XQC-WST200OETWireless Contact

WST-200-OET Wireless Contact Specifications Frequency: 433.92MHz Operating Temperature: 32°-120°F (0°-49°C) Battery: 3V lithium CR2032 Operating Humidity: 5-95% RH non condensing Battery life: up to 5 years Compatible with OET 433MHz receivers Magnet gap: 5/8 th inch max Supervisory signal interval: 60 min(approx.) Enrolling Each product has a label with a unique 6 digit serial number. You will need this serial number to add this contact to your security system. Refer to your specific control panel or wireless receiver installation instructions for details on adding a new contact. Mounting Included with the contact is double sided tape for the contact and the magnet. For reliable bonding ensure the surface is clean and dry. Apply the tape to the sensor and then to the desired location. Apply firm pressure for several seconds. It is not recommended to mount the tape at temperatures below 50°F, although after 24 hours the bond will hold at low temperatures. One side of the sensor is marked with 3 lines; this indicates the location of the reed switch. The magnet should be mounted facing this side of the sensor, and it must be no further than 5/8 of an inch from the sensor. Interchangeable covers The contact comes from the factory assembled with a white cover, but included are optional brown covers. To change the cover simply slide the front cover to disengage it from the sensor then remove. Replace with the brown cover ensuring the Top (as marked on the inside of the cover) points away from the battery. You should hear a click when the cover engages and disengages from the sensor. You do not need to replace the back plastic because once mounted the back is not visible. To replace the magnet cover you will need to gently pry the white cover off with a flat head screw driver and snap the brown cover in place. Replacing the Battery When the battery is low a signal will be sent to the control panel. To replace the battery: 1. Slide the top cover to disengage it from the sensor, then remove to reveal the battery. 2. Replace with a CR2032 battery ensuring the + side of the battery faces towards you. 3. Re-attached the cover, ensure the Top (as marked on the inside of the cover) points away from the battery. You should hear a click when the cover engages properly. Note: Removing the cover will trigger a zone tamper signal to the control panel FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Re-orient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment to an outlet on a different circuit from the receiver Consult the dealer or an experienced radio/TV contractor for help. Warning: Changes or modifications not expressly approved by Ecolink Intelligent Technology Inc. could void the user’s authority to operate the equipment. Industry Canada Compliance Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. C’et appareil est conforme la norme d'Industrie Canada exempts de licence RSS. Son fonctionnement est soumis aux deux conditions suivantes: c’et appareil ne peut pas provoquer d'interférences, et c’et appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de la dispositif. FCC ID: XQC-WST200OET IC: 9863B-WST200OET LIMITED WARRANTY This limited warranty is provided by Ecolink Intelligent Technology (“Ecolink”) to you as the original purchaser of the product. Ecolink warrants this product to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. The determination of whether the product is defective shall be made by Ecolink in its sole discretion with consideration given to the overall performance of the product. If Ecolink determines that any product is defective, Ecolink’s sole obligation and your sole and exclusive remedy shall be that Ecolink will replace the product. This warranty does not apply to damage caused by shipping or handling, or damage caused by accident, abuse, misuse, misapplication, ordinary wear, improper maintenance, failure to follow instructions or as a result of any unauthorized modifications. The foregoing limited warranty is and shall be in lieu of any and all other warranties, whether expressed or implied and of all other obligations or liabilities on the part of Ecolink. Ecolink neither assumes responsibility for, nor authorizes any other person purporting to act on its behalf to modify or to change this warranty, nor to assume for it any other warranty or liability concerning this product. It is recommended that the customer check their equipment on a regular basis for proper operation. DISCLAIMER AND LIMITATION OF LIABILITY OT…

Text truncated - open the document above for the full version.

December 07, 2020 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Ecolink Intelligent Technology, 2055 Corte Del Nogal, Carlsbad, CA 92011, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Ecolink Intelligent Technology product: Model WST-200-OET Door Contact under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Ecolink Intelligent Technology nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Ecolink Intelligent Technology will notify the Federal Communications Commission if, at any time, the situation changes causing Ecolink Intelligent Technology to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at (855)432-6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology 2055 Corte Del Nogal, Carlsbad, CA 92011

1 December 05, 2020 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Ecolink Intelligent Technology, would like to declare that the application being submitted for the device with FCC ID: XQC-WST200OET, has not been submitted to another TCB or FCC for certification. If you have any questi ons, please do not hesitate t o contact us at (855)432-6546. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technologies

1(1) December 07, 2020 Attention: Application Examiner RE: Request for Confidentiality Applicant: Ecolink Intelligent Technology FCC ID: XQC-WST200OET To Whom It May Concern: Request is hereby submitted by Ecolink Intelligent Technology to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: Schematics Detailed Block Diagrams Detailed Operational/Functional Description Ecolink Intelligent Technology has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The information contained in the confidential exhibits listed above is not available to the public. Sincerely, Jay Stone Director of Engineering Ecolink Intelligent Technology 2055 Corte Del Nogal, Carlsbad, CA 92011

Model #: WST-200-OET FCC ID: XQC-WST200OET IC: 9863B-WST200OET Ecolink Intelligent Technology, Inc.Page 1 of 1 2055 Corte Del Nogal Carlsbad, CA 92011 WST-200-OET Regulatory Label Information Model Number: WST-200-OET FCC ID: XQC-WST200OET IC: 9863B-WST200OET The FCC ID label material for this is: Adhesive is acrylic resin Substrate is white paper Ink printed Model #: WST-200-OET FCC ID: XQC-WST200OET IC: 9863B-WST200OET

Inside View of the EUT #1 Inside View of the EUT #2 Top View of the PCB - View #1 Top View of the PCB - View #2 Top View of the PCB - View #3 Bottom View of the PCB - View #1 Bottom View of the PCB - View #2 Bottom View of the PCB - View #3

Compatible Electronics, Inc.https://celectronics.com 114 Olinda Drive Brea, CA 92823 This device FCC ID: Prepared By: Date: The maximum power that the transmitter is capable of is 0.39 mW Applied duty cycle? no Using the following formula from section 4.3.1 of KDB 447498 at test separation distances ≤ 50 mm [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [ √ f(GHz)] Duty Cycle 50.00% Value 1-g (mW) 10-g (mW) 0.05 152 535 "Value" shall be ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR 1-g power limit 10-g power limit 255 638 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An example of this is the determination of exposure from a device that uses digital technology such as a time-division multiple-access (TDMA) scheme for transmission of a XQC-WST200OET Max Peak Power (dBm) Min Separation distance (mm) * Frequency (Ghz) < 50mm power limits for above frequency and distance When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 0.345 5 -4.12 Kyle FujimotoNovember 25, 2020 SAREXJUST-B-0-43 D 02/27/2020

Report Number: B01125D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Door Window Contact Model: WST-200-OET Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 22 FCC PART 15, SUBPART B and C; FCC 15.231; and RSS-210 & RSS GEN TEST REPORT for DOOR WINDOW CONTACT Model: WST-200-OET Prepared for ECOLINK INTELLIGENT TECHNOLOGY, INC. 2055 CORTE DEL NOGAL CARLSBAD, CALIFORNIA 92011 Prepared by:_____________________ JAMES ROSS Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: DECEMBER 8, 2020 REPORT APPENDICES TOTAL BODY A B C D E PAGES 22 2 2 2 10 25 63 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B01125D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Door Window Contact Model: WST-200-OET Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 22 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1 Decision Rule & Risk 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration – Emissions 9 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 Emissions Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Measurement Uncertainty 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions Test 14 7.1.3 RF Emissions Test Results 16 7.1.4 Sample Calculations 17 7.1.5 Duty Cycle Calculation 19 7.1.6 99 % Bandwidth 20 7.1.7 -20 dB Bandwidth 20 7.1.8 Transmission Time 21 8. CONCLUSIONS 22 Report Number: B01125D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Door Window Contact Model: WST-200-OET Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 22 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Models Covered Under This Report D Diagrams, Charts, and Photos  Test Setup Diagrams  Antenna and Effective Gain Factors  Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Layout of the Semi-Anechoic Test Chamber LIST OF TABLES TABLE TITLE 1 Radiated Emission Results Report Number: B01125D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Door Window Contact Model: WST-200-OET Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 22 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used by the client to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the United States government. Device Tested: Door Window Contact Model: WST-200-OET S/N: N/A Product Description: The equipment under test is a battery powered Door Window Contact manufactured by Ecolink Intelligent Technology. The transmit frequency is 433.92 MHz. The clock oscillator is 13.56 MHz. Dimensions: 5.2 cm (L) x 2.6 cm (W) x 0.8 cm (H). Modifications: The EUT was not modified to meet the specifications. Customer: Ecolink Intelligent Technology, Inc. 2055 Corte Del Nogal Carlsbad, California 92011 Test Date: November 25, 2020 Test Specifications covered by accreditation: Test Specifications : Emissions requirements CFR Title 47, Part 15, Subpart B; CFR Title 47, Part 15, Subpart C, sections 15.205, 15.209, and 15.231; RSS-210 and RSS-Gen Test Procedures: ANSI C63.4 and ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B01125D1 FCC Part 15 Subpart B and FCC Section 15.231; RSS-210 & RSS-GEN Test Report Door Window Contact Model: WST-200-OET Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 22 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Spurious Radiated RF Emissions, 9 kHz – 4.34 GHz (Transmitter and Digital portion) Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; the limits of CFR Title 47, Part 15 Subpart C, sections 15.205, 15.209, and 15.231; and the limits of RSS-210 and RSS-Gen Highest reading in relation to spec limit 38.77 dBuV/m (AVG) @ 946.50 MHz (*U = 3.19 dB) 2 -20 dB Bandwidth Complies with limits of CFR Title 47, Part 15 Subpart C, section 15.231 (c); and the …

Text truncated - open the document above for the full version.

FRONT VIEW 撨 ECOLINK INTELLIGENT TECHNOLOGY, INC. ECOLINK INTELLIGENT TECHNOLOGY, INC. DOOR WINDOW CONTACT MODEL: WST-200-OET FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. DOOR WINDOW CONTACT MODEL: WST-200-OET FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – BELOW 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. DOOR WINDOW CONTACT MODEL: WST-200-OET FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS B rea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 REAR VIEW ECOLINK INTELLIGENT TECHNOLOGY, INC. DOOR WINDOW CONTACT MODEL: WST-200-OET FCC SUBPART B AND C; RSS-210 AND RSS-GEN – RADIATED EMISSIONS – ABOVE 1 GHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS
