CS-6 12 Flood and Freeze Sensor patent pending Installation Manual Operating Temperature: 32°-120°F (0°-49°C) Operating Humidity: 5-95% RH non condensing SPECIFICATIONS Frequency: 345 MHz Battery: One 3Vdc lithium CR2450 (620mAH) Battery life: up to 5 years Compatible with ClearSky Det ect Freeze at 41°F (5°C) restores at 45°F (7°C) Supervisory signal interval: 64 min(approx.) Detect a minimum of 1/64 th in of water OPERATION The CS-612 sensor is designed to detect water across the gold probes and will alert immediately when present. The Freeze sensor will trigger when the temperature is below 41°F (5°C) and will send a restoral at 45°F (7°C). ENROLLING To enroll the sensor, set your panel into sensor learn mode. Refer to your specific alarm panel instruction manual for details on these menus. The CS-612 locate the flood probes on the bottom of the sensor, you will need to bridge two adjacent probes to initiate a transmission from the sensor. 1.To learn in as a flood/freeze sensor, bridge two adjacent probes to initiate a transmission from the sensor. PLACEMENT Place the flood detector anywhere that you wish to detect a flood or freezing temperature, such as under a sink, in or near a hot water heater, a basement or behind a washing machine. If you would like to make sure the flood does not move from its intended location, use the provided sensor bracket and secure it either to the floor or wall. Testing the unit By bridging adjacent probes, you can send a Flood/Freeze transmission. Bridge two adjacent probes using a paperclip or metal object and remove it within 1 second. This will send a Flood/Freeze transmission. REPLACING THE BATTERY When the battery is low a signal will be sent to the control panel. To replace the battery: 1.Carefully remove the white rubber feet on the bottom of the flood detector. 2.Remove the 3 screws and open the case. Replace battery with a Panasonic CR2450 Lithium Battery 3.Replace the screws and rubber feet FCC COMPLIANCE STATEMENT This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference and (2)this device must accept any interference received, including interference that may cause undesired operation.These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the followingmeasures: •R e‐orient or relocate the receiving antenna •Increase the separation between the equipment and receiver •Connect the equipment to an outlet on a different circuit from the receiver •Consult the dealer or an experienced radio/TV contractor for help. © 2020 Ecolink Intelligent Technology Inc. W arning: Changes or modifications not expressly approved by Ecolink Intelligent Technology Inc. could void the user’s authority to operate the equipment. This device complies with Industry Canada licence‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) t his device may not cause interference, and (2) t his device must accept any interference, including interference that may cause undesired operation of the device. C’et appareil est conforme la norme d'Industrie Canada exempts de licence RSS. Son fonctionnement est soumis aux deux conditions suivantes: (1) c ’et appareil ne peut pas provoquer d'interférences, et (2) c ’et appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de la dispositif. F CC ID: XQC-CS612 IC:9863B-CS612 WARRANTY Ecolink Intelligent Technology Inc . warrants that for a period of 5 years from the date of purchase that this product is free from defects in material and workmanship. This warranty does not apply to damage caused by shipping or handling, or damage caused by accident, abuse, misuse, misapplication, ordinary wear, improper maintenance, failure to follow instructions or as a result of any unauthorized modifications. If there is a defect in materials and workmanship under normal use within the warranty period Ecolink Intelligent Technology Inc. shall, at its option, repair or replace the defective equipment upon return of the equipment to the original point of purchase. The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other warranties, whether expressed or implied and of all other obligations or liabilities on the part of Ecolink Intelligent Technology Inc. neither assumes responsibility for, nor authorizes any other person purporting to act on its behalf to modify or to change this warranty, T he maximum liability for Ecolink Intelligent Technology Inc. under all circumstances for any warranty issue shall be limited to a replacement of the defective product . It is recommended that the customer check their equipment on a regular basis for proper operation. Ecolink Intelligent Technology Inc. 2055 Corte Del Nogal Carlsbad CA 92011 855-632-6546 PN CS-612 R2.00 REV DATE: 12/08/2020 pa tent pending

December 07, 2020 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Ecolink Intelligent Technology, 2055 Corte Del Nogal, Carlsbad, CA 92011, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Ecolink Intelligent Technology product: Model CS-612 Flood/Freeze under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept th is letter as an attestation that neither Ecolink Intelligent Technology nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Ecolink Intelligent Technology will notify the Federal Communications Commission if, at any time, the situation changes causing Ecolink Intelligent Technology to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at (855)432-6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology 2055 Corte Del Nogal, Carlsbad, CA 92011

1 October 05,2020 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Ecolink Intelligent Technology, would like to declare that the application being submitted for the device with FCC ID: XQC-CS612, has not been submitted to another TCB or FCC for certification. If you have any questi ons, please do not hesitate t o contact us at (855)432-6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technologies

1(1) October 17, 2020 Attention: Application Examiner RE: Request for Confidentiality Applicant: Ecolink Intelligent Technology FCC ID: XQC-CS612 To Whom It May Concern: Request is hereby submitted by Ecolink Intelligent Technology to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Block Diagrams Detailed Operational/Functional Description Ecolink Intelligent Technology has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The information contained in the confidential exhibits listed above is not available to the public. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology 2055 Corte Del Nogal, Carlsbad, CA 92011

材質 比例 品號 規格 視角 日期 品名 繪圖 VISION MM 單位 版本 審核 承認 CS-612 Model: CS-612 FCC ID: XQC-CS612 IC: 9863B-CS612 Made in Taiwan 23.7mm 10.7mm C100 /M 44 C 57 / Y100 Model: CS-612 FCC ID: XQC-CS612 IC: 9863B-CS612 Made in Taiwan The FCC ID label material for this is: Adhesive is acrylic resin Substrate is white paper Ink printed

Compatible Electronics, Inc.https://celectronics.com 114 Olinda Drive Brea, CA 92823 This device FCC ID: Prepared By: Date: The maximum power that the transmitter is capable of is 0.81 mW Applied duty cycle? no Using the following formula from section 4.3.1 of KDB 447498 at test separation distances ≤ 50 mm [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [ √ f(GHz)] Duty Cycle 50.00% Value 1-g (mW) 10-g (mW) 0.10 152 535 "Value" shall be ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR 1-g power limit 10-g power limit 255 638 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An example of this is the determination of exposure from a device that uses digital technology such as a time-division multiple-access (TDMA) scheme for transmission of a XQC-CS612 Max Peak Power (dBm) Min Separation distance (mm) * Frequency (Ghz) < 50mm power limits for above frequency and distance When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 0.345 5 -0.91 Kyle FujimotoDecember 14, 2020 SAREXJUST-B-0-43 D 02/27/2020 Compatible Electronics, Inc.https://celectronics.com 114 Olinda Drive Brea, CA 92823 SAREXJUST-B-0-43 D 02/27/2020

Report Number: B01105D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Flood Freeze Sensor Model: CS-612 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 22 FCC PART 15, SUBPART B and C; FCC 15.231; and RSS-210 & RSS GEN TEST REPORT for FLOOD FREEZE SENSOR Model: CS-612 Prepared for ECOLINK INTELLIGENT TECHNOLOGY, INC. 2055 CORTE DEL NOGAL CARLSBAD, CALIFORNIA 92011 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JANUARY 28, 2021 REPORT APPENDICES TOTAL BODY A B C D E PAGES 22 2 2 2 10 25 63 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B01105D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Flood Freeze Sensor Model: CS-612 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 22 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1 Decision Rule & Risk 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration – Emissions 9 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 Emissions Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Measurement Uncertainty 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions Test 14 7.1.3 RF Emissions Test Results 16 7.1.4 Sample Calculations 17 7.1.5 Duty Cycle Calculation 19 7.1.6 99% Bandwidth 20 7.1.7 -20 dB Bandwidth 20 7.1.8 Transmission Time 21 8. CONCLUSIONS 22 Report Number: B01105D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Flood Freeze Sensor Model: CS-612 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 22 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Models Covered Under This Report D Diagrams, Charts, and Photos  Test Setup Diagrams  Antenna and Effective Gain Factors  Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLE TITLE 1 Radiated Emission Results Report Number: B01105D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Flood Freeze Sensor Model: CS-612 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 22 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used by the client to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the United States government. Device Tested: Flood Freeze Sensor Model: CS-612 S/N: N/A Product Description: The equipment under test is a battery powered Flood Freeze Sensor manufactured by Ecolink Intelligent Technology. The transmit frequency is 345 MHz. The clock frequencies are 4 MHz and 10.78125 MHz. Dimensions: 6.0 cm (L) x 2.5 cm (W) x 0.7 cm (H). Modifications: The EUT was not modified to meet the specifications. Customer: Ecolink Intelligent Technology, Inc. 2055 Corte Del Nogal Carlsbad, California 92011 Test Dates: November 5, 2020 and December 14, 2020 Test Specifications covered by accreditation: Test Specifications : Emissions requirements CFR Title 47, Part 15, Subpart B; CFR Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.231; RSS-210 and RSS-Gen Test Procedures: ANSI C63.4 and ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B01105D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Flood Freeze Sensor Model: CS-612 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 22 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Spurious Radiated RF Emissions, 9 kHz – 3.45 GHz (Transmitter and Digital portion) Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; the limits of CFR Title 47, Part 15 Subpart C, sections 15.205, 15.209, and 15.231; and the limits of RSS-210 and RSS-Gen Highest reading in relation to spec limit 75.20 dBuV/m (AVG) @ 345 MHz (*U = 3.19 dB) 2 -20 dB Bandwidth Complies with limits of CFR Title 47, Part 15 Subpart C, section 15.231 (c); and the limit…

Text truncated - open the document above for the full version.

FRONT VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. FLOOD FREEZE SENSOR MODEL: CS-612 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. FLOOD FREEZE SENSOR MODEL: CS-612 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS B rea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 FRONT VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. FLOOD FREEZE SENSOR MODEL: CS-612 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. FLOOD FREEZE SENSOR MODEL: CS-612 FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONs
