1 PA0956 User Manual SHUOYING INDUSTRIAL（SHENZHEN）CO.,LTD shuoying Road,Hebei Industry Area,Dalang,LongHua Town,Baoan,Shenzhen,China Attention: This handbook contains important security measures and correct use of the product information, in order to avoid accidents. Please make sure to read the manual carefully before using the device.
Please don’t be in high temperature, high moisture or areas of high dust
Please don’t be in high temperature. Especially in the summer don't put the device in the car when windows are closed.
Avoid drops or violent collisions of the device. Don’t allow the TFT display screen to shake or fall, this could cause it to be damaged
Please choose the appropriate volume. Headphones should not be too loud. If your ears begin to ring or hurt, lower the volume or stop using immediately
When the device is formatting or a file is uploading or downloading, please don't suddenly disconnect. This could cause an application error.
For those who, because of damage to the product, repair, or other causes, erase the memory, The Company shall not be liable for any responsibility. Please follow the user manual for the standardized operation to use the device.
Don’t disassemble the product, or use alcohol, thinner or benzene to wipe product
Don't use the device anywhere it is prohibited to use electronic equipment 2 such as an airplane
Please don't use the Tablet PC when you are driving or walking down the street,
USB only to be used for data transmission The company reserves the right to improve product, product specification and design. The information is subject to changes without prior notice. (This tablet has no waterproof function) 【Remark】All pictures in this manual are just for your reference. 1. Appearance and buttons: 3 4 2. First use 2.1 Battery management and charge Before first use, please make sure the device's battery is fully charged Just need to connect the adaptor or USB interface, then you can charge The first two times charging please charge for 6 hours, after that you just need 4 hours to charge. 【Remark】: This tablet using Built-in type polymer battery, Charger must be standard adaptor (Input: AC100~240V 50/60Hz), this device include DC charging. USB interface can charge, Choose USB interface to charge During the charging, the battery icon will scroll When finished charging, battery icon will become green and stop scrolling In order to prolong the service life of the machine, suggest using out the battery power before recharging it 【Remark】: 1. If you don’t use this tablet for a long time, to avoid power consumption damage, please charge/use the battery once a month. 2. After low battery shut down, connect DC adaptor. Device will remind of low battery charging. You need to wait some time until the battery has enough power to enter into main menu. 3. Device charging should be in standby status for reach normal charging time. Device screen power consumption may cause longer charging time. 2.2 Connection with PC Use USB cable to connect device to PC, device will pop up the USB connection window, click Turn on USB storage to connect to PC. 5 Into the USB mass storage mode, you can copy and delete the file on the device and the file on the memory card. 3. Equipment operation interface 3.1 Main interface describe The main interface of the handheld tablet includes two modes: the small tools on the desktop mode and the icons of application programs mode, both of which can be switched between via the button at the top right corner. The mode of small tools on the desktop is shown as follows: 6 Tap button on the shortcut bar to enter the interface of icon modes for application programs, which is shown as follows: 7 Tap button to enter the desktop interface. 3.2 Usage of Small Tools on Desktop Users can add, delete or install the small tools on the desktop, as well as add or delete icons of application programs or adjust the positions of icons; the icons can be dragged within the working zone, or between the working zone and the shortcut bar. Users can also add or delete the icons. Under the interface of the mode of small tools on the desktop, press and hold the icons of small tools, a check will popup on the interface, and a sign of trash bin will popup in the center of the shortcut bar. At that time, it is able to drag the icon anywhere on the desktop, or drag it directly to the trash bin to delete it. 4. Browse Webpage Users can connect to the Internet via the browser: Tap the browser icon on the desktop to open the network browser, and then the interface below will popup: 8 5. Introduction to Typical Application 5.1 E-mails Tap the E-mail icon to enter E-mails. Do the following: 1. Set E-mail accounts 2. Setup new E-mails. 3. Receive/send E-mails 4. Download or open attachments. Note: The Shortcut menu will popup by pressing Menu key. 5.2 Browse Files Tap the My Pad icon to enter the interface of Browsing files 9 After entering the interface of Browsing file, you can copy, cut, paste, add new, rename, or delete the LOCAL, SD1 or U disk. Install Files To install files in the file browser, tap the installation file with extension name as APK, an installation window will popup. Select “Install” to install the software on the tablet. 5.3 Music Tap the icon to enter the interface of Music. Tap the menu to popup the following shortcut menus, including Media gallery, 10 Music, My favorite and my list. Tap Music to enter the playing interface 1. Tap icon to enter the mode of random playing. 2. Tap icon to switch between the mode of loop for all and the mode of single song playing. 5.4 Calendar 11 Tap icon to check date and time, as well as add memorandums. Please set the calendar before using. Do the following: 1. Firstly, connect the network. Then, open the Calendar to add Exchange account, E-mail address, and password into the popup dialog box. Then tap Next step. 2. After setting the server, take the next step according to the tips. Note: in the ste…
