XQC-TLTZ25Garage Door Tilt Sensor

© 2015 Ecolink Intelligent Technology Inc. PN TLT-ZWAVE2.5 R1.03 Tilt Sensor Installation Instructions Product Overview  Z-Wave+ TM enabled device which transmits when a garage door is opened or closed  Uses a tilt sensor to detect the angle of a door and transmits open/closed status  Reports tamper condition if cover is removed Product Specifications  For indoor use only  Operating frequency: 908.42 MHz  Operating range: Up to 100 feet (30.5 meters) line-of-sight  Operating temperature: 0 ̊C to 49 ̊C, 32 ̊F to 120 ̊F (ambient temperature)  Battery type: 3V Lithium CR123A  Battery life: 5 to 8 years depending upon operating conditions Network Inclusion The sensor must be added to a Z-Wave network prior to use. To include the sensor in a network both the sensor and the network controller must be in inclusion mode at the same time. Refer to the instructions provided by the manufacturer of your specific controller for details on initiating the controller’s inclusion mode. STEP ONE Start by placing the controller into inclusion mode. STEP TWO Activate inclusion mode for the sensor by inserting the battery. When the inclusion process is complete the red LED will turn on for approximately 10 seconds and then it will go out. If the LED continues to flash, repeat the inclusion process. STEP THREE Test the garage door sensor before mounting it. Hold the sensor in your hand. Flip the sensor upside- down and watch the LED while doing so. The LED will flash each time the position of the sensor is changed. If your Z-Wave network has a software interface you may verify that the messages from the sensor are being received each time the sensor is flipped. Notes: If you need to repeat the inclusion process, repeat STEP ONE above, then for STEP TWO you will need to simply remove the cover of the sensor, remove the battery for 5 seconds, reinsert the battery, and replace the sensor cover. This will re-enter the sensor in inclusion mode. © 2015 Ecolink Intelligent Technology Inc. PN TLT-ZWAVE2.5 R1.03 Network Inclusion: Key Points to Remember  Controller inclusion mode must be activated BEFORE starting sensor inclusion mode.  The sensor can only be included in one network at a time. The sensor must be excluded from one network before inclusion in another.  The sensor automatically enters inclusion mode at power-up.  Exclusion mode on the senor is initiated following the same exact procedure as inclusion. Installation No tools required. Drill, screwdriver, pencil optional. The package contains the following: 1- Sensor 1- Sensor mounting bracket 2- mounting bracket screws 1- sensor to bracket screw 1- battery 1- piece of adhesive tape STEP ONE Identify Location for Tilt Sensor: Choose a mounting method that is appropriate for your garage door. It is very important that the Tilt sensor be located on the top section of a multi-panel garage door. This will be the first section to tilt when the door is opened and the last to move to the vertical position when closing. STEP TWO Mount the Tilt sensor to a clean dry surface WITH THE ARROW ON THE SIDE OF THE SENSOR POINTING UP Before you mount the sensor, make certain that the arrow on the side of the Tilt sensor is pointing UP when assembled in the mounting bracket. The sensor can be mounted using adhesive tape and/or screws. Caution: Use of the screws is only recommended for garage doors that are thicker than the screws are long. Use the adhesive tape for any garage door that is thinner than the length of the provided screws (including many modern metal garage doors). © 2015 Ecolink Intelligent Technology Inc. PN TLT-ZWAVE2.5 R1.03 Adhesive Tape: Make sure that the desired mounting location on the door is clean and dry. The adhesive tape can withstand the temperature and humidity conditions of a typical garage. However, it is recommended that the sensor be mounted when air or surface temperatures are not extreme. Installing the adhesive tape when the conditions are right promotes a good long-lasting adhesive bond between the bracket and the surface of the door. Peel back the outer layer of one side of the adhesive tape, stick the tape to the garage door and press firmly. Peel back the outer layer on the other side of the tape and press the mounting bracket firmly onto the adhesive tape. Screws: Place the mounting bracket in the desired position on the garage door. Use the mounting bracket as a template to mark the location of the screw holes with a pencil. Drill a small hole through each of the marked locations. Use a screwdriver to fasten the mounting bracket to the door. Adhesive Tape Mounting Bracket Bracket Screws (optional) Senso r Senso r Screw © 2015 Ecolink Intelligent Technology Inc. PN TLT-ZWAVE2.5 R1.03 Z-Wave Device Class and Command Class Information IMPORTANT: The Tilt sensor must be located on the top panel AND have the arrow on the side of the sensor pointing UP in order to operate properly. © 2015 Ecolink Intelligent Technology Inc. PN TLT-ZWAVE2.5 R1.03 This Z-Wave sensor is a Z-Wave generic Device Class of GENERIC_TYPE_SENSOR_NOTIFICATION, and a specific device class of SPECIFIC_TYPE_NOTIFICATION_SENSOR, and the supported command classes are COMMAND_CLASS_ZWAVEPLUS_INFO, COMMAND_CLASS_VERSION, COMMAND_CLASS_MANUFACTURER_SPECIFIC, COMMAND_CLASS_POWERLEVEL, COMMAND_CLASS_BATTERY, COMMAND_CLASS_NOTIFICATION_V4, COMMAND_CLASS_ASSOCIATION, COMMAND_CLASS_ASSOCIATION_GRP_INFO, COMMAND_CLASS_WAKE_UP, COMMAND_CLASS_SENSOR_BINARY, COMMAND_CLASS_CONFIGURATION, COMMAND_CLASS_BASIC. Manufacturer Specific Manufacturer ID: 0x014A Product Type: 4 Product ID: 3 Factory Default To restore this sensor to factory default settings, follow the instructions in this manual to exclude this sensor from the Z-Wave network. Upon completion of removal from the network the sensor will restore itself to factory default settings automatically. Use this procedure only in the event that the network primary controller is missing or otherwise inoperable. Keeping Awake …

Text truncated - open the document above for the full version.

October 13, 2015 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement Ecolink Intelligent Technology FCC ID: XQC-TLTZ25 To Whom It May Concern: We, Ecolink Intelligent Technology, hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number XQC-TLTZ25 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is September 11, 2015. The Limited Agency Agreement expires on September 11, 2017, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology

1(2) 10/21/2015 Attention: Application Examiner RE: Request for Confidentiality Applicant: Ecolink Intelligent Technology FCC ID: XQC-TLTZ25 To Whom It May Concern: Request is hereby submitted by Ecolink Intelligent Technology to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics  Detailed Block Diagrams  Detailed Operational/Functional Description Request is hereby submitted by Ecolink Intelligent Technology to withhold from public review for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 45 days from the date of Authorization:  Test setup photos  Internal photos  User manual Rationale for request for confidentiality: Ecolink Intelligent Technology has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development. The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. 2(2) Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology

Non-Specific Radio Report Shell Rev. August 2015 Page 1 of 27 Ecolink, Model: TILT-ZWAVE2.5-ECO EMC TEST REPORT Report Number: 102222335LAX-001 Project Number: G102222335 Report Issue Date: October 18, 2015 Model(s) Tested: TILT-ZWAVE2.5-ECO Standards: FCC CFR47 Part 15 Subpart C, October 2014 Intentional Radiator §15.249, Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHz, and 24.0-24.25 GHz FCC CFR47 Part 15 Subpart B, October 2014 Unintentional Radiator Industry Canada RSS-210 Issue 8, December 2010 License-exempt Radio Apparatus (All Frequency Bands): Category I Equipment §A2.9, Bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHz Industry Canada ICES-003 Issue 5 Information Technology Equipment (ITE) - Limits and methods of measurement Tested by: Client: Intertek 25791 Commercentre Drive Lake Forest, CA 92630 USA Ecolink 2055 Corte Del Nogal Carlsbad, CA 92011 USA Report prepared by Report reviewed by Grace Lin EMC Staff Engineer Krishna Vemuri EMC Senior Staff Enginee This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Report Number: 102222335LAX-001 Issued: 10/18/2015 Non-Specific Radio Report Shell Rev. August 2015 Page 2 of 27 Ecolink, Model: TILT-ZWAVE2.5-ECO Table of Contents 1 Introduction and Conclusion .............................................................................................................. 3 2 Test Summary ...................................................................................................................................... 3 3 Client Information ................................................................................................................................ 4 4 Description of Equipment Under Test and Variant Models ............................................................. 4 5 System Setup and Method .................................................................................................................. 6 6 Fundamental Field Strength ............................................................................................................... 7 7 Occupied Bandwidth ......................................................................................................................... 11 8 Transmitter Radiated Spurious Emissions ..................................................................................... 14 9 Receiver Radiated Spurious Emissions .......................................................................................... 21 10 AC Mains Conducted Emissions .................................................................................................. 25 11 Revision History ............................................................................................................................. 27 Intertek Report Number: 102222335LAX-001 Issued: 10/18/2015 Non-Specific Radio Report Shell Rev. August 2015 Page 3 of 27 Ecolink, Model: TILT-ZWAVE2.5-ECO 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 4.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested does not comply with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. Intertek does not make any claims of compliance for samples or variants which were not tested. 2 Test Summary Section Test full name Result 6 Fundamental Field Strength (FCC §15.249(a), FCC §15.249(c); IC RSS-210 Issue 8 §A2.9) Compliant 7 Occupied Bandwidth (FCC §15.215; IC RSS-Gen Issue 4 §6.6) Compliant 8 Transmitter Radiated Spurious Emissions (FCC §15.249(a), FCC §15.249(c), FCC §15.249(d), FCC §15.209; IC RSS-210 Issue 8 §A2.9, IC RSS-Gen Issue 4 §8.9) Compliant 9 Receiver Radiated Spurious Emissions (FCC §15.109; IC ICES-003 Issue 5 §6.2) Compliant 10 AC Mains Conducted Emissions (FCC §15.207; IC RSS-Gen Issue 4 §8.8) (FCC §15.107; IC ICES-003 Issue 5 §6.1) N/A* *: EUT is battery powered Intertek Report Number: 102222335LAX-001 Issued: 10/18/2015 Non-Specific Radio Report Shell Rev. August 2015 Page 4 of 27 Ecolink, Model: TILT-ZWAVE2.5-ECO 3 Client Information This EUT was tested at the request of: Client: Ecolink 2055 Corte Del Nogal Carlsbad, CA 92011 USA Contact: Mike Archbold Telephone: (760) 431-8804 Fax: Email: [email protected] 4 Description of Equipment Under Test and Variant Models Equipment Under Test Description Manufacturer Model Number Serial Number Home Motion Sensor Ecolink TILT-ZWAVE2.5-ECO 908.42 MHz Home Motion Sensor Ecolink TILT-ZWAVE2.5-ECO 916.00 MHz Home Motion Sensor Ecolink TILT-ZWAVE2.5-ECO Production Firmware Receive Date: 07/30/2015, 09/16/2015 Received Condition: Good Type: Production Description of Equipmen…
