XCNDVW32GWireless eMTA

Ubee Interactive — www.ubeeinteractive.com 1 Ubee DVW32G6 – Safety and Installation Produc t Insert v1.0 DVW32G6 Advanced Wireless Voice Gateway - Safety and Installation Product Insert Federal Communications Commission (FCC) Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device , pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Regulatory Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. There is one statement for this product: • Only the type of PCB antenna tested may be Ubee Interactive — www.ubeeinteractive.com 2 Ubee DVW32G6 – Safety and Installation Produc t Insert v1.0 used. Devices will not permit operations on channels 120-132 for 11a and 11n/a which overlap the 5600 - 5650 MHz band. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. For product available in the USA/Canada market, only channel 1 ~ 11 can be operated. Selection of other channels is not possible. For operation within 5.15 ~ 5.25GHz / 5.47 ~5.725GHz frequency range, it is restricted to indoor environment. FCC Radiation Exposure Statement: This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated at a minimum distance of 28cm between itself and your body. This device and it's antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. Safety Notices Read these instructions carefully before operating the device. It is important to be aware of these safety instructions. Install the device according to these instructions and keep this guide for future reference. 1. Do not use this device in a humid space, in the rain, or near splashing water. 2. Do not install during thunder or lightning storms. 3. Do not cover any ventilation openings in the device case. 4. Do not place the device near heat sources such as radiators or stoves. Ubee Interactive — www.ubeeinteractive.com 3 Ubee DVW32G6 – Safety and Installation Produc t Insert v1.0 5. Clean the device only with a clean, dry cloth. Do not use liquid or chemical cleaners. 6. Avoid static discharge when touching the device by first touching the coaxial connector of the coaxial cable. 7. Installation of the device should include grounding the coaxial cable to the earth at the building entrance per ANSI/NFPA 70 and the National Electrical Code (NEC, in particular, Section 820.93, Grounding of the Outer Conductive Shield of a Coaxial Cable). The device is designed for IT power systems with phase-to-phase voltage at 110V. 8. Disconnecting the Device : If the device becomes damaged or encounters some other abnormality, disconnect the power plug from the AC wall outlet immediately. 9. The device should be installed in a location not to exceed the maximum temperature of 40 degrees Celsius (104 degrees Fahrenheit). 10. This device MUST be placed upright for best WiFi coverage with the aid of the stand, the stand must be fixed at a 90-degree angle to the device. Otherwise, the device will have the risk of tipping over. 11. Keep the device away from Children and Pets. 12. Place the device on a cool surface. Failure to do so may result in overheating which can cause extreme damage. 13. Do not modify or attempt to disassemble the device. Use it only according to the instructions. 14. Do not dispose of the device in a trash container. Please recycle. Ubee Interactive — www.ubeeinteractive.com 4 Ubee DVW32G6 – Safety and Installation Produc t Insert v1.0 Installation To install this device, follow the procedures below and refer to the following page for a connection diagram. 1. Connect one end of a coaxial cable (not included) to the CABLE port on the device. Connect the other end to a cable splitter or the cable wall outlet. Be sure not to bend or over tighten the cables as this may strain the connector and cause damage. If you plan to connect the device and a television to the same cable wall outlet, you must use a cable line splitter (not included). 2. Connect one end of the supplied Ethernet cable to one of the ETHERNET ports (ETH1 to ETH4) on the device. Connect the other end to the ETHERNET port on a PC. Note: Category 5e or Category 6 Ethernet cables with RJ-45 connectors must be used when connecting Ethernet devices to the LAN ports. This ensures Gigabit Ethernet speeds (unless the computer does not support it). 3. Connect one end of an RJ-11 phone cable to one of the TEL ports on the device (a port that has been provisioned for voice service as specified by the service provider). Connect the other end to the phone port of the telephone. Note: If voice service is not provision…

Text truncated - open the document above for the full version.

Software Operational Description

Report No.: 141029E01 1 of 25 CONSTRUCTION PHOTOS OF EUT Report No.: 141029E01 2 of 25 Report No.: 141029E01 3 of 25 Report No.: 141029E01 24 of 25 Report No.: 141029E01 25 of 25

Factory ID list =========================== (100544-836) FUHONG PRECISION COMPONENT (BAC GIANG) LTD DINH TRAM INDUSTRY PARK VIET YEN DISTRICT VIET NAM Factory ID:Y =========================== (100568-850) NANNING FUGUI PRECISION INDUSTRIAL CO LTD 18 ZONGBU RD NEW & HIGH-TECH INDUSTRIAL DEVELOPMENT ZONE NANNING GUANGXI CHINA Factory ID:N ============================ (128685-001) AMBIT MICROSYSTEMS (SHANGHAI) LTD 1925 NAN-LE RD SONGJIANG EXPORT PROCESSING ZONE SHANGHAI 201613 CHINA Factory ID:E ================================ (223850-001) HONG FU JIN PRECISION INDUSTRY (SHENZHEN) CO LTD 10TH YOUSONG INDUSTRIAL DISTRICT 2ND DONGHUAN RD NO 2 BAO'AN LONGHUA TOWN SHENZHEN 518109 GUANGDONG CHINA Factory ID:F ================================== Packaging Style 2014.07.30 U10C095.80 I.T.E. E199598 8G92 Vendor code Scale:1:1 Vendor provide 500.0XXXX.005 "X": UL Factory ID, please see the list, if the manufacturer is not in the list, please confirm with PM or Compliance Engineer. Foxconn printing Arial, 5pt Scale:1:1 Foxconn printing,Arial Bold 8.4pt Foxconn printing,Arial Regular 8.4pt 0.12014.10.30update FCC warningZhou Cun 0.22014.11.19update ratingZhou Cun Factory ID: X Ubee Part No.: DVW32G6 FCC ID: XCNDVW32G Model No.: DVW32G This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Rating: 120Vac,60Hz,0.9A Ubee Part No.: FCC ID: XCNDVW32G Model No.: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Rating: 120Vac,60Hz,0.9A (Fig. 1) FCC ID: XCNDVW32G FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. EUT Back Label

Report No.: 141029E01 4 of 25 Report No.: 141029E01 5 of 25 Report No.: 141029E01 6 of 25 Rev 1.0 Report No.: 141029E01 7 of 25 Report No.: 141029E01 8 of 25 Report No.: 141029E01 9 of 25 Report No.: 141029E01 10 of 25 Report No.: 141029E01 11 of 25 Report No.: 141029E01 12 of 25 Antenna set 1 Report No.: 141029E01 13 of 25 Report No.: 141029E01 14 of 25 Report No.: 141029E01 15 of 25 Report No.: 141029E01 16 of 25 Report No.: 141029E01 17 of 25 Report No.: 141029E01 18 of 25 Antenna set 2 Report No.: 141029E01 19 of 25 Report No.: 141029E01 20 of 25 Report No.: 141029E01 21 of 25 Report No.: 141029E01 22 of 25 Report No.: 141029E01 23 of 25

Report No.: SA141029E01 1 of 9 Report Format Version 5.2.1 RF EXPOSURE REPORT REPORT NO.: SA141029E01 MODEL NO.: DVW32G FCC ID: XCNDVW32G RECEIVED:Oct. 29, 2014 TESTED:Dec. 08, 2014 ISSUED:Dec. 23, 2014 APPLICANT: Ubee Interactive Corp. ADDRESS: 10F-1, No.5, Taiyuan 1st St. Jhubei Hsinchu, 302 Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA141029E01 2 of 9 Report Format Version 5.2.1 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT ............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN ...................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER .......................... 7 Report No.: SA141029E01 3 of 9 Report Format Version 5.2.1 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA141029E01 Original release Dec. 23, 2014 Report No.: SA141029E01 5 of 9 Report Format Version 5.2.1 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 28cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA141029E01 6 of 9 Report Format Version 5.2.1 5. ANTENNA GAIN 1. The antennas provided to the EUT, please refer to the following table: Antenna set 1 Antenna No. Brand Model Gain (dBi) Including cable loss Antenna Type Connecter Type Frequency range (GHz to GHz) 1 WHA YU NA 4.6 Dipole (PCB) MHF 2.4~2.4835 4.4 5.15~5.25 6.3 5.725~5.850 2 WHA YU NA 6 Dipole (PCB) MHF 2.4~2.4835 4.6 5.15~5.25 5.8 5.725~5.850 3 WHA YU NA 5.3 Dipole (PCB) MHF 2.4~2.4835 3.8 5.15~5.25 4.2 5.725~5.850 Antenna set 2 Antenna No. Brand Model Gain (dBi) Including cable loss Antenna Type Connecter Type Frequency range (GHz to GHz) 1 (Black) TONGDA NA 4.453 Dipole (PCB) MHF 2.4~2.4835 4.289 5.15~5.25 6.158 5.725~5.850 2 (Gray) TONGDA NA 5.989 Dipole (PCB) MHF 2.4~2.4835 4.442 5.15~5.25 5.633 5.725~5.850 3 (White) TONGDA NA 5.120 Dipole (PCB) MHF 2.4~2.4835 3.508 5.15~5.25 4.058 5.725~5.850 Report No.: SA141029E01 7 of 9 Report Format Version 5.2.1 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): CDD Mode: 802.11b: FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 ~ 2462 437.359 10.09 28 0.45322 1 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 + 10 G3/20 ) 2 / 3] = 10.09dBi 802.11g: FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 ~ 2462 679.335 10.09 28 0.70397 1 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 + 10 G3/20 ) 2 / 3] = 10.09dBi VHT20: FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 ~ 2462 584.672 10.09 28 0.60588 1 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 + 10 G3/20 ) 2 / 3] = 10.09dBi VHT40: FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2422 ~ 2452 188.996 10.09 28 0.19585 1 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 + 10 G3/20 ) 2 / 3] = 10.09dBi Beamforming Mode: VHT20: FREQUE…

Text truncated - open the document above for the full version.

Report No.:RF141029E01-2 1 of 29 Report Format Version 5.2.1 Supplemental “Transmit Simultaneously” Test Report REPORT NO.: RF141029E01-2 MODEL NO.: DVW32G FCC ID: XCNDVW32G RECEIVED: Oct. 29, 2014 TESTED: Oct. 29 to Dec. 08, 2014 ISSUED: Dec. 23, 2014 APPLICANT: Ubee Interactive Corp. ADDRESS: 10F-1, No.5, Taiyuan 1st St. Jhubei Hsinchu, 302 Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.:RF141029E01-2 2 of 29 Report Format Version 5.2.1 Table of Contents RELEASE CONTROL RECORD ......................................................................................................... 3 1. CERTIFICATION .................................................................................................................... 4 2. SUMMARY OF TEST RESULTS ............................................................................................ 5 2.1 MEASUREMENT UNCERTAINTY ......................................................................................... 6 3. GENERAL INFORMATION .................................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ....................................................................................... 7 3.2 TEST MODE APPLICABLITY AND TESTED CHANNEL DETAIL: ...................................... 10 3.3 DESCRIPTION OF SUPPORT UNITS ................................................................................. 12 3.4 CONFIGURATION OF SYSTEM UNDER TEST .................................................................. 13 4. TEST TYPES AND RESULTS .............................................................................................. 14 4.1 CONDUCTED EMISSION MEASUREMENT ....................................................................... 14 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................................... 14 4.1.2 TEST INSTRUMENTS ......................................................................................................... 14 4.1.3 TEST PROCEDURES .......................................................................................................... 15 4.1.4 DEVIATION FROM TEST STANDARD ................................................................................ 15 4.1.5 TEST SETUP ....................................................................................................................... 15 4.1.6 EUT OPERATING CONDITIONS ......................................................................................... 16 4.1.7 TEST RESULTS ................................................................................................................... 17 4.2 RADIATED EMISSION MEASUREMENT ............................................................................ 19 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 19 4.2.2 TEST INSTRUMENTS ......................................................................................................... 20 4.2.3 TEST PROCEDURES .......................................................................................................... 22 4.2.4 DEVIATION FROM TEST STANDARD ................................................................................ 22 4.2.5 TEST SETUP ....................................................................................................................... 23 4.2.6 EUT OPERATING CONDITIONS ......................................................................................... 23 4.2.7 TEST RESULTS ................................................................................................................... 24 4.3 CONDUCTED OUT-BAND EMISSION MEASUREMENT ................................................... 26 4.3.1 LIMITS OF CONDUCTED OUT-BAND EMISSION MEASUREMENT ................................ 26 4.3.2 TEST INSTRUMENTS ......................................................................................................... 26 4.3.3 TEST PROCEDURE ............................................................................................................ 26 4.3.4 DEVIATION FROM TEST STANDARD ............…

Text truncated - open the document above for the full version.

Report No.: RF141029E01 1 of 86 Report Format Version 5.2.1 FCC TEST REPORT (WLAN 15.247) REPORT NO.: RF141029E01 MODEL NO.: DVW32G FCC ID: XCNDVW32G RECEIVED: Oct. 29, 2014 TESTED: Nov. 25 to Dec. 08, 2014 ISSUED: Dec. 23, 2014 APPLICANT: Ubee Interactive Corp. ADDRESS: 10F-1, No.5, Taiyuan 1st St. Jhubei Hsinchu, 302 Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF141029E01 2 of 86 Report Format Version 5.2.1 Table of Contents RELEASE CONTROL RECORD .......................................................................................... 4 1. CERTIFICATION ....................................................................................................... 5 2. SUMMARY OF TEST RESULTS .............................................................................. 6 2.1 MEASUREMENT UNCERTAINTY ............................................................................ 7 3. GENERAL INFORMATION ....................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ......................................................................... 8 3.2 DESCRIPTION OF TEST MODES ......................................................................... 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ......................... 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................ 15 3.4 DUTY CYCLE OF TEST SIGNAL ........................................................................... 16 3.5 DESCRIPTION OF SUPPORT UNITS ................................................................... 17 3.6 CONFIGURATION OF SYSTEM UNDER TEST .................................................... 18 4. TEST TYPES AND RESULTS ................................................................................ 19 4.1 CONDUCTED EMISSION MEASUREMENT ......................................................... 19 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ....................................... 19 4.1.2 TEST INSTRUMENTS ............................................................................................ 19 4.1.3 TEST PROCEDURES ............................................................................................ 20 4.1.4 DEVIATION FROM TEST STANDARD................................................................... 20 4.1.5 TEST SETUP .......................................................................................................... 20 4.1.6 EUT OPERATING CONDITIONS ........................................................................... 21 4.1.7 TEST RESULTS ..................................................................................................... 22 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................. 24 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 24 4.2.2 TEST INSTRUMENTS ............................................................................................ 25 4.2.3 TEST PROCEDURES ............................................................................................ 27 4.2.4 DEVIATION FROM TEST STANDARD................................................................... 27 4.2.5 TEST SETUP .......................................................................................................... 28 4.2.6 EUT OPERATING CONDITIONS ........................................................................... 28 4.2.7 TEST RESULTS (MODE 1) .................................................................................... 29 4.2.8 TEST RESULTS (MODE 2) .................................................................................... 42 4.3 6dB BANDWIDTH MEASUREMENT ...................................................................... 48 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................... 48 4.3.2 TEST INSTRUMENTS ............................................................................................ 48 4.3.3 TEST PROCEDURE ............................................................................................... 48 4.3.4 DEVIATION FROM TEST STANDARD.........................…

Text truncated - open the document above for the full version.

Report No.: RF141029E01-1 1 of 87 Report Format Version 5.3.0 FCC TEST REPORT (WLAN 15.407) REPORT NO.: RF141029E01-1 MODEL NO.: DVW32G FCC ID: XCNDVW32G RECEIVED: Oct. 29, 2014 TESTED: Nov. 25 to Dec. 08, 2014 ISSUED: Dec. 23, 2014 APPLICANT: Ubee Interactive Corp. ADDRESS: 10F-1, No.5, Taiyuan 1st St. Jhubei Hsinchu, 302 Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF141029E01-1 2 of 87 Report Format Version 5.3.0 Table of Contents RELEASE CONTROL RECORD ............................................................................. 4 1. CERTIFICATION ........................................................................................... 5 2. SUMMARY OF TEST RESULTS .................................................................. 6 2.1 MEASUREMENT UNCERTAINTY ................................................................ 7 3. GENERAL INFORMATION ........................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ............................................................. 8 3.2 DESCRIPTION OF TEST MODES ............................................................. 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............. 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ...........................…

Text truncated - open the document above for the full version.
