XJG-JOHNS1MOBILE PHONE; BRAND: JOHN'S; MODEL: JOHN'S 1

Initialize each page: Page 1/15 User Manual Model：John’s 1 Brand：John’s EXHIBIT D: FTS PHONE SOFTWARE SPEC (SW) Initialize each page: Page 2/15 Contents 1. For Your Safety ............................................................................................................................... 3 2. Phone Feature .................................................................................................................................. 4 3. Keys and Part .................................................................................................................................. 5 4. Basic Function ................................................................................................................................. 6 4.1 Get started ......................................................................................................................... 6 4.2 Security .............................................................................................................................. 9 5．Screens referenced in this SW ................................................................................................. 9 EXHIBIT D: FTS PHONE SOFTWARE SPEC (SW) Initialize each page: Page 3/15 1. For Your Safety Please read these simple guidelines. Not following them may be dangerous or illegal。 Road safety comes first Do not use the phone hand-held while driving. If using the phone hand-held, park the vehicle before conversing. Switch off in aircraft Switch your phone off when on an aircraft. The aircraft’s systems may be affected by the phone signal. You are legally obliged to comply with this recommendation. Switch off near blasting Switch your phone off when blasting is in progress. Observe any provided guidelines or regulations. Switch off when refueling Do not use your phone when refueling. You should keep your phone away from fuel and chemicals. Switch off in hospitals Follow any restrictions. Switch the phone off near medical equipment. EXHIBIT D: FTS PHONE SOFTWARE SPEC (SW) Initialize each page: Page 4/15 interference All wireless phones may be susceptible to interference , which could affect performance。 Enhancements and batteries Use only approved enhancements and batteries. Do not connect incompatible products. use sensibly Use only in the normal position as explained in the produce documentation. Do not touch the antenna unnecessarily. Emergency calls Ensure the phone is switched on and in service. Enter the emergency number ,then press the call key. Give your location. Do not end the call until given permission to do so. 2. Phone Feature EXHIBIT D: FTS PHONE SOFTWARE SPEC (SW) Initialize each page: Page 5/15 3. Keys and Part Keys Description SIM card Volume Key User profiles Key * Key Power on/off lock Key Talk Key MIC C Key # Key Number Key Earpiece LCD EXHIBIT D: FTS PHONE SOFTWARE SPEC (SW) Initialize each page: Page 6/15 Talk Key Dial a phone number and answers a call. C Key press it to clear the input number one by one; ～0～9 Number Key In idle, press to dial numbers; Long press it to speed dial; * Key In idle, press it to input “*”/ “+” / “P”/“W” ＃Key To iuput # Volume Key Press it to adjust the volume User Profiles Key Push it to switch user profiles. adjusted to Normal , Loud, Mute. Power on/off lock Key Push it to switch Power on/off.,or locked the keypad or unlock. 4. Basic Function 4.1 Get started EXHIBIT D: FTS PHONE SOFTWARE SPEC (SW) Initialize each page: Page 7/15 1 Power on/off/Key Lock The power switch can switch the phone to power on/off/key lock mode. When the phone is in key lock mode, all keys will be invalid except when a call is incoming the C key and Talk Key are valid, and the Volume wheel. 2 DIAL When a dialing key is pushed, the corresponding letter will be displayed in screen and a keytone will be played except when the phone is in Down Mute Mode. If the letters keyed in is more than the max letters that can be displayed in screen, the letters displayed will roll to left and the new one will be added at the end of the existing letters. When the user pushes the C Key, the numbers keyed in will be cleared. 3 Speed Dial Speed dial will be executed (call activated) when holding a 0-9 number key for 2 seconds, and a confirmation ‘Click’ will be played。 4 Speed dial number seting ,for example: if ** 1*12345678#. 1) press * key to input **; 2) press number key 1 to input 1; 3) press number key to input the phone number 12345678; 4) press the # key to input #; 5) press the Talk key to save the speed dial number. 5 Voice Volume setting EXHIBIT D: FTS PHONE SOFTWARE SPEC (SW) Initialize each page: Page 8/15 The volume setting is only active during calling. When starting a new call, the volume will be the same since the last adjustment; The Volume Key can go up and down, the volume goes up and down without ‘steps’; The volume wheels returns to its original ‘middle’ position. This volume setting is also the setting for when the ‘Headset’ is plugged in. 6 User Profiles Speaker volume adjusting for RINGTONE and KEYTONE, It can be adjusted to Normal, Loud, Mute profiles. The User profile key on up step is normal profile ; The User profile key on middle step is loud profile ; The User profile key on down step is mute profile . Vibrating alert is always switched on; This volume is also adjusted for the ‘Headset’ when the headset is plug in, Ringtone and Key tone are played in the headset as well. 7 Ringtone setting Can input the code to switch the ringtone 1 to 4 Ringtone1 : #78737627538# Ringtone2 : #5646363# Ringtone3 : #7925626# Ringtone4 : #3669# 8 Call Incoming When a call is incoming and the phone is not calling, the phone will play the ringtone (except the phone is in DOWN MUTE MODE) and vibrate and the key light will be shown. During a call, a second incoming call cannot be taken. (The caller will hear the tone of an occupied line). The phone will not make a sound or beep; EXHIBIT D: FTS PHONE SOFTWARE SPEC (SW) Initialize each pa…

Text truncated - open the document above for the full version.

Function Block Diagram RF Transmit Block Diagram ■ TX 1. MT6223D sends I/Q Signals into AD6548 2. These signals are modulated and up-converted in AD6548 3. RF7163 amplifies the power level of TX RF signal, and amplified signal is transferred to antenna. RF Receive Block Diagram ■ RX 1. RX RF signal is transferred to AD6548 through FEM in RF7163. 2. RX RF signal is demodulated and down-converted in AD6548. 3. MT6223D processes these signals from AD6548. Power Supply Block Diagram MT6223D includes 7 LDOs and KEY backlight control block and it can control the charging management.

TOP VIEW OF SAMPLE BOTTOM VIEW OF SAMPLE LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE FRONT VIEW OF SAMPLE BACK VEIW OF SAMPLE

FCC ID Label Location

FCC ID Label

INTERNAL PHOTO OF SAMPLE -1 INTERNAL PHOTO OF SAMPLE – 2 INTERNAL PHOTO OF SAMPLE – 3

1 13 VERSIONV1.0 2 13 block diagram 3 13 RF part 2.1 RF block diagram GSM RF and BB interface diagram 2.2 RF TRANSMIT PART This circuit shows the transmitter path. The RF signal which is amplified by RF PA is transmitted to antenna through antenna switch and then radiated to the air. MT6223D controls RFPA through PA_EN,BANDSW,APC CONTROL. 4 13 2.3 RF RECEIVE PART This circuit shows the receiver path. When receiving, the antenna receives the RF signal, and then demodulated by AD6548 after band filter. MT6223D control the RF switch to select the proper band(DCS or GSM ) through band select signal. MT6223D controls AD6548 through SPI, and transmit/receive data throught I/Q bus. 5 13 BB PART POWER MANAGEMENT PART 6 13 Audio part Audio PA part and Receiver Part Speaker is also as receiver. R507, R508 is used to reduce the power to receiver. MIC This is microphone circuit. MICBIASP provides the bias voltage for microphone. B501,B502 are used to restrain high frequency signals. 7 13 IO circuit The I/O circuit contains earphone port, download port and charge input. Earphone and download share pin2 and pin3. CPU can determine witch function will be used by controlling GPIO24. Earphone function is selected as default. 8 13 Charge circuit part The MT6223 integrate the charger control circuit. When inserting the charging adapter, CHRIN detect high level, and start the charging program. GATEDRV can control the charging current. ISENSE and VBAT can sense the charging current. If battery is over discharged, charging current can pass D305,D306,D307,D308,R302 into battery. MT6223CHRIN MT6223 GATE DRV MT6223 ISENSE 9 13 Battery protect circuit This part is battery protect circuit. It will protect battery from overcharge and over discharge. 10 13 DISPLAY PART Display part is OLED. The OLED connects to MT6223 through FPC. The signals are defined as follows: VDDOLED inner driver working voltageprovided by MT6223 LCD_CSOLED Chip select signal LCD_SA0: OLED data/command select signal LCD_RSTReset signal LCD_SDAOLED data/command signal LCD_SCLKOLED clock signal VCC_LEDOLED driving voltage, control the brightness. 11 13 OLED driving voltage is provided by the boost circuit. GPIO25 and GPIO51 are connected to control the OLED open or close. 12 13 KEY PAD PART The keypad is a 5*5 scan matrix (5 inputs and 5 outputs), can support 21 keys. KROW0~KROW4 is output for row scan, and KCOL0~KCOL4 is input for column scan. When some key is pressed, the column detects low level, CPU start the keypad scan program, judge the key value, and start the corresponding operation. 13 13 Side key part CPU can judge witch profile is selected by the input value of GPIO15 and GPIO17. CPU is woke up by EINT1. This part is power on/off and lock/unlock circuit. EINT2 can wake up CPU.

Operational Description Transmit Frequency GSM：824.2～848.8 MHz PCS：1850.2‐1909.8MHz Modulation GMSK Hardware Version DSM918 V1.0 Software Version M918_H10S05 Emission Designator 200Khz Freq.stability +‐1ppm DATA Transmission N/A Voltage DC 3.5~4.2V Current Idel:<5mA Traffic<=1.5A Transmitter Power GSM:2W PCS:1W RF Antenna GSM850/1900 Cystal F0 26MHz+‐30ppm Specific operating power range: Power Classs 1 GSM Power control level 5 +33dbm+2dbm/‐2dbm Power control level 6 +31dbm+3dbm/‐3dbm Power control level 7 +29dbm+3dbm/‐3dbm Power control level 8 +27dbm+3dbm/‐3dbm Power control level 9 +25dbm+3dbm/‐3dbm Power control level 10 +23dbm+3dbm/‐3dbm Power control level 11 +21dbm+3dbm/‐3dbm Power control level 12 +19dbm+3dbm/‐3dbm Power control level 13 +17dbm+3dbm/‐3dbm Power control level 14 +15dbm+3dbm/‐3dbm Power control level 15 +13dbm+3dbm/‐3dbm Power control level 16 +11dbm+5dbm/‐5dbm Power control level 17 +9dbm+5dbm/‐5dbm Power control level 18 +7dbm+5dbm/‐5dbm Power control level 19 +5dbm+5dbm/‐5dbm PCS Power control level 0 +30dbm+2dbm/‐2dbm Power control level 1 +28dbm+3dbm/‐3dbm Power control level 2 +26dbm+3dbm/‐3dbm Power control level 3 +24dbm+3dbm/‐3dbm Power control level 4 +22dbm+3dbm/‐3dbm Power control level 5 +20dbm+3dbm/‐3dbm Power control level 6 +18dbm+3dbm/‐3dbm Power control level 7 +16dbm+3dbm/‐3dbm Power control level 8 +14dbm+3dbm/‐3dbm Power control level 9 +12dbm+4dbm/‐4dbm Power control level 10 +10dbm+4dbm/‐4dbm Power control level 11 +8dbm+4dbm/‐4dbm Power control level 12 +6dbm+4dbm/‐4dbm Power control level 13 +4dbm+4dbm/‐4dbm Power control level 14 +2dbm+4dbm/‐4dbm Power control level 15 0dbm+4dbm/‐4dbm

Description UNIT PCB,DSM9181 DSM918_MB_PCB_1.01 ADI RF IC，AD65481 MTK IC，MT6223D1 Amplifier+ASM,RF71631 NOR+PSRAM(64Mb+32Mb)，TV00560002EDGB1 Switch,NLASB3157DFT2G3 IC(2-5),CP21251 Battery Protect IC,DW01+1 Dual N CHANNEL MOSFET,FS8205A1 LDO(3.3V,150mA),AS2915M5-33/TR-LF1 LED，LED WHITE / BL-HZ336G-L8-TRB,0.4T10 Filter(PCS-RX),SAFEA1G96FA0F00R121 SAW-1800MHZ-1.4X1.1MM-M,Saw Filter 1800 MHz/SAFEA1G84FA0F001 SAW-900MHZ-1.4X1.1MM-M,Saw Filter 900 MHz /SAFEA942MFL0F001 SAW-850MHZ-1.4X1.1MM-M,Saw Filter 850 MHz /SAFEA881MFL0F001 Amplifier,CP2290GITLX1 Diode，RB521S-306 MOSFET,MC31171 Crystal,32.768KHz,±20ppm,12.5pF,SSP-T7-F1 Crystal,26M crystal for AD6548,X1E0000210314001 Diode(0402)，DF2S6.8FS(TH3,T)8 0402 RES,VPORT0402100MV0518 Diode(0603)，ESD5Z7.0T1G1 0402 RES (0Ω)，0402WGJ0000TCE15 RES，ResChip0402,1/16W,10R±5%，0402WGJ0100TCE3 0402 RES (51Ω),0402WGJ0510TCE2 0402 RES (82Ω),0402WGJ0820TCE2 0402 RES (100Ω)，0402WGJ0101TCE2 0402 RES (200Ω),0402WGJ0201TCE12 0402 RES (1kΩ)，0402WGJ0102TCE25 0402 RES (1.5kΩ)，0402WGJ0152TCE3 0402 RES (2kΩ),0402WGJ0202TCE1 0402 RES (2.2kΩ),0402WGJ0222TCE4 0402 RES (10kΩ)，0402WGJ0103TCE7 0402 RES (15kΩ),0402WGJ0153TCE1 0402 RES (20kΩ)，0402WGJ0203TCE2 0402 RES (24kΩ)，0402WGJ0243TCE1 0402 RES (33kΩ),0402WGJ0333TCE1 0402 RES (100kΩ)，0402WGJ0104TCE14 0402 RES (150kΩ),0402WGJ0154TCE1 0402 RES (910kΩ),0402WGJ0914TCE1 0603 RES (30Ω),0603WAJ0300T5E2 0805 RES (0.2Ω,1%),0805W8F200LT5E1 BOM 0402 CAP（7pF），CL05C070DB5ANNC4 0402 CAP (15pF)，CL05C150JB5NNNC1 0402 CAP (18pF)±5%，CL05C180JB5NNNC4 0402 CAP (22pF)，CL05C220JB5NNNC6 0402 CAP（27pF），CL05C270JB5NNNC2 0402 CAP (33pF)，CL05C330JB5NNNC12 0402 CAP（39pF），CL05C390JB5NNNC2 0402 CAP (47pF)，CL05C470JB5NNNC1 0402 CAP (56pF)±5%,CL05C560JB5NNNC1 0402 CAP (82pF)±5%,CL05C820JB5NNNC2 0402 CAP (100pF)，CL05C101JB5NNNC5 0402 CAP (220pF)，CL05B221KB5NNNC1 0402 CAP (1nF)，CL05B102KB5NNNC2 0402 CAP (10nF)，CL05B103KB5NNNC1 0402 CAP (33nF)±10%,CL05B333KO5NNNC1 0402 CAP (47nF)，CL05B473KO5NNNC2 0402 CAP (100nF)，CL05B104KO5NNNC30 0402 CAP (220nF)±10%,CL05A224KP5NNNC1 CAP，Ceramic CapChip 0402 X5R 10V,1uF±10%，CL05A105KP5NNNC4 0603 CAP (1uF)±10%,CL10A105KO8NNNC1 0603 CAP (2.2uF)，CL10A225KP8NNNC3 0603 CAP (4.7uF)，CL10A475KQ8NNNC7 0805 CAP (4.7uF)±10%,CL21A475KPCLNNC1 0805 CAP (10uF)，CL21A106KPCLQNC4 0805 CAP (22uF)±20%,CL21A226MQQNNNE3 3216 CAP 4.5uF 1.7mmH,TCA1C475M8R,1 Inductor (4.3nH)，LQG15HN4N3S02D2 Inductor_0402_15nH,LQG15HN15NJ02D2 0805 Inductor（10uH）,CB2012T100M1 0402 bead,BLM15BD102SN1D5 Micro USB connector (5PIN,H2.4),UAF95-05253-15001 SIM card connector（H2.2,）,SA0956511-R1 switch（H1.4，3positions),SSSS8122012 RF connector,CON-RF-3*3*1.75mm,MM8430-26101 switch,NM301-PL03-GT_OD1 ASSEMBLY1 LCM, OLED,128*32,UG-2832GSWFG021 Receiver&Speaker二合一,RSR1318T35-W03-T43W25-0011 fixed battery,3.7V,1200mAh,69*27*(H)5.1mm,20mm1 Motor,3V, 11.9*5.3*5.1(H)mm，KLWD04004C1 MIC,ROM40T15-W10-40T22-4231

Report No.: RZA2010-0113 TESTING No. L2264 OET 65 TEST REPORT Product Name Mobile Phone Model John's 1 FCC ID XJG-JOHNS1 Client DESAY A&V SCIENCE AND TECHNOLOGY CO., LTD. TA Technology (Shanghai) Co., Ltd. GENERAL SUMMARY Product Name Mobile Phone Model John's 1 FCC ID XJG-JOHNS1 Report No. RZA2010-0113 Client DESAY A&V SCIENCE AND TECHNOLOGY CO., LTD. Manufacturer DESAY A&V SCIENCE AND TECHNOLOGY CO., LTD. Reference Standard(s) ANSI/IEEE Std C95.1-1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. IEEE 1528–2003: Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head Due to Wireless Communications Devices: Experimental Techniques. OET Bulletin 65 supplement C, published June 2001 including DA 02-1438, published June 2002: Additional Information for Evaluating Compliance of Mobile and Portable Devices with FCC Limits. Transition Period for the Phantom Requirements of Supplement C to OET Bulletin 65. IEC 62209-1:2006 Human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices – Human models, instrumentation, and procedures –Part 1: Procedure to determine the Specific Absorption Rate (SAR) for hand-held devices used in close proximity to the ear. (frequency range of 300 MHz to 3 GHz). IEC 62209-2:2008(106/162/CDV): Human exposure to radio frequency fields from handheld and body-mounted wireless communication devices – Human models, instrumentation, and procedures –Part 2: Procedure to determine the Specific Absorption Rate (SAR) for wireless communication devices used in close proximity to the human body. ( frequency rang of 30MHz to 6GHz ) Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: February 1 st , 2010 Comment The test result only responds to the measured sample. Approved by Yang Weizhong Revised by Ling Minbao Performed by Li Jinchang TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 3of 97 TABLE OF CONTENT 1. General Information ..................................................................................................................... 5 1.1. Notes of the test report.........................................................................................................5 1.2. Testing laboratory .................................................................................................................5 1.3. Applicant Information ............................................................................................................6 1.4. Manufacturer Information ......................................................................................................6 1.5. Information of EUT................................................................................................................7 1.6. Test Date ..............................................................................................................................8 2. Operational Conditions during Test ..............................................................................................9 2.1. General description of test procedures .................................................................................9 2.2. GSM Test Configuration ........................................................................................................9 3. SAR Measurements System Configuration ................................................................................ 10 3.1. SAR Measurement Set-up ..................................................................................................10 3.2. DASY4 E-field Probe System ............................................................................................. 11 3.2.1. EX3DV4 Probe Specification ....................................................................................... 11 3.2.2. E-field Probe Calibration ..............................................................................................12 3.3. Other Test Equipment .........................................................................................................12 3.3.1. Device Holder for Transmitters ....................................................................................12 3.3.2. Phantom......................................................................................................................13 3.4. Scanning procedure............................................................................................................13 3.5. Data Storage and Evaluation ..............................................................................................15 3.5.1. Data Storage................................................................................................................15 3.5.2. Data Evaluation by SEMCAD ......................................................................................15 3.6. System check......................................................................................................................18 3.7. Equivalent Tissues ..............................................................................................................19 4. Laboratory Environment............................................................................................................. 20 5. Characteristics of the Test .......................................................................................................... 20 5.1. Applicable Limit Regulations ...............................................................................................20 5.2. Applicable Measurement Standards...................................................................................20 6. Conducted Ou…

Text truncated - open the document above for the full version.

TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 61of 97 ANNEX D: Probe Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 62of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 63of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 64of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 65of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 66of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 67of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 68of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 69of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 70of 97 ANNEX E: D835V2 Dipole Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 71of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 72of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 73of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 74of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 75of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 76of 97

TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 77of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 78of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 79of 97 ANNEX F: D1900V2 Dipole Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 80of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 81of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 82of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 83of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 84of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 85of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 86of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 87of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 88of 97 ANNEX G: DAE4 Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 89of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 90of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 91of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 92of 97

TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 61of 97 ANNEX D: Probe Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 62of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 63of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 64of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 65of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 66of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 67of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 68of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 69of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 70of 97 ANNEX E: D835V2 Dipole Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 71of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 72of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 73of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 74of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 75of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 76of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 77of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 78of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 79of 97 ANNEX F: D1900V2 Dipole Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 80of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 81of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 82of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 83of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 84of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 85of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 86of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 87of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 88of 97 ANNEX G: DAE4 Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 89of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 90of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 91of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 92of 97 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 93of 97 ANNEX H: The EUT Appearances and Test Configuration Picture 6: Constituents of EUT TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 94of 97 Picture 7: Left Hand Touch Cheek Position Picture 8: Left Hand Tilt 15 Degree Position TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 95of 97 Picture 9: Right Hand Touch Cheek Position Picture 10: Right Hand Tilt 15 Degree Position TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 96of 97 Picture 11: Body, The EUT display towards ground, the distance from handset to the bottom of the Phantom is 15mm Picture 12: Body, The EUT display towards phantom, the distance from handset to the bottom of the Phantom is 15mm TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA2010-0113 Page 97of 97 Picture 13: Body with earphone, The EUT display towards ground, the distance from handset to the bottom of the Phantom is 15mm) Picture 14: Body with earphone, The EUT display towards phantom, the distance from handset to the bottom of the Phantom is 15mm)

CAM350 V 8.0.5 : Thu Nov 19 17:34:04 2009 - (Untitled) : art001.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:04 2009 - (Untitled) : art002.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:06 2009 - (Untitled) : art003.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:07 2009 - (Untitled) : art004.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:11 2009 - (Untitled) : art005.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:15 2009 - (Untitled) : art006.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:15 2009 - (Untitled) : dd001024.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:16 2009 - (Untitled) : sm001021.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:16 2009 - (Untitled) : sm008028.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:17 2009 - (Untitled) : ssb008029.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:17 2009 - (Untitled) : sst001026.pho CAM350 V 8.0.5 : Thu Nov 19 17:34:17 2009 - (Untitled) : drl0102.drl CAM350 V 8.0.5 : Thu Nov 19 17:34:17 2009 - (Untitled) : drl0106.drl CAM350 V 8.0.5 : Thu Nov 19 17:34:17 2009 - (Untitled) : drl0205.drl CAM350 V 8.0.5 : Thu Nov 19 17:34:17 2009 - (Untitled) : drl0506.drl

RF Model Title Sheet DWG Date sheet 1 of 9 2009 04 16 DSM918 1 VCCFE 2 I 3 IB 4 VCC_BBI 5 SDATA 6 SCLK 7 SEN 8 NC 9 VLDO3 10 TXOP_LO 11 TXOP_HI 12 VCC_TXVCO 13 VDD 14 VBAT 15 VLDO1 16 VLDO2 17 VCC_REF 18 VAFC 19 REFINB 20 REFIN 21 REF_OP 22 QB 23 Q 24 VCC_BBQ 25 RX1900B 26 RX1900 27 RX1800B 28 RX1800 29 RX900B 30 RX900 31 RX850B 32 RX850 33 GND U103 MT6129B_TQC0_6 AD6548 1 HOT 2 GND 3 HOT 4 GND U105 TCVCXO_0A TXC X'tal 26MHz C114 18pF C115 18pF 1 2 L113 15nH C112 7pF C113 7pF 1 2 L112 4n3 R114 82R R115 82R C127 33nF C124 100nF C125 100nF C123 220nF C122 100nF R122 10R C119 100nF R119 1K C120 39pF C121 100nF R120 0R R116 2K3 R117 2K3 R118 51R C118 82pF R123 2K3 R124 2K3 C128 82pF C126 100nF C129 39pF C117 1nF C116 47pF 1 2 L114 NC R125 0R R128 NC R129 NC R126 NC R127 NC R136 0R C136 7pF C137 7pF 1 2 L101 4n3 1 IN 5 G 2 G 3 OUT 4 OUT U106 SAFEA1G84FA0F00 L107 NC L117 0R C105 22pF L108 NC R101 10K C106 15pF C107 100nF C108 22pF C109 220pF R102 15K C110 NC R137 1K R103 0R 1 2 L109 NC 1 W101 ANTENNA2X3 1 W102 ANTENNA2X3 1 2 L118 NC 14 GND 1 GND 6 GND 4 RFIN_LB 18 GSM_RX 5 GND 17 DCS_RX 21 GND 3 GND 19 NC 15 ANT 12 NC 13 GND 20 GND 2 RFIN_HB 16 NC 9 GPCTRL0 8 TX_EN 7 VRAMP 10 GPCTRL1 11 VBATT 22 GND 23 GND 24 GND U102 RF7168 C144 56pF C143 22pF C145 33pF C146 33pF C111 22pF C147 22uF C104 22uF C101 18pF C102 18pF 1 2 L102 15nH 1 IN 5 G 2 G 3 OUT 4 OUT U101 SAFEA1G84FA0F00 5 3 2 6 4 1 SA1001 SWDMM8430 1 SH103 DSM918RFSH C148 22uF C103 33pF C130 NC C132 0 C135 33pf C134 NC C133 0 1 IN 5 G 2 G 3 OUT 4 OUT U107 SAFEA1G84FA0F00 1 IN 5 G 2 G 3 OUT 4 OUT U104 SAFEA1G84FA0F00 1 SH101 DSM918BBSH LE SCLK SDATA VBAT VDD VAFC Q QB I IB 26MHZ VRF VRF_SENSE VCCRF VCCRF PA_EN VAPC VBAT 850EN 850/1900RX HB_TX

FCC Part 22H and 24E Test Report For Mobile Phone Model Name: John’s 1 Brand Name: John’s FCC ID: XJG-JOHNS1 Report No.: AGC11110911SZ03-3E4 Date of Issue: Feb.02, 2010 Prep…
