XJNDC222DIGITAL CAMERA

DSP SEENSOR SPI/NANA F LASH SDRAM USB TV OVT SD CARD LCD/LCM POWER KEY UI 32.768KHZ ARD 27.00MHZ AUDIO OVT LENS

External of EUT

FCC ID Label FCC ID: XJNDC222 Model Number: DC222 Made in China This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Label Location Proposed Label Location on EUT

Internal of EUT

Product Diagram Information 1. Product function introduce DV222 is a digital video camera ，playing audio and video in SD card，audio recorder。 2. Structure 1.77" TFT LCD Display ，1.3Mega Pixels CMOS Sensor ，5.0 Mega Pixels (2592×1944) ,3.1 Mega Pixels (2048×1536) , 1.3 Mega Pixels (1280×960)，VGA(640× 480)Pixels @30fps ，QVGA(320*240)Pixels @30fps，SDRAM 4X16Mb（No storage function）&SPI 1MB ，SD/MMCSDHC up to 32GB，10s Self-Timer ，2Xaaa Power Source 2.1Structure Introduce Frequency Range：27MHZ 2.2 2*AAA BATTERY

DC122SB V1.0.sch-1 - Tue Apr 26 13:38:35 2011 DC122SB V1.0.sch-2 - Tue Apr 26 13:38:40 2011 DC122SB V1.0.sch-3 - Tue Apr 26 13:38:44 2011

FCC ID: XJNDC222 SHENZHEN EMTEK CO., LTD. Report No.: ES110919083F Page 1 of 36 TEST REPORT For SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. Digital Camera Model No.: DC222 FCC ID: XJNDC222 Report Number : ES110919083F Date of Test : September 19, 2011 to September 22, 2011 Date of Report : September 23, 2011 Prepared for : SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. Address : NO.1 Shuoying Rd., Hebei Industry Area, Dalang, Longhua Town, Baoan, Shenzhen, China Prepared by : SHENZHEN EMTEK CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 FCC ID: XJNDC222 SHENZHEN EMTEK CO., LTD. Report No.: ES110919083F Page 2 of 36 TABLE OF CONTENT Test Report Description Page 1. SUMMARY OF TEST RESULT ..................................................................................................... 4 2. GENERAL INFORMATION........................................................................................................... 5 2.1. Description of Device (EUT) ....................................................................................................... 5 2.2. Description of Support Device..................................................................................................... 6 2.3. Description of Test Facility .......................................................................................................... 7 2.4. Measurement Uncertainty ............................................................................................................ 7 3. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 8 3.1. For Power Line Conducted Emission Measurement.................................................................... 8 3.2. For Radiated Emission Measurement(3m Chamber)................................................................... 8 4. POWER LINE CONDUCTED EMISSION MEASUREMENT .................................................. 9 4.1. Block Diagram of Test Setup ....................................................................................................... 9 4.2. Measuring Standard ..................................................................................................................... 9 4.3. Power Line Conducted Emission Limits (Class B) ..................................................................... 9 4.4. EUT Configuration on Measurement...........................................................................................9 4.5. Operating Condition of EUT...................................................................................................... 10 4.6. Test Procedure............................................................................................................................ 10 4.7. Measuring Results...................................................................................................................... 10 5. RADIATED EMISSION MEASUREMENT.................................................................................11 5.1. Block Diagram of Test Setup ..................................................................................................... 11 5.2. Measuring Standard ................................................................................................................... 11 5.3. Radiated Emission Limits (Class B) .......................................................................................... 12 5.4. EUT Configuration on Measurement......................................................................................... 12 5.5. Operating Condition of EUT...................................................................................................... 12 5.6. Test Procedure............................................................................................................................ 13 5.7. Measuring Results...................................................................................................................... 13 6. PHOTOGRAPHS............................................................................................................................ 14 6.1. Photos of Conducted Emission Measurement ........................................................................... 14 6.2. Photos of Radiation Emission Measurement ............................................................................. 15 APPENDIX I (2 Pages) APPENDIX II (10 Pages) APPENDIX III (Photos of EUT) (4 Pages) FCC ID: XJNDC222 SHENZHEN EMTEK CO., LTD. Report No.: ES110919083F Page 3 of 36 TEST REPORT DESCRIPTION Applicant : SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. Manufacturer : SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. EUT : Digital Camera Model No. : DC222 FCC ID : XJNDC222 Power Supply : 3*AAA Battery Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart B Class B October 2009 & FCC / ANSI C63.4-2009 The device described above is tested by SHENZHEN EMTEK CO., LTD. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and SHENZHEN EMTEK CO., LTD. is assumed full of responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of SHENZHEN EMTEK CO., LTD. Date of Test : September 19, 2011 to September 22, 2011 Prepared by : (Engineer) Reviewer : (Quality Manager) Approved & Authorized Signer : (Manager) FCC ID: XJNDC222 SHENZHEN EMTEK CO., LTD. Report No.: ES110919083F Page 4 of 36 1. SUMMARY OF TEST RESULT EMISSION Description of Test Item Standard & Limits Results Conducted Disturbance at Mains Terminals FCC Part 15, Subpart B, Class B …

Text truncated - open the document above for the full version.

RADIATED EMISSION TEST CONDUCTED EMISSION TEST
