XJGDS0015BLU-RAY DISC PLAYER

MODEL: HBD316 USER MANUAL USB SPECIFICATIONS 20 TROUBLE SHOOTING 19 SYSTEM SETUP 15 SPECIAL FUNCTION PLAYBACK 12 ADVANCED PLAYBACK 11 BASIC PLAYBACK 10 REMOTE CONTROL 09 BASIC CONNECTION 07 ACCESSORIES AND PANEL 06 PLAYABLE DISCS 05 NOTICE 04 IMPORTANT SAFETY INSTRUCTIONS 03 SAFETY PRECAUTIONS 01 TABLE OF CONTENTS SAFETY PRECAUTIONS 01 TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE, DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY. When replacing the unit's plug or power cord, the replacement must be the exactly the same; or one recommended by the manufacturer. The lightning flash with arrowhead symbol, within an equila- teral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage " within the product's en- closure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. This Digital Video Disc player employs a laser system. The symbol for CLASS II (Double Insulation). Use of controls, adjustments or the performance of procedures other than those specified may result To prevent direct expo- sure to laser beam, do not try to open the enclosure. DO NOT STARE INTO BEAM. in hazardous exposure to radiation. WARNING: CAUTION: Laser radiated lable stick at the bottom of unit. * Disposal of your old appliance 1. When this crossed-out wheeled bin symbol is attached to a product, it means the product is covered by the European Directive 2002/96/EC. 2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities. 3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health. 4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product. This item incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering or disassembly is prohibited. Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS Digital Surround and the DTS logos are trademarks of DTS, Inc. Product includes software. DTS, Inc. All Rights Reserved. FCC statement: FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. SAFETY PRECAUTIONS 02 Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. The Blu-ray Disc player are Energy Star qualified DVD. When in idle mode these DVD draw less than 1 Watt of current, to help lower your electric bills and protect the environment. Products that earn the ENERGY STAR prevent greenhouse gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and the U.S. Department of Energy. HBD316 03 53125A IMPORTANT SAFETY INSTRUCTIONS : 1. Read these instructions - All the safety and operating instructions should be read before this product is operated. 2. Keep these instructions - The safety and operating instructions should be retained for future reference. 3. Heed all warnings - All warnings on the appliance and in the operating instructions should be adhered to. 4. Follow all instructions - All operating and use instructions should be followed. 5. Do not use this apparatus near water - The appliance should not be used near water or moisture. for example, in a wet basement or near a swimming pool, and the like. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance wi…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 DESAY A&V SCIENCE AND TECHNOLOGY CO.,LTD 2012/5/21 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, __ DESAY A&V SCIENCE AND TECHNOLOGY CO.,LTD _ hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: BLU-RAY DISC PLAYER model name: DS-B202-R We affirm that between SIEMIC and _ _ DESAY A&V SCIENCE AND TECHNOLOGY CO.,LTD _, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Chao.Li / Engineer Contact information / address: Desay 3 rd Industry Zone, Chenjiang Town, Huizhou City, Guangdong, 516229, China

FCC ID:BUQB005 EST Technology Co.,Ltd Report No.ESTE-R1203004 Page 171 of 178 12. PHOTOS OF EUT External Photos Lable Location

FCC ID:BUQB005 EST Technology Co.,Ltd Report No.ESTE-R1203004 Page 172 of 178 Internal Photos FCC ID:BUQB005 EST Technology Co.,Ltd Report No.ESTE-R1203004 Page 173 of 178 Internal Photos FCC ID:BUQB005 EST Technology Co.,Ltd Report No.ESTE-R1203004 Page 174 of 178 Internal Photos FCC ID:BUQB005 EST Technology Co.,Ltd Report No.ESTE-R1203004 Page 175 of 178 Internal Photos FCC ID:BUQB005 EST Technology Co.,Ltd Report No.ESTE-R1203004 Page 176 of 178 Internal Photos FCC ID:BUQB005 EST Technology Co.,Ltd Report No.ESTE-R1203004 Page 177 of 178 Internal Photos FCC ID:BUQB005 EST Technology Co.,Ltd Report No.ESTE-R1203004 Page 178 of 178 Internal Photos Antenna

EST Technology Co., Ltd. Report No. ESTE-F1205013 Page 1 of 25 FCC TEST REPORT for DESAY A&V SCIENCE AND TECHNOLOGY CO.,LTD BLU-RAY DISC PLAYER Prepared for : DESAY A&V SCIENCE AND TECHNOLOGY CO.,LTD Address : Desay 3rd Industry Zone, Chenjiang Town, Huizhou City, Guangdong, 516229, China Prepared by : EST Technology Co., Ltd. Address : San Tun Management Zone, Houjie District, Dongguan, Guangdong, China Tel: 86-769-83081888 Fax: 86-769-83081878 Report No. : ESTE-F1205013 Date of Report : May.24, 2012 EST Technology Co., Ltd. Report No. ESTE-F1205013 Page 2 of 25 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION ...................................................................................4 1.1. Product Function ................................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................................ 4 1.3. Difference between Model Numbers .................................................................................................... 4 1.4. Independent Operation Modes .............................................................................................................. 4 2. TEST SITES....................................................................................................................................5 2.1. Description of Standards and Results.................................................................................................... 5 2.2. Test Facilities ........................................................................................................................................ 6 2.3. List of Test and Measurement Instruments ........................................................................................... 7 3. TEST SET-UP AND OPERATION MODES ..............................................................................8 3.1. Principle of Configuration Selection..................................................................................................... 8 3.2. Block Diagram of Test Set-up............................................................................................................... 8 3.3. Test Operation Mode and Test Software............................................................................................... 8 3.4. Special Accessories and Auxiliary Equipment .....................................................................................9 3.5. Countermeasures to Achieve EMC Compliance ................................................................................... 9 4. EMISSION TEST RESULTS......................................................................................................10 4.1. Conducted Emission at the Mains Terminals Test .............................................................................. 10 4.2. Radiated Emission Test ....................................................................................................................... 13 5. PHOTOGRAPHS OF TEST SETUP .........................................................................................16 6. PHOTOGRAPHS OF THE EUT ................................................................................................18 EST Technology Co., Ltd. Report No. ESTE-F1205013 Page 3 of 25 EST Technology Co., Ltd. Applicant: Address: DESAY A&V SCIENCE AND TECHNOLOGY CO.,LTD Desay 3rd Industry Zone, Chenjiang Town, Huizhou City, Guangdong, 516229, China Manufacturer: Address: DESAY A&V SCIENCE AND TECHNOLOGY CO.,LTD Desay 3rd Industry Zone, Chenjiang Town, Huizhou City, Guangdong, 516229, China Factory: Address: DESAY A&V SCIENCE AND TECHNOLOGY CO.,LTD Desay 3rd Industry Zone, Chenjiang Town, Huizhou City, Guangdong, 516229, China E.U.T: BLU-RAY DISC PLAYER Model Number: DS-B202-R , HBD316; DS-XXXXX (where X could be any alphanumeric or blank) Trade Name: DESAY; HITACHI Serial No.: ------ Date of Receipt: Apr.20.2012 Date of Test: May.18~24, 2012 Test Specification: FCC Part 15 Subpart B Class B: 2011 ANSI C63.4:2003 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: May.24.2012 Prepared by: Tested by: Approved by: Ada / Assistant Tony / Engineer Iceman Hu / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of EST Technology Co., Ltd. EST Technology Co., Ltd. Report No. ESTE-F1205013 Page 4 of 25 1. GENERAL PRODUCT INFORMATION 1.1. Product Function Refer to Technical Construction Form and User Manual. 1.2. Description of Device (EUT) Description : BLU-RAY DISC PLAYER Model No. : DS-B202-R System Input Voltage : AC 110~240V, 50/60Hz mainboard crystal frequency : 27 MHz AC Line : Unshielded, Undetachable 1.6m Ethernet Cable : Shielded, Detachable 1.6m Coaxial Cable : Unshielded, Detachable 1.6m HDMI Cable : Shielded, Detachable 1.6m 1.3. Difference between Model Numbers Note: The products are difference for the model number only. But the PCB board inside are identical. 1.4. Independent Operation Modes The basic operation modes are: 1.4.1. Network & BD Playing EST Technology Co., Ltd. Report No. ESTE-F1205013 Page 5 of 25 2. TEST SITES 2.1. Description of Standards and Results The EUT have been tested according to the applicable standards as referenced below . EMISSION Description of Test Item Standard Limits Results Class B PASS Conducted disturbance at mains terminals FCC Part 15:2011 ANSI C63.4:2003 Minimum passing margin is 8.36 dB at 2.12 MHz Class B PASS Radiated Emission Test FCC Part 15:2011 ANSI C63.4:2003 Minimum passing margin is 3.00 dB at 959.97 MHz EST Technology Co., Ltd.…

Text truncated - open the document above for the full version.

EST Technology Co., Ltd. Report No. ESTE-F1205013 Page 16 of 25 5. PHOTOGRAPHS OF TEST SETUP Conducted Emission Test EST Technology Co., Ltd. Report No. ESTE-F1205013 Page 17 of 25 Radiated Emission Test
