XMF-CVS0336Car Multimedia System

JDVD1500 CD / MP3 / WMA / DVD PLAYER / RECEIVER Installation and Operation Manual 2 JDVD1500 INTRODUCTION System Features Features of the Jensen JDVD1500 mobile audio system include: • 3-Wire power (ACC, Batt, Gnd) • Detachable faceplate • 1-DIN (sleeve-mount) chassis design • Segmented LCD Display • Blue LED panel illumination • Electronic AM/FM tuner (US) • Station presets (18FM, 12AM) • Auto-Store (AS)/ Preset Scan (PS) • Single DVD / CD player (Plays DVD, CD-A, CD-R/RW Media) • Plays MP3 and WMA Encoded Discs • Electronic Skip Protection (ESP) CD (8 Sec) DVD (3 Sec) • Front panel Aux Video / Stereo Audio input (3.5mm) • Encoded rotary volume control • Audio Mute / Loudness • Preset EQ (Pop, Rock, Classic) • Stereo Pre-amp Audio Output (Front and Rear RCA) • 2 Composite Video Output (RCA) • 1 Composite Video Input (RCA) • 4x40W Maximum Audio Power Output • Subwoofer Output (Pre-amp RCA) • Wireless (Jensen IR Codes) Credit Card size remote control (i ncluded) • Wired remote ready (MWR75 sold separately) 3 JDVD1500 • IR repeater eye ready (IRPMRPT sold separately) • Regulatory Certifications: FCC Content List • Jensen Heavy Duty Radio • Hardware Kit • Installation Manual • Quick reference Guide SAFETY INFORMATION When Driving Keep the volume level Iow enough to be aware of the road and tr affic conditions. When Washing your Vehicle Do not expose the product to water or excessive moisture. Moist ure can cause electrical shorts, fire or other damage. When Parked Parking in direct sunlight can produce very high temperatures i nside your vehicle. Give the interior a chance to cool down before starting playback. Use the Proper Power Supply This product is designed to operate with a 12 volt DC negative ground battery system (the standard system in a North American vehicle). Protect the Disc Mechanism Avoid inserting any foreign objects into the disc slot. Misuse may cause malfunction or permanent damage due to the precise mechanism of this unit. CAUTION: THIS MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. THIS UNIT US ES A VISIBLE/ INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION IF E XPOSED DIRECTLY. BE SURE TO OPERATE THE MOBILE DVD PLAYER AS INSTRUCTE D. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OR PROCEDURES OTH ER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION E XPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR BY YOURSELF. PLEASE REFER SERVICING TO A QUALIFIED TECHNICIAN. WARNING: • TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE T HIS EQUIPMENT TO RAIN OR MOISTURE. • TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND ANNOYING INTERFERENCE, USE ONLY THE RECOMMENDED ACCESSORIES. • THIS DEVICE IS INTENDED FOR CONTINUOUS OPERATION. This product incorporates copyright protection technology that is protected by method claims of certain U.S. Patents and other intellectual property rights own ed by Macrovision Corporation and other rights owners. Use of this copyright protection technolog y must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or d isassembly is prohibited. Region Management Information This Mobile DVD Player is designed and manufactured to respond to the Region Management Information recorded on indivi dual DVD discs. If the Region num ber described on the DVD disc does not correspond to the Region number(s) supported by this M obile DVD Playe r, the di sc will not play in this unit. 4 JDVD1500 DISC NOTES Compatible Disc Types DVD Video DVDs contain excellent sound and video quality due to Dolby Dig ital and MPEG2 encoding. A DVD is 12 cm in diameter and can hold more than seven times the dat a of a CD-ROM. The maximum playing time can be up to 2 hours (a double-sided DVD is up to 4 hours). There are four types of DVD discs: single-layer single-sided (1), two-layer single-side d (2), single-layer doublesided (3), and two-layer double-sided (4). CD-DA CD-DA discs can play voice data . The playing time of the standa rd 12 cm CD-DA disc is 74 minutes. DTS-CD The DTS digital surround sound uses 6 digital sound tracks to r eplace the analog voice tracks in movies. HDCD HDCD, or “High Definition Compatible Digital,” is a recording/p laying technology that improves CD audio quality. Based on full compliance with CD specifications, it can enhance the quality and quantity of digital sounds in the highest scale. It encodes the required messages that were deserted by the CD format, and stores the related commands into the LSB. Without changing the CD format, it is output through the 24-bit D/A converter, which will ultimately enhance the quality of playback. MP3/WMA/JPEG This unit is compatible with CD- R, CD-RW, and C D-ROM discs cont aining MP3, WMA, and JPEG tracks. CD-R/CD-RW This unit is compatible with CD-R and CR-RW discs that support ISO9660 specifications. “.MP3”, “.JPG”, “.JPEG”, “.AC3”, “.PCM”, “.MPG”, “.MPE”, and “.WAV” for mats can be included on ISO9660-compatible discs. DVD-R / DVD-RW This unit is compatible with DVD-R and DVD-RW discs that suppor t UDF specifications. “.MP3”, “.JPG”, “.JPEG”, “.AC3”, ”.PCM”, “.MPG”, “.MPE”, and “.WAV” for mats can be included on UDFcompatible discs. Incompatible Disc Types • 8 cm disc • CD ROM • CDV, CDI, CDG • LD • DVD ROM • DVD RAM NOTE: DVD-R and DVD-RW discs will not play unless the recording session is closed and the DVD is finalized. Table 1: General Disc Information Disc Type Logo Diameter/ Playable Sides Playback Time DVD Video 12 cm single/double side (1 layer & 2 layer) 133 minutes (4.7 GB) 242 minutes (8.5 GB) 266 minutes (9.4 GB) 484 minutes (17 GB) Audio CD 12 cm single side 74 minutes MP3/MWA Disc CD-Rs or CD-RWs recorded in MP3, MPEG1 or 2, 2.5 Au dio Layer 3 and WMA Version 7 and 8. The recorded format must be compliant with ISO 9660 Level 1, ISO 9660 Level 2, Romeo, or Joliet. Disc Maintenance Before playing, wipe the disc us ing a clean cloth, working from th…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Lightcomm Technology Co., Ltd. 2015-08-24 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Lightcomm Technology Co., Ltd. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Car Multimedia System MODEL No.: JDVD1500, CVS0336-P FCC ID: XMF-CVS0336 Sincerely, Jason Zeng/Certification Engineer E-mail: [email protected] Phone: 0085221913611 Fax: 0085221913612 Address: RM1708-10, 17/F, PROSPERITY CENTRE, 25 CHONG YIP STREET, KWUN TONG, HONG KONG

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Lightcomm Technology Co., Ltd. 2015-08-24 To: Industry Canada Certification and Engineering Bureau P.O. Box 11490, Station H 3701 Carling Avenue (Building 94) Ottawa, Ontario K2H 8S2 Attention: Manager, Equipment Certification Subject: Permanent Confidentiality Request for FCC: XMF-CVS0336 We hereby request confidential treatment of information accompanying this application as outlined below: - block diagrams; - operational description; - schematic diagrams. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Jason Zeng/Certification Engineer E-mail: [email protected] Phone: 0085221913611 Fax: 0085221913612 Address: RM1708-10, 17/F, PROSPERITY CENTRE, 25 CHONG YIP STREET, KWUN TONG, HONG KONG

Family models declaration letter. 2015-8-27 We Lightcomm Technology Co., Ltd. Of RM1708-10, 17/F, PROSPERITY CENTRE, 25 CHONG YIP STREET, KWUN TONG, HONG KONG （address） Declare under our sole responsibility that the product Product: Car Multimedia System Model No.: JDVD1500, CVS0336-P FCC ID: XMF-CVS0336 All models have the same constructions, circuit diagram and PCB layout. Only model name is different. Unless otherwise stated Sincerely, Jason Zeng/Certification Engineer E-mail: [email protected] Phone: 0085221913611 Fax: 0085221913612 Address: RM1708-10, 17/F, PROSPERITY CENTRE, 25 CHONG YIP STREET, KWUN TONG, HONG KONG

Lightcomm Technology Co., Ltd. Car Multimedia System MODEL No.: JDVD1500 FCC ID: XMF-CVS0336 Made in HK This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Lightcomm Technology Co., Ltd. Car Multimedia System MODEL No.: CVS0336-P FCC ID: XMF-CVS0336 Made in HK This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.

Label Location

Module Antenna

FCC ID : XMF-CVS0336 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 Measurement Result Antenna gain: 0dBi BT Mode Channel Freq. (MHz) Measured power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain (dBi) Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) GFSK 2402 -1.328 -2.0±1 -1.0 0 0.0002 1 GFSK 2441 -2.206 -2.0±1-1.000.0002 1 GFSK 2480 -1.523 -2.0±1-1.000.0002 1 1/4Π-DQPSK 2402-1.391 -2.0±1-1.000.0002 1 1/4Π-DQPSK 2441 -2.336 -2.0±1-1.000.0002 1 1/4Π-DQPSK 2480 -1.704 -2.0±1-1.000.0002 1 8DPSK 2402 -1.302 -2.0±1-1.000.0002 1 8DPSK 2441 -2.204 -2.0±1-1.000.0002 1 8DPSK 2480 -1.563 -2.0±1-1.000.0002 1

TRF No.:FCC 15.247/A Page 1 of 60 Report No.: ES150813167E Ver.1.0 Access to the World FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT For Car Multimedia System MODEL No.: JDVD1500, CVS0336-P FCC ID: XMF-CVS0336 Trademark: N/A REPORT NO.: ES150813167E ISSUE DATE: August 20, 2015 Prepared for Lightcomm Technology Co., Ltd. RM1708-10, 17/F, PROSPERITY CENTRE, 25 CHONG YIP STREET, KWUN TONG, HONG KONG Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.:FCC 15.247/A Page 2 of 60 Report No.: ES150813167E Ver.1.0 Access to the World Table of Contents 1 TEST RESULT CERTIFICATION ............................................................................................................. 3 2 EUT TECHNICAL DESCRIPTION............................................................................................................ 4 3 SUMMARY OF TEST RESULT ................................................................................................................ 5 4 TEST METHODOLOGY ........................................................................................................................... 6 4.1 General Description Of Applied Standards .................................................................................... 6 4.2 Measurement Equipment Used ..................................................................................................... 6 4.3 Description Of Test Modes ............................................................................................................. 6 5 FACILITIES AND ACCREDITATIONS ...................................................................................................... 8 5.1 Facilities ......................................................................................................................................... 8 5.2 Laboratory Accreditations And Listings .......................................................................................... 8 6 TEST SYSTEM UNCERTAINTY .............................................................................................................. 9 7 SETUP OF EQUIPMENT UNDER TEST ............................................................................................... 10 7.1 Radio Frequency Test Setup 1 ..................................................................................................... 10 7.2 Radio Frequency Test Setup 2 ..................................................................................................... 10 7.3 Conducted Emission Test Setup .................................................................................................. 12 7.4 Block Diagram Configuration Of Test System .............................................................................. 13 7.5 Support Equipment ...................................................................................................................... 13 8 FREQUENCY HOPPING SYSTEM REQUIREMENTS ......................................................................... 14 8.1 Standard Applicable ..................................................................................................................... 14 8.2 EUT Pseudorandom Frequency Hopping Sequence................................................................... 14 8.3 Equal Hopping Frequency Use .................................................................................................... 15 8.4 Frequency Hopping System ........................................................................................................ 15 9 TEST REQUIREMENTS ........................................................................................................................ 16 9.1 20db Bandwidth ........................................................................................................................... 16 9.2 Carrier Frequency Separation ...................................................................................................... 22 9.3 Number Of Hopping Frequencies ................................................................................................ 28 9.4 Average Time Of Occupancy (Dwell Time) .................................................................................. 30 9.5 Maximum Peak Conducted Output Power ................................................................................... 33 9.6 Conducted Suprious Emission ..................................................................................................... 39 9.7 Radiated Spurious Emission ........................................................................................................ 46 9.8 Conducted Emission Test ............................................................................................................ 59 9.9 Antenna Application ..................................................................................................................... 60 TRF No.:FCC 15.247/A Page 3 of 60 Report No.: ES150813167E Ver.1.0 Access to the World 1 TEST RESULT CERTIFICATION Applicant: Lightcomm Technology Co., Ltd. RM1708-10, 17/F, PROSPERITY CENTRE, 25 CHONG YIP STREET, KWUN TONG, HONG KONG Manufacturer: Lightcomm Technology Co., Ltd. RM1708-10, 17/F, PROSPERITY CENTRE, 25 CHONG YIP STREET, KWUN TONG, HONG KONG Product Description: Car Multimedia System Model Number: JDVD1500, CVS0336-P Trademark: N/A File Number: ES150813167E Date of Test: August 13, 2015 to August 20, 2015 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as …

Text truncated - open the document above for the full version.

Radiated Spurious Emission
