XQC-DWZB1ECOZigbee 3.0 Door/Window Contact Sensor

DWZB1-ECO Rev002 12/25/19 ECOLINK Zigbee 3.0 Door/Window Sensor DWZB1-ECO INTRODUCTION Door/Window sensors are designed to secure the perimeter of the residential premise, and provide the ability to add various automation services. The Door/Window sensor, which consists of a magnet that attaches to a door or window, will communicate door events to the home security system. When the magnet is moved away from the sensor, a signal will be sent to the control panel that communicates the changed state to the security system. Signals can also be used to activate a chime or convenience lighting based on system settings. SPECIFICATIONS Frequency: 2.4GHz Battery Type: CR123A Battery Operating Temperature: 0 ̊ C to 50 ̊ C (32°F - 122°F) Storage Temperature: -20 ̊ C to 60 ̊ C (-4°F - 140°F) Battery Life: 5 Years Dimension: Sensor: 70 x 21 x 22 mm (2.73” x 0.83” x 0.86”) Magnet: 30 x 10 x 11 mm (1.19” x 0.39” x 0.43”) Magnet Spacer: 30 x 10 x 6 mm (1.19” x 0.39” x 0.25”) PAIRING SENSOR This Door/Window sensor needs to be paired before installation. 1. Pull the exposed plastic tab from the sensor. (Figure 1) 2. The LED indicator will be lit for two seconds to indicate a successful booting. 3. It will blink three times approximately every 30 seconds while scanning the network. 4. If network is not found after 10 minutes, the sensor will go into sleep mode. To wake the sensor again, you need to use magnet or tamper (Figure 2) to trigger a paring process, and then sensor will repeat steps from 3 to 4. INSTALLATION 1. Please make sure that the sensor and magnet is located less than 0.25 inch from each other. For optimal performance, it is highly recommended to install the Door/Window sensor on the fixed frame and the magnet on the moving part of the door/window. Place the sensor near the top of the door that close to the opening edge of the door. This is the mounting location for the sensor. 2. Use the provided double-sided tape on the sensor. Attach the sensor to the door/window frame. Press firmly and hold in place for a few seconds (Figure 3). Secure it with silicone if needed. For mounting with screws, please use the screw holes located in the battery compartment. (Figure 3) 3. Use provided double-sided tape on the magnet. Make sure the alignment of both sensor and magnet is correct (Figure 4). The magnet aligns from the top of the sensor case. Press firmly and hold in place for a few seconds. Secure it with silicone if needed. 4. Spacers are used to raise the level of the magnet to be level/closer to sensor. Install spacers as shown in Figure 5. The spacers are ¼” thick. Figure 3 Figure 5 Figure 1 Figure CR123 Battery Green Pairing LED Indicator Battery Tab 3M double sided Tape Magnet 0.25” Figure 4 Magnet Spacer DWZB1-ECO Rev002 12/25/19 OPERATION 1. The Green Pairing LED will stay off during the normal operation. 2. The sensor is equipped with a tamper switch. If the cover of sensor is removed, the sensor will send an alarm to the home controller or security system. 3. A separation gap of 1.25” to 2” between the sensor and the magnet will report open/close events to your security system during normal operation. RESET TO FACTORY DEFAULTS & REBOOT If sensor needs to be factory defaulted (for example, to prepare it for joining with a home controller or security system). 1. Remove sensor cover. 2. Remove the battery from sensor. 3. Depress the tamper switch for three seconds before inserting the battery. 4. Insert the battery. The sensor should illuminate the LED once when boot-up/initialization tasks are complete. 5. Release the tamper switch while the LED is illuminated (it will be lit for 4 seconds). The sensor should then reset to factory default settings and begin searching for any available home controller or security system. If you need to reboot the device, remove the battery for at least 5 seconds, then re-insert the battery. 6. Place the cover back on sensor. NOTE: Replace Battery with Panasonic CR123A or Sony CR123A only. Use of another battery may negatively impact the performance of the product. TROUBLESHOOTING If device has trouble with pairing to the home controller or security system: 1. Separate the sensor and magnet or trigger tamper. The sensor will re-attempt to pair. 2. If device continues to have trouble pairing, remove the battery for 5 seconds and then re-insert it. 3. If device continues to have trouble pairing, use “Reset to Factory Defaults” procedure to attempt pairing again. If device was communicating with the home controller or security system but is no longer communicating: 1. Move the device to a location closer to the controller. Separate and close the magnet or trigger tamper from the sensor. If the controller successfully shows the sensor’s status, then install a repeater so the system’s range can reach the desired location for the sensor. 2. If the device has been in use for months or years and the failure is sudden, check the controller to see if the device has a low battery. Follow the instructions provided to replace the battery. FCC COMPLIANCE STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. To satisfy RF exposure requirements, this device and its antenna must operate with a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful i…

Text truncated - open the document above for the full version.

January 20, 2020 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Ecolink Intelligent Technology, 2055 Corte Del Nogal, Carlsbad, CA 92011, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Ecolink Intelligent Technology product: Model: DWZB1-ECO Co ntact Sensor under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept th is letter as an attestation that neither Ecolink Intelligent Technology nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Ecolink Intelligent Technology will notify the Federal Communications Commission if, at any time, the situation changes causing Ecolink Intelligent Technology to be denied federal benefits. If you have any further questions or need additional i nformation, please feel free to give me a call at (855)432 -6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology

1 January 20, 2020 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Ecolink Intelligent Technology, would like to declare that the application being submitted for the device with FCC ID: XQC-DWZB1ECO, has not been submitted to another TCB or FCC for certification. If you have any questions, please do not hesitate to contact us at (855)432-6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology

(1) January 20, 2020 Attention: A pplication Examiner RE: Request for Confidentiality Applicant: Ecolink Intelligent Technology FCC ID: XQC-DWZB1ECO To Whom It May Concern: Request is hereby submitted by Ecolink Intelligent Technology to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: •Schematics •Detailed Block Diagrams •Detailed Operational/Functional Description Ec olink Intelligent Technology has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The information contained in the confidential exhibits listed above is not available to the public. Sinc erely, Jay Stone Director of Engineering Ecolink Intelligent Technology

材質 比例 品號 規格 視角 日期 品名 繪圖 VISION MM 單位 版本 審核 承認 Model: DWZB1-ECO FCC ID: XQC-DWZB1ECO IC: 9863B-DWZB1ECO Made in Taiwan 23.7mm 10.7mm C100 /M 44 C 57 / Y100 Model: DWZB1-ECO FCC ID: XQC-DWZB1ECO IC: 9863B-DWZB1ECO Made in Taiwan

= where: S = transmitter operating variables: must be blank if dB values are entered P = = 13.2 (dBm) - or - (mW) 7 G = = 0 (dBi) - or - (numeric gain) R = = (cm) ( PG)/(4*R 2 *  ) = (mW/cm 2 ) 20.89296131 1.00000 20 (mw) (gain) (cm) ()/(4**  3 ) = (mW/cm 2 ) ()/( ) = (mW/cm 2 ) SS 20.89296131 ) 400 5026.548246 20.89296131 0.004157 4* POWER DENSITY ESTIMATIONS BASED ON POWER OUTPUT, ANTENNA GAIN, AND DISTANCE FROM ANTENNA maximum power density (mW/cm 2 ) (mW/cm 2 ) ) = distance to the center of the radiation of the antenna -- >> 3.1 20 ( ( S S ( P G ) / ( 4 R 2  ) power input to the antenna --------------------------------- >> gain of the antenna - worst case -------------------------- >> 2 *  /

Report Number: B91212D1 FCC Part 15 Subpart B and FCC Section 15.249; RSS-210 & RSS-GEN Test Report Zigbee 3.0 Door/Window Contact Sensor Part Number: DWZB1-ECO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 19 FCC PART 15, SUBPART B and C; RSS-210, RSS GEN TEST REPORT for ZIGBEE 3.0 DOOR/WINDOW CONTACT SENSOR Part Number: DWZB1-ECO Prepared for ECOLINK INTELLIGENT TECHNOLOGY, INC. 2055 CORTE DEL NOGAL CARLSBAD, CALIFORNIA 92011 Prepared by:_____________________ HARVEY SAMACO Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: DECEMBER 12, 2019 REPORT APPENDICES TOTAL BODY A B C D E PAGES 19 2 2 2 14 43 82 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B91212D1 FCC Part 15 Subpart B and FCC Section 15.249; RSS-210 & RSS-GEN Test Report Zigbee 3.0 Door/Window Contact Sensor Part Number: DWZB1-ECO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 19 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration – Emissions 9 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 Emissions Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Measurement Uncertainty 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions Test 14 7.1.3 RF Emissions Test Results 16 7.1.4 Sample Calculations 17 7.1.5 Duty Cycle Calculation 18 7.1.6 99% Bandwidth 18 8. CONCLUSIONS 19 Report Number: B91212D1 FCC Part 15 Subpart B and FCC Section 15.249; RSS-210 & RSS-GEN Test Report Zigbee 3.0 Door/Window Contact Sensor Part Number: DWZB1-ECO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 19 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Model Covered Under This Report D Diagrams and Charts • Test Setup Diagrams • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLE TITLE 1 Radiated Emission Results Report Number: B91212D1 FCC Part 15 Subpart B and FCC Section 15.249; RSS-210 & RSS-GEN Test Report Zigbee 3.0 Door/Window Contact Sensor Part Number: DWZB1-ECO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 19 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the federal government. Device Tested: Zigbee 3.0 Door/Window Contact Sensor Part Number: DWZB1-ECO S/N: N/A Product Description: The equipment under test is a door contact sensor Modifications: The EUT was not modified to meet the specifications. Customer: Ecolink Intelligent Technology, Inc. 2055 Corte Del Nogal Carlsbad, California 92011 Test Dates: December 11-12 and December 18, 2019 Test Specifications covered by accreditation: Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, Sections 15.205, 15.209, and 15.249; RSS-210 Issue 9 (2017), and RSS-Gen Issue 5 (2018) Test Procedures: ANSI C63.4: 2014 and ANSI C63.10: 2013 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B91212D1 FCC Part 15 Subpart B and FCC Section 15.249; RSS-210 & RSS-GEN Test Report Zigbee 3.0 Door/Window Contact Sensor Part Number: DWZB1-ECO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 19 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Spurious Radiated RF Emissions, 9 kHz – 25000 MHz (Transmitter, Receiver, and Digital portion) Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; and the limits of CFR Title 47, Part 15 Subpart C, section 15.205, 15.209 and 15.249; RSS-210 and RSS-Gen Highest reading in relation to spec limit 89.22 dBuV/m (AVG) @ 2405 MHz (*U = 3.63 dB) Report Number: B91212D1 FCC Part 15 Subpart B and FCC Section 15.249; RSS-210 & RSS-GEN Test Report Zigbee 3.0 Door/Window Contact Sensor Part Number: DWZB1-ECO Brea Division 114 Olinda Drive Brea, CA 92823 (…
