TM9701W510L Quick Start Guide For complete Instructions, visit www.nuvision.com 3 Introduction Thank you for purchasing the NuVision TM970W510L 9.7” Windows 8.1 PC tablet. It features a vibrant 2048 x 1536 IPS display and utilizes touch technology to make your personal computing and rich media content experience fast, seamless and immersive. The tablet is the perfect companion for accomplishing everyday tasks, enhancing productivity on the go, playing video games, Xbox Music and Video, taking photos, and surfing the internet with Internet Explorer. When it’s time to work, the TM970W510L comes with Microsoft Office 365 Personal which includes Word, Excel, Outlook, PowerPoint, OneNote, Access, and Publisher. You’ll find many more features including WiFi, Bluetooth connectivity, a memory card slot for additional storage, dual cameras, and internal storage of 32GB and 2GB RAM. With a sleek design and bright high-definition IPS touch screen display. Using finger gestures you can swipe down from the top side, up from the bottom edge, or inward from the left and right edges of the display to navigate the Tablet. The following information will help you get the most out of your tablet. NuVision Customer Service Phone: (800) 890-1288 Hours: 8:30am to 5:30pm PST M-F Email: [email protected] Customer Service For expedited customer support, please visit www.nuvision.com 10 10. Windows Key: Press the Windows Key to return to the Start Menu. 89 Starting your Tablet Power On/Off/Standby Mode ON: Press and hold the side POWER button on the side for about 3 seconds until the logo screen appears, then release. OFF: Press and hold the side POWER button until the POWER OFF window appears, then slide down to turn off. STANDBY MODE: While the Tablet is on, press the side POWER button quickly to power off the display only. The Tablet will enter a sleep mode which minimizes some of the battery functions (turn off completely to avoid unnecessary battery drainage). Press the POWER button quickly to wake from sleep mode so that you can use the Tablet immediately. NOTE: Another way to access Power, Shut Down, or Update and Restart is to swipe left from the right edge of the screen and tap SETTINGS. First time Setup Setup runs the first time you power on your Tablet. During setup you’ll choose a language, color scheme, and name, all of which can be change at a later time. User and Password Setup Swipe inward at left edge of display to call up the Charm Menu. When a password is required, you can choose one to sign in. Here’s how: 1. Swipe inward from the left edge of the display to call up the Charm Menu. Open the SETTINGS charm, then tap or click PC settings > Accounts > Sign-in options. 2. Under Password policy, choose an item from the list: Microsoft account: Choose a time frame or to Always require a password. Local account: Choose a time frame, Always require a password, or Never require a password. NOTE: Password policy setting may not be available if you’ve added a work email account to the Mail app. 1415 Common Finger Gestures Swipe to right to Access Open Apps Swipe to Left for Search, Share, or Settings Swipe the left edge: Switch between open apps by swiping inward the left edge of the screen. Each time you swipe you will switch to another app. To switch to a specific app, swipe inward from the left edge and with your finger still on the touchscreen, move it back towards the left edge. Then tap the desired app. Swipe the right side edge: Swipe to search, share, or access PC settings. Pinch to Zoom: In some apps (such as Maps, Browser, and Gallery), you can zoom in and out by placing two fingers on the screen at once, and pinching them together (to zoom out) or spread them apart (to zoom in.) Swipe downward Swipe down from top edge and access app commands. Swipe side to side Swipe finger side to side to move an image. Swipe the bottom edge Swipe upward from the bottom edge to choose an item on the bar of app commands. Pinch & ZoomEnlarge 17 View Apps Side by Side To display two apps side-by-side, swipe an open app inward from the left edge, drag it and hold. Release to one side. A dual screen interface will appear to place a second application. To change one of the apps, go to Start Menu or the Apps view and tap on an app. It will appear on top of the first two apps. Tap the left of right edge of the screen. To undo the dual screen, tap the middle partition line and drag to the right or left edge. 16 Apps Menu To display the menu of all available apps, tap and drag your finger upward from anywhere below the Start Menu tiles until you see the Apps Menu. Type an app name or scroll to view desired apps. To add one to the Start screen, tap and hold the desired app for 2 seconds. A checkmark will appear. To unpin from Start or uninstall, use the same process. To return to the Start Menu and dismiss the Apps Menu, tap and drag your finger downward from the top of the screen. To Close Desktop Apps Apps can be closed in two ways. You can close the app when finished, or you can begin using a second app and the first app will automatically close after a period of time of non-use. To completely close an App, drag it to the bottom of the screen with your finger, and hold it there until the app flips over. View open apps and services in Task Manager (Type Task Manager into Search to find this app). NOTE: Having too many apps open at the same time will reduce the overall performance of the tablet and drain battery power more rapidly. 19 Charm Menu Column - Search, Share, Connect, Settings From the right edge of the screen, swipe your finger inward to bring up the Charm Menu column. 18 Connecting to the Internet This Tablet utilizes WiFi 802.11b/g/n networks to connect with the internet so that you may access the world wide web, send emails, and download apps. (WiFi distance may be affected by your surrounding environment and WiFi router). In order to connect to the internet, you will need the following: Connect to a WiFi Ne…

Text truncated - open the document above for the full version.

Lightcomm Technology Co., Ltd. RM1708-10,17/F,PROSPERITY CENTRE, 25 CHONG YIP STREET,KWUN TONG, KOWLOON, HONG KONG DATE :2015-5-13 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hank Yan of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Lightcomm Technology Co., Ltd. and RM1708-10,17/F,PROSPERITY CENTRE, 25 CHONG YIP STREET,KWUN TONG, KOWLOON, HONG KONG Dated this / Day of 5/13/2015 / Agency agreement expiration date: 5/13/2016 By: Jason Zeng Signature Printed Title: Certification Engineer On behalf of : Lightcomm Technology Co., Ltd. Telephone: 0085221913611

Differences Declaration To whom concern, We company Lightcomm Technology Co., Ltd. hereby declares: The product model(s) TM970W510L is identical in the same PCB layout, interior structure and electrical circuits with the model MID9701-IB which tested in Global United Technology Services Co., Ltd., the only differences are the model name for commercial purpose. Authorized signature: Position: Certification Engineer Date: 2015-5-13

Date: 5/13/2015 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: XMF-MID9701 To Whom It May Concern: We, Lightcomm Technology Co., Ltd., are applying FCC DOC for product MID which model no. are MID9701-IB, TM970W510L. the FCC DOC is doing at proper FCC authorized and recognized lab, and FCC DOC will be issued soon. If you have any question or concerns, pls. contact us. Sincerely, By: Jason Zeng Signature Printed Title: Certification Engineer On behalf of : Lightcomm Technology Co., Ltd. Telephone: 0085221913611 MRA lab, and FCC DOC will be issued soon.

Lightcomm Technology Co., Ltd. RM1708-10,17/F,PROSPERITY CENTRE, 25 CHONG YIP STREET,KWUN TONG, KOWLOON, HONG KONG 2015-5-13 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: XMF-MID9701 Product Name: MID Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 5/13/2015 By: Jason Zeng Signature Printed Title: Certification Engineer On behalf of : Lightcomm Technology Co., Ltd. Telephone: 0085221913611

FCC ID: XMF-MID9701 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation          [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,     !-" #$%  &  ! -g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, ---10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---3m So pt = (EXd) 2 /30 x gt Field strength = 95.79dBuV/m @3m Ant gain =2.5dBi, s o Ant numeric gain= 1.78 30x1.0 }x1000 mW = 0.636mW So (0.636 mW /5mm)x '402 = 0.197<3 Then SAR evaluation is not required So pt={ [10 (95.79) /10 6 x 3] 2 / 30x1.78 }x1000 mW = 0.636mW
