XQLS-KW258SL-DReceiver of Wireless Keyboard

Sunday Electronics Technology Co., Ltd. S-KW258SL Ver. A1 Page 1 of 6 Model: S-KW258SL 2.4G wireless solar keyboard Installation& User’s Guide Version:A1 2014-08-22 Sunday Electronics Technology Co., Ltd. S-KW258SL Ver. A1 Page 2 of 6 1．Overview „ 2.4GHz Wireless Technology range up to 5-10M „ Exquisite mini USB receiver „ USB Nano Receiver „ Plug and play with Windows 2000/ME/XP/NT/VISTA/7 2．INSTALLATION STEP 1: Connect the USB receiver to an open USB port on your computer or to a port on an additional USB hub. The computer will prompt “find a new hardware”. This indicates that the receiver is connected and functioning. STEP 2: Take out of the battery insulation sheet behind the keyboard . STEP 3: Please turn on the power switch . Sunday Electronics Technology Co., Ltd. S-KW258SL Ver. A1 Page 3 of 6 You are now ready to begin using your wireless keyboard If you don’t want to use it, please turn off the power switch and unplug the dongle HOT KEYS GUIDE: Following is a guide showing all the hot keys that are preset in this keyboard. Web/Home Sleep Volume+ Mute Volume- 3．Charge Description z When the battery is fully charged, it can power the keyboard for two months under complete darkness. z When the light intensity is 200LUX (about two meters away from the window), the charging current of the solar panel is 0.6mA. . z When the light intensity is 100000LUX (in direct sunlight at noon), the charging current of the solar panel is 60mA. z When the light intensity is 100,000 LUX , the battery can be fully charged in three hours. z In order to maintain enough battery charge, when not use the keyboard, do try to place it in the sun or anywhere indoor light is sufficient. It’s better to put the keyboard at a distance of not more than 9 feet (3 meters) from windows where direct sunslight is available.Do not worry, the keyboard can absorb light even when turned off. z After three years’ usage, please replace the battery (MAXELL ML2032) as shown below: 1) Open the battery cover Sunday Electronics Technology Co., Ltd. S-KW258SL Ver. A1 Page 4 of 6 2) Take out the old battery 3) Put new battery into battery slot Sunday Electronics Technology Co., Ltd. S-KW258SL Ver. A1 Page 5 of 6 4) Close the battery cover 4． Disposal If possible,dispose of the used appliance at a recycling centre. Do not dispose of the used appliance with the household waste. 5．Safety z Never try to open or to repair this product yourself. z Keep this appliance away from fluids,such as water. 6．Copyright z Reproduction of this manual or any part of it is prohibited without permission from Sunday Electronics Technology co., Ltd. Sunday Electronics Technology Co., Ltd. S-KW258SL Ver. A1 Page 6 of 6

Sep 12, 2014 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: XQL-KW258SL-D Product Name: Receiver of Wireless Keyboard Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Sep 12, 2014 20 By: Judy Chu Signature Printed Title: Sales On behalf of : GUANGZHOU SUNDAY ELECTRONICS CO., LTD. . Telephone: +86-20-87071000

Guangzhou Sunday Electronics Co., Ltd. We Declare that: We have the following models application for FCC ID: S-KW258SL, S-KW1xxxx- S-KW6xxxx (the “x” means one discretionary character of A/a – Z/z or one Arabic number of 0 – 9) . These models are identical in circuit diagram, PCB layout, and electrical components. Only because of different costumer, the model names are different. Dated this Sep 12, 2014 20 By: Judy Chu Signature Printed Title: Sales On behalf of : GUANGZHOU SUNDAY ELECTRONICS CO., LTD. . Telephone: +86-20-87071000

Outside View Photo for the EUT Outside View

FCC ID: XQL-KW258SL-D

Mark Location: FCC ID Label Location

Interior View Interior View

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength =93.48dBuV/m @3m Ant gain =0dBi So pt={ [10 (93.48/20) /10 6 x3] 2 /30x1 }x1000 mW = 0.67mW So ( 0.67 mW/5mm)x √2.408 = 0.21 <3 Then SAR evaluation is not required

ISO/IEC17025 Accredited Lab. Report No: FCC1408147-01 File reference No: 2014-09-12 Applicant: Guangzhou Sunday Electronics Co., Ltd. Product: Receiver of Wireless Keyboard Model No: Receiver of S-KW258SL, S-KW1xxxx- S-KW6xxxx ( the “x” means one discretionary character of A/a – Z/z or one Arabic number of 0 – 9) Brand Name: Sunday Test Standards: FCC Part 15 Subpart C, Paragraph 15.249 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.4&FCC Part 15 Subpart C, Paragraph 15.249 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: Sep 12, 2014 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO., LTD East 5/Block 4, Anhua Industrial Zone, No.8,Tairan Rd. CheGongMiao, FuTian District, Shenzhen, CHINA. Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No: 1408147-01 Page 2 of 36 Date: 2014-09-12 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co .,Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co .,Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co .,Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co .,Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 899988. IC- Registration No.: IC5205A-02 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration IC No.: 5205A-02. Report No: 1408147-01 Page 3 of 36 Date: 2014-09-12 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co .,Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co .,Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co .,Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co .,Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 4 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 5 3.0 Technical Details............................................................................................. 6 3.1 Summary of Test Results..................................................................................... 6 3.2 Test Standards.................................................................................................. 6 4.0 EUT Modification............................................................................................. 6 5.0 Power Line Conducted Emission Test...................................................................... 7 5.1 Schematics of the Test........................................................................................ 7 5.2 Test Method and Test Procedure............................................................................ 7 5.3 Configuratio…
