XJN-PA0852MID

1 PA0852 User Guide SHUOYING INDUSTRIAL（SHENZHEN）CO.,LTD shuoying Road,Hebei Industry Area,Dalang,LongHua Town,Baoan,Shenzhen,China FCC DECLARATION This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this device. Caution: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to 2 which the receiver is connected. - Consult the dealer or an experienced radio TV technician for help. Pertinent testing documentation is available for verification. - FCC RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. Attention: This handbook contains important security measures and product information essential for using the device safely. Please read this manual carefully before using the device. z Do not place the device in high temperatures, moist areas or very dusty places. z During seasons with hot temperatures do not leave the device in a car with the windows closed. z This tablet is a sophisticated device. Please handle with care and do not drop as it may damage the display screen. z Please choose the appropriate volume. When utilizing headphones please ensure the volume is not set at high level. z Charge the device under the following conditions, A、 The battery power ICONS show there is no power B、 The system automatically shuts off C、 The Operation buttons does not respond z Do not disconnect the device when it is formatting, downloading or uploading a file as it can cause an application error. z Follow the user manual for standardized operational use of the device. z Don’t disassemble the product. Do not use alcohol, thinner or benzene to 3 scrub the product. z Don't use the device in a place that prohibits use of electronic equipment. z Please don't use the Tablet PC when you are driving or walking down the street. z USB is only to be used for data transmission. The company reserves the right to improve the product, product specifications and design and/or make any other changes. The information is subject to change without prior notice. (This tablet does not have a waterproof function) 【Remark】All pictures in this manual are only for your reference. The products specification and design may change. The information is subject to change without prior notice. 4 1. Appearance and button: 1.1 Touch panel 8” Capacitive touch panel: In the Operation, to click, drag on the touch panel 1.2 POWER Startup: Hold down the power button for several seconds. The tablet will turn Vo l - Vo l + E S C Headphone Jack Touch Panel 5 on and then the system will enter the main interface. Shutdown: In the main menu interface, Press the power button for several seconds to shutdown, The system will hint the "power off" option, Click ”ok”. Now you can safely shut down. Turn off screen: When the screen is on, short press Power button to turn off screen. Short press Power button again to turn on screen. Remark 1.When the power is depleted the system will shut down automatically. 2. Restart will scan and restore the disk. It may take a longer time to enter into system. 1.3 Home Press the Home button to return to the last interface. 1.4 Volume +, Volume- Use the buttons on the top Volume + and Volume- to adjust the volume. 1.5 Headphone jack 3.5 mm standard headphone jack 1.6 TF card TF-CARD slot: external T-FLASH card 1.7 Micro USB Micro USB jack: can be used to connect the computer for data transmission, charging and an external connection for a USB flash drive. 1.8 Power Jack One end of the AC adaptor can be inserted to the Power Jack and then the charger is inserted to a standard AC wall outlet to charge the battery of the tablet. 1.9 Reset In case the operation of the tablet is interrupted for any reason, press Reset button to reset and resume operation. 6 2. First use 2.1 Battery management and charge Prior to first use, make sure the battery is fully charged To charge simply connect the adaptor or USB interface. Charge for six hours for the first two times .Following that the battery need only be charged for 4 hours. 【Remark】: This tablet has a Built-in type Lithium ion battery, To charge, use a standard adaptor (Input: AC100~240V 50/60Hz Max：0.3A. Output: DC5V/2A). Without adaptor, use USB cable to connect to micro USB jack of the tablet and USB port on your computer to charge. While charging, the battery icon will scroll. When charging is complete the battery icon will become green and stop scrolling. In order to prolong the service life of the device, let the battery deplete before charging. 【Remark】: 1. Charge the battery at least once a month to avoid power consumption ca…

Text truncated - open the document above for the full version.

SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. Date: 2013-03-28 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: XJN-PA0852 To Whom It May Concern: This letter is to ascertain that Shenzhen Yudafu Electronic Co., Ltd. MID MODEL No.: PA0852 has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Contact Person: Tony Pan / General Manager E-mail: : [email protected] Phone: 86-755-29809865 Fax: 86-755-28177333 Address : NO.1Shuoying Road, Hebei Industry Area, Dalang, Longhua Town,Baoan, Shenzhen, China

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. Date: 2013-03-28 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): FCC ID: XJN-PA0852 (MID MODEL No.: PA0852) We affirm that between SIEMIC and SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Contact Person: Tony Pan / General Manager E-mail: : [email protected] Phone: 86-755-29809865 Fax: 86-755-28177333 Address : No.1 Shuoying Road, Hebei Industry Area, Dalang, Longhua Town,Baoan, Shenzhen, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. Date: 2013-03-28 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: XJN-PA0852 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Contact Person: Tony Pan / General Manager E-mail: : [email protected] Phone: 86-755-29809865 Fax: 86-755-28177333 Address : No.1 Shuoying Road, Hebei Industry Area, Dalang, Longhua Town,Baoan, Shenzhen, China

ID Label MID FCC ID: XJN-PA0852 Model Number: PA0852 Made in China This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label loacation

Antenna WIFI module

FCC ID: XJN-PA0852 WLAN (Portable device) According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V05 Frequency Range Low Frequency (MHz) High Frequency(MHz) Center frequency (MHz) Limitation (mw) 2412 2462 2437 10.mw Maximum measured transmitter power: 802.11b Conducted Power (dBm) Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 7.85 6.10 2 9.66 Maximum measured transmitter power: 802.11g Conducted Power (dBm) Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 7.42 5.52 2 8.75 Maximum measured transmitter power: 802.11n Conducted Power (dBm) Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 7.28 5.36 2 8.47 For the Tune Up information from the applicant, the maximum output power is 1.51mW, so the worst case of Conducted Power and EIRP will be still less than FCC SAR exemption threshold. Threshold at which no SAR required is 10mw. Maximum Tx power is 9.66mw EIRP Conclusion: No SAR is required. Sincerely, Contact Person: Tony Pan / General Manager E-mail: : [email protected] Phone: 86-755-29809865 Fax: 86-755-28177333 Address : No.1 Shuoying Road, Hebei Industry Area, Dalang, Longhua Town,Baoan, Shenzhen, China

TRF NoFCC 15.247/A Page 1 of 62 Report No ES130314118E ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF MID MODEL No.: PA0852 FCC ID: XJN-PA0852 REPORT NO: ES130314118E ISSUE DATE: March 28, 2013 Prepared for SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. NO.1 shuoying Road,Hebei Industry Area,Dalang,Longhua Town,Baoan,Shenzhen,China Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 This report shall not be reproduced, except in full, without the written approval of SHENZHEN EMTEK CO., LTD. TRF NoFCC 15.247/A Page 2 of 62 Report No ES130314118E VERIFICATION OF COMPLIANCE Applicant: SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. NO.1 shuoying Road, Hebei Industry Area,Dalang, Longhua Town, Baoan, Shenzhen, China Manufacturer: SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. NO.1 shuoying Road, Hebei Industry Area,Dalang, Longhua Town, Baoan, Shenzhen, China Product Description: MID Model Number: PA0852 File Number: ES130314118E Date of Test: March 18,2013 to March 28,2013 We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Date of Test : March 18,2013 to March 28,2013 Prepared by : Jessie Hu/Editor Reviewer : King Wang/Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF NoFCC 15.247/A Page 3 of 62 Report No ES130314118E Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................................................ 5 1.1 PRODUCT DESCRIPTION.................................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT(S)................................................................................................................. 5 1.3 TEST METHODOLOGY....................................................................................................................................... 6 1.4 SPECIAL ACCESSORIES...................................................................................................................................... 6 1.5 EQUIPMENT MODIFICATIONS............................................................................................................................ 6 1.6 TEST FACILITY.................................................................................................................................................. 6 2. SYSTEM TEST CONFIGURATION ................................................................................................................... 7 2.1 EUT CONFIGURATION....................................................................................................................................... 7 2.2 EUT EXERCISE................................................................................................................................................. 7 2.3 TEST PROCEDURE............................................................................................................................................. 7 2.4 CONFIGURATION OF TESTED SYSTEM............................................................................................................... 7 3. DESCRIPTION OF TEST MODES ..................................................................................................................... 9 4. SUMMARY OF TEST RESULTS....................................................................................................................... 10 5. CONDUCTED EMISSIONS TEST.................................................................................................................... 11 5.1 MEASUREMENT PROCEDURE.......................................................................................................................... 11 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................................. 11 5.3 MEASUREMENT EQUIPMENT USED................................................................................................................. 11 5.4 CONDUCTED EMISSION LIMIT......................................................................................................................... 11 5.5 MEASUREMENT RESULT.................................................................................................................................. 12 6. RADIATED EMISSION TEST ........................................................................................................................... 13 6.1 MEASUREMENT PROCEDURE.......................................................................................................................... 13 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................................. 13 6.3 MEASUREMENT EQUIPMENT USED................................................................................................................. 14 6.4 RADIATED EMISSION LIMIT............................................................................................................................. 14 6.5 MEASUREMENT RESULT.................................................................................................................................. 16 7. 6DB BANDWIDTH TEST........................................................................................................................…

Text truncated - open the document above for the full version.

Radiated test setup: Conducted test setup:
