XQ9R50200AudioRock 5

2 Tech Support: 1-800-KLIPSCH The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. CAUTION: Risk of Electrical Shock - Do not submerge the product in water CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No user servicable parts – refer servicing to qualified service personnel only. WARNING: To reduce the risk of fire or electric shock, do not submerge this product in water The AudioRock speaker uses a 12 volt Lithium Ion Battery for operation. Please review the following safety instructions before use: Li Ion Battery Safety Instructions: Misuse can result in the batteries short-circuiting, the insulator melting and damage to the safety valves or safety mechanisms, leading to leakage, heat generation, or rupturing. Please observe the following precautions when using batteries. • Do not dispose in fire or expose to high temperature (140 o F/60 o C) • Do not under any circumstances insert the batteries with the positive and negative poles reversed. • If the connection with the charger does not operate correctly, do not force the battery in, but instead check the direction of the positive and negative poles. • Do not charge with chargers not specified for this product • Do not short the positive terminal and the negative terminal with metals such as wire, coins, etc. Also, do not store or carry the batteries with metal necklaces, etc. • Do not disassemble or modify the battery. • Don not puncture the battery • Do not directly solder the battery. • Do not use the battery if it shows signs of leakage, a change of color or shape or any other changes in appearance. • Do not wet the battery or place it in water or sea water. This may lead to the battery generating heat or rusting. • Store the battery out of reach of small children. • When not using the battery, or not using the device for a prolonged period, remove the battery from the device and store it in a dry place between the temperatures of -20 o C and +35 o C. This prevents decreased battery performance and service life • The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. Tech Support: 1-800-KLIPSCH 3 IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. Keep these instructions. Heed all Warnings. Follow all instructions. 2. Do not use this apparatus in water. The apparatus can be exposed to rain, snow or any weather element without risk of injury or damage. Do not submerge in water or other liquids. The product is water resistant not water proof. 3. Clean only with a wet rag or light spray of water from garden hose. Do not use high pressure hoses or washers to clean the product. 4. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 5. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 6. Only use approved batteries in this product in accordance with the manufacturers instructions 7. Only use attachments/accessories specified by the manufacturer. 8. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 9. The weight of this device may cause instability of a free-standing table or stand near a pool, pond or other standing water. Insure that the surface or object that the product is placed on is stable and cannot be tipped over causing the product to be immearsed in water. 11. FOR USE WHERE EXPOSED TO THE WEATHER PAS EXPOSER AUX INTEMPÉRIES Declaration of Conformity Trade Name: LightSpeaker Model: R 5.2.0 Responsible Party: Kadence Inc. Address: PO Box 2359, Thompson Falls, MT 59873 Telephone Number: 877-81AUDIO This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling. 4 Tech Support: 1-800-KLIPSCH Congratulations Thank you for choosing the wireless, portable AudioRock TM from Klipsch Speakers. With proper installation and operation, you will enjoy years of trouble-free use. Klipsch Speakers offers numerous loudspeakers for use inside or outside your home. To see the complete Klipsch Speakers product assortment, visit us on the Internet at: www. Klipsch.com. Tech Support: 1-800-KLIPSCH 5 Table of Contents AudioRock TM Overview.........................................................................6 What is in this box................................................................................8 Installation Considerations................................................................9 Selecting Locations...............................................................................9…

Text truncated - open the document above for the full version.

FCC ID: XQ9R50200 FRN: 0019101443. Date: 5/30/10 To whom it may concern: We, the undersigned, hereby authorize NS Technology Co., Ltd. NS to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by NS within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Sam M. Romano Jr. Design Consultant Kadence Designs LLC Tel: 1- 877-812-8346 Fax: 1- 877-812-8346 Website: www.lightspeaker.net E-Mail: [email protected]

. Date: 5/30/10 Federal Communications Commission Authorization and Evaluation Division FCC ID: XQ9R50200 FRN: 0019101443 Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Sam M. Romano Jr. Design Consultant Kadence Designs LLC Tel: 1- 877-812-8346 Fax: 1- 877-812-8346 Website: www.lightspeaker.net E-Mail: [email protected] E-Mail: [email protected]

Label Location

CONFORMS TO UL STD. 1993 CERTIFIED TO CAN/CSA STD. E968 CONFORMS TO ANSI/UL STD. 60065 CERTIFIED TO CAN/CSA STD. C22.2 No. 60065 CAUTION RISK OF ELECTRICAL SHOCK DO NOT OPEN CAUTION: RISK OF ELECTRICAL SHOCK DO NOT IMMERSE IN WATER ATTENTION: RISQUE DE CHOC ÉLECTRIQUE NE PAS PLONGER DANS L'EAU Model R5.2.0 Designed in USA Manufactured in China AUDIOROCK INPUT: 11.1V 2.0A Rating Power: 8Wx2 IC: 8684A-R50200 FCC ID: XQ9R50200 THIS DEVICE COMPLIES WITH FCC RULES PART 15 . Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received including that may cause undesired operation. CAUTION: USE SPECIFIED BATTERY ONLY ATTENTION: UTILISEZ UNIQUEMENT LA PILE SPÉCIFIÉE 49 mm Label Dimensions 70 mm Rock Rear Cover Inside Label Date: 6/9/2010 Revision: 6 Risque D’ÉLECTROCUTION MISE EN GARDE ne pas ouvrir 3193575 CELEWAVE ELECTRONICS CO.,LTD

Antenna location Antenna location

NS Technology Co., Ltd. Report No. NSE-F10064933 Page 1 of 4 FCC ID:XQ9R50200 FCC TEST REPORT for KADENCE DESIGNS LLC AudioRock 5 Model Number: R5.2.0 Prepared for : KADENCE DESIGNS LLC Address : P.O.Box 2359,Thompson Falls,MT 59873 Prepared By : NS Technology Co., Ltd. Address : Chenwu Industrial Zone, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-85935656 Fax: +86-769-85991080 Report Number : NSE-F10064933 Date of Test : May 23, 2010 Date of Report : May 26, 2010 Te s t L a b Cert 2951.01 NS Technology Co., Ltd. Report No. NSE-F10064933 Page 2 of 4 FCC ID:XQ9R50200 NS Technology Co., Ltd. Applicant: Address: KADENCE DESIGNS LLC P.O.Box 2359,Thompson Falls,MT 59873 Manufacturer: Address: Celewave Electronics(shenzhen) Co.,Ltd No 1-2 building,No 2 Industry District, Shang Heng lang Huaxing Road, Dalang Street,Baoan District, Shenzhen City,China E.U.T: AudioRock 5 Model Number: R5.2.0 Report Number: NSE- F10064933 Tr a de Name : Lightspeaker Operating Frequency: 2412～2464MHz Date of Receipt: Apr.17, 2010 Date of Test: May 23, 2010 Test Specification: 47 CFR FCC Part 2 Subpart J, section 2.1091 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: May 26, 2010 Tested by: Reviewed by: Approved by: Jade/ Engineer Iceman Hu / Supervisor Steven Lee / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products ,It is not permitted to be duplicated in extracts without written approval of NS Technology Co., Ltd. NS Technology Co., Ltd. Report No. NSE-F10064933 Page 3 of 4 FCC ID:XQ9R50200 Maximum Permissible Exposure 1 Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density(S) (mW/cm 2 ) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100000 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density(S) (mW/cm2) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100000 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density 2 MPE Calculation Method E (V/m) = (30*P*G) 0.5 /d Power Density: Pd (W/m 2 ) = E 2 /377 E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = (30*P*G) / (377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. NS Technology Co., Ltd. Report No. NSE -F10064933 Page 4 of 4 FCC ID:XQ9R50200 3 Calculated Result and Limit Mode CH Output power (dBm) Output power (mW) Antenna Gain (dBi) MPE estimation result (mW/cm²) at 20cm Limit of MPE Estimation (mW/cm²) Test result CH1:2412MHz 15.84 38.37*10 -3 5.5 0.0564 1 Compiles CH2:2438MHz 13.71 23.50*10 -3 5.5 0.0346 1 Compiles Antenna1 CH3:2464MHz 13.91 24.60*10 -3 5.5 0.0362 1 Compiles CH1:2412MHz 14.33 27.10*10 -3 5.5 0.0399 1 Compiles CH2:2438MHz 11.35 13.65*10 -3 5.5 0.0201 1 Compiles Antenna2 CH3:2464MHz 10.74 11.86*10 -3 5.5 0.0175 1 Compiles

FCC ID: XQ9R50200 NS Technology Co., Ltd. Report No. NSE-F10064932 Page 1 of 64 FCC TEST REPORT for Kadence Designs LLC AudioRock 5 Model Number: R5.2.0 Prepared for : Kadence Designs LLC Address : P.O.Box 2359,Thompson Falls,MT 59873 Prepared By : NS Technology Co., Ltd. Address : Chenwu Industrial Zone, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-85935656 Fax: +86-769-85991080 Report Number : NSE-F10064932 Date of Test : May 12~May 23, 2010 Date of Report : May 26, 2010 Test Lab Cert 2951.01 FCC ID: XQ9R50200 NS Technology Co., Ltd. Report No. NSE-F10064932 Page 2 of 64 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION ......................................................................... 4 1.1. Product Function ......................................................................................................................... 4 1.2. Description of Device (EUT) ...................................................................................................... 4 1.3. Difference between Model Numbers .......................................................................................... 4 1.4. Independent Operation Modes ....................................................................................................4 2. TEST SITES.......................................................................................................................... 5 2.1. Test Facilities .............................................................................................................................. 5 2.2. List of Test and Measurement Instruments ................................................................................. 6 3. TEST SET-UP AND OPERATION MODES .................................................................... 7 3.1. Principle of Configuration Selection...........................................................................................7 3.2. Block Diagram of Test Set-up..................................................................................................... 7 3.3. Test Operation Mode and Test Software..................................................................................... 7 3.4. Special Accessories and Auxiliary Equipment ........................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance......................................................................... 7 4. TEST SUMMARY................................................................................................................ 8 5. EMISSION TEST RESULTS.............................................................................................. 9 5.1. Radiated Emission....................................................................................................................... 9 5.2. 6dB Bandwidth ......................................................................................................................... 41 5.3. Power Spectral Density Test .....................................................................................................43 5.4. Output Power Test..................................................................................................................... 45 5.5. Band Edge ................................................................................................................................. 47 5.6. ANTENNA REQUIREMENT .................................................................................................. 64 FCC ID: XQ9R50200 NS Technology Co., Ltd. Report No. NSE-F10064932 Page 3 of 64 NS Technology Co., Ltd. Applicant: Address: Kadence Designs LLC P.O.Box 2359,Thompson Falls,MT 59873 Manufacturer: Address: Celewave Electronics(shenzhen) Co.,Ltd No 1-2 building,No 2 Industry District, Shang Heng lang Huaxing Road, Dalang Street,Baoan District, Shenzhen City,China E.U.T: AudioRock 5 Model Number: R5.2.0 Trade Name: Lightspeaker Operating Frequency: 2412~2464MHz Date of Receipt: Apr.17, 2010 Date of Test: May 12~May 25, 2010 Test Specification: FCC Part15C :2009 ANSI C63.4:2003 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: May 26, 2010 Tested by: Reviewed by: Approved by: Jade/ Engineer Iceman Hu / Supervisor Steven Lee / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products ,It is not permitted to be duplicated in extracts without written approval of NS Technology Co., Ltd. FCC ID: XQ9R50200 NS Technology Co., Ltd. Report No. NSE-F10064932 Page 4 of 64 1. GENERAL PRODUCT INFORMATION 1.1. Product Function Details please refer to Technical Construction Form and User Manual. 1.2. Description of Device (EUT) E.U.T. : AudioRock 5 Model No. : R5.2.0 Operating Frequency : 2412~2464MHz Number of Channels : 3 Channels Type of Modulation : DSSS(QPSK) Antenna Type : Integral Antenna Gain : 5.5dBi System Input Voltage : DC 11.1V Temperature Range(Operating) : 0 ~+ 40°C 1.3. Difference between Model Numbers 1.4. Independent Operation Modes The basic operation modes are: 1.4.1 TX CH1 (2412MHz) 1.4.2. TX CH2 (2438MHz) 1.4.3. TX CH3 (2464MHz) FCC ID: XQ9R50200 NS Technology Co., Ltd. Report No. NSE-F10064932 Page 5 of 64 2. TEST SITES 2.1. Test Facilities EMC Lab : Accredited by TUV Rheinland, Germany Date of registration: July 28, 2003 Accredited by CNAS, China Registration No.: L1744 Date of registration: November 25, 2004 Accredited by Intertek ETL SEMKO Registration No.: TMP-013 Date of registration: June 11, 2005 Accredited by TUV/PS, Hong Kong Date of registration: December 1, 2005 Accredited by ATCB, USA Date of registration: August 3, 2006 Accredited by VCCI, Japan Member No.:2115 Registration No.: R-2527, R-3012 & C-2770 Date of registration: March 23, 2007 Accredited by …

Text truncated - open the document above for the full version.

Set-up for radiated emission test (30MHz~1GHz) Set-up for output power test Set-up for 6dB bandwith test Set-up for radiated emission test (Above 1GHz)
