XMF-MDT9001PDVD and Tablet Combo

PLTDVD9200-B Thanks for choosing our product. This User Manual is designed to guide you through the functions and features of the device. And we reserve the right to change spec. without prior notice as continuous product improvement.To ensure your proper use of the device, please read through the Manual carefully. And the description in this Manual is based on default setting.Important safety and warning guidance to make sure normal function of the device: Warning To reduce the risk of fire or electric shock, do not expose this device in rain or moisture. -Please do not try to dissemble the device by yourself -Please do not place the device near water, fire, dusty, high temperature and humid environment -Please do not drop, or collide and shake the device with force, esp. touch panel. -Please do not clean the device by alcohol, or other chemical detergents, clean the surface only with soft cloth. -Please do not charge the device in high temperature environment such as near oven, electric warmer etc. And do not cover the device or adaptor with quilt, or clothes while charging. -Please use only with supplied AC adaptor. -Please charge the device regularly should the device not to be used for long to keep battery in good condition. -Replace battery only with authorized personnel. -Please handle the device with care, dropping or collision accidentally may lead to device damage or internal data loss. -Please do not use the device when driving or during walking. -Please regularly duplicate your data and files saved in this device. -You're solely responsible for any data loss or damage if due to negligence on above or repair and battery replacement and other individual reasons. -Please do not disconnect while the device is formatting or in data-transmitting. -Always keep away from fire or fire source. Other points to be noted: -This device is with internal memory of 8G, while the programs pre-stored plus Android system already take part of the memory. That's why when you check File Manager from App list and you will notice less internal storage. In order to achieve better performance or to download new programs, please turn off or unload programs used no more to help speeding up demand and make room for new programs. -When CPU is working with high speed, esp. in 3D games or playing back HD video long, the device will get hot and this is normal, while we suggest to cool down for a while. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Attentions Chapter One(overview) Appearance Buttons Homepage information column Text input Connections C a t a l o g 1.1 1.2 1.3 1.4 1.5 1 2 2 3 3 Chapter Two (DVD play mode) Chapter Three (internet) Browser 3.1 2 4 6 Chapter Four ()Application Explorer Downloads 4.1 4.2 5.1 5.2 5.3 5.4 Chapter Six (Rechargeable battery use) Chapter Seven (Specification) 6 7 7 7 8 8 8 10 Chapter Five(System setting) Wireless networks setting Sound setting Display setting Date & Time setting Main Features *9" digital panel of higher resolution *Built-in rechargeable Lithium polymer battery. *Built-in one speaker. *Support playback DVD/VCD/CD/MP3 *Support Android 5.1, Quad core, Arm Cortex-A7 @1.3GHz, wifi: 802.11b/g/n *Built-in internal memory of 8g *Support HDMI, Bluetooth (Tablet mode) *Touch control functions. *Stand on back plate Package DVD player with tablet combo AC power wall adaptor USB cable User manual 1 1 1 1 1 1 DC power car adaptor Mounting straps Earphone Earphone splitter 2 1 1.1 Appearance Chapter OneOverview 1 Volume+ Volume- POWER Open loader MIC HDMI USB RESET TF CARD EARPHONE 1.2 Buttons 2 Power button Volume Press / to adjust volume. Open Long press 2~3 seconds, screen will light up and pictures will show up until the interface page. Shut down Long press , it'll ask if you will turn power off, press OK to shut down. While charging, if the device is off, press , it will show charging status. Standby mode In boot mode, when tapping ,the system will go into standby mode with screen turns black, which can save power. Tap again to go back and light up screen for further operation. Open loader Pull down ,user can open the loader and take in or out the disc. Lock and unlock the screen LOCK You can setup sleep time in the Settings, choose Display. The system will enter into sleep mode automatically and lock the screen to standby mode, if without operating exceeding preset time. UNLOCK Pull down and drag to unlock the screen and enter application interface. 1.3 Connections Earphone jack: To connect external earphone Micro USB jack:…

Text truncated - open the document above for the full version.

Lightcomm Technology Co., Ltd. RM1708-10,17/F,PROSPERITY CENTRE, 25 CHONG YIP STREET,KWUN TONG, KOWLOON, HONG KONG DATE :2015-11-12 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hank Yan of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Lightcomm Technology Co., Ltd. and RM1708-10,17/F,PROSPERITY CENTRE, 25 CHONG YIP STREET,KWUN TONG, KOWLOON, HONG KONG Dated this / Day of 11/12/2015 / Agency agreement expiration date: 11/12/2016 By: Jason Zeng Signature Printed Title: Certification Engineer On behalf of : Lightcomm Technology Co., Ltd. Telephone: 0085221913611

Lightcomm Technology Co., Ltd. RM1708-10,17/F,PROSPERITY CENTRE, 25 CHONG YIP STREET,KWUN TONG, KOWLOON, HONG KONG 2015-11-12 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: XMF-MDT9001 Product Name: PDVD and Tablet Combo Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 11/12/2015 By: Jason Zeng Signature Printed Title: Certification Engineer On behalf of : Lightcomm Technology Co., Ltd. Telephone: 0085221913611

FCC ID: XMF-MDT9001

Label location:

FCC ID: XMF-MDT9001 The device has a standalone transmission. According to KDB 447498 D01 General RF Exposure Guidance v0.5 The 1-g and 10-g SAR test exclusion thresholds for 100MHz to 6GHz at test separation distances≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz power and distance are rounded to the nearest mW and mm before calcuation The result is rounded to one decimal place for comparison Worse case is as below:[2412MHz 7.63dBm(5.79mW) output power] (5.79mW/5mm) ·[√2.412(GHz)]=1.80 <3.0 for 1-g SAR Then SAR evaluation is not required.

Global United Technology Services Co., Ltd. Report No.: GTSE15110204201 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC Report (WIFI) Applicant: Lightcomm Technology Co., Ltd. Address of Applicant: RM1708-10,17/F,PROSPERITY CENTRE, 25 CHONG YIP STREET,KWUN TONG, HONG KONG Equipment Under Test (EUT) Product Name: PDVD and Tablet Combo Model No.: MDT900X, MDT9001, MDT9002, MDT9003, PLTDVD9200-B, PLTDVD9200, SLTDVD9200, PLTDVD9208, SLTDVD9208 FCC ID: XMF-MDT9001 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247:2014 Date of sample receipt: November 04,2015 Date of Test: November 05-11,2015 Date of report issued: November 12,2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE15110204201 Global United Technology Services Co., Ltd. Project No.: GTSE151102042RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone,Xixiang Road, Baoan District, Shenzhen 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 61 2 Version Version No. Date Description 00 November 12,2015 Original Prepared By: Date: November 12,2015 Project Engineer Check By: Date: November 12,2015 Reviewer Report No.: GTSE15110204201 Global United Technology Services Co., Ltd. Project No.: GTSE151102042RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone,Xixiang Road, Baoan District, Shenzhen 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 61 3 Contents Page 1 COVER PAGE ...........................................................................................................................................1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 6 5.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 6 5.5 TEST FACILITY.................................................................................................................................... 7 5.6 TEST LOCATION................................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS................................................................................................................... 10 7.3 CONDUCTED PEAK OUTPUT POWER.................................................................................................. 13 7.4 CHANNEL BANDWIDTH...................................................................................................................... 14 7.5 POWER SPECTRAL DENSITY............................................................................................................. 19 7.6 BAND EDGES.................................................................................................................................... 24 7.6.1 Conducted Emission Method ..................................................................................................... 24 7.6.2 Radiated Emission Method ........................................................................................................27 7.7 SPURIOUS EMISSION.........................…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
