XJNP0702001Mini PC

Size:750x820.5mm 128 Warning: Changes or modifications to this unit not expressly approved by theparty responsible for compliance could void the user’s authority to operate theequipment.NOTE: This equipment has been tested and found to comply with the limits fora Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:ο Reorient or relocate the receiving antenna.ο Increase the separation between the equipment and receiver.ο Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.ο Consult the dealer or an experienced radio/TV technician for help.Shielded cables must be used with this unit to ensure compliance with the Class B FCC limits.

IMAP200_V4.1

External Photos

Label Artwork and Location

Internal Photos

0702 circuit Technical Description The Equipment Under Test (EUT) is a Mini PC with Wifi operating at 2.412-2.462GHz, 11 channels seletction separated by 5MHz channel spacing. The EUT can carry out the base function of PC. The device is powered by 1x3.7V rechargeable battery or AC 120V/60Hz via an external Adapter. Type of Modulation: CCK for 802.11b and OFDM for 802.11g/n. Antenna Type: Internal integral PIFA Antenna. Frequency List: 2412MHz, 2417MHz, 2422MHz, 2427MHz, 2432MHz, 2437MHz, 2442MHz, 2447MHz, 2452MHz, 2457MHz, 2462MHz Main IC Fuction: At MAIN PCB 1) U1(InfoTM IMP210) is CPU with varied function such as Control Unit Arithmetic Logic Unit. 2) U2, U3 are DDR2 SDRAM. 3) U9 is NAND flash memory. 4) U7 is Stereo CODEC. 5) U10 is System-on-chip Processor. 6) U23 is Surface Mount type 4 Direction Detector. 7) U18, U14, U15 are Synchronous Buck Regulator. 8) U17 is Smart Card Interface. 9) U16, U20, U21 are compatible D/A converter. 10) U22 is I2C TOUCH SCREEN CONTROLLER. 11) U4, U12, U13, U5, U6 are power regulator. 12 ) X1 is oscillator for U1 main frequncy. 13) X2 is oscillator for U1 RTC frequncy. WiFi board: 1) U2 is WiFi chip which generate the RF signal. 2) XTAL1 is OSC for U2.

INTERTEK TESTING SERVICES Radio Frequency Radiation Exposure, FCC Rule 15.247(i): The EUT is a Mini PC with WiFi unit used in portable application, less than 20 cm from any body part of the user or near by persons. The power thresholds for source-based time-averaging Conducted output power (in the worst-case 802.11n-20M 2412MHz) = 12.8dBm And SAR Low Threshold Level: 60/f (GHz) = 60/2.45 = 24.5mW = 13.9dBm Since 12.8dBm is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. FCC ID: XJNP0702001
