XCNDVW2100BCM3379 Wireless eMTA For Modular:802.11b/g/n WLAN

Neutron Engineering Inc. Project No.: 1006C283 Page 2 of 5 1006C283 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 2 of 5 1006C283 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 3 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 3 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 4 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 4 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 5 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 5 of 5 1006C283 1006C283

Foxconn Confidential T77H241T00 標籤製作黏貼方式 1. Foxconn Label P/N:503.00539.005 (20*8mm) MAC : XXXXXXXXXXXX T77H241T00 HF MO-VVSS MADE IN CHINA Foxconn Label 黏貼位置 圖片僅供參考 Label 列印內容： T77H241T00 HFMO-VVSS: MO: Foxconn Manufa cture Order No: ( 工單號); VVSS ： 產品版本號; VV 為工程版本 ( 參見製造文件封面 Foxconn Label Rev. 欄位 ) 。 - SS 為 A300/A400 產品之版本 ( 參見製造文件封 面 Doc Rev. 之主版本 ) 。 MAC : XXXXXXXXXXXX; MAC Range follow Foxconn Standard; 1 MAC/ pcs Barcode 內容: XXXXXXXXXXXX 為12位 MAC ID 。 Foxconn Confidential 3.Tray Label:503.00090.005(45*8mm) T: Tray 的大寫字母,E : 廠區代碼 ( Follow Last page ） 912: 年周別,如9表示2009年; 12:第12週.A68D:流水號, （36進制） T77H241T00 標籤製作黏貼方式 Foxconn Confidential T77H241T00 標籤製作黏貼方式 廠區代碼(產地編號)

Neutron Engineering Inc. Project No.: 1006C283 Page 2 of 5 1006C283 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 2 of 5 1006C283 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 3 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 3 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 4 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 4 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 5 of 5 1006C283 1006C283 Neutron Engineering Inc. Project No.: 1006C283 Page 5 of 5 1006C283 1006C283

1.1. Test Result of RF Exposure Evaluation . Product: BCM3379 Wireless eMTA For Modular:802.11b/g/n WLAN Test Item: RF Exposure Evaluation Data . Test site: OATS . Test Mode: Normal Operation 1.1.1. Antenna Gain The maximum Gain is 2.0 dBi. 1.1.2. EUT Operation condition Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.1.3. Output Power into Antenna & RF Exposure Evaluation Distance Modulation Standard: DSSS Test Date: Jul 18, 2010 Temperature:24°C Humidity: 60％ TX B MODE CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.0 1.5849 16.21 41.7830 0.01318106 1 Complies 2.0 1.5849 16.18 41.4954 0.01309032 1 Complies 2.0 1.5849 16.35 43.1519 0.01361289 1 Complies Modulation Standard: OFDM Test Date: Jul 18, 2010 Temperature:24°C Humidity: 60％ TX G MODE CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.0 1.5849 15.03 31.8420 0.01004501 1 Complies 2.0 1.5849 15.16 32.8095 0.01035024 1 Complies 2.0 1.5849 15.22 33.2660 0.01049422 1 Complies Modulation Standard: OFDM Test Date: Jul 18, 2010Temperature: 24°C Humidity: 60％ TX N-20M MODE CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.0 1.5849 14.56 28.5759 0.00901468 1 Complies 2.0 1.5849 14.41 27.6058 0.00870864 1 Complies 2.0 1.5849 14.63 29.0402 0.00916116 1 Complies Modulation Standard: OFDM Test Date: Jul 18, 2010 Temperature: 24°C Humidity: 60％ TX N-40M MODE CH03, CH06, CH09 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.0 1.5849 12.45 17.5792 0.00554562 1 Complies 2.0 1.5849 12.36 17.2187 0.00543188 1 Complies 2.0 1.5849 12.58 18.1134 0.00571413 1 Complies The max out EIRP output power of this device is 0.01361289 mW/cm 2 which is below the threshold Level of 1 mW/cm 2 for SAR requirements, So, RF exposure limit warning or SAR test are not required. a For 2412~2462 MHz, the EUT will only be used with a separation of 20cm or greater between the antenna and nearby persons and can therefore be considered a mobile transmitter per 47CFR2.1091 (b). The RF Exposure Information page from the manual is included here for reference.
