XR2WIZFI250WiFi Module

[鍵入文字] This document is controlled and confidential under the terms of WIZNET . 1 WizFi250 User Manual Datasheet July 10 2013 Rev 2.1 802.11b/g/n WICED Module (WM-N-BM-14) FCC Statement NOTICE; 1. The RF module limited to OEM installation ONLY. The OEM integrator is responsible for the compliance to all the rules that apply to the product into which this certified RF module is integrated. 2. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 3. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient or relocate the receiving antenna. l Increase the separation between the equipment and receiver. l Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. l Consult the dealer or an experienced radio/TV technician for help. FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is intended only for OEM integrators under the following conditions: The antenna must be installed such that 20 cm is maintained between the antenna and users, and The transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed. This document is controlled and confidential under the terms of WIZNET . 2 IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co- location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: XR2WIZFI250”. The grantee's FCC ID can be used only when all FCC/ IC compliance requirements are met. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user's manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. This document is controlled and confidential under the terms of WIZNET . 3 802.11b/g/n Wireless LAN WICED Module This document is controlled and confidential under the terms of WIZNET . 4 Introduction The WM-N-BM-14 wireless WICED module which is a small size module and consists of a Broadcom BCM43362 single-chip, a ST STM32F205RG MCU, and a 2.4G antenna. The WM-N-BM-14 provides for the highest-level integration, featuring 802.11b/g and 802.11n. It includes a 2.4 GHz WLAN CMOS power amplifier (PA) that meets the output power requirements of most handheld systems. An optional external low-noise amplifier (LNA) and external PA are also supported. Along with the integrated power amplifier, the WM-N- BM-14 also includes integrated transmit and receive baluns, further reducing the overall solution cost. The small size & low profile physical design make it easier for system design to enable high performance wireless connectivity without space constrain. This multi- functionality and board to board physical interface provides SPI/I2C/I2S/UART interface options. Hardware WAPI acceleration engine, AES, TKIP, WPA and WPA2 are supported to provide the latest security requirement on your network. For the software and driver development, USI provides extensive technical document and reference software code for the system integration under the agreement of Broadcom International Ltd. Hardware evaluation kit and development utilities will be released base on listed OS and processors to OEM customers. Features BCM43362 Wi-Fi
Single band 2.4GHz IEEE 802.11b/g/n
Supports wireless data rates up to 65Mbit/s
Integrated RF power amplifier STM32F205RGY6 Microprocessor
ARM 32-bit Cortex-M3 CPU
CPU frequency up to 120MHz
1 MB Flash memory
128 kB SRAM
Low-power sleep, standby and stop modes
Extend one 8Mbit Flash memory WM-N-BM-14 Wireless Module
Featuring integrated IEEE 802.11 b/g/n
Supports per packet Rx Antenna diversity
Low power consumption & excellent power management performance ext…

Text truncated - open the document above for the full version.

WIZNET Co., LTD. 4F Humax Village, 11-4, Sunae-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Date: March 3, 2014 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To whom it may concern: I, the undersigned, hereby authorize KT Kang of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by KT Kang of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; WIZNET Co., LTD. 4F Humax Village, 11-4, Sunae-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Byung- kook Kim / Senior Engineer REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

WIZNET Co., LTD. 4F Humax Village, 11-4, Sunae-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Date: March 3, 2014 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: XR2WIZFI250 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Part List CONF APPENDIX_ WizFi250_Part List.PDF Schematics Diagram(s) CONF APPENDIX_ WizFi250_Circuit diagram.PDF Block diagram CONF APPENDIX_ WizFi250_Block diagram.PDF Operation description CONF APPENDIX_ WizFi250_Operation description.PDF The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Byung- kook Kim / Senior Engineer

WIZNET Co., LTD. 4F Humax Village, 11-4, Sunae-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Applicant / Grantee WIZNET Co., LTD. FCC ID XR2WIZFI250 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The device is equipped with Metal shielding to cover RF section. Refer to the external photos Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. All inputs to the modules are buffered through logic or microprocessor inputs. Y 3 The modular transmitter must have its own power supply regulation.. Power supply regulation built into module. Refer to the circuit diagram. Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Connector is unique. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters Refer to the test report and setup photo. Y WIZNET Co., LTD. 4F Humax Village, 11-4, Sunae-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A Label is to be placed on front of the EUT, and other label is to be placed in the User Manual. Refer to the FCC ID label format. Y WIZNET Co., LTD. 4F Humax Village, 11-4, Sunae-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea copy of these instructions must be included in the application for equipment authorization. 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Refer to the User manual Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. It complies with RF exposure requirement. Y Byung-kook Kim / Senior Engineer WIZNET Co., LTD

External photos Model No.: WizFi250 Page 1 of 4 External photos Model No.: WizFi250 Page 2 of 4 External photos Model No.: WizFi250 Page 3 of 4 External photos Model No.: WizFi250 Page 4 of 4

Internal photos Model No.: WizFi250 Page 1 of 1

Model No.: WizFi250 Page 1 of 1 RF exposure According to FCC part 1.1310 : The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in § 1.1307(b) Limits for Maximum Permissible Exposure (MPE) f= frequency in ㎒ Friis transmission formula: Pd = (Pout×G)/(4×pi×R 2 ) Where, Pd = power density in ㎽/㎠ Pout = output power to antenna in ㎽ G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd the limit of MPE, f/1500 ㎽/㎠. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Results - UFL type PCB antenna Operation mode / Data Rate Frequency (㎒) Peak output power (㏈m) Antenna gain (㏈i) Power density at 20 ㎝(㎽/㎠) Limit (㎽/㎠) 802.11g / 6Mbps 2 412 19.32 2.50 0.042 53 1 802.11g / 6Mbps 2 437 18.76 2.50 0.037 38 1 802.11g / 6Mbps 2 462 18.86 2.50 0.038 25 1 - PCB antenna Operation mode / Data Rate Frequency (㎒) Peak output power (㏈m) Antenna gain (㏈i) Power density at 20 ㎝(㎽/㎠) Limit (㎽/㎠) 802.11g / 6Mbps 2 412 20.15 4.15 0.085 46 1 802.11g / 6Mbps 2 437 20.14 4.15 0.085 27 1 802.11g / 6Mbps 2 462 19.86 4.15 0.079 94 1 Frequency range (㎒) Electric field strength(V/m) Magnetic field strength (A/m) Power density (㎽/㎠) Average time (A) Limits for Occupational / Control Exposures 300 – 1 500 -- -- f/300 6 1 500 - 100000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300 – 1 500 -- -- f/1500 6 1 500 – 100 000 -- -- 1 30

KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (2 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 Revision history Revision Date of issue Test report No. Description - 2014.03.18 KES-RF-14T0004 Initial KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (3 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 TABLE OF CONTENTS 1. General information ................................................................................................................................................... 4 1.1. EUT description ........................................................................................................................................ 4 1.2. Test frequency ........................................................................................................................................... 4 1.3. Information about derivative model .......................................................................................................... 4 1.4. Device modifications ................................................................................................................................. 4 1.5 Device information .................................................................................................................................... 4 1.6. Test facility ................................................................................................................................................ 5 1.7. Laboratory accreditations and listings ....................................................................................................... 5 2. Summary of tests ........................................................................................................................................................ 6 3. Test results .................................................................................................................................................................. 9 3.1 Radiated spurious emissions...................................................................................................................... 9 3.2 Conducted spurious emissions ................................................................................................................ 21 3.3. 6 ㏈ bandwidth ...................................................................................................................................... 40 3.4. Output power ........................................................................................................................................... 51 3.5. Power spectral density ............................................................................................................................. 54 3.6. AC conducted emissions ......................................................................................................................... 65 Appendix A. Measurement equipment ......................................................................................................................... 70 Appendix B. Test setup photo ....................................................................................................................................... 71 KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (4 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 1. General information 1.1. EUT description Equipment under test Wifi Module Model name WizFi250 Serial number N/A Frequency range 2 412 ㎒ ~ 2 462 ㎒ (802.11 b/g/n_HT20) Modulation technique DSSS, OFDM Number of channels 11(802.11 b/g/n_HT20) Antenna type & gain UFL type PCB antenna // 2.50 ㏈i PCB antenna // 4.15 ㏈i Power source DC 3.3 V 1.2. Test frequency - 802.11b/g/n_HT20 Low channel Middle channel High channel Frequency (㎒) 2 412 2 442 2 462 1.3. Information about derivative model N/A 1.4. Device modifications N/A 1.5 Device information - The device have two type antenna. When it use a UFL type PCB antenna, PCB Antenna does not operating, and vice versa. - The device does not transmit simultaneously for UFL type PCB antenna and PCB antenna. - The device duty cycle ≥ 98 percent KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (5 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 1.6. Test facility C-3701, Simin-daero 365-40, Dongan-gu, Anyang-si, Gyeonggi-do,431-716, Korea 473-29, Gayeo-ro, Yeoju-si, Gyeonggi-do, Korea The open area test site is constructed in conformance with the requirements ANSI C63.4-2003/2009. 1.7. Laboratory accreditations and listings Country Agency Scope of accreditation Certificate No. USA FCC 3 & 10 meter Open Area Test Sites and one conducted site to perform FCC Part 15/18 measurements. 343818 KOREA KC EMI (10 meter Open Area Test Site and two conducted sites) Radio (3 & 10 meter Open Area Test Sites and one conducted site) KR0100 CANADA IC 3 & 10 meter Open Area Test Sites…

Text truncated - open the document above for the full version.

KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (40 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 3.3. 6 ㏈ bandwidth Test setup EUT Attenuator Spectrum analyzer Test procedure KDB 558074_v03r01 – section 8.2 option 1 or option 2. Option 1: a) Set RBW = 100 ㎑. b) Set the video bandwidth(VBW) ≥ 3 × RBW. c) Detector = peak. d) Trace mode = max hold. e) Sweep = auto couple. f) Allow the trace to stabilize. g) Measure the maximum width of the emission that is constrained by the frequencies associated with the two outermost amplitude points (upper and lower frequencies) that are attenuated by 6 ㏈ relative to the maximum level measured in the fundamental emission. Option 2: The automatic bandwidth measurement capability of an instrument may be employed using the X bandwidth mode with X set to 6 ㏈, if the functionality described above (i.e., RBW = 100 ㎑, VBW ≥ 3 × RBW, peak detector with maximum hold) is implemented by the instrumentation function. When using this capability, care shall be taken so that the bandwidth measurement is not influenced by any intermediate power nulls in the fundamental emission that might be ≥ 6 ㏈. Limit According to §15.247(a)(2), systems using digital modulation techniques may operate 902 ~ 928 ㎒, 2 400 ~ 2 483.5 ㎒, and 5 725 ~ 5 850 ㎒ bands. The minimum 6 ㏈ bandwidth shall be at least 500 ㎑. KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (41 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 Test results - UFL type PCB antenna - PCB antenna Operation mode Frequency(㎒) 6 ㏈ bandwidth(㎒) Limit(㎒) 802.11b 2 412 7.21 0.5 2 437 7.35 2 462 7.79 802.11g 2 412 15.08 2 437 15.08 2 462 15.08 802.11n (HT20) 2 412 15.08 2 437 15.11 2 462 15.08 Operation mode Frequency(㎒) 6 ㏈ bandwidth(㎒) Limit(㎒) 802.11b 2 412 7.70 0.5 2 437 7.79 2 462 7.82 802.11g 2 412 15.31 2 437 15.11 2 462 15.08 802.11n (HT20) 2 412 15.11 2 437 15.11 2 462 15.11 KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (42 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 - UFL type PCB antenna 802.11b // Low channel 802.11b // Middle channel KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (43 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 802.11b // High channel 802.11g // Low channel KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (44 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 802.11g // Middle channel 802.11g // High channel KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (45 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 802.11n(HT20) // Low channel 802.11n(HT20) // Middle channel KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (46 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 802.11n(HT20) // High channel - PCB antenna 802.11b // Low channel KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (47 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 802.11b // Middle channel 802.11b // High channel KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (48 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 802.11g // Low channel 802.11g // Middle channel KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (49 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 802.11g …

Text truncated - open the document above for the full version.

KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test report No.: KES-RF-13T0004 Page (71 ) of (72) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The test results in the report only apply to the tested sample. KES-P-5101-14 Rev. 1 KES A4 Appendix B. Test setup photo Radiated spurious KES Co., Ltd. C-3701, Simin-daero 365-40l, Dongan-gu, Anyang-si, Gyeonggi-do, 431-716, Korea Tel: +82-31-425-6200 / Fax…
