Model: 100026191 7” Tablet Gen 2 PRODUCT GUIDE November , 2020_V1 We’d love to hear from you. Scan with your Walmart app and let us know what you think.   1 Introduction Thank you for purchasing the onn. Android 10 (Go edition) tablet with Google Play. Featuring a fast and responsive quad core processor, this tablet is perfect for accomplishing everyday tasks, streaming music and movies, taking photos, checking emails, and engaging with social media. The tablet oers 16GB of internal storage, Bluetooth connectivity, Micro SD slot for up to 128GB of additional storage, on-the-go productivity services, and a utility app. The following information will help you get the most out of your tablet. What You Should Know to Ensure Best Performance: • Charge the battery completely before first use. • While updates download in the background, tablet performance can be affected until completed. • Close unused applications. Open apps that run in the background will affect overall performance. • Battery Consumption: Play times on a fully charged battery will vary depending on your display settings, apps that remain open, and internet use(ie: streaming video content). • Suggest customer use tablet screen protector and tablet case to protect the tablets. TMTM 2 In The Box 7’’ Tablet Quick Start GuideUSB cable Model: 100026191 7” Tablet Gen 2 PRODUCT GUIDE November , 2020_V1 We’d love to hear from you. Scan with your Walmart app and let us know what you think.  7” Tablet Gen 2 Quick Start Guide User Manual Charger Size:40*31*22mm Model: TEKA-UCA10US Input:100-210V~ 50/60Hz, 0.3A Output:5.0V 1.0A Manufacturer: SHENZHEN TEKE TECHNOLOGY CO LTD 3 Getting to Know Your Tablet 1. Camera(Rear) 2. Micro SD Card Slot 3. Earphone 4. Volume Control 5. Power On/Off 6. Speaker 7. USB Type C 8. Camera(Front) 12 38 4 5 67 4 Charging Your Tablet It is recommended to fully charge the tablet before first use. To charge the tablet, plug the 1) USB cable in to the AC adapter,2) attach the other end to the USB Type C input on the tablet,3) Plug the AC adapter in to a wall outlet. When the tablet is ON and charging, the battery icon will pulsate. It is normal for the tablet to get warm while charging, playing high in tensity games, or streaming video. Battery life will vary depending on usage. Note: Leave tablet in well ventilated area while charging. 5 Turning on your tablet 1. Press and hold the Power button 4-5 seconds until onn. logo appears. 2. Select your desired language, then tap START. 3. Follow the onscreen instructions to configure your tablet. Power button 6 Starting Your Tablet 1. At the Start-up screen, slide your finger up to unlock. 2. Once you' ve arrived at the Home screen, you can begin using your tablet. 11:32 Tue. May 8 2 1 345 6 7 Home Screen At-a-Glance 1.Status Bar 2.Search Box 3.Walmart App Suite 4.Go Back 5.Home 6.Recents 8 Using the Camera Tap on the Camera lcon 1. Switch Cameras(Front/Rear) 2. Settings 3. Recent Photo 4. Take Photo Settings let you configure the tablet, set Wi-Fi, Bluetooth and other preferences. On the HOME screen, tap the Settings icon to go to settings. 9 Settings 10 Touching and Typing To select an item on the screen, simply tapit once with your fingertip. Some items may require you to "double-tap". To type in to an text field(i.e, when inputting your name, or a web address), tap the text field. The on-screen keyboard will appear, and allow you to type the information you wish to enter. Touch and Hold:Keep your finger on an on-screen item until it glows or activates an alternate menu. Drag: Move an App or object by touching and holding the image, then sliding it to the destination. Slide: When there are extra "screens “to the side, slide one or more fingers from one side to another. 11 Connecting to the Internet In order to connect to the internet, you will need the following: • A wireless router or an access point with a broadband internet connection. • The name of your network(SSID), as well as the password or other credentials, if your network is secure. The wireless router must support Wi-Fi 802.1 1 a/b/g/n/ac connections. Go to Settings > Network & internet > Wi-Fi Tap on Wi-Fi to activate wireless connectivity. The Tablet will scan for available Wi-Fi networks within range. Secured networks will require a password. Once you have successfully entered your information the tablet will remember your settings. 12 Connecting Bluetooth Your Tablet is compatible with Bluetooth capable devices. Once your tablet searches and finds the Bluetooth device, follow on-screen instructions to initiate the pairing of the device with the Tablet. Add or "pair “a Bluetooth compatible device with your Tablet as follows: 1) Turn on the compatible Bluetooth device and make it discoverable. 2) Open the Settings > Connected devices. 3) Tap on Pair new device view available devices. To ensure the tablet runs smoothly it is recommended to perform periodic system software updates, especially during initial set up of the tablet. You may receive notifications(on the Lock screen) from time to time that software updates are available. Tap the notification to be directed to the update. Other options to access updates: 1. Tab on Settings > System > Advanced > About Tablet > Wireless Update. NOTE: To perform an update, you must be connected to Wi-Fi. 13 Tablet Updates The first time you sign on to Google Play Store, updates will automatically start downloading on to the tablet. The download icon will appear in the status bar at the top left of screen. Installing a new application while multiple apps are downloading will reduce tablet speed and performance. After all downloads and updates have been installed, the tablet will resume normal operating performance. To view the progress of downloads working in the background, slide your finger down from the top edge of the screen. 14 Google Play Updates We would like you to have a safe and enjoyable experience. Please read the following instr…

Text truncated - open the document above for the full version.

Lightcomm Technology Co., Ltd. Add: UNIT 1306 13/F ARION COMMERCIAL CENTRE,2-12 QUEEN'S ROAD WEST, SHEUNG WAN HK Date: 2020/12/30 FCC ID: XMF-MID7018 Dear Sir/Madam, We, Lightcomm Technology Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: onn 7" Tablet Model no.: 100026191, MID7018 Sincerely, Name/Title： Jack Sun/Certification Manager Company: Lightcomm Technology Co., Ltd. Address: UNIT 1306 13/F ARION COMMERCIAL CENTRE,2‐12 QUEENʹS ROAD WEST, SHEUNG WAN HK Phone: 85 221913611 Fax: 85 221913612 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2020/12/30> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name XMF-MID7018 100026191 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sinc Nam Com Add Pho Fax E-M cerely, me/Title： mpany: dress: one: : Mail: Jack Sun/ Lightcom UNIT 13 ROAD W 85 221913 85 221913 sunshuhu /Certificatio mm Technol 306 13/F A WEST, SHEU 3611 3612 ui@hcn2000 on Manager ogy Co., Lt d RION COM UNG WAN 0.com d. MMERCIAL HK L CENTREE,2‐12 QUE EENʹS

Lightcomm Technology Co., Ltd. UNIT 1306 13/F ARION COMMERCIAL CENTRE,2-12 QUEEN'S ROAD WEST, SHEUNG WAN HK Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2020/12/30 To whom it may concern: We, Lightcomm Technology Co., Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: XMF‐MID7018 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Jack Sun/Certification Manager Company: Lightcomm Technology Co., Ltd. Address: UNIT 1306 13/F ARION COMMERCIAL CENTRE,2‐12 QUEENʹS ROAD WEST, SHEUNG WAN HK Phone: 85 221913611 Fax: 85 221913612 E-Mail: [email protected]

Page: 3 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Page: 4 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT Page: 5 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT Page: 6 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Photo 7 Appearance of EUT Photo 8 Appearance of EUT

Page: 1 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Appendix IFCC ID Label Size for the label: 40mm X 30mm FCCID: XMF-MID7018 Model: 100026191 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Page: 2 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION

Page: 7 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 9 Internal of EUT Photo 10 Internal of EUT Antenna Page: 8 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Photo 11 Appearance of PCB Photo 12 Appearance of PCB Page: 9 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Photo 13 Appearance of PCB Photo 14 Appearance of PCB

Ref : ACR.233.1.17.SATU.A WALTEK TESTING GROUP (SHENZHEN) CO., LTD. 1/F, BUILDING A, HONGWEI INDUSTRIAL PARK, LIUXIAN 2ND ROAD BAO'AN DISTRICT SHENZHEN (518101), CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 45/15 EPGO280 Calibrated at MVG US 2105 Barrett Park Dr. - Kennesaw, GA 30144 Calibration Date: 07/03/2020 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in MVG USA using the CALISAR / CALIBAIR test bench, for use with a COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.233.1.17.SATU.A Page: 2/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 7/3/2020 Checked by : Jérôme LUC Product Manager 7/3/2020 Approved by : Kim RUTKOWSKI Quality Manager 7/3/2020 Customer Name Distribution : Waltek Testing Group (Shenzhen) Co., Ltd. Issue Date Modifications A 7/3/2020 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.233.1.17.SATU.A Page: 3/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment .................................................................................................... 10 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.233.1.17.SATU.A Page: 4/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 45/15 EPGO280 Product Condition (new / used) New Frequency Range of Probe 0.7 GHz-6GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.193 M Dipole 2: R2=0.188 M Dipole 3: R3=0.198 M A yearly calibration interval is recommended. 2PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – MVG COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.233.1.17.SATU.A Page: 5/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid, with the plastic …

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn Page 1 of 57 TEST REPORT Reference No. .................... : WTX20X11088300W FCC ID ................................ XMF-MID7018 Applicant ........................... : Lightcomm Technology Co., Ltd. Address ............................. : UNIT 1306 13/F ARION COMMERCIAL CENTRE,2-12 QUEEN'S ROAD WEST,SHEUNG WAN HK Product Name ................... : onn 7" Tablet Test Model. ........................ : 100026191 Standards .......................... : FCC Part 2.1093 ANSI / IEEE C95.1 : 2005+A1:2010 ANSI / IEEE C95.3 : 2002(R2008) IEEE 1528 :2013 Date of Receipt sample .... : Nov.20, 2020 Date of Test........................ : Nov.24, 2020 to Dec.29, 2020 Date of Issue ..................... : Dec.31, 2020 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Tested by: Reviewed By: Approved & Authorized By: Hubrey Cai / Project Engineer Lion Cai / RF Manager Silin Chen / Manager Reference No.: WTX20X11088300W Page 2 of 57 Waltek Testing Group (Shenzhen) Co., Ltd. http://www.semtest.com.cn TABLE OF CONTENTS 1. General Information ................................................................................................................................................... 3 1.1 Product Description for Equipment Under Test (EUT) ......................................................................................... 3 1.2 Test Standards .................................................................................................................................................... 5 1.3 Test Methodology ................................................................................................................................................ 5 1.4 Test Facility ......................................................................................................................................................... 5 2. Summary of Test Results .......................................................................................................................................... 6 3. Specific Absorption Rate (SAR) ................................................................................................................................ 7 3.1 Introduction .......................................................................................................................................................... 7 3.2 SAR Definition ..................................................................................................................................................... 7 4. SAR Measurement System ........................................................................................................................................ 8 4.1 The Measurement System .................................................................................................................................. 8 4.2 Probe ................................................................................................................................................................... 8 4.3 Probe Calibration Process ................................................................................................................................. 11 4.4 Phantom ............................................................................................................................................................ 12 4.5 Device Holder .................................................................................................................................................... 12 4.6 Test Equipment List ........................................................................................................................................... 13 5. Tissue Simulating Liquids ....................................................................................................................................... 14 5.1 Composition of Tissue Simulating Liquid ........................................................................................................... 14 5.2 Tissue Dielectric Parameters for Head and Body Phantoms ............................................................................. 15 5.3 Tissue Calibration Result ................................................................................................................................... 16 6. SAR Measurement Evaluation ................................................................................................................................ 17 6.1 Purpose of System Performance Check ............................................................................................................ 17 6.2 System Setup .................................................................................................................................................... 17 6.3 Validation Results .............................................................................................................................................. 19 7. EUT Testing Position ............................................................................................................................................... 20 7.1 EUT Antenna Position ....................................................................................................................................... 20 7.2 EUT Testing Position ..............................................................…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC178074 Page: 1 of 83 TB-RF-074-1.0 FCC Radio Test Report FCC ID: XMF-MID7018 Original Grant Report No. : TB-FCC178074 Applicant : Lightcomm Technology Co., Ltd. Equipment Under Test (EUT) EUT Name : onn 7" Tablet Model No. : 100026191 Series Model No. : MID7018 Brand Name : onn Sample ID : 20201103-05-1-01#& 20201103-05-1-04# Receipt Date : 2020-11-05 Test Date : 2020-11-06 to 2020-12-28 Issue Date : 2020-12-29 Standards : FCC Part 15, Subpart C 15.247 Test Method : ANSI C63.10: 2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC requirements Test/Witness Engineer : Rebeca Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC178074 Page: 2 of 83 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 7 1.4 Description of Support Units .............................................................................................. 7 1.5 Description of Test Mode .................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 9 1.8 Test Facility ......................................................................................................................... 10 2. TEST SUMMARY ..................................................................................................................... 11 3. TEST SOFTWARE ................................................................................................................... 11 4. TEST EQUIPMENT .................................................................................................................. 12 5. CONDUCTED EMISSION TEST ........................................................................................... 13 5.1 Test Standard and Limit .................................................................................................... 13 5.2 Test Setup ........................................................................................................................... 13 5.3 Test Procedure ................................................................................................................... 13 5.4 Deviation From Test Standard ......................................................................................... 14 5.5 EUT Operating Mode ........................................................................................................ 14 5.6 Test Data ............................................................................................................................. 14 6. RADIATED EMISSION TEST ................................................................................................ 15 6.1 Test Standard and Limit .................................................................................................... 15 6.2 Test Setup ........................................................................................................................... 16 6.3 Test Procedure ................................................................................................................... 17 6.4 Deviation From Test Standard ......................................................................................... 17 6.5 EUT Operating Condition ................................................................................................. 17 6.6 Test Data ............................................................................................................................. 17 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 18 7.1 Test Standard and Limit .................................................................................................... 18 7.2 Test Setup ........................................................................................................................... 18 7.3 Test Procedure ................................................................................................................... 18 7.4 Deviation From Test Standard ......................................................................................... 19 7.5 EUT Operating Condition ................................................................................................. 19 7.6 Test Data ............................................................................................................................. 19 8. NUMBER OF HOPPING CHANNEL .................................................................................... 20 8.1 Test Standard and Limit .................................................................................................... 20 8.2 Test Setup .............................................................................................................…

Text truncated - open the document above for the full version.

Page: 10 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Appendix V EUT Test Photographs 15C Test Setup Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz) Page: 11 of 11 FCC ID: XMF-MID7018 TB-RF-074-1.0 Photo of Setup for Conducted Emission Photo of Setup for DFS Test -----END OF REPORT-----
