WST-742 Wireless PIR Motion Sensor with Pet Immunity Installation Instructions and User Manual 1.S pecifications Frequency: Operating Temperature: Operating Humidity: Battery : B attery Life : C ompatibility : P et Immunity: Supervisory Interval: Coverage Area: Light Immunity: 345 MHz 32°-120°F (0°- 49°C) 5- 95% RH non-condensing 1x CR123A, Lithium 3V DC up to 5 Years Honeywell and 2GIG receivers Up to 50 lbs Approximately 60 minutes 40 feet by 40 feet, 90° angle 2000 Lux C overage Pattern: Side View: Top View: 2.Package Contents 1x Sensor1x Sensitivity Jumper 4x Screws & Wall Anchor 1x CR123A battery (installed) 2x Sensor Case Screw 1x Back Mounting 2-Sided Adhesive Tape 1x Manual 2x Side Mounting 2-Sided Adhesive Tape 3.Component Identification 4.E nrollment: To enroll the motion sensor, set your panel into programming mode according to the panel manufacturer’s instruction. When prompted by th e panel, enter the 7 digit serial number printed on the sensor label. Make sure t he loop number is set to Loop 1. Some panels can enroll your sensor by capturing the serial number transmitted by your sensor. The sensor can be enrolled by triggering wireless transmissions. Place the sensor into walk test mode by holding down the sensor’s tamper switch while inserting the battery. The red LED will begin to flash for 30 seconds. When the LED stops flashing, the sensor can be triggered by waving your hand in front of the motion sensor. The sensor will transmit every time motion is detected. Trigger the motion sensor as many times as necessary until the panel recognizes the sensor’s serial number. Make sur e t he loop number is set to Loop 1. 7.5 ft 0 3 6 10 13 16 19 23 26 29 33 36 40 (feet) 29 26 23 19 16 13 9 6 3 0 3 6 9 13 16 19 23 26 29 0 3 6 10 13 16 19 23 26 29 33 36 40 0 3 6 10 13 16 19 23 26 29 33 36 40 Tamper Switch Sensitivity Jumper CR123A Battery Case Release Button Sensor Case Screws (feet) (feet) 5. Mounting Mount the motion sensor at 7.5 feet (2.3 meters) above the floor. Press the case release button to separate the front and back sensor case. The back case gives access to both the flush mount and corner mount screw knock outs. Remove the appropriate knockouts and use the included screws to mount in the desired mounting location. It is recommend to ensure there is a tight seal around the knockouts to prevent bugs from entering the sensor and causing false alarms. Replace the front sensor cover to snap shut and screw in the sensor case screws on the top and bottom of the back sensor case. The WST-742 intrusion detection unit shall be installed in accordance with the Standard for Installation and Classification of Residential Burglar Alarm Systems, CAN/ULC-S310. The WST-742 is intended to be installed in accordance with the Standard for Installation and Classification of Residential Burglar Alarm Systems, UL1641. 6. Sensitivity Jumper Settings For normal sensitivity motion detection leave the jumper in the default setting (on). Remove the jumper if increased sensitivity to movement is desired. 7. Walk Test Mode Walk test mode can be used to test the motion sensor detection coverage area. To enter walk-test mode hold down the tamper button while inserting the battery. The red LED will begin to flash indicating that the motion sensor is warming up. After 30 seconds the LED no longer flashes and the motion sensor is ready to detect motion. The LED will illuminate each time motion is detected. Once the LED goes out, the sensor is ready to detect motion again. Walk test mode ends after twenty motion detections or if no motion is seen for one minute. It is recommended that the WST-742 PIR is tested monthly to ensure proper function. 8. Operation During normal operation, the LED will not turn on even if motion is detected. This is done to maximize battery life. Furthermore, when motion is detected and a signal is transmitted to the panel, the sensor will not transmit again for a period of three minutes. The WST-742 is an intrusion detection unit and shall provide for connection into an alarm system in accordance with the Standard for the Installation and Classification of Residential Burglar Alarm Systems, CAN/ULC-S310. 9. Maintenance - Replacing the Battery When the battery is low, a signal will be sent to the control panel. To insert or replace the battery: • Remove the front cover to expose the battery • Remove the backplate using a bottom-to -top lifting motion. • Remove the CR123A lithium battery. Note the correct orientation of the battery as shown on the sensor cover plate. Always match the plus (+) sign on the battery with the flat side of the compartment and the minus (-) sign on the battery with the spring side. • Replace the front cover. WARNING: Failure to follow these warnings and instructions can lead to heat generation, rupture, leakage, explosion, fire, or other injury, or damage. Do not insert the battery into the compartment in the wrong direction. Always replace the battery with the same or equivalent type (see Specifications on page 1). Never recharge or disassemble the battery. Never place the battery in fire or water. Always keep batteries away from small children. If batteries are swallowed, promptly see a doctor. • Always dispose and/or recycle used batteries in accordance with the hazardous waste recovery and recycling regulations for your location. Your city, state, or country may also require you to comply with additional handling, recycling, and disposal requirements. 10. `Environmental and Other Useful Information • While the PIR is a highly reliable intrusion detection device, it does not guarantee against burglary. Any intrusion device is subject to a “failure to warn” for a variety of reasons. Consider the following when installing and setting up the PIR: • This PIR has built-in protection to keep bugs from getting into the sensor area and causing false alarms. Note that this protection does not prevent insects from crawling across the lens of the PIR, which cou…

Text truncated - open the document above for the full version.

December 07, 2020 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Ecolink Intelligent Technology, 2055 Corte Del Nogal, Carlsbad, CA 92011, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Ecolink Intelligent Technology product: Model WST-742 Motion Detector under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Ecolink Intelligent Technology nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti -Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Ecolink Intelligent Technology will notify the Federal Communications Commission if, at any time, the situation changes causing Ecolink Intelligent Technology to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at (855)432-6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology 2055 Corte Del Nogal, Carlsbad, CA 92011

1 December 05, 2020 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Ecolink Intelligent Technology, would like to declare that the application being submitted for the device with FCC ID: XQC-WST742, has not been submitted to another TCB or FCC for certification. If you have any questi ons, please do not hesitate t o contact us at (855)432-6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technologies

1(1) December 07, 2020 Attention: Application Examiner RE: Request for Confidentiality Applicant: Ecolink Intelligent Technology FCC ID: XQC-WST742 To Whom It May Concern: Request is hereby submitted by Ecolink Intelligent Technology to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Block Diagrams Detailed Operational/Functional Description Ecolink Intelligent Technology has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The information contained in the confidential exhibits listed above is not available to the public. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology 2055 Corte Del Nogal, Carlsbad, CA 92011

Top View of the EUT Top View of the EUT - View #2 Bottom View of the EUT Side View #1 of the EUT Side View #2 of the EUT Side View #3 of the EUT sSide View #4 of the EUT

材質 比例 品號 規格 視角 日期 品名 繪圖 VISION MM 單位 版本 審核 承認 WST-742 Model: WST-742 FCC ID: XQC-WST742 IC: 9863B-WST742 Made in Taiwan 23.7mm 10.7mm C100 /M 44 C 57 / Y100 Model: WST-742 FCC ID: XQC-WST742 IC: 9863B-WST742 Made in Taiwan The FCC ID label material for this is: Adhesive is acrylic resin Substrate is white paper Ink printed

Inside View of the EUT Top View of the PCB - View #1 Top View of the EUT - View #2 Top View of the EUT - View #3 Top View of the EUT - View #4 Top View of the PCB - View #5 Top View of the PCB - View #6 Top View of the PCB - View #7 Bottom View of the EUT - View #1 Bottom View of the EUT - View #2

Compatible Electronics, Inc.https://celectronics.com 114 Olinda Drive Brea, CA 92823 This device FCC ID: Prepared By: Date: The maximum power that the transmitter is capable of is 1.03 mW Applied duty cycle? no Using the following formula from section 4.3.1 of KDB 447498 at test separation distances ≤ 50 mm [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [ √ f(GHz)] Duty Cycle 50.00% Value 1-g (mW) 10-g (mW) 0.12 152 535 "Value" shall be ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR 1-g power limit 10-g power limit 255 638 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An example of this is the determination of exposure from a device that uses digital technology such as a time-division multiple-access (TDMA) scheme for transmission of a XQC-WST742 Max Peak Power (dBm) Min Separation distance (mm) * Frequency (Ghz) < 50mm power limits for above frequency and distance When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 0.345 5 0.11 Kyle FujimotoDecember 15, 2020 SAREXJUST-B-0-43 D 02/27/2020

Report Number: B01216D1 FCC Part 15 Subpart B and C; FCC Section 15.231; RSS-210 & RSS-GEN Test Report Motion Detector Model: WST-742 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 22 FCC PART 15, SUBPART B and C; FCC 15.231; and RSS-210 & RSS GEN TEST REPORT for MOTION DETECTOR Model: WST-742 Prepared for ECOLINK INTELLIGENT TECHNOLOGY, INC. 2055 CORTE DEL NOGAL CARLSBAD, CALIFORNIA 92011 Prepared by:_____________________ JAMES ROSS Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: FEBRUARY 2, 2021 REPORT APPENDICES TOTAL BODY A B C D E PAGES 22 2 2 2 10 26 64 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B01216D1 FCC Part 15 Subpart B and C; FCC Section 15.231; RSS-210 & RSS-GEN Test Report Motion Detector Model: WST-742 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 22 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1 Decision Rule & Risk 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration – Emissions 9 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 Emissions Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Measurement Uncertainty 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions Test 14 7.1.3 RF Emissions Test Results 16 7.1.4 Sample Calculations 17 7.1.5 Duty Cycle Calculation 19 7.1.6 99 % Bandwidth 20 7.1.7 -20 dB Bandwidth 20 7.1.8 Transmission Time 21 8. CONCLUSIONS 22 Report Number: B01216D1 FCC Part 15 Subpart B and C; FCC Section 15.231; RSS-210 & RSS-GEN Test Report Motion Detector Model: WST-742 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 22 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Models Covered Under This Report D Diagrams, Charts, and Photos  Test Setup Diagrams  Antenna and Effective Gain Factors  Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLE TITLE 1 Radiated Emission Results Report Number: B01216D1 FCC Part 15 Subpart B and C; FCC Section 15.231; RSS-210 & RSS-GEN Test Report Motion Detector Model: WST-742 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 22 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used by the client to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the United States government. Device Tested: Motion Detector Model: WST-742 S/N: N/A Product Description: The equipment under test is a battery powered Motion Detector manufactured by Ecolink Intelligent Technology. The transmit frequency is 345 MHz. The oscillator(s) are 10.78 MHz. Dimensions: 9.0 cm (L) x 6.8 cm (W) x 4.5 cm (H). Modifications: The EUT was not modified to meet the specifications. Customer: Ecolink Intelligent Technology, Inc. 2055 Corte Del Nogal Carlsbad, California 92011 Test Dates: December 15 and 16, 2020 Test Specifications covered by accreditation: Test Specifications : Emissions requirements CFR Title 47, Part 15, Subpart B; CFR Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.231; RSS-210 and RSS-Gen Test Procedures: ANSI C63.4 and ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B01216D1 FCC Part 15 Subpart B and C; FCC Section 15.231; RSS-210 & RSS-GEN Test Report Motion Detector Model: WST-742 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 22 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Spurious Radiated RF Emissions, 9 kHz – 3.45 GHz (Transmitter and Digital portion) Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; the limits of CFR Title 47, Part 15 Subpart C, sections 15.205, 15.209, and 15.231; and the limits of RSS-210 and RSS-Gen Highest reading in relation to spec limit 75.34 dBuV/m (AVG) @ 345 MHz (*U = 3.19 dB) 2 -20 dB Bandwidth Complies with limits of CFR Title 47, Part 15 Subpart C, section 15.231 (c); and the limits of RSS-210 3 Transmission Time Complie…

Text truncated - open the document above for the full version.

FRONT VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. MOTION DETECTOR MODEL: W ST-742 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. MOTION DETECTOR MODEL: W ST-742 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. MOTION DETECTOR MODEL: W ST-742 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. MOTION DETECTOR MODEL: W ST-742 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONs
