1 134567890267 7.85” Tablet Quick Start Guide For complete Instructions, visit www.nuvision.com TM785A520L NuVision Customer Service Phone: (800) 890-1288 Hours: 8:30am to 5:30pm PST M-F Email: [email protected] Customer Service Full User Manual Available at www.nuvision.com 3 Introduction Thank you for purchasing the NuVision TM785A520L 7.85” Internet tablet with Google Play. It features the latest operating system for Android called Lollipop that offers a bold and beautiful design with 3D graphic support. You can now add a guest account, access your notifications faster, and manage battery life with a new battery saver feature. The tablet utilizes touch technology and includes a high definition IPS wide-view display screen for an immersive personal experience. The quad-core tablet powered by Intel is the perfect companion for accomplishing everyday tasks, playing adventurous games, and enhancing your productivity while on the go. The tablet features 16GB of internal storage, Bluetooth connectivity, a memory card slot for storage of an additional 64GB, a front camera for video chats, and a 2MP camera for taking photos and movies. We have included additional apps for casual gaming, productivity, and trial access to a popular fun and learning app for kids within a parent-protected environment. What You Should Know to Ensure Best Performance: • Charge battery completely before first use. • When Google Play Store downloads updates to apps in the background, the tablets performance may be affected. • Close unused applications. Open apps continue to run in the background so they will affect performance. • Battery usage: Play times will vary depending on you display settings, apps that remain open, and internet usage (streaming over the web and playing HD action games will reduce battery time). 4 TM785A520L Tablet At-a-Glance Tablet Transfer Cable AC Power Adapter (May differ in appearance.) 5 1. Camera (Front) 2. Micro USB 3. Headphone Jack 4. Camera (Back) 5. Power Button 6. Volume Control 7. TF Card Slot 8. Microphone 9. Speakers 6 Home Screen At-a-Glance 1. Connection/Activity 2. Google Search Box 3. Google Audio Search 4. Status Bar 5. Previous Page 6. App 7. Home 8. Open Apps 9. Options 10. Take Screenshot 11. Volume 12. App Tray 7 Starting Your Tablet 1. Press and hold the Power button for 3 seconds. (If your tablet does not turn on, or instructs you to “Connect your charger”, connect the AC adapter and charge the unit.) 2. At the Start-up screen, slide your finger up to unlock. 3. Once you’ve arrived at the Home screen, you can begin using your tablet. It is recommended to fully charge the tablet before first use. To charge the tablet, plug the 1) USB cable into the AC adapter, and 2) attach the other end to the DC input on the tablet. 3) Plug the AC adapter into a wall outlet. If the tablet is on, the battery icon will pulse, showing that it is being charged. It is fully charged when an icon of a full battery is displayed on the screen. A complete battery charge may take up to 5 hours. It is normal for the tablet to be warm to the touch as it is being charged, used while plugged in to AC power, or when enclosed in a case. Battery life will vary dependent on usage. 1 2 3 8 Charging Your Tablet 9 Touching and Typing Type goes in field Need Information Type goes in field Need Information Type goes in field Need Information Type goes in field Need Information Type goes in field Need Information Type goes in field Need Information To select an item on the screen, simply tap it once with your fingertip. Some items may require you to “double-tap”. To type into an text field (i.e., when inputting your name, or a web address), tap the text field. The on-screen keyboard will appear, and allow you to type the information you wish to enter. Touch and Hold: Keep your finger on an on-screen item until it glows or activates an alternate menu. Drag: Move an App or object by touching and holding the image, then sliding it to the destination. Slide: When there are extra “screens” to the side, slide one or more fingers from one side to another. 10 Connecting to the Internet In order to connect to the internet, you will need the following: • A wireless router or an access point with a broadband internet connection. • The name of your network (SSID), as well as the password or other credentials, if your network is secure. The wireless router must support WiFi 802.11b/g/n connections. Go to SETTINGS > WIRELESS & NETWORKS > WiFi Turn on the WiFi setting from OFF to ON by sliding the switch to the right. The Tablet will scan for available WiFi networks within range. Secured networks will require a password. Once you have successfully entered your information the tablet will remember your settings. Distance may vary or WiFi Available Here + Network Name/SSID Password Wireless Router Wireless Router 11 Apps that come with your Tablet The App Tray is a convenient way to access all of your applications (apps). After tapping the icon, the screen will open to the Launcher Tab page. At the top, you will find options to see all apps (applications) or widgets. Maxthon provides you with world’s fastest web browsers available for Android based devices. Google Play Store Google Play™ is music, books, magazines, movies, TV shows, and apps, available anywhere you go. Wild Tangent games. Play thousands of casual, family and adventure games. Pro Pack Comes with 10GB of free cloud storage and triple encryption. Multiple bundle offers are available to increase productivity and capabilities with innovative app and cloud solutions for you and family. Gmail Users If you have a Gmail Account, we recommend using the Gmail App. Insure that you are online. Kido’z turns your tablet into a kid friendly device that is both educational and fun. Learning has never been easier. Password protected child lock and you can set time limits. Swiftkey is an award-winning keyboard application that delivers better next- word prediction, smarter aut…

Text truncated - open the document above for the full version.

Differences Declaration To whom concern, We company Lightcomm Technology Co., Ltd. hereby declares: The product model(s) TM785A520L, MID7803-IA, MID7803-IB is identical in the same PCB layout, interior structure and electrical circuits with the model MID7803-I which tested in Global United Technology Services Co., Ltd., the only differences are the model name for commercial purpose. Authorized signature: Position: Certification Engineer Date: 2015-4-28

20.3 mm 14 m m 34 m m 53.00 m m 35.00 mm 4.07 m m 45X11

FCC ID: XMF-MID7803 The device has a standalone transmission. According to KDB 447498 section 4.3.1, the 1-g SAR test exclusion thresholds at test separation distances≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHz)] ≤ 3.0 The maximum tune-up limit power is 4.40dBm (2.75mW) @ 2.402GHz For the head and body SAR, use 5mm as the conservative minimum test separation distance, [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHz)] =0.852≤ 3.0 So standalone SAR measurements are not required for both head and body.

Global United Technology Services Co., Ltd. Report No.: GTSE15040055002 1Cover Page FCC Report(Bluetooth) Applicant: Lightcomm Technology Co., Ltd. Address of Applicant: RM1708-10,17/F,PROSPERITY CENTRE, 25 CHONG YIP STREET,KWUN TONG, KOWLOON, HONG KONG Equipment Under Test (EUT) Product Name: MID Model No.: MID7803-I, TM785A520L, MID7803-IA, MID7803-IB FCC ID: XMF-MID7803 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247:2014 Date of sample receipt: April 22, 2015 Date of Test: April 23-24, 2015 Date of report issued: April 27, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. RobinsonLLLLo Report No.: GTSE15040055002 2Version Version No.DateDescription 00April 27, 2015Original Prepared By: Date: April 27, 2015 Project Engineer Check By:Date: April 27, 2015 Reviewer Global United Technology Services Co., Ltd.Project No.: GTSE150400550RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone,Xixiang Road, Baoan District, Shenzhen 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960Page 2 of 44 Report No.: GTSE15040055002 3Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENTINFORMATION.......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 7 5.4 TEST FACILITY.................................................................................................................................... 7 5.5 TEST LOCATION.................................................................................................................................. 7 5.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 7 5.7 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS................................................................................................................... 10 7.3 CONDUCTEDPEAKOUTPUT POWER.................................................................................................. 13 7.4 20DBEMISSION BANDWIDTH............................................................................................................. 17 7.5 CARRIER FREQUENCIES SEPARATION................................................................................................ 21 7.6 HOPPING CHANNEL NUMBER............................................................................................................. 25 7.7 DWELL TIME..................................................................................................................................... 26 7.8 PSEUDORANDOM FREQUENCY HOPPING SEQUENCE.......................................................................... 28 7.9 BAND EDGE...................................................................................................................................... 29 7.9.1 Conducted Emission Method ..................................................................................................... 29 7.9.2 Radiated Emission Method ........................................................................................................33 7.1…
