XCNDVW325BCM 3383Z Wireless eMTA

Ubee Interactive — www.ubeeinteractive.com 1 Ubee DVW325 – Safety and Installation Product Insert v1.0 DVW325 Advanced Wireless Voice Gateway - Safety and Installation Product Insert Federal Communications Commission (FCC) Interference Statement This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, the device may cause harmful interference to radio communications. There is no guarantee, however, that interference will not occur in a particular installation. If the DEVICE causes harmful interference to radio or television reception, which can be determined by turning it off and on, the user can try to correct the interference by one of the following measures:  Increase the separation between the DEVICE and the equipment with which it is interfering (for example, a television or radio).  Connect the DEVICE into an electrical outlet on a different circuit than the interfered device is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC Regulatory Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. There are two statements for this product:  Only the type of Metal PIFA antenna tested may be used. Ubee Interactive — www.ubeeinteractive.com 2 Ubee DVW325 – Safety and Installation Product Insert v1.0  The device must carry a label stating “FCC ID: XCNDVW325.” FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this device. IEEE 802.11b or 802.11g operation of this device in the U.S.A. is firmware-limited to channels 1 through 11. For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules FCC Radiation Exposure Statement: This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated at a minimum distance of 20cm between itself and your body. This device must not be co-located or operating in conjunction with any other antenna or transmitter. Safety Notices Read these instructions carefully before operating the device. It is important to be aware of these safety instructions. Install the device according to these instructions and keep this guide for future reference. 1. Do not use this device in a humid space, in the rain, or near splashing water. 2. Do not install during thunder or lightening storms. 3. Do not cover any ventilation openings in the device case. 4. Do not place the device near heat sources such as radiators or stoves. 5. Clean the device only with a clean, dry cloth. Do not use liquid or Ubee Interactive — www.ubeeinteractive.com 3 Ubee DVW325 – Safety and Installation Product Insert v1.0 chemical cleaners. 6. Avoid static discharge when touching the device by first touching the coaxial connector of the coaxial cable. 7. Installation of the device should include grounding the coaxial cable to the earth at the building entrance per ANSI/NFPA 70 and the National Electrical Code (NEC, in particular, Section 820.93, Grounding of the Outer Conductive Shield of a Coaxial Cable). The device is designed for IT power systems with phase-to-phase voltage at 120-240V. 8. Disconnecting the Device: If the device becomes damaged or encounters some other abnormality, disconnect the power plug from the AC wall outlet immediately. 9. The device should be installed in a location not to exceed the maximum temperature of 40 degrees Celsius (104 degrees Fahrenheit). 10. When this device is placed upright with the aid of the stand, the stand must be fixed at a 90 degree angle to the device. Otherwise, the device will have the risk of tipping over. Installation To install this device, follow the procedures below and refer to the following page for a connection diagram. 1. Connect one end of a coaxial cable (not included) to the CABLE port on the device. Connect the other end to a cable splitter or the cable wall outlet. Be sure not to bend or over tighten the cables as this may strain the connector and cause damage. If you plan to connect the device and a television to the same cable wall outlet, you must use a cable line splitter (not included). Ubee Interactive — www.ubeeinteractive.com 4 Ubee DVW325 – Safety and Installation Product Insert v1.0 2. Connect one end of the supplied Ethernet cable to one of the ETHERNET ports (ETH1 to ETH4) on the device. Connect the other end to the ETHERNET port on a PC. Note: Category 5e or Category 6 Ethernet cables with RJ45 connectors must be used when connecting Ethernet devices to the LAN ports. This ensures Gigabit Ethernet speeds (unless the computer does not support it). 3. Connect one end of an RJ11 phone cable to one of the TEL ports on the device (a port that has been provisioned for voice service as specified by the service provider). Connect the other end to the phone port of the telephone. Note: If voice service is not provisioned through the service provider, telephone service is not available. 4. Connect the power adapter to the POWER port on the device. Plug the other end of the power adapter into the AC wall outlet. Important: Use only the power adapter that is shipped with the device. Ubee Interactive — www.ubeeinteractive.com 5 Ubee DVW325 – Safety and Installation Product Insert v1.0 Wall-Mount Installation You can mount the device on a wall using the 2…

Text truncated - open the document above for the full version.

Report No.: 121129C04 Page 1 CONSTRUCTION PHOTOS OF EUT Model: DVW325 Report No.: 121129C04 Page 10 Report No.: 121129C04 Page 11

0.02012.08.29 U10C076.91 PTT Label 500.01577.005 Yanli Yu Cun Zhou Cun Factory ID list =========================== (100544-836) FUHONG PRECISION COMPONENT (BAC GIANG) LTD DINH TRAM INDUSTRY PARK VIET YEN DISTRICT VIET NAM Factory ID: Y =========================== (100568-850) NANNING FUGUI PRECISION INDUSTRIAL CO LTD 18 ZONGBU RD NEW & HIGH-TECH INDUSTRIAL DEVELOPMENT ZONE NANNING GUANGXI CHINA Factory ID: N ============================ (128685-001) AMBIT MICROSYSTEMS (SHANGHAI) LTD 1925 NAN-LE RD SONGJIANG EXPORT PROCESSING ZONE SHANGHAI 201613 CHINA Factory ID: E ================================ (223850-001) HONG FU JIN PRECISION INDUSTRY (SHENZHEN) CO LTD 10TH YOUSONG INDUSTRIAL DISTRICT 2ND DONGHUAN RD NO 2 BAO'AN LONGHUA TOWN SHENZHEN 518109 GUANGDONG CHINA Factory ID: F ================================== NOTES: 1.Material: #50 Mylar + 25# PET(matte, printable) 2.Adhesive: 3.Adhesive thickness : 50#Mylar: 0.025+/-0.003mm 25#PET: 0.018+/-0.003mm 4.Printing Color:Black 5.Background: White 6.Liner:Glassine release paper 7.Packaging Style: Reel 8.The part must be RoHS compliant Model name: DVW325 FCC ID: XCNDVW325 This device complies with part 15 of the FCC Rules. RoHS 2011/65/EU Model name: DVW325 FCC ID: XCNDVW325 This device complies with part 15 of the FCC Rules. RoHS 2011/65/EU Ubee Part No.: DVW325.GB Rating: 100-240VAC,50-60Hz,0.8A Max PTT label 500.01577.005 54*40mm Ubee Part No.: Rating: 100-240VAC,50-60Hz,0.8A Max Factory ID: X Scale:1/1 Vendor Provide Foxconn printing Arial, 6.2pt "X": UL Factory ID, please see the list, if the manufacturer is not in the list, please confirm with PM or Compliance Engineer. Foxconn printing Arial, 6pt 0.1 2012.12.11 change Customer PN to DVW325.GB Cun T Housing label Label placement T PTT label

Report No.: 121129C04 Page 2 Model: DVW325 Report No.: 121129C04 Page 3 Report No.: 121129C04 Page 4 Report No.: 121129C04 Page 5 Report No.: 121129C04 Page 6 Report No.: 121129C04 Page 7 Report No.: 121129C04 Page 8 Report No.: 121129C04 Page 9

FCC ID: XCNDVW325 Report No.: RF121129C04 Operational Description This device is a 3BCM 3383Z Wireless eMTA, which operates in both 2.4GHz and 5GHz bands; the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by the 12Vdc from AC adapter. The antenna is PIFA antenna with I-PEX antenna connector. The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA121129C04 1 of 6 Report Format Version 5.0.0 : RF EXPOSURE REPORT REPORT NO.: SA121129C04 MODEL NO.: DVW325 FCC ID: XCNDVW325 RECEIVED: Nov. 29, 2012 TESTED:Jan. 15, 2013 ISSUED:Jan. 31, 2013 APPLICANT: Ubee Interactive Corp. ADDRESS: 10F-1, No.5, Taiyuan 1st St., Jhubei City Hsinchu Country 302, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA121129C04 2 of 6 Report Format Version 5.0.0 : TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT ............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER .......................... 6 Report No.: SA121129C04 3 of 6 Report Format Version 5.0.0 : RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA121129C04 Original release Jan. 31, 2013 Report No.: SA121129C04 4 of 6 Report Format Version 5.0.0 : 1. CERTIFICATION PRODUCT: BCM 3383Z Wireless eMTA BRAND NAME: Ubee MODEL NO.: DVW325 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Ubee Interactive Corp. TESTED DATE: Jan. 15, 2013 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: DVW325) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Jan. 31, 2013 ( Claire Kuan, Specialist ) APPROVED BY : , DATE:Jan. 31, 2013 ( May Chen, Deputy Manager ) Report No.: SA121129C04 5 of 6 Report Format Version 5.0.0 : 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA121129C04 6 of 6 Report Format Version 5.0.0 : 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 557.261 4.10 20 0.28496 1 For 15.247(5GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 475.399 5.37 20 0.32568 1 For 15.407(5GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180 ~ 5240 48.295 4.73 20 0.02855 1 --- END ---

Report No.: RF121129C04 R1 1 of 91 Report Format Version 5.1.0 Cancels and replaces the report No.: RF121129C04 dated Jan. 31, 2013 FCC TEST REPORT (15.247) REPORT NO.: RF121129C04 R1 MODEL NO.: DVW325 FCC ID: XCNDVW325 RECEIVED: Nov. 29, 2012 TESTED: Jan. 15 to 17, 2013 ISSUED: Feb. 04, 2013 APPLICANT: Ubee Interactive Corp. ADDRESS: 10F-1, No.5, Taiyuan 1st St., Jhubei City Hsinchu Country 302, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF121129C04 R1 2 of 91 Report Format Version 5.1.0 Cancels and replaces the report No.: RF121129C04 dated Jan. 31, 2013 Table of Contents RELEASE CONTROL RECORD .......................................................................................... 5 1. CERTIFICATION ...................................................................................................... 6 2. SUMMARY OF TEST RESULTS .............................................................................. 7 2.1 MEASUREMENT UNCERTAINTY ........................................................................... 8 3. GENERAL INFORMATION ....................................................................................... 9 3.1 GENERAL DESCRIPTION OF EUT ......................................................................... 9 3.2 DESCRIPTION OF TEST MODES ......................................................................... 12 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ......................... 13 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................ 16 3.4 DESCRIPTION OF SUPPORT UNITS ................................................................... 17 3.5 CONFIGURATION OF SYSTEM UNDER TEST .................................................... 18 4. TEST TYPES AND RESULTS (fOR 2.4GHz, 2.400 ~ 2.4835GHz Band) .............. 19 4.1 CONDUCTED EMISSION MEASUREMENT ......................................................... 19 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................... 19 4.1.2 TEST INSTRUMENTS ........................................................................................... 19 4.1.3 TEST PROCEDURES ............................................................................................ 20 4.1.4 DEVIATION FROM TEST STANDARD .................................................................. 20 4.1.5 TEST SETUP ......................................................................................................... 20 4.1.6 EUT OPERATING CONDITIONS ........................................................................... 21 4.1.7 TEST RESULTS ..................................................................................................... 22 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................. 24 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 24 4.2.2 TEST INSTRUMENTS ........................................................................................... 25 4.2.3 TEST PROCEDURES ............................................................................................ 27 4.2.4 DEVIATION FROM TEST STANDARD .................................................................. 27 4.2.5 TEST SETUP ......................................................................................................... 28 4.2.6 EUT OPERATING CONDITIONS ........................................................................... 28 4.2.7 TEST RESULTS ..................................................................................................... 29 4.3 6dB BANDWIDTH MEASUREMENT ..................................................................... 42 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................... 42 4.3.2 TEST INSTRUMENTS ........................................................................................... 42 4.3.3 TEST PROCEDURE .............................................................................................. 42 4.3.4 DEVIATION FROM TEST STANDARD .................................................................. 42 4.3.5 TEST SETUP ..........................................…

Text truncated - open the document above for the full version.

Report No.: RF121129C04-1 R1 1 of 52 Report Format Version 5.1.0 Cancels and replaces the report No.: RF121129C04-1 dated Jan. 31, 2013 FCC TEST REPORT (15.407) REPORT NO.: RF121129C04-1 R1 MODEL NO.: DVW325 FCC ID: XCNDVW325 RECEIVED: Nov. 29, 2012 TESTED: Jan. 15 to 17, 2013 ISSUED: Feb. 04, 2013 APPLICANT: Ubee Interactive Corp. ADDRESS: 10F-1, No.5, Taiyuan 1st St., Jhubei City Hsinchu Country 302, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF121129C04-1 R1 2 of 52 Report Format Version 5.1.0 Cancels and replaces the report No.: RF121129C04-1 dated Jan. 31, 2013 Table of Contents RELEASE CONTROL RECORD ............................................................................. 4 1. CERTIFICATION ........................................................................................... 5 2. SUMMARY OF TEST RESULTS .................................................................. 6 2.1 MEASUREMENT UNCERTAINTY ..................................................................... 7 3. GENERAL INFORMATION ........................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ............................................................. 8 3.2 DESCRIPTION OF TEST MODES ............................................................. 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............. 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................. 14 3.4 DUTY CYCLE OF TEST SIGNAL ............................................................... 15 3.5 DESCRIPTION OF SUPPORT UNITS ....................................................... 16 3.6 CONFIGURATION OF SYSTEM UNDER TEST ......................................... 17 4. TEST TYPES AND RESULTS .................................................................... 18 4.1 CONDUCTED EMISSION MEASUREMENT .............................................. 18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................... 18 4.1.2 TEST INSTRUMENTS ................................................................................ 18 4.1.3 TEST PROCEDURES ................................................................................ 19 4.1.4 DEVIATION FROM TEST STANDARD ....................................................... 19 4.1.5 TEST SETUP .............................................................................................. 19 4.1.6 EUT OPERATING CONDITIONS ............................................................... 20 4.1.7 TEST RESULTS ......................................................................................... 21 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ..................... 23 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ... 23 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS23 4.2.3 TEST INSTRUMENTS ................................................................................ 24 4.2.4 TEST PROCEDURES ................................................................................ 26 4.2.5 DEVIATION FROM TEST STANDARD ....................................................... 26 4.2.6 TEST SETUP .............................................................................................. 27 4.2.7 EUT OPERATING CONDITION .................................................................. 27 4.2.8 TEST RESULTS ......................................................................................... 28 4.3 TRANSMIT POWER MEASUREMENT ...................................................... 37 4.3.1 LIMITS OF TRANSMIT POWER MEASUREMENT .................................... 37 4.3.2 TEST INSTRUMENTS ................................................................................ 37 4.3.3 TEST PROCEDURE ................................................................................... 38 4.3.4 DEVIATION FROM TEST STANDARD ....................................................... 38 4.3.5 TEST SETUP .............................................................................................. 38 4.3.6 EUT OPERATING CONDITIONS ............................................................... 39 4.3.7 TEST RESULTS ....…

Text truncated - open the document above for the full version.

Report No.: 120702E04 1 of 2 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: 120702E04 2 of 2 RADIATED EMISSION TEST
