XMF-BTD01Bluetooth Stereo Speaker with Power Bank

Quick Setup Guide | NS‐SPBTBRICK Bluetooth Stereo Speaker with Powerbank Before using your new product, please read these instructions to prevent any damage. CHARGING AN EXTERNAL DEVICE 1 Open the port cover on the back of the speaker. 2 Plug one end of a USB cable into your external device and the other end into the DC OUT port on the speaker. 3 Switch the ON/OFF switch to . Your external device is being charged. CONNECTING WITH BLUETOOTH 1 Make sure that your Bluetooth device is turned on and within 33 feet (10 meters) of your speaker. 2 On your speaker, press and hold the button. Your speaker enters pairing mode, and the LED on your speaker blinks. Your speaker remains in pairing mode until it pairs with a Bluetooth device. Note: Press and hold the button to return to pairing mode. 3 Turn on your Bluetooth device and turn on Bluetooth. Set your device to pairing mode, then select NS-SPBTBRICK. See the instructions that came with your Bluetooth device for information about pairing. 4 If you are asked for a password, enter 0000. When pairing is complete, the LED on your speaker lights solid blue. 5 To disconnect from the paired Bluetooth device, press and hold the button on your speaker for three seconds. You will hear a beep. Your speaker disconnects from the Bluetooth device and enters pairing mode again. SAFETY INSTRUCTIONS • Never expose the product to fire as this could result in personal injury. • Do not store the product in an extremely cold or warm environment. • Never dismantle the product. • Never let children play with the product. • Do not expose the product to dampness or moisture. • The product should not be exposed to dripping or splashing. CHARGING YOUR SPEAKER 1 Connect the small end of the charging cable to the micro USB port on the back of your speaker. 2 Connect the other end to a USB port on your computer. Note: When the battery is low, you will hear beeps. About five minutes later, the speaker will power off automatically. TURNING YOUR SPEAKER ON AND OFF • Slide the ON/OFF to ON. The LED indicator blinks quickly and the speaker enters pairing mode. PACKAGE CONTENTS • Bluetooth speaker • USB cable • Quick Setup Guide FEATURES • Wirelessly stream from any Bluetooth device • Rechargeable battery lasts up to 30 hours • Integrated power bank charges your mobile devices • Water-resistant body Top view Back view LED Blinks blue Solid blue DESCRIPTION Speaker is in pairing mode Speaker is paired OR an AUX device is connected CHARGING INDICATOR Solid red Off DESCRIPTION Charging Fully charged Your speaker loses the Bluetooth connection if you... Turn off your speaker. Move the Bluetooth device out of range. Turn off your Bluetooth device. Turn off Bluetooth on your Bluetooth device. Connect your Bluetooth device to another Bluetooth device. To reconnect... Turn on your speaker. Your speaker searches for the last connected Bluetooth device and reconnects. Make sure that your Bluetooth device is within 33 feet of your speaker. Turn on your Bluetooth device, then make sure that Bluetooth is on. Turn on Bluetooth on your Bluetooth device. Disconnect your Bluetooth device from the other Bluetooth device, then set your device to pairing mode. Select NS-SPBTBRICK on your Bluetooth device. Flat size (W×H): 355.6 × 139.7 mm Final folded size: 44.45 × 139.7 mm Microphone LED indicator Play/pause/phone Bluetooth pairing Previous Next Volume down Volume up Charging indicator AUX IN jackDC OUT ON/OFF/000 switch Micro USB charging port RECONNECTING TO A PAIRED DEVICE When your speaker is not paired to a device, the LED blinks blue. Notes: • If a device does not automatically reconnect, you may need to reselect NS-SPBTBRICK on your Bluetooth device. • If you move your device out of range, it will remain paired for 10 minutes, but no sound will come from the speaker until you come back within range. After 10 minutes, the speaker will reenter pairing mode. LISTENING TO MUSIC 1 Slide the ON/OFF switch to ON, then connect to your Bluetooth device. 2 Begin playback on your Bluetooth device. 3 Adjust the volume on your speaker by pressing the + or - buttons. Note: Press the to start playback. Press the and to go to the next or previous track. NS-SPBTBRICK_15-0655_QSG_V2_EN.ai 1 8/4/2015 2:09:20 PMNS-SPBTBRICK_15-0655_QSG_V2_EN.ai 1 8/4/2015 2:09:20 PM Bef or e using your new product, please read these instructions to prevent any damage. V2 ENGLISH 15-0655 PLAYING MUSIC FROM AN EXTERNAL SOUND SOURCE 1 Connect an external sound source, such as an MP3 player, by plugging an audio cable with a 3.5 mm plug (not included) into the AUX IN jack on the right side of your speaker. Notes: • When an AUX cable is connected, Bluetooth goes into standby mode. To play music from your Bluetooth device, press play ( ) on the speaker or your Bluetooth device. To return to AUX mode, press pause or stop on the speaker or your Bluetooth device. • When playing music via audio cable, you should pause the Bluetooth sound source paired to your speaker or disconnect the Bluetooth device. 2 Start playback on the external device. 3 Press + or – to adjust the volume. 4 Control playback using the controls on the external device. TAKING A CALL 1 OR Press and hold the button to reject an incoming call. 2 Press the button during a call to end the call. RESETTING THE SPEAKER Caution: This will remove all paired Bluetooth devices. • Turn on the speaker, then press and hold the previous button ( ) and the volume up + buttons at the same time for approximately TROUBLESHOOTINGLEGAL NOTICES FCC This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide r…

Text truncated - open the document above for the full version.

Attestation Statements Here，Lightcomm Technology Co., Ltd. Declare that: the USB interface of the Bluetooth Speaker BTD01A-A is only used for charging, no data transfer function. Certification Engineer:

Produkte Products Prüfbericht - Nr.: Test Report No. 17051282 001 Seite 66 von 70 Page 66 of 70 6 Safety Human Exposure 6.1 Radio Frequency Exposure Compliance 6.1.1 Electromagnetic Fields RESULT: Pass Test Specification Test standard : FCC KDB Publication 447498 v05r02 RSS-102 Issue 5 March 2015 The minimum distance for the EUT is 5mm, since maximum peak output power of the transmitter is 5.20 mW <10 mW, hence the EUT is excluded from SAR evaluation according to FCC KDB Publication 447498 D01 General RF Exposure Guidance v05r02 The maximum peak output power of the transmitter is 5.20 mW (7.16 dBm), only, which less than 20mW. Hence the EUT is exempted from routine evaluation limits (SAR Evaluation) according to clause 2.5.1 of RSS-102 Issue 5.

Produkte Products Prüfbericht - Nr.: T est Report No. 17051282 001 Seite 2 von 70 Page 2 of 70 Test Summary 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 PEAK CONDUCTED OUTPUT POWER RESULT: Pass 5.1.3 CONDUCTED POWER SPECTRAL DENSITY RESULT: Pass 5.1.4 6DB BANDWIDTH RESULT: Pass 5.1.5 99% BANDWIDTH RESULT: Pass 5.1.6 CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH RESULT: Pass 5.1.7 RADIATED SPURIOUS EMISSION RESULT: Pass 5.1.8 20DB BANDWIDTH RESULT: Pass 5.1.9 CARRIER FREQUENCY SEPARATION RESULT: Pass 5.1.10 NUMBER OF HOPPING FREQUENCY RESULT: Pass 5.1.11 TIME OF OCCUPANCY RESULT: Pass 5.1.12 CONDUCTED EMISSIONS RESULT: Pass 5.1.13 RADIATED EMISSION RESULT: Pass 6.1.1 ELECTROMAGNETIC FIELDS RESULT: Pass Produkte Products Prüfbericht - Nr.: T est Report No. 17051282 001 Seite 3 von 70 Page 3 of 70 Contents 1 GENERAL REMARKS ....................................................................................................... 5 1.1 COMPLEMENTARY MATERIALS ....................................................................................... 5 2 TEST SITES ..................................................................................................................... 5 2.1 TEST FACILITIES ............................................................................................................. 5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS .......................................................... 6 2.3 TRACEABILITY ................................................................................................................. 7 2.4 CALIBRATION .................................................................................................................. 7 2.5 MEASUREMENT UNCERTAINTY ........................................................................................ 7 2.6 LOCATION OF ORIGINAL DATA ........................................................................................ 7 2.7 STATUS OF FACILITY USED FOR TESTING ....................................................................... 7 3 GENERAL PRODUCT INFORMATION ................................................................................. 8 3.1 PRODUCT FUNCTION AND INTENDED USE ....................................................................... 8 3.2 RATINGS AND SYSTEM DETAILS ..................................................................................... 8 3.3 INDEPENDENT OPERATION MODES ............................................................................... 10 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ................................................ 10 3.5 SUBMITTED DOCUMENTS .............................................................................................. 10 4 TEST SET-UP AND OPERATION MODES ......................................................................... 11 4.1 PRINCIPLE OF CONFIGURATION SELECTION .................................................................. 11 4.2 TEST OPERATION AND TEST SOFTWARE ...................................................................... 11 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ................................................... 11 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE ................................................. 11 4.5 TEST SETUP DIAGRAM .................................................................................................. 12 5 TEST RESULTS ............................................................................................................. 14 5.1 TRANSMITTER REQUIREMENT & TEST SUITES .............................................................. 14 5.1.1 Antenna Requirement ........................................................................................................................... 14 5.1.2 Peak Conducted Output Power ........................................................................................................... 15 5.1.3 Conducted Power Spectral Density .................................................................................................... 22 5.1.4 6dB Bandwidth ....................................................................................................................................... 25 5.1.5 99% Bandwidth ...................................................................................................................................... 28 5.1.6 Conducted Spurious Emissions Measured in 100 kHz Bandwidth ................................................ 34 5.1.7 Radiated Spurious Emission ................................................................................................................ 43 5.1.8 20dB Bandwidth ..................................................................................................................................... 44 5.1.9 Carrier Frequency Separation ............................................................................................................. 48 5.1.10 Number of Hopping Frequency ...................................................................................................... 51 5.1.11 Time of Occupancy........................................................................................................................... 53 5.1.12 Conducted Emissions ...................................................................................................................... 64 Produkte Products Prüfbericht - Nr.: T est Report No. 17051282 001 Seite 4 von 70 Page 4 of 70 5.1.13 Radiated Emission ............................................................................................................................ 65 6 SAFETY HUMAN EXPOSURE .......................................................................................... 66 6.1 RADIO FREQUENCY EXPOSURE COMPLIANCE .............................................................. 66 6.1.1 Electromagnetic Fields ........................................................................................…
