XJN-DVH198Digital Video Camera

SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Oct 24, 2012
Application Purpose: Original Equipment
Date of Application: Oct 24, 2012
Equipment Note: Digital Video Camera
Company: SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 Foreword Thank you for choosing our digital video. Please read this manual carefully before using, and keep it in a safe place for future reference. The content involved in this manual is the latest information during compilation. The screen display and figures adopted by this manual are used to introduce the operation of the digital video in a more detailed and intuitive way, which may vary from the one in actual use due to the difference of technical development and production batches. Introduction Please use the digital video pursuant to the following sequence: Note: Any new memory card or the one used in other digital videos/cameras before should be formatted by the digital video if such card will be used in the digital video. Please backup the important data on other media, such as soft disks, hard disks or optical disks, etc. Check the digital video power Insert and format the memory card Record video/ Shoot Install the drivers Connect computers 2 Operation Instructions There is write-protection switch on SD card. It can prevent deleting or formatting saved data. Push write-protection switch to the bottom. Saved data in SD card will be protected. Push the switch to the top, the data will be unprotected. Operations on Storage Card ● If use any new memory card, or the one with data unable to be recognized by the digital video or photos shot by other digital videos, please format the memory card before using. • Turn off the digital video power before inserting or removing the memory card. • Using the memory card for many times may reduce its performance. If so, please replace it with new ones. • The memory card is a precise electronic device. Metal Pin of Storage Card Write-Protect Switch 3 Please do not bend the card, and prevent it from falling down or being pressed heavily. • Please do not expose the memory card in strong electronic/ magnetic fields, such as speakers or near TV receivers. • Please don’t use or keep the memory card in extra hot/cold circumstances. • Please keep the memory card clean and avoid touching it with any liquid. If so, dry it with soft cloth. • Keep the memory card in the card holder when not using. • Please note that it is normal for the memory card to become warm after using for a long time. • Do not use any memory card that used in other digital videos/cameras before. Please format any memory card to be used in the digital video. • Do not use any memory card formatted by other digital video or memory card reader. • Under any of the following conditions, data stored on the memory card may be damaged: - Use of the memory card inappropriately. 4 - Turn the power off or remove the memory card while recording, deleting (formatting) or reading. • Recommend to backup important data in other media, such as soft disks, hard disks and optical disks. Maintenance for Digital Video Keep the digital video at dry place and remove its battery when not using. • Wear the wrist strap to avoid sliding it off while using. • Use proper protective film to avoid scratching the lens or display screen. • To clean the lens, firstly, move dust on it, and then use proper cloth or tissue fit for cleaning optical devices to wipe the lens softly. If necessary, use lens detergents. Do not use organic solvent to clean the digital video. • Do not touch the surface of lens by fingers. 5 System Requirements When operating the digital video, please refer to the computer system with minimum requirements. We strongly recommend you to use better computer system for best performance of the digital video. The minimum system requirements are as follows: System Requirements Operating Microsoft Windows 7 2000,XP,VISTA Operating system Above Intel PIII667 or other CPU with equivalent performance RAM Above 128 MB Audio card Video card Support DirectX8 or higher versions CD-ROM Above 4 times speed Hard disk More than 1 GB free space Others One standard USB 1.1 or USB 2.0 port Functions & Features The digital video has various features and functions: Digital Video Digital camera (5 million pixels) 6 MENU Up Playbac mode right OK down Left Busy lamp Mass Storage (Removable disk) PC Digital video (Camera) 4 times digital zoom Appearance Introduction 7 Battery cover switch Shooting Battery 8 Lens Tripod SD card slot 9 Digital Video’s Key Functions and Indicators Press/ Indicator Functions Power key Turn the digital video on/off Shooting key 1.Shooting 2.Recording/Stop MENU key Open/exit the menu. Stop playing (while playing video) MODE key Switch among picture, video and preview mode (press this key to switch to PCCAM after connecting to PC) Playback key Enter/exit playing mode. Up key Select menu. Zoom in and move the picture (when the picture is zoomed in) Down key Select menu. Zoom out and move the picture (when the picture is zoomed in). In preview mode, press this key to enter grid screen. Left key Move the picture (when the picture is zoomed in). Turn on/off flash. While 10 playing video, press and hold to reverse fast. Right key In picture mode, adjust the shooting mode (self portrait \2S \10S \continuous). Move the picture (when the picture is zoomed in). While playing video, press and hold to forward fast. OK key Press this button to enter menu and start setting. Confirm and return to upper menu. Pause/play video. Busy lamp The indicator is constantly lit when the camera is turned on. Start Using Insert Battery This digital video uses 2 AA batteries. Before replacing batteries, please turn it off. Open the battery cover, and then insert batteries according to the prompt of the positive/negative poles in the battery compartment. Replace the battery cover. 11 Insert SD/MMC Memory Card Insert a SD/MMC memory card in the memory card slot with the metal pins towards inside in light of the prompts next to the card slot. To remove the memory card, press the SD/MMC memory card downwards, and then remove it. ─────────────────────────────────── Note: Turn the power off before replacing the memory card. …

Text truncated - open the document above for the full version.

Cover Letter(s)

SHUOYING INDUSTRIAL（SHENZHEN）CO.,LTD 第 1 页共 5 页 Declaration To：BV FROM ：SHUOYING INDUSTRIAL（SHENZHEN）CO.,LTD Product Name: Digital Video Camera Model No.: DVH198 FCC ID: XJN-DVH198 We applied the item FCC ID in BV DG, in order to cooperate with passing the testing, we debugged the product as below: As well, we declare that make these products will keep identical to the testing product, 1. Shield the LCD flat cable and the back side of LCD. Place six conductive foam on the PCB board and ground earth. 2. Add a piece of copper foil on the PCB board and place one conductive foam and ground earth. 3. Add a piece of copper foil on the PCB board and shield the flat cable. 4. Spray conductive paint on the enclosure, add a core on the power line and carried the power line twice around. Core model No.:F5K12.5*6*7. 5. Place three conductive foam on the PCB board and ground earth. Add non detachable protective cover on HDMI port and AV port. 6. Use the shield USB cable with core. SHUOYING INDUSTRIAL （SHENZHEN）CO.,LTD Oct 25 th 2012 SHUOYING INDUSTRIAL（SHENZHEN）CO.,LTD 第 2 页共 5 页 Location of modification 1 Location of modification 2 Sheild the LCD flat cable and the back side of LCD Place six conductive foam on the PCB board and ground earth. Spary conductive paint on the enclousure sheild the flat cable sheild the flat cable place three conductive foam and ground earth Add a piece of copper foil on the PCB board SHUOYING INDUSTRIAL（SHENZHEN）CO.,LTD 第 3 页共 5 页 Location of modification 3 Location of modification 4 add a core on the power line and carried the power line twice around. Spary conductive paint on the enclousure sheild the flat cable sheild the flat cable Add a piece of copper foil on the PCB board SHUOYING INDUSTRIAL（SHENZHEN）CO.,LTD 第 4 页共 5 页 Location of modification 5 Location of modification 6 Place three conductive foam on the PCB board and ground earth Add non detachable potective cover on HDMI port and AV port. SHUOYING INDUSTRIAL（SHENZHEN）CO.,LTD 第 5 页共 5 页 Use the sheild USB cable with core.

External Photos

Internal Photos

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 19 Report Version 1 Test Report No.: FC120921N021 TEST REPORT Applicant SHUOYING INDUSTRIAL（SHENZHEN）CO.,LTD Address Shuoying Road,Hebei Industry Area,Dalang,Longhua Town,Baoan,Shenzhen,China Manufacturer or Supplier SHUOYING INDUSTRIAL（SHENZHEN） CO.,LTD Address Shuoying Road,Hebei Industry Area,Dalang, Longhua,Town,Baoan,Shenzhen,China Product Digital Video Camera Brand Name N/A Model DVH198 Additional Model & Model Difference N/A Date of tests Sep. 22 ~ Oct. 12, 2012 The submitted sample of the above equipment has been tested for according to the requirements of the following standards: FCC Part 15, Subpart B, Class B CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Breeze Jiang Project Engineer / EMC Department Approved by Sam Tung Manager/ EMC Department This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 19 Report Version 1 Test Report No.: FC120921N021 Table of Contents RELEASE CONTROL RECORD ................................................................................3 1 SUMMARY OF TEST RESULTS ..................................................................... 4 1.1 MEASUREMENT UNCERTAINTY...................................................................4 2 GENERAL INFORMATION .............................................................................. 5 2.1 GENERAL DESCRIPTION OF EUT ................................................................5 2.2 DESCRIPTION OF TEST MODES ..................................................................6 2.3 DESCRIPTION OF SUPPORT UNITS ............................................................6 3 EMISSION TEST ............................................................................................. 7 3.1 CONDUCTED EMISSION MEASUREMENT...................................................7 3.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ................................7 3.1.2 TEST INSTRUMENTS.....................................................................................7 3.1.3 TEST PROCEDURE........................................................................................8 3.1.4 DEVIATION FROM TEST STANDARD............................................................8 3.1.5 TEST SETUP...................................................................................................9 3.1.6 EUT OPERATING CONDITIONS ....................................................................9 3.1.7 TEST RESULTS ............................................................................................10 3.2 RADIATED EMISSION MEASUREMENT......................................................12 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ...................................12 3.2.2 TEST INSTRUMENTS...................................................................................13 3.2.3 TEST PROCEDURE......................................................................................14 3.2.4 DEVIATION FROM TEST STANDARD..........................................................14 3.2.5 TEST SETUP.................................................................................................15 3.2.6 EUT OPERATING CONDITIONS ..................................................................15 3.2.7 TEST RESULTS ............................................................................................16 4 PHOTOGRAPHS OF THE TEST CONFIGURATION .................................... 18 5 APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................... 19 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 19 Report Version 1 Test Report No.: FC120921N021 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Oct. 15, 2012 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 19 Report Version 1 Test Report No.: FC120921N021 1 SUMMARY OF TEST …

Text truncated - open the document above for the full version.

Test Setup Photos
