XMF-MDT100810.1 inch QUAD CORE TABLET PDVD COMBO

3+=,09 0'705  9哺ᱛ㣧 PELTDV1029 70 Safety PrecautionPackageMain FeaturesOverviewCharge the BatteryStart the device DVD PlaybackCamera FunctionWi-Fi ConnectionMirror Cast ConnectionText InputBattery Use Trouble shooting LIMITED PRODUCT WARRANTY 01040405060608101112131314151517 Caution---use of controls or adjustments or performance of procedures other 1) Please read the instruction manual carefully and follow all the requirements of safe operation to operate the device. 2) Do not use or leave the device in direct sunlight or a hot environment such as a vehicle etc. Overheating can damage the device 4) Do not overcharge the device,do not leave the device on the charger for very long after the battery has been fully charged. 5) Device should be protected from any physical impact or damage and care should be taken not to drop the device. 6) Only use the factory supplied charger. The use of unapproved charger or cable may cause the battery to fail, explode and/or damage the device. 7) Do not disassemble, puncture, crush or expose your device to temperatures above 40 °C / 104 °F. 9) Keep your device from moisture and extreme temperatures. 10) Should your battery swell or expand, please immediately discontinue use of your device. A probable cause is it having been overheated at some point or overcharged. Please contact us for support . 3) There’s a rechargeable battery built inside the device. If the device is not used for long, it may occur no charging indication when power up. Under this circumstance, please keep power connected and wait for about 5~10 minutes. You’re advised to charge the battery every 3 months to keep the device in good condition. 8 01 11) Do not install near any heat sources such as radiators, heat registers, stoves,12) Unplug this unit during lightning storms or when unused for long time. 13) About Cleaning: Unplug the system, use only wet cloth to clean. Do not use liquid detergent or aerosol. when the unit has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the unit, exposed to moisture, does not operate normally. Don't try to repair the device by yourself because of the danger of high voltage and electric shock. 15) Do not use irregular shaped discs such as heart or star-shaped discs as they may cause the unit to malfunction. 16 This device is not compatible with Blue-ray disc while playing DVD. 18 While playing DVD, in wireless connection, there’s a slight audio lag less than 5 seconds. This is normal and design related. 19) It is recommended that volume level of your earphones should be adjusted toan appropriate level to avoid damages to your hearings due to high volume. (earpho ne not included) or during this device is in operation, to avoid data loss and system error.the airline company if you want to use this device on the airplane. 23) For data safety, please back up important data on a timely manner. This product is not a toy. To use only under adult supervision. 14 02 17 BD type disc not supported. 03 DVD Player with tablet comboCar adapterAC/DC adapterUSB cableUser manual * 10.1” panel of 800X1280 resolution * Built-in rechargeable Lithium-ion battery * Built-in two HIFI speakers * Support playback DVD/VCD/CD/MP3 * Built-in internal memory of 32GB* Support Wireless connection (Tablet mode)* Touch control functions * Stand on back plate * 2MP front camera 04 Note:This unit is NOT compatible with Blu-ray. 11 MT8168 TYPE-C USB PORT Micro SD EarphoneReset Camera Press it to open the unit and put the disc on the loading tray. To record if recording function turned on. Long press 2-3 seconds,screen will light up and pictures will show up until the interface page.a screenshot.Press +/- to adjust volume. TYPE-C USB port: For both power supply input and connecting with PC(For thelatter, after connecting the USB cable with PC, select Settings-> Connected Devices->USB->Use USB for File Transfer.) to insert a micro SD per instruction. To connect external earphone. To restart the system if abnormal situation happens and the device can’t be Camera: 2 Million pixel, for camera use. Pull it out to put the device on the table. 05 Bracket a) Connect the USB cable to the device.b) Connect the other end of the USB cable to the USB power adapter (wall charger), then plug the adapter into a power outlet. It takes about 5 hours to fully charge the device.Caution: Use only the included power adapter to charge the battery. An incompatible adapter may cause damage. a) After connecting the power adapter, screen will light up and show battery once, the unit will light up again. If screen does not light up, please charge and wait for about 5 minutes. If still no response, please call after sales service for help. boot will take about 5-10 minutes, please be patient. c) After boost, Android user wizard will appear, you are required to do some setup, or you can skip it. 06 d) Turn on the device, you will see the main page which has a lot of app icons. or swipe up to go to app page where all the pre-installed apps can be found. No matter what you’re looking for, Google Play has it all. Get your music, movies, TV, books, magazines, apps and games all in one place.e) Function buttons at the bottom of the interface. Touch it to back to last step or quit the current app. Touch it to go to the main page at once. Touch it to show recent app list. 07 Touch it to enter Walmart App. If you want to close recent apps, touch to show recent items, wipe it up to close the corresponding item. If you want to close all recent used items, please slide right, "CLEAR ALL" will show up at the left, then touch it, the system will close all recent items. A lot of apps will take up memory space and slow down the speed, worsen your device agile and running smoothly. a) Touch DVD icon on the main page or choose it from the app list.b) Press Open button ( )on the top of the unit open the device and load a disc. After cl…

Text truncated - open the document above for the full version.

Differences Declaration To whom concern, We company Lightcomm Technology Co., Ltd. hereby declares: The product models PELTDV1029, PELTDV1029_COMBO, PELTDV1029_12DISP, MDT1008-MR are identical in the same PCB layout, interior structure and electrical circuits, the only difference is the model name for commercial purpose. Authorized signature: Date: 2022-05-25

DATE : 2022-05-25 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint JasonWuofGlobalUnitedTechnologyServicesCo.,Ltd.andNo. 123Ͳ128,TowerA,JinyuanBusinessBuilding,No.2,LaodongIndustrialZone,XixiangRoad, BaoanDistrict,Shenzhen,Guangdong,China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Lightcomm Technology Co., Ltd. and UNIT 1306 13/F ARION COMMERCIAL CENTRE,2-12 QUEEN'S ROAD WEST,SHEUNG WAN HK Signature: Name: Jack Sun Title: Certification Manager Compan y: Lightcomm Technology Co., Ltd.

Lightcomm Technology Co., Ltd. DATE : 2022-05-25 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: X MF-MDT1008 Product Name: 10.1“ QUAD CORE TABLET PDVD COMBO Request for Confidentiality To Who m It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitel y. Thes e documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature: Name: Jack Sun Title: Certification Manager Company: Lightcomm Technology Co., Ltd.

10.0 mm 10.0 mm 79.8 mm 59.8 mm 字体：consolas 10号（字体高于2mm） 大货时数字随着条码而相应滚动 条码用code 39生成 （不含S/N:） 流水号范围： A2208452710000001~ A2208452710024000 IMPORTED BY/IMPORTÉE PAR: C.I.LTD. MISSISSAUGA, ON, L5S 2A3. CANADA. MADE IN CHINA/ FABRIQUÉ EN CHINE S/N: A2208452710000001 August, 2022 79.8*59.8*0.2MM 75#哑银龙+上光膜，黑底银字 -0.1~0mm 22PHZ012-RL-V1.1 MDT1008-MR Cut line 切线 Remarks: 注释: 类型 Structure Style 材质/工艺 Material 尺寸 Size 公差 Tolerance 描述 Description 后牌贴 Size marking 规格标注 文件名 File Name 机型 Project# 比例 Scale 1:1 设计 Designer 审核 Checked 设计日期 Design Date 陈慧虹 黄春花 2022.5.11 technique TEMPERATURE CAUTION: Operating ambient temperature range: 0°C~40°C. Do not leave the player in a closed car on a sunny day, exposed to direct sunlight or near any source of heat such as a TV set. [Otherwise the surface may warp,change color or be damaged.] When the player is used for a long period,the surface may be hot, this is not a malfunction, however, take caution against burns. OTHER CAUTION: Charge only with the supplied power adaptor. BEWARE OF WATER SPLASH: For avoiding electric shock or short circuit,do not place the player near where liquid splashed. LASER BEAM WARNING: Do not stare at the laser beam. Strong light will cause eye injury. Complies with DHHS Rules 21 Subchapter J parts 1040-10 and 1040-11 at date of manufacture. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. PELTDV1029 FCC ID: XMF-MDT1008 10.1" QUAD CORE TABLET/PDVD COMBO DC INPUT: 5V 2 A 备注： 日期为：September, 2021

FCC ID: XMF-MDT1008 RF Exposure Evaluation According to KDB 447498 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, For BT Max Conducted Output Power(dBm) Max tune-up Power(dBm) Max tune-up Power(mW) Frequency (MHz) Min. distance(mm) Calc. thresholds limit 5.47 5.5 3.55 2480 5 1.12 3.0 For BLE Max Conducted Output Power(dBm) Max tune-up Power(dBm) Max tune-up Power(mW) Frequency (MHz) Min. distance(mm) Calc. thresholds limit -2.87 -2 0.63 2440 5 0.20 3.0 For WIFI 2.4G Max Conducted Output Power(dBm) Max tune-up Power(dBm) Max tune-up Power(mW) Frequency (MHz) Min. distance(mm) Calc. thresholds limit 8.91 9 7.94 2412 5 2.47 3.0 So compliance.

Global United Technology Services Co., Ltd. Report No.: GTS202205000048F02 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 27 TEST REPORT Applicant: Lightcomm Technology Co., Ltd. Address of Applicant: UNIT 1306 13/F ARION COMMERCIAL CENTRE,2-12 QUEEN'S ROAD WEST,SHEUNG WAN HK Manufacturer: Lightcomm Technology Co., Ltd. Address of Manufacturer: UNIT 1306 13/F ARION COMMERCIAL CENTRE, 2-12 QUEEN'S ROAD WEST, SHEUNG WAN HK Factory: Huizhou Hengdu Electronics Co., Ltd. Address of Factory: No.8 Huitai Road, Huinan High-tech Industrial Park, Huiao Avenue, Huizhou, Guangdong, China Equipment Under Test (EUT) Product Name: 10.1“ QUAD CORE TABLET PDVD COMBO Model Number: PELTDV1029, PELTDV1029_COMBO, PELTDV1029_12DISP, MDT1008-MR FCC ID: XMF-MDT1008 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: May 09, 2022 Date of Test: May 09-25, 2022 Date of report issued: May 25, 2022 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 27 2 Version Version No. Date Description 00 May 25, 2022 Original Prepared By: Date: May 25, 2022 Project Engineer Check By: Date: May 25, 2022 Reviewer Report No.: GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 27 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................7 5.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 5.4 DEVIATION FROM STANDARDS ..............................................................................................................7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 5.6 TEST FACILITY ....................................................................................................................................7 5.7 TEST LOCATION ..................................................................................................................................7 5.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................7 6 TEST INSTRUMENTS LIST ......................................................................................................................8 7 TEST RESULTS AND MEASUREMENT DATA .....................................................................................10 7.1 ANTENNA REQUIREMENT ....................................................................................................................10 7.2 CONDUCTED EMISSIONS ....................................................................................................................11 7.3 CONDUCTED OUTPUT POWER ............................................................................................................14 7.4 CHANNEL BANDWIDTH .......................................................................................................................15 7.5 POWER SPECTRAL DENSITY ..............................................................................................................16 7.6 SPURIOUS EMISSION IN NON-RESTRICTED & RESTRICTED BANDS ........................................................17 7.6.1 Conducted Emission Method ......................................................................................................17 7.6.2 Radiated Emission Method .........................................................................................................18 8 TEST SETUP PHOTO .............................................................................................................................27 9 EUT CONSTRUCTIONAL DETAILS .......................................................................................................27 Report No.: GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 27 4 Test Summary Test Item Section in CFR 47 Result An…

Text truncated - open the document above for the full version.

GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 1 of 14 Appendix for 15.247 1. Duty Cycle 1.1 Test Result Test Mode Channel Frequency(M Hz) TX Type ANT No. T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) 1M 2402 SISO 1 0.382 0.625 61.12 2.14 2440 SISO 1 0.382 0.625 61.12 2.14 2480 SISO 1 0.382 0.625 61.12 2.14 1.2 Test Graph GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 14 GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 14 2. Bandwidth 2.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. 6dB Bandwidth Verdict Test Result (MHz) 1M 2402 SISO 1 0.680 PASS 2440 SISO 1 0.676 PASS 2480 SISO 1 0.683 PASS Test Mode Frequency (MHz) TX Type ANT No. 99% Occupied Bandwidth Test Result (MHz) 1M 2402 SISO 1 1.043 Only for Report Use 2440 SISO 1 1.044 Only for Report Use 2480 SISO 1 1.044 Only for Report Use 2.2 Test Graph - 6dB Bandwidth GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 14 GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 5 of 14 2.3 Test Graph - 99% Occupied Bandwidth GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 6 of 14 GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 7 of 14 3. Maximum Conducted Output Power 3.1 Test Result Test Mode Frequency (MHz) Tx Type Measured Peak Output Power (dBm) Limits (dBm) Verdict 1M 2402 SISO -3.67 30 PASS 2440 SISO -2.87 30 PASS 2480 SISO -2.94 30 PASS 3.2 Test Graph GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 8 of 14 GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 9 of 14 4. Maximum Power Spectral Density (PSD) 4.1 Test Result Test Mode Frequency (MHz) Tx Type Maximum Power Spectral Density (dBm/3KHz) Limits (dBm/3kHz) Verdict Ant 1 1M 2402 SISO -18.37 ≤8 PASS 2440 SISO -17.59 ≤8 PASS 2480 SISO -17.65 ≤8 PASS 4.2 Test Graph GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 10 of 14 GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 11 of 14 5. Unwanted Emissions in Non-restricted Frequency Bands 5.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. Spurious Conducted Emission (dBm) Limits (dBm) Verdict 1M 2402 SISO 1 Refer to test graph -23.40 PASS 2440 SISO 1 Refer to test graph -23.40 PASS 2480 SISO 1 Refer to test graph -23.40 PASS 5.2 Test Graph GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 12 of 14 GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 13 of 14 GTS202205000048F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 14 of 14 ------End------

Global United Technology Services Co., Ltd. Report No.: GTS202205000048F03 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 39 TEST REPORT Applicant: Lightcomm Technology Co., Ltd. Address of Applicant: UNIT 1306 13/F ARION COMMERCIAL CENTRE,2-12 QUEEN'S ROAD WEST,SHEUNG WAN HK Manufacturer: Lightcomm Technology Co., Ltd. Address of Manufacturer: UNIT 1306 13/F ARION COMMERCIAL CENTRE, 2-12 QUEEN'S ROAD WEST, SHEUNG WAN HK Factory: Huizhou Hengdu Electronics Co., Ltd. Address of Factory: No.8 Huitai Road, Huinan High-tech Industrial Park, Huiao Avenue, Huizhou, Guangdong, China Equipment Under Test (EUT) Product Name: 10.1“ QUAD CORE TABLET PDVD COMBO Model Number: PELTDV1029, PELTDV1029_COMBO, PELTDV1029_12DISP, MDT1008-MR FCC ID: XMF-MDT1008 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: May 09, 2022 Date of Test: May 09-25, 2022 Date of report issued: May 25, 2022 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202205000048F03 Global United Technology Services Co., Ltd. No. 123-128, Tower A,Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 39 2 Version Version No. Date Description 00 May 25, 2022 Original Prepared By: Date: May 25, 2022 Project Engineer Check By: Date: May 25, 2022 Reviewer Report No.: GTS202205000048F03 Global United Technology Services Co., Ltd. No. 123-128, Tower A,Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 39 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................7 5.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 5.4 DEVIATION FROM STANDARDS ..............................................................................................................7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 5.6 TEST FACILITY ....................................................................................................................................7 5.7 TEST LOCATION ..................................................................................................................................7 5.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................7 6 TEST INSTRUMENTS LIST ......................................................................................................................8 7 TEST RESULTS AND MEASUREMENT DATA .....................................................................................10 7.1 ANTENNA REQUIREMENT ....................................................................................................................10 7.2 CONDUCTED EMISSIONS ....................................................................................................................11 7.3 CONDUCTED PEAK OUTPUT POWER ...................................................................................................14 7.4 CHANNEL BANDWIDTH .......................................................................................................................15 7.5 POWER SPECTRAL DENSITY ..............................................................................................................16 7.6 SPURIOUS EMISSION IN NON-RESTRICTED & RESTRICTED BANDS ........................................................17 7.6.1 Conducted Emission Method ......................................................................................................17 7.6.2 Radiated Emission Method .........................................................................................................18 8 TEST SETUP PHOTO .............................................................................................................................39 9 EUT CONSTRUCTIONAL DETAILS .......................................................................................................39 Report No.: GTS202205000048F03 Global United Technology Services Co., Ltd. No. 123-128, Tower A,Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 39 4 Test Summary Test Item Section Result Antenna requirement…

Text truncated - open the document above for the full version.

GTS202…
