XQ9T2020Transmitter

1 Tech Support: 1-800-KLIPSCH OWNER’S MANUAL AND INSTALLATION INSTRUCTIONS State-of-the-art LIGHT & SOUND One complete system that installs in 30 minutes or less! OWNER'S MANUAL klipsch version.indd 1OWNER'S MANUAL klipsch version.indd 111/2/2009 12:18:59 AM11/2/2009 12:18:59 AM 2 Tech Support: 1-800-KLIPSCH The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. Le symbole de l’éclair fléché dans un triangle équilatéral, a pour but d’avertir l’utilisateur de la présence non isolées d’une «tension dangereuse» dans le boîtier du produit que mai d’une magnitude suffisante pour constituer un risque d’électrocution pour les personnes. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. Le point d’exclamation dans un triangle équilatéral sert à alerter l’utilisateur de la présence d’importantes exploitation et de maintenance (entretien) dans la documentation accompagnant l’appareil. Caution marking is located at the side of the apparatus. Attention marquage est situé sur le côté de l’appareil. CAUTION: Risk of Electrical Shock - Use in Dry Locations Only ATTENTION: Risque de Choc Électrique - Utiliser Seulement Dans des Endroits Secs CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No user servicable parts – refer servicing to qualified service personnel only. ATTENTION: Pour réduire le risque de choc électrique, ne pas retirer le couvercle (ou l’arrière). Non utilisateur servicable parts - confier l’entretien de service qualifie seul le personnel. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. AVERTISSEMENT: Pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil sous la pluie et l’humidité. OWNER'S MANUAL klipsch version.indd 2OWNER'S MANUAL klipsch version.indd 211/2/2009 12:26:44 AM11/2/2009 12:26:44 AM 3 Tech Support: 1-800-KLIPSCH IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all Warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plus has two blades with one wider that the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. OWNER'S MANUAL klipsch version.indd 3OWNER'S MANUAL klipsch version.indd 311/2/2009 12:26:44 AM11/2/2009 12:26:44 AM 4 Tech Support: 1-800-KLIPSCH Congratulations Thank you for choosing a LightSpeaker ® from Klipsch ® . You have chosen one of the most unique, patented, audio systems in the world. With proper installation and operation, you will enjoy years of trouble-free use. Klipsch ® sells numerous loudspeakers for use inside or outside your home. To see the complete Klipsch ® product assortment, visit us on the Internet at: www.lightspeaker.net. SCREWS IN 15 minute installation* LED LIGHT Replaces up to 65 watt bulb.** AMPLIFIER Replaces your 40 lb. amplifier WIRELESS No more cords and wiring. SPEAKER Replaces bulky speakers. OWNER'S MANUAL klipsch version.indd 4OWNER'S MANUAL klipsch version.indd 411/2/2009 12:26:44 AM11/2/2009 12:26:44 AM 5 Tech Support: 1-800-KLIPSCH Table of Contents System Overview....................................................................................6 What is in this box................................................................................8 Step 1 - Where will you install......................................................9 Step 2 - Check your connector type...........................................9 Step 3 - Test fit your LightSpeaker ® ...........................................10 Step 4 - Removing the trim ring....................................................11 Step 5 - Installing the trim ring....................................................14 Step 6 - Adjusting the Simple Tabs TM .....................................15 Step 7 - Setting the zone and stereo switches.....................16 Step 8 - Installing your LightSpeakers ® .................................20 Step 9 - Pairing...................................................................................21 Step 10 - Plug in your sources....................................................23 Step 11 - Rock & Roll.................................................................…

Text truncated - open the document above for the full version.

Attestation for FCC Declaration of Conformity FCC ID: XQ9T2020 Data: Nov. 1, 2009 Please be notified that we,the undersigned, Kadence Designs LLC declares that the product which bears the above FCC ID is also compliant with the FCC requirements for Doc,The test report number supporting the DoC is 902411,Testing in regards to this report was done by SIEMIC Inc, located at 2206 Ringwood Avenue,San Jose,CA 95131 USA which has been accredited in accordance to all of the requirements of 47CFR2.948(d)and(e)of the FCC rules and KDB349827 Sincerely, Sam Romano / Design Consultant Kadence Designs LLC Tel: +1-877-812-8346 Fax: +1-877-812-8346 Email: [email protected]

IC ID: 8684A-T2020 FCC ID:XQ9T2020 FRN: 0019101443. Date: 9/18/09 To whom it may concern: We, the undersigned, hereby authorize NS Technology Co., Ltd. NS to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by NS within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Sam M. Romano Jr. Design Consultant Kadence Designs LLC Tel: 1- 877-812-8346 Fax: 1- 877-812-8346 Website: www.lightspeaker.net E-Mail: [email protected]

Federal Communications Commission Date: 11/5/09 Authorization and Evaluation Division IC ID: 8684A-T2020 FCC ID: XQ9T2020 FRN: 0019101443 Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Sam M. Romano Jr. Design Consultant Kadence Designs LLC Tel: 1- 877-812-8346 Fax: 1- 877-812-8346 Website: www.lightspeaker.net E-Mail: [email protected]

Label Location

RX Antenna TX Antenna

FCC ID: XQ9T2020 IC ID: 8648A-T2020 NS Technology Co., Ltd. Report No. NSE-F09103960 Page 1 of 92 FCC COMPLIANCE REPORT for Kadence Designs LLC Transmitter Model Number: T2.2 Prepared for : Kadence Designs LLC Address : P.O.Box 2359,Thompson Falls,MT 59873 Prepared By : NS Technology Co., Ltd. Address : Chenwu Industrial Zone, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-85935656 Fax: +86-769-85991080 Report Number : NSE-F09103960 Date of Test : Sept. 8~Oct. 30, 2009 Date of Report : Nov. 1, 2009 FCC ID: XQ9T2020 IC ID: 8648A-T2020 NS Technology Co., Ltd. Report No. NSE-F09103960 Page 2 of 92 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION ................................................................................... 4 1.1. Product Function ................................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................................ 4 1.3. Difference between Model Numbers .................................................................................................... 4 1.4. Independent Operation Modes .............................................................................................................. 4 2. TEST SITES.................................................................................................................................... 5 2.1. Test Facilities ........................................................................................................................................ 5 2.2. List of Test and Measurement Instruments ........................................................................................... 6 3. TEST SET-UP AND OPERATION MODES .............................................................................. 7 3.1. Principle of Configuration Selection..................................................................................................... 7 3.2. Block Diagram of Test Set-up............................................................................................................... 7 3.3. Test Operation Mode and Test Software............................................................................................... 7 3.4. Special Accessories and Auxiliary Equipment .....................................................................................7 3.5. Countermeasures to Achieve EMC Compliance................................................................................... 7 4. TEST SUMMARY.......................................................................................................................... 8 5. EMISSION TEST RESULTS........................................................................................................ 9 5.1. Conducted Emission at The Mains Terminals Test............................................................................... 9 5.2. Radiated Emission............................................................................................................................... 14 5.3. 20dB Bandwidth ................................................................................................................................. 54 5.4. 99% Bandwidth ................................................................................................................................... 57 5.5. Band Edge ........................................................................................................................................... 60 FCC ID: XQ9T2020 IC ID: 8648A-T2020 NS Technology Co., Ltd. Report No. NSE-F09103960 Page 3 of 92 NS Technology Co., Ltd. Applicant: Address: Kadence Designs LLC P.O.Box 2359,Thompson Falls,MT 59873 Manufacturer: Address: Celewave Electronics(Shenzhen) Co.,Ltd No 1-2 building,No 2 Industry District, Shang Heng lang Huaxing Road, Dalang Street,Baoan District, Shenzhen City,China E.U.T: Transmitter Model Number: T2.2 Trade Name: Lightspeaker TM Operating Frequency: IEEE802.11b 2412~2462MHz IEEE802.11g 2412~2462MHz Date of Receipt: Sept. 8, 2009 Date of Test: Sept. 8~Oct. 30, 2009 Test Specification: FCC Part 15 Subpart C: July. 10, 2008 ANSI C63.4:2003 RSS-210,Issue 7 June 2007, Annex2.9 RSS-GEN, Issue 2 June 2007 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Nov. 1,2009 Tested by: Reviewed by: Approved by: Jade/ Engineer Iceman Hu / Supervisor Steven Lee / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products ,It is not permitted to be duplicated in extracts without written approval of NS Technology Co., Ltd. FCC ID: XQ9T2020 IC ID: 8648A-T2020 NS Technology Co., Ltd. Report No. NSE-F09103960 Page 4 of 92 1. GENERAL PRODUCT INFORMATION 1.1. Product Function Details please refer to Technical Construction Form and User Manual. 1.2. Description of Device (EUT) E.U.T. : Transmitter Model No. : T2.2 Operating Frequency : 2412~2462MHz Number of Channels : 11 Channels Channel frequency F = 2412 + 5(K-1) K=1,2,.......11 Type of Modulation : DSSS for IEEE 802.11b/g Antenna Type : Integral System Input Voltage : DC 9V from adapter input AC 120V/60Hz Temperature Range(Operating) : 0 ~+ 40°C Adapter M/N:YS01-090065U I/P:100-240V~50/60Hz 0.32A MAX O/P:9V 0~650mA DC Line:Unshielded,Undetachable ,1.5m Ipod M/N:MB147H S/N:JQ74121YMV Audio line:Unshielded,Detachable,0.3m 1.3. Difference between Model Numbers 1.4. Independent Operation Modes The basic operation modes are: 1.4.1. IEEE 802.11b; TX CH1 (2412MHz) 1.4.2. IEEE 802.11b; TX CH 6 (2437MHz) 1.4.3. IEEE 802.11b; TX CH11 (2462MHz) 1.4.4. IEEE 802.11g; TX CH1 (2412MHz) 1.4.5. IEEE 802.11g; TX CH 6 (2437MHz) 1.4.6. IEEE 802.11g; TX CH11 (2…

Text truncated - open the document above for the full version.

Set-up for conducted emission at the mains terminals test Set-up for radiated emission test (30MHz~1GHz) Set-up for radiated emission test（Above 1GHz）
