XQC-CS102Key Fob

© 2020 E colink Intelligent Technology Inc. PN: CS102 Manual R ev 1.00 CS-102 Four Button Wireless Remote Users Guide and Manual The Ecolink 4‐Button Keyfob Remote communicates with the ClearSky controller on the 345 MHz frequency. The keyfob is a lithium coin cell, battery powered, wireless keyfob designed to fit on a key chain, in a pocket, or in a purse. It gives users the ability to turn the security system function ON and OFF before entering the home or after exiting. When the control panel and keyfob are configured, and there is an emergency, you can turn on the siren and automatically call the central monitoring station. Keyfobs can also operate c ontrol panel auxiliary functions when configured. It provides a convenient option for the following system operations: •Arm the system AWAY (all zones) •Arm the system STAY ( all zones except interior follower zones) •Arm the system with no entry delay (if programmed) •Disarm the system •Trigger panic alarms Verify that the package includes the following: •1—4‐Button Keyfob Remote •1—Lithium Coin Battery C R2032 (included) Figu re 1: 4‐Button Keyfob Remote Co ntroller p rogramming: No te: Refer to the latest instructions for the controller or security system being used to learn in/program your new keyfob. Lea rn In: When learning the keyfob into the ClearSky controller, press the Arm Stay button and the Aux button simultaneously. On ce the keyfob has been properly learned in, test the keyfob by testing each of the keyfobs standard functions: •Di sarm button. Hold for two (2) seconds to disarm the Control Panel. All zones except life safety are disarmed. •Away button. Hold for two (2) seconds to arm the Control Panel in Away mode. All zones are armed. •Stay button. Hold for two (2) seconds to arm the Control Panel in Stay mode. All zones except interior follower are armed. •Auxiliary button. If programmed, can trigger a pre‐selected output. See the Control Panel’s Installation & Programming Guide for details. •Away & Disarm buttons. If programmed, pressing BOTH the Away and Disarm buttons at the same time, will send one of four types of emergency signals: (1) auxiliary panic (paramedics); (2) audible alarm (police); (3) silent panic (police); or (4) fire (fire department). Programmable Options The Ecolink 4‐Button Keyfob Remote (Ecolink‐CS‐102) has alternate programable configurations that can be enabled by the end user. To enter configuration mode: Press and hold Arm Away button and AUX button at the same time until led blinks. Configuration option 1: Press the AWAY button to enable 1 second press required to send transmission from all buttons. Configuration option 2: Press the DISARM button to enable a 3 second delay for the AUX button. Configuration option 3: Press AUX button one time. (This sets the keyfob for press and hold 3 seconds of the AUX button to initiate panic alarm RF signal instead of holding the ARM AWAY and DISARM buttons. NOTE: The panic RF signal is then processed by panel. It will be 4‐5 seconds before audible alarm. • Exit programming and test keyfob by pressing AUX button for 3 seconds. Watch keyfob LED for a blink. This indicates the RF signal has been sent to the panel. Alarm will occur at t his point. Arm Away Disarm Arm Stay Aux P N: CS102 Manual R ev 1.00 Replacing the Battery When the battery is low a signal will be sent to the control panel, or when a button is pressed the LED will appear dim or will not turn on at all. Follow these simple steps to replace the battery 1. With a key or small screwdriver, push up on the black tab located at the bottom of the remote (fig.1) and slide the chrome trim off. 2. Carefully separate the front and back piece of plastic to reveal the battery 3. Replace with a CR2032 battery ensuring the + side of the battery faces up (fig.2) 4. Re‐ass emble the plastics and ensure they click together 5. Ensur e the notch in the chrome trim is aligned with the back of the plastic. It will only go on one way. (fig.3) Figure 1 Figure 2 Figure 3 FCC Compliance Statement This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference and (2)this device must accept any interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Re‐orient or relocate the receiving antenna •Increase the separation between the equipment and receiver •Connect the equipment to an outlet on a different circuit from the receiver •Consult the dealer or an experienced radio/TV contractor for help. © 2020 Ecolink Intelligent Technology Inc. Warning: Changes or modifications not expressly approved by Ecolink Intelligent Technology Inc. could void the user’s authority to operate the equipment. This device complies with Industry Canada licence‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. C’et appareil est conforme la norme d'Industrie Canada exempts de licence RSS. Son fonctionnement est soumis aux deux conditions suivantes: (1) c’et appareil ne peut pas provoquer d'interférences, et (2) c…

Text truncated - open the document above for the full version.

September 17, 2020 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Ecolink Intelligent Technology, 2055 Corte Del Nogal, Carlsbad, CA 92011, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Ecolink Intelligent Technology product: Model CS-102 Key Fob under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Ecolink Intelligent Technology nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Ecolink Intelligent Technology will notify the Federal Communications Commission if, at any time, the situation changes causing Ecolink Intelligent Technology to be denied federal benefits. I f you have any further questions or need additional i nformation, please feel free to give me a call at (855)432-6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology 2055 Corte Del Nogal, Carlsbad, CA 92011

1 September 17, 2020 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Ecolink Intelligent Technology, would like to declare that the application being submitted for the device with FCC ID: XQC-CS102, has not been submitted to another TCB or FCC for certification. If you have any questi ons, please do not hesitate t o contact us at (855)432-6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology 2055 Corte Del Nogal, Carlsbad, CA 92011

1(1) September 17, 2020 Attention: Application Examiner RE: Request for Confidentiality Applicant: Ecolink Intelligent Technology FCC ID: XQC-CS102 To Whom It May Concern: Request is hereby submitted by Ecolink Intelligent Technology to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Block Diagrams Detailed Operational/Functional Description Ecolink Intelligent Technology has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The information contained in the confidential exhibits listed above is not available to the public. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology 2055 Corte Del Nogal, Carlsbad, CA 92011

Top View of the EUT Bottom View of the EUT Side View #1 of the EUT Side View #2 of the EUT Side View #3 of the EUT Side View #4 of the EUT

Ecolink Intelligent Technology, Inc.Page 1 of 1 2055 Corte Del Nogal Carlsbad, CA 92011 CS-102 Regulatory Label Information Model Number: CS-102 FCC ID: XQC-CS102 IC: 9863B-CS102 The FCC ID label material for this is: Adhesive is acrylic resin Substrate is white paper Ink printed Model #: CS-102 FCC ID: XQC-CS102 IC: 9863B-CS102

Inside View #1 Inside View #2 Inside View #3 Top View of the PCB with Sticker Top View of the PCB - No Sticker Bottom View of the PCB - View #1 Bottom View of the PCB - View #2

Compatible Electronics, Inc.https://celectronics.com 114 Olinda Drive Brea, CA 92823 This device FCC ID: Prepared By: Date: The maximum power that the transmitter is capable of is 0.21 mW Applied duty cycle? no Using the following formula from section 4.3.1 of KDB 447498 at test separation distances ≤ 50 mm [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [ √ f(GHz)] Duty Cycle 50.00% Value 1-g (mW) 10-g (mW) 0.02 152 535 "Value" shall be ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR 1-g power limit 10-g power limit 255 638 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An example of this is the determination of exposure from a device that uses digital technology such as a time-division multiple-access (TDMA) scheme for transmission of a XQC-CS102 Max Peak Power (dBm) Min Separation distance (mm) * Frequency (Ghz) < 50mm power limits for above frequency and distance When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 0.345 5 -6.78 Kyle FujimotoSeptember 25, 2020 SAREXJUST-B-0-43 D 02/27/2020

Report Number: B00924D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Key Fob Model: CS-102 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 21 FCC PART 15, SUBPART B and C; FCC 15.231; and RSS-210 & RSS GEN TEST REPORT for KEY FOB Model: CS-102 Prepared for ECOLINK INTELLIGENT TECHNOLOGY, INC. 2055 CORTE DEL NOGAL CARLSBAD, CALIFORNIA 92011 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: SEPTEMBER 21, 2020 REPORT APPENDICES TOTAL BODY A B C D E PAGES 21 2 2 2 10 26 63 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B00924D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Key Fob Model: CS-102 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 21 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1 Decision Rule & Risk 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration – Emissions 9 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 Emissions Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Measurement Uncertainty 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions Test 14 7.1.3 RF Emissions Test Results 16 7.1.4 Sample Calculations 17 7.1.5 Duty Cycle Calculation 18 7.1.6 99 % Bandwidth 19 7.1.7 -20 dB Bandwidth 19 7.1.8 Transmission Time 20 8. CONCLUSIONS 21  Report Number: B00924D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Key Fob Model: CS-102 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 21 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Models Covered Under This Report D Diagrams, Charts, and Photos xTest Setup Diagrams xAntenna and Effective Gain Factors xRadiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURETITLE 1 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLETITLE 1 Radiated Emission Results Report Number: B00924D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Key Fob Model: CS-102 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 21 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used by the client to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the United States government. Device Tested: Key Fob Model: CS-102 S/N: N/A Product Description: The equipment under test is a battery powered Key Fob manufactured by Ecolink Intelligent Technology. The transmit frequency is 345 MHz. The clock frequencies are 4 MHz and 10.78125 MHz. Dimensions: 6.0 cm (L) x 3.0 cm (W) x 1.0 cm (H). Modifications: The EUT was not modified to meet the specifications. Customer: Ecolink Intelligent Technology, Inc. 2055 Corte Del Nogal Carlsbad, California 92011 Test Dates: September 24 and 25, 2020 Test Specifications covered by accreditation: Test Specifications : Emissions requirements CFR Title 47, Part 15, Subpart B; CFR Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.231; RSS-210 and RSS-Gen Test Procedures: ANSI C63.4 and ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B00924D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Key Fob Model: CS-102 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 21 SUMMARY OF TEST RESULTS TEST DESCRIPTIONRESULTS 1 Spurious Radiated RF Emissions, 9 kHz – 3.45 GHz (Transmitter and Digital portion) Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; the limits of CFR Title 47, Part 15 Subpart C, sections 15.205, 15.209, and 15.231; and the limits of RSS-210 and RSS-Gen Highest reading in relation to spec limit 53.74 dBuV/m (AVG) @ 2760 MHz (*U = 3.95 dB) 2 -20 dB Bandwidth Complies with limits of CFR Title 47, Part 15 Subpart C, section 15.231 (c); and the limits of RSS-210 3 Transmission Time Complies wi…

Text truncated - open the document above for the full version.

FRONT VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. KEY FOB MODEL: CS-102 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. KEY FOB MODEL: CS-102 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. KEY FOB MODEL: CS-102 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. KEY FOB MODEL: CS-102 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONs
