEVIATION FROM TEST STANDARD 16 4.1.5 TEST SETUP 16 4.1.6 EUT OPERATING CONDITIONS 16 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 MEASUREMENT INSTRUMENTS LIST 20 4.2.3 TEST PROCEDURE 20 4.2.4 TEST SETUP 21 4.2.5 EUT OPERATING CONDITIONS 21 4.2.6 TEST RESULTS-BETWEEN 30MHZ - 1000MHZ 22 4.2.7 TEST RESULTS - ABOVE 1000MHZ - BAND 1 24 5 . 26dB Spectrum Bandwidth 56 5.1 APPLIED PROCEDURES / LIMIT 56 5.1.1 MEASUREMENT INSTRUMENTS LIST 56 5.1.2 TEST PROCEDURE 56 5.1.3 DEVIATION FROM STANDARD 56 5.1.4 TEST SETUP 56 5.1.5 EUT OPERATION CONDITIONS 56 5.1.6 TEST RESULTS - BAND 1 57 6 . Maximum Conducted Output Power 63 Report No.: NEI-FCCP-2-1009C165 Page 4 of 111 Neutron Engineering Inc. Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 63 6.1.1 MEASUREMENT INSTRUMENTS LIST 63 6.1.2 TEST PROCEDURE 63 6.1.3 DEVIATION FROM STANDARD 64 6.1.4 TEST SETUP 64 6.1.5 EUT OPERATION CONDITIONS 64 6.1.6 TEST RESULTS - BAND 1 65 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 75 7.1 APPLIED PROCEDURES / LIMIT 75 7.1.1 MEASUREMENT INSTRUMENTS LIST 75 7.1.2 TEST PROCEDURE 75 7.1.3 DEVIATION FROM STANDARD 75 7.1.4 TEST SETUP 75 7.1.5 EUT OPERATION CONDITIONS 75 7.1.6 TEST RESULTS 76 8 . POWER SPECTRAL DENSITY TEST 90 8.1 APPLIED PROCEDURES / LIMIT 90 8.1.1 MEASUREMENT INSTRUMENTS LIST 90 8.1.2 TEST PROCEDURE 90 8.1.3 DEVIATION FROM STANDARD 90 8.1.4 TEST SETUP 90 8.1.5 EUT OPERATION CONDITIONS 90 8.1.6 TEST RESULTS - BAND 1 91 9 . Peak Excursion Measurement 97 9.1 APPLIED PROCEDURES / LIMIT 97 9.1.1 MEASUREMENT INSTRUMENTS LIST 97 9.1.2 TEST PROCEDURE 97 9.1.3 DEVIATION FROM STANDARD 97 9.1.4 TEST SETUP 97 9.1.5 EUT OPERATION CONDITIONS 97 9.1.6 TEST RESULTS - BAND 1 98 10 . Frequency Stability Measurement 104 10.1 APPLIED PROCEDURES / LIMIT 104 10.1.1 MEASUREMENT INSTRUMENTS LIST 104 10.1.2 TEST PROCEDURE 104 10.1.3 DEVIATION FROM STANDARD 104 10.1.4 TEST SETUP 105 10.1.5 EUT OPERATION CONDITIONS 105 10.1.6 TEST RESULTS 106 Report No.: NEI-FCCP-2-1009C165 Page 5 of 111 Neutron Engineering Inc. Table of Contents Page 11 . RF EXPOSURE TEST 107 11.1 APPLIED PROCEDURES / LIMIT 107 11.1.1 MEASUREMENT INSTRUMENTS LIST 107 11.1.2 MPE CALCULATION METHOD 107 11.1.3 DEVIATION FROM STANDARD 108 11.1.4 TEST SETUP 108 11.1.5 EUT OPERATION CONDITIONS 108 11.1.6 TEST RESULTS - BAND 1 109 12 . EUT TEST PHOTO 110 Report No.: NEI-FCCP-2-1009C165 Page 6 of 111 Neutron Engineering Inc. 1. CERTIFICATION Equipment : BCM3380Z D3.0 Wireless eMTA Brand Name : Ubee Model Name : DVW3201B Applicant : Ubee Interactive Corp. Factory : 1. Hon Fu Jin Precision Industry (ShenZhen) Co., Ltd. 2. Ambit Microsystems (Shanghai) Ltd. Address : 1. No.2, 2 nd Donghuan Road, 10 th Yousong Industrial District, Longhua Town, Baoan,Shenzhen, Guang Dong, China 2. No.1925, Nanle Road Songjiang Export Processing Zone, Shanghai Chia, Post code:201613 Date of Test : Sep. 20, 2010 ~ Oct. 20, 2010 Standards : FCC Part15, Subpart E(15.407) / ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-2-1009C165) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: NEI-FCCP-2-1009C165 Page 7 of 111 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart E Standard Section Test Item Judgment Remark 15.207 AC Power Line Conducted Emissions PASS 15.407(a)(1) DA 02-2138 26dB Spectrum Bandwidth PASS 15.407(a)(1) DA 02-2138 Maximum Conducted Output Power PASS 15.407(a)(1) DA 02-2138 Power Spectral Density PAS…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1009C165 Page 188 of 189 10. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1009C165 Page 188 of 189 10. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1009C165 Page 189 of 189 Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1009C165 Page 189 of 189 Radiated Measurement Photos
