XQ9W60200Subwoofer W6.2.0

1 Tech Support: 1-800-268-1172 OWNER’S MANUAL and installation instructions State-of-the-Art Wireless SubWoofer Installs in 5 minutes or less! NOTE: This SubWoofer can only be used with the e² wireless LightSpeaker ® transmitter. It cannot be used or operated without the LightSpeaker ® transmitter. e2 Sub Manual English.indd 110-07-28 11:36 AM 2 Tech Support: 1-800-268-1172 EU Compliance Information Eligible to bear the CE mark, Conforms to European Union Low Voltage Directive 73/23/EEC and 2006/95/EC; Conforms to European Union EMC Directives 89/336/EEC and 2004/108/EC. WEEE Notice Note: This mark applies only to countries within the European Union (EU) and Norway. This application is labeled in accordance with European Directive 2002/96/EC concerning waste electrical and electronic equipment (WEEE). This label indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. The lightning ’ash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of suf–cient magnitude to constitute a risk of electrical shock to persons. WARNING: To reduce the risk of –re or electrical shock, do not expose this apparatus to rain or moisture. WARNING: No naked ’ame sources – such as candles – should be placed on the product. WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all servicing to quali–ed service personnel. Place the equipment near a main power supply outlet and make sure that you can easily access the power breaker switch. WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the back panel or included power supply of the product. Operation from other voltages other than those indicated may cause irreversible damage to the product and void the product’s warranty. The use of AC Plug Adapters is cautioned because it can allow the product to be plugged into voltages in which the product was not designed to operate. If the product is equipped with a detachable power cord, use only the type provided with your product or by your local distributor and/or retailer. If you are unsure of the correct operational voltage, please contact your local distributor and/or retailer. AMPLIFIER REQUIREMENTS Due to the high output levels these speakers are capable of reproducing, exercise caution with the volume control. Excessive volume over long periods of time can permanently damage your hearing. Overdriving your ampli–er could also damage your speakers. Check with your dealer to make sure your particular ampli–er is best suited to your application. We want you listening for a lifetime. CARE AND CLEANING Your speakers have a durable –nish that should only require dry dusting. Avoid use of abrasive or solvent-based cleaners and harsh detergents. The brush attachment of your vacuum or a damp cloth should remove any dust from your speaker grilles. The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. The lightening flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons. WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus to rain or moisture. WARNING No naked flame sources - such as candles - should be placed on the product. WARNING - Do not open! Risk of electrical shock voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all servicing to qualified service personnel. Place the equipment near a main power supply outlet and make sure that you can easily access the power breaker switch. WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the back panel or included power supply of the product. Operation from other voltages other than those indicated may cause irreversible damage to the product and void the product’s warranty. The use of AC Plug Adapters is cautioned because it can allow the product to be plugged with a detachable power cord, use only the type provided with your product or by your local distributor and/or retailer. If you are unsure of the correct operational voltage, please contact your local distributor and/or retailer. AMPLIFIER REQUIREMENTS Due to the high output levels these speakers are capable of reproducing, exercise caution with the volume control. Excessive volume over long periods of time can permanently damage your hearing. Overdriving your amplifier could also damage your speakers. Check with your dealer to make sure your particular amplifier is best suited to your application. We want you listening for a lifetime. CARE AND CLEANING Your speakers have a durable finish that should only require dry dusting. Avoid use of abrasive or solvent-based cleaners and harsh detergents. The brush attachment of your vacuum or a damp cloth should remove any dust from your speaker grilles. EU Compliance Information Eligible to bear the CE mark, Conforms to European Union Low Voltage Directive 73/23/EEC and 2006/95/EC; Conforms to European Union EMC Directive 89/336/EEC and 2004/108/EC. WEEE Notice Note: This mark applies only to countries within the European Union (EU) and Norway. This application is labeled in accordance with European Directive 2002/96EC concerning waste electrical and electronic equipment (WEEE…

Text truncated - open the document above for the full version.

Tech Support: 1-800-KLIPSCH 1 OWNER’S MANUAL and installation instructions State-of-the-Art Wireless SubWoofer Installs in 5 minutes or less! NOTE: This SubWoofer can only be used with the Klipsch wireless LightSpeaker ® transmitter. It cannot be used or operated without the LightSpeaker ® transmitter. 2 Tech Support: 1-800-KLIPSCH EU Compliance Information Eligible to bear the CE mark, Conforms to European Union Low Voltage Directive 73/23/EEC and 2006/95/EC; Conforms to European Union EMC Directives 89/336/EEC and 2004/108/EC. WEEE Notice Note: This mark applies only to countries within the European Union (EU) and Norway. This application is labeled in accordance with European Directive 2002/96/EC concerning waste electrical and electronic equipment (WEEE). This label indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. The lightning ash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufcient magnitude to constitute a risk of electrical shock to persons. WARNING: T o reduce the risk of re or electrical shock, do not expose this apparatus to rain or moisture. WARNING: No naked ame sources – such as candles – should be placed on the product. WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all servicing to qualied service personnel. Place the equipment near a main power supply outlet and make sure that you can easily access the power breaker switch. WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the back panel or included power supply of the product. Operation from other voltages other than those indicated may cause irreversible damage to the product and void the product’s warranty. The use of AC Plug Adapters is cautioned because it can allow the product to be plugged into voltages in which the product was not designed to operate. If the product is equipped with a detachable power cord, use only the type provided with your product or by your local distributor and/or retailer. If you are unsure of the correct operational voltage, please contact your local distributor and/or retailer. AMPLIFIER REQUIREMENTS Due to the high output levels these speakers are capable of reproducing, exercise caution with the volume control. Excessive volume over long periods of time can permanently damage your hearing. Overdriving your amplier could also damage your speakers. Check with your dealer to make sure your particular amplier is best suited to your application. We want you listening for a lifetime. CARE AND CLEANING Your speakers have a durable nish that should only require dry dusting. Avoid use of abrasive or solvent-based cleaners and harsh detergents. The brush attachment of your vacuum or a damp cloth should remove any dust from your speaker grilles. The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. The lightening flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons. WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus to rain or moisture. WARNING No naked flame sources - such as candles - should be placed on the product. WARNING - Do not open! Risk of electrical shock voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all servicing to qualified service personnel. Place the equipment near a main power supply outlet and make sure that you can easily access the power breaker switch. WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the back panel or included power supply of the product. Operation from other voltages other than those indicated may cause irreversible damage to the product and void the product’s warranty. The use of AC Plug Adapters is cautioned because it can allow the product to be plugged with a detachable power cord, use only the type provided with your product or by your local distributor and/or retailer. If you are unsure of the correct operational voltage, please contact your local distributor and/or retailer. AMPLIFIER REQUIREMENTS Due to the high output levels these speakers are capable of reproducing, exercise caution with the volume control. Excessive volume over long periods of time can permanently damage your hearing. Overdriving your amplifier could also damage your speakers. Check with your dealer to make sure your particular amplifier is best suited to your application. We want you listening for a lifetime. CARE AND CLEANING Your speakers have a durable finish that should only require dry dusting. Avoid use of abrasive or solvent-based cleaners and harsh detergents. The brush attachment of your vacuum or a damp cloth should remove any dust from your speaker grilles. EU Compliance Information Eligible to bear the CE mark, Conforms to European Union Low Voltage Directive 73/23/EEC and 2006/95/EC; Conforms to European Union EMC Directive 89/336/EEC and 2004/108/EC. WEEE Notice Note: This mark applies only to countries within the European Union (EU) and Norway. This application is labeled in accordance with European Directive 2002/96EC concerning waste electrical and electronic equipment (WEEE). This label indicates that this product …

Text truncated - open the document above for the full version.

Date: 2,August ,2010 Federal Communications Commission Authorization and Evaluation Division FCC ID: XQ9W60200 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, （親筆簽名）（英文） Sam M. Romano Jr. Design Consultant Kadence Designs LLC Tel: 1- 877-812-8346 Fax: 1- 877-812-8346 Website: www.lightspeaker.net E-Mail: [email protected]

AGENCY AUTHORIZATION LETTER FCC ID: XQ9W60200 Date: 2,August ,2010 To whom it may concern: We, the undersigned, hereby authorize NS Technology Co., Ltd. NS to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by NS within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, （親筆簽名）（英文） Sam M. Romano Jr. Design Consultant Kadence Designs LLC Tel: 1- 877-812-8346 Fax: 1- 877-812-8346 Website: www.lightspeaker.net E-Mail: [email protected]

Label Location

Rev 14 Date: 8/06/10 3193575 65W 37mm 1 4 m m IC : 864A-W602008 FCC ID: XQ9W60200 This device is verified to comply with Part 15 of the FCC Rules.Operation subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.） 3193575 65W Rev 14 Date: 8/06/10 37mm 1 4 m m IC : 864A-W602008 FCC ID: XQ9W60200 This device is verified to comply with Part 15 of the FCC Rules.Operation subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.） 3193575 65W Rev 14 Date: 8/06/10 37mm 1 4 m m IC : 864A-W602008 FCC ID: XQ9W60200 This device is verified to comply with Part 15 of the FCC Rules.Operation subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.） TM 3193575 65W Rev 14 Date: 8/06/10 37mm 1 4 m m IC : 864A-W602008 FCC ID: XQ9W60200 This device is verified to comply with Part 15 of the FCC Rules.Operation subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.）

NS Technology Co., Ltd. Report No. NSE-F10085185 Page 1 of 4 FCC ID:XQ9W60200 IC ID:8684A-W60200 FCC and IC TEST REPORT for KADENCE DESIGNS LLC Subwoofer W6.2.0 Model Number: W6.2.0 Prepared for : KADENCE DESIGNS LLC Address : P.O.Box 2359,Thompson Falls,MT 59873 Prepared By : NS Technology Co., Ltd. Address : Chenwu Industrial Zone, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-85935656 Fax: +86-769-85991080 Report Number : NSE-F10085105 Date of Test : Jul. 30, 2010 Date of Report : Aug. 9, 2010 Te s t L a b Cert 2951.01 NS Technology Co., Ltd. Report No. NSE-F10085185 Page 2 of 4 FCC ID:XQ9W60200 IC ID:8684A-W60200 NS Technology Co., Ltd. Applicant: Address: KADENCE DESIGNS LLC P.O.Box 2359,Thompson Falls,MT 59873 Manufacturer: Address: Celewave Electronics(shenzhen) Co.,Ltd No 1-2 building,No 2 Industry District, Shang Heng lang Huaxing Road, Dalang Street,Baoan District, Shenzhen City,China E.U.T: Subwoofer W6.2.0 Model Number: W6.2.0 Report Number: NSE-F10085185 Tra de Name: Operating Frequency: 2412～2464MHz Date of Receipt: Jul.17, 2010 Date of Test: Jul. 30, 2010 Test Specification: RSS-210 Issue 7 2007 47 CFR FCC Part 2 Subpart J, section 2.1091 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Aug. 9, 2010 Tested by: Reviewed by: Approved by: Jade/ Engineer Iceman Hu / Supervisor Steven Lee / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products ,It is not permitted to be duplicated in extracts without written approval of NS Technology Co., Ltd. NS Technology Co., Ltd. Report No. NSE-F10085185 Page 3 of 4 FCC ID:XQ9W60200 IC ID:8684A-W60200 Maximum Permissible Exposure 1 Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density(S) (mW/cm 2 ) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100000 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density(S) (mW/cm2) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100000 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density 2 MPE Calculation Method E (V/m) = (30*P*G) 0.5 /d Power Density: Pd (W/m 2 ) = E 2 /377 E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = (30*P*G) / (377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. NS Technology Co., Ltd. Report No. NSE-F10085185 Page 4 of 4 FCC ID:XQ9W60200 IC ID:8684A-W60200 3 Calculated Result and Limit Mode CH Output power (dBm) Output power (mW) Antenna Gain (dBi) MPE estimation result (mW/cm²) at 20cm Limit of MPE Estimation (mW/cm²) Test result CH1:2412MHz 15.19 33.04 5.5 0.0486 1 Compiles CH2:2438MHz 15.05 31.99 5.5 0.0471 1 Compiles Antenna1 CH3:2464MHz 14.91 30.97 5.5 0.0447 1 Compiles CH1:2412MHz 14.82 30.34 5.5 0.0447 1 Compiles CH2:2438MHz 14.29 26.85 5.5 0.0395 1 Compiles Antenna2 CH3:2464MHz 14.34 27.16 5.5 0.0400 1 Compiles

FCC ID: XQ9W60200 IC ID: 8684A-W60200 NS Technology Co., Ltd. Report No. NSE-F10085176 Page 1 of 86 FCC and IC TEST REPORT for Kadence Designs LLC Subwoofer W6.2.0 Model Number: W6.2.0 Prepared for : Kadence Designs LLC Address : P.O.Box 2359,Thompson Falls,MT 59873 Prepared By : NS Technology Co., Ltd. Address : Chenwu Industrial Zone, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-85935656 Fax: +86-769-85991080 Report Number : NSE-F10085176 Date of Test : Jul. 25~Aug. 2, 2010 Date of Report : Aug. 9, 2010 Test Lab Cert 2951.01 FCC ID: XQ9W60200 IC ID: 8684A-W60200 NS Technology Co., Ltd. Report No. NSE-F10085176 Page 2 of 86 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION ......................................................................... 4 1.1. Product Function ........................................................................................................................ 4 1.2. Description of Device (EUT) .....................................................................................................4 1.3. Difference between Model Numbers ......................................................................................... 4 1.4. Independent Operation Modes ................................................................................................... 4 2. TEST SITES.......................................................................................................................... 5 2.1. Test Facilities ............................................................................................................................. 5 2.2. List of Test and Measurement Instruments ................................................................................ 6 3. TEST SET-UP AND OPERATION MODES .................................................................... 7 3.1. Principle of Configuration Selection.......................................................................................... 7 3.2. Block Diagram of Test Set-up....................................................................................................7 3.3. Test Operation Mode and Test Software.................................................................................... 7 3.4. Special Accessories and Auxiliary Equipment .......................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance........................................................................ 7 4. TEST SUMMARY................................................................................................................ 8 5. EMISSION TEST RESULTS.............................................................................................. 9 5.1. Conducted Emission at The Mains Terminals Test.................................................................... 9 5.2. Radiated Emission.................................................................................................................... 14 5.3. 6dB Bandwidth ........................................................................................................................ 62 5.4. 99% Bandwidth ........................................................................................................................ 64 5.5. Power Spectral Density Test ....................................................................................................66 5.6. Output Power Test.................................................................................................................... 68 5.7. Band Edge ................................................................................................................................ 69 5.8. ANTENNA REQUIREMENT ................................................................................................. 86 FCC ID: XQ9W60200 IC ID: 8684A-W60200 NS Technology Co., Ltd. Report No. NSE-F10085176 Page 3 of 86 NS Technology Co., Ltd. Applicant: Address: Kadence Designs LLC P.O.Box 2359,Thompson Falls,MT 59873 Manufacturer: Address: Celewave Electronics(shenzhen) Co.,Ltd No 1-2 building,No 2 Industry District, Shang Heng lang Huaxing Road, Dalang Street,Baoan District, Shenzhen City,China E.U.T: Subwoofer W6.2.0 Model Number: W6.2.0 Trade Name: Operating Frequency: 2412~2464MHz Date of Receipt: Jul.17, 2010 Date of Test: Jul. 25~Aug. 2, 2010 Test Specification: FCC Part15C :Oct.1, 2009 ANSI C63.4:2003 RSS-210,Issue 7 June 2007 RSS-GEN, Issue 2 June 2007 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Aug. 9, 2010 Tested by: Reviewed by: Approved by: Jade/ Engineer Iceman Hu / Supervisor Steven Lee / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products ,It is not permitted to be duplicated in extracts without written approval of NS Technology Co., Ltd. FCC ID: XQ9W60200 IC ID: 8684A-W60200 NS Technology Co., Ltd. Report No. NSE-F10085176 Page 4 of 86 1. GENERAL PRODUCT INFORMATION 1.1. Product Function Details please refer to Technical Construction Form and User Manual. 1.2. Description of Device (EUT) E.U.T. : Subwoofer W6.2.0 Model No. : W6.2.0 Operating Frequency : 2412~2464MHz Number of Channels : 3 Channels Type of Modulation : DSSS(QPSK) Antenna Type : Integral Antenna Gain : 5.5dBi System Input Voltage : AC 120V/60Hz Temperature Range(Operating) : 0 ~+ 40°C AC Line : Unshielded,Detachable 1.2m 1.3. Difference between Model Numbers 1.4. Independent Operation Modes The basic operation modes are: 1.4.1 TX CH1 ANT1 (2412MHz) 1.4.2. TX CH2 ANT1 (2438MHz) 1.4.3. TX CH3 ANT1 (2464MHz) 1.4.4. TX CH1 ANT2 (2412MHz) 1.4.5. TX CH2 ANT2 (2438MHz) 1.4.6. TX CH3 ANT2 (2464MHz) NOTE:ANT=antenna FCC ID: XQ9W60200 IC ID: 8684A-W60200 NS Technology Co., Ltd. Report No. NSE-F10085176 Page …

Text truncated - open the document above for the full version.

Set-up for conducted emission at the mains terminals test Set-up for radiated emission test (30MHz~1GHz) Set-up for radiated emission test（Above 1GHz） Set-up for Power Spectral Density and 99% Bandwidth test
