XNNMD120AC2.4GHz ZigBee Wireless Module

   V1.01 1 Benefits
Microminiature module solutions
Ready to use in products
Minimizes product development time
No RF test required for systems
Compliant with FCC part 15 rules, IC Canada Features: Module
2.4GHz IEEE802.15.4 & ZigBee PRO Compatible
2.7 -3.6V for SOC
Sleep Current ( with Active Sleep Timer ) 2.6μA
Receiver Sensitivity -98dBm
TX Power +20dBm
PIFA Antenna Gain +3.5dBi
TX Current 130mA
RX Current 30mA
Dimension
30 *18*3.5mm
Weight
2.5g Features: Microcontroller
32-Bit RISC CPU,up to 32MIPs with low power
128KB RAM, 128KB ROM
4Mbit serial flash for program code and data
On chip OTP efuse
JTAG debug interface
4-input 12-bit ADC, 2 12-Bit DACs, 2 Comparators
3 Application Timer / Counters, 3 System Timers
2 UARTs (One for In-System Debug)
SPI Port with 5 Selects
2-Wire Serial Interface
4-wire digtal audio interface
Watchdog timer
19 GPIO Temperature Range -40°C to +85°C Humidity 10 to 95% RH IEEE802.15.4 / ZigBee PIFA High Power Module Family Overview This MD-120AC-5148A ZigBee PIFA Module is a surface mount module with 100mW output power that enables users to implement IEEE802.15.4 or ZigBee PRO networking applications with minimum time to market and at the lowest cost. They remove the need for expensive and lengthy development of custom RF board designs and test suites. The modules provide a comprehensive solution with high radio performance and all RF components included. All that is required to develop and manufacture wireless control or sensing products is to connect a power supply and peripherals such as switches, actuators and sensors, considerably simplifying product development. Applications
Robust and secure low power wireless applications
ZigBee PRO networks
Home and commercial building automation
Home networks
Toys and gaming peripherals
Industrial systems
Telemetry and utilities (e.g. AMR)
   V1.01 2 Revised History Date Revision Description 2012/03/20 1.0 1 st Released Table of Contents 1. Introduction...................................................................................................... 3 1.1 Key Features ......................................................................................... 3 1.1.1 Module........................................................................................... 3 1.1.2 Microcontroller ............................................................................. 3 1.2 Applications .......................................................................................... 3 2. Specifications .................................................................................................... 4 3. FCC Statement ................................................................................................. 6 4. IC Statement..................................................................................................... 8 5. Contact Information ......................................................................................... 9
   V1.01 3 1. Introduction This MD-120AC-5148A ZigBee PIFA Module built is a surface mount module with 100mW output power that enables users to implement IEEE802.15.4 or ZigBee PRO networking applications with minimum time to market and at the lowest cost. They remove the need for expensive and lengthy development of custom RF board designs and test suites. The modules provide a comprehensive solution with high radio performance and all RF components included. All that is required to develop and manufacture wireless control or sensing products is to connect a power supply and peripherals such as switches, actuators and sensors, considerably simplifying product development. 1.1 Key Features 1.1.1 Module

 !" # $ %  & '
'    ( & &  )  * +  , -.   /  '    0   & 1  # 2 -
  .   /  & ' ) 3    /   4 !5 6
07  + & 8  6
 9 --)   ) )     ) 8 "  6
07 ( & &  )   "  -
 7 ( & &  )  "  -
:    ) 3   )
" ; ; "
<  ,
    1.1.2 Microcontroller
"!   '=
 > -? @   >  ?
! )  (   !   -: @  !  : -3 @     &    & 3
"-    .     ) 0   & A ( )   & 3 @ "'4 3    0   & 3
= - 03
'  &  +  ,  '   .  3
!< &  ' &     )   & %  .
!< &  6      ( 6    )   & %  .
5     1.2 Applications
Robust and secure low power wireless applications
ZigBee PRO networks
Home and commercial building automation
Home networks
Toys and gaming peripherals
Industrial systems
Telemetry and utilities (e.g. AMR)
   V1.01 4 2. Specifications VDD=3.0V @ +25
C Typical DC Characteristics Notes Deep Sleep Current 1.3uA Sleep Current 2.6uA With active sleep timer Radio Transmit Current 110mA CPU in doze, radio transmitting Radio Receive Current 30mA CPU in doze, radio receiving Centre Frequency Accuracy ±20ppm Additional ±20ppm allowance for temperature and ageing Typical RF Characteristics Notes Receive Sensitivity -98dBm Nominal for 1% PER, as per 802.15.4 section 6.5.3.3 Maximum Transmit Power (without PIFA Antenna) +18.5dBm Total Transmit Current 110mA Total Receive Current 30mA Maximum Input Signal -5dBm For 1% PER, measured as sensitivity RSSI Range -105 to -20 dBm RF Port Impedance -PIFA Antenna 50 ohm 2.4 - 2.5GHz VSWR (Max) 2:1 2.4 - 2.5GHz Peripherals Notes Master SPI Port 3 selects 250kHz - 16MHz Slave SPI Port
250kHz - 8MHz Two UARTs
16550 compatible TwoWire Serial I/F (Compatible with SMbus & I 2 C)
Up to 400kHz Two Programmable Timer/Counters with Capture/Compare Facility, Tick Timer
16MHz clock Two Programmable …
