XS5-IONM1719HPION-M17HP/19HP
Andrew Wireless System
Click to zoom
Application Details
- Equipment Class
- AMP - Amplifier
- Date of Grant
- Nov 15, 2011
- Application Purpose
- Original Equipment
- Date of Application
- Nov 15, 2011
- Equipment Note
- ION-M17HP/19HP
- Frequency Range
- 1930.00000000 - 1995.00000000
- Company
- Andrew Wireless System
- Country
- Germany
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Optical Remote Unit ION™-M17HP/19HP (ML-Cabinet) Manual MF0143AXA Manual for ION™-M17HP/19HP (ML-cab) Page 2 Manual ION-M17HP-19HP MF0143AXA.doc © Copyright 2011 CommScope, Inc. All rights reserved. Andrew Solutions is a trademark of CommScope, Inc. All information contained in this manual has been revised thoroughly. Yet Andrew Solutions accepts no liability for any omissions or faults. Andrew Solutions reserves the right to change all hard- and software characteristics without notice. Names of products mentioned herein are used for identification purposes only and may be trademarks and / or registered trademarks of their respective companies. No parts of this publication may be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronical, mechanical photocopying, recording or otherwise, without prior written permission of the publisher. Andrew Wireless Systems GmbH, 20-October-2011 Page 3 TABLE OF CONTENTS 1. GENERAL 6 1.1. USED ABBREVIATIONS 6 1.2. HEALTH AND SAFETY WARNINGS 7 1.3. ABOUT ANDREW SOLUTIONS 9 1.4. INTERNATIONAL CONTACT ADDRESSES FOR CUSTOMER SUPPORT 10 2. FUNCTIONAL DE SCRIPTION 12 2.1. PURPOSE 12 2.2. THE ION-M17HP/19HP (INTELLIGENT OPTICAL NETWORK; MMR) 12 3. COMMISSIONING 15 3.1. MECHANICAL INSTALLATION 15 3.1.1. General 15 3.1.2. Wall Mounting of RU 17 3.1.3. Pole Mounting of RU 18 3.2. ELECTRICAL INSTALLATION 20 3.2.1. General 20 3.2.2. Connections 21 3.2.3. Grounding 22 3.3. CONNECTION OF THE ANTENNA CABLES 23 3.4. POWER CONNECTION 23 3.5. OPTICAL-FIBRE-CABLE CONNECTION - RULES 24 3.5.1. Protective Plug 27 3.5.2. Protective-Tube Kit 29 3.6. COMMISSIONING 31 4. ALARMS 35 4.1. BITE AND ALARMS 35 4.2. HANDLING OF ALARMS 35 4.3. ALARM STATUS 35 4.4. STATUS LED ALARMS 36 4.5. EXTERNAL ALARM INPUTS AND OUTPUTS 37 Manual for ION™-M17HP/19HP (ML-cab) Page 4 Manual ION-M17HP-19HP MF0143AXA.doc 4.6. TROUBLESHOOTING 38 5. MAINTENANCE 39 5.1. GENERAL 39 5.2. REPLACING THE FAN UNIT 40 5.3. CLEANING THE HEAT SINK 41 6. APPENDIX 42 6.1. ILLUSTRATIONS 42 6.2. SPECIFICATIONS 43 6.2.1. Electrical Specifications 43 6.2.2. Mechanical Specifications 43 6.2.3. Environmental and Safety Specifications 43 6.3. SPARE PARTS 44 7. INDEX 45 Page 5 FIGURES AND TABLES figure 3-1 Mounting bracket installation ....................................................................17 figure 3-2 RU wall mounting .....................................................................................17 figure 3-3 Pole-mounting kit, view from different sides .............................................18 figure 3-4 Pole-mount ing, ML-cabinet, assembly drawing ........................................19 figure 3-5 Pole mounting of RU, finished ..................................................................19 figure 3-6 Connector flange of ION-M17HP/19HP....................................................21 figure 3-7 RS485 connector ......................................................................................22 figure 3-8 Grounding bolt..........................................................................................22 figure 3-9 Grounding bolt, schematic view ................................................................22 figure 3-10 AC power supply plug.............................................................................23 figure 3-11 Protective-plug assembly .......................................................................27 figure 3-12 Tube-kit installation .................................................................................30 figure 4-1 Flange connector, 5 poles........................................................................37 figure 4-2 Flange connector, 7 poles ........................................................................37 figure 4-3 Alarm inputs and outputs, standard ..........................................................38 figure 5-1 Fan unit and heat sink..............................................................................40 figure 6-1 Cabinet drawing........................................................................................42 table 1-1 List of international contact addresses.......................................................11 table 3-1 Specified torques.......................................................................................16 table 3-2 RS485 connector, pin assignment .............................................................22 table 4-1 Status LED alarms .....................................................................................36 Manual for ION™-M17HP/19HP (ML-cab) Page 6 Manual ION-M17HP-19HP MF0143AXA.doc 1. GENERAL 1.1. USED ABBREVIATIONS 3GPP 3 rd Generation Partnership Project 4G 4 th Generation ALC Automatic Level Control AMPS American Mobile Phone System or Advanced Mobile Phone System AWS Advanced Wireless Services BBU Battery Backup Unit BCCH Broadcast Control Channel BITE Built-In Test Equipment BTS Base Transceiver Station CDMA Code Division Multiple Access CEPT Conférénce Européenne des Postes et Télécommunications CF Center Frequency CFO Center Frequency Offset CPD Channel Power Detection DL Downlink DoC Declaration of Conformity EDGE Enhanced Data Rates for GSM Evolution ESD Electrostatic Discharge ETS European Telecommunication Standard ETSI European Telecommunication Standards Institute FCC Federal Communications Commission FSK Frequency Shift Keying GSM Global System for Mobile Communication GUI Graphical User Interface I 2 C-Bus Inter Integrated Circuit Bus (Philips) ID No Identification Number IF Intermediate Frequency LMT Local Maintenance Terminal LNA Low-Noise Amplifier LO Local Oscillator LTE Long Term Evolution MIMO Multiple Input Multiple Output MS Mobile Station OMC Operation and Maintenance Center OTRx Optical Transceiver = SRMU (Subrack Master Unit) PCMCIA Personal Computer Modem Communication International Association PCS Personal Communication System PSTN Public Switched Telephone Network R&TTE Radio & Tele…
Text truncated - open the document above for the full version.
Users Manual
Optical Remote Unit ION™-M17HP/19HP (ML-Cabinet) Manual MF0143AXA Manual for ION™-M17HP/19HP (ML-cab) Page 2 Manual ION-M17HP-19HP MF0143AXA.doc © Copyright 2011 CommScope, Inc. All rights reserved. Andrew Solutions is a trademark of CommScope, Inc. All information contained in this manual has been revised thoroughly. Yet Andrew Solutions accepts no liability for any omissions or faults. Andrew Solutions reserves the right to change all hard- and software characteristics without notice. Names of products mentioned herein are used for identification purposes only and may be trademarks and / or registered trademarks of their respective companies. No parts of this publication may be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronical, mechanical photocopying, recording or otherwise, without prior written permission of the publisher. Andrew Wireless Systems GmbH, 20-October-2011 Page 3 TABLE OF CONTENTS 1. GENERAL 6 1.1. USED ABBREVIATIONS 6 1.2. HEALTH AND SAFETY WARNINGS 7 1.3. ABOUT ANDREW SOLUTIONS 9 1.4. INTERNATIONAL CONTACT ADDRESSES FOR CUSTOMER SUPPORT 10 2. FUNCTIONAL DE SCRIPTION 12 2.1. PURPOSE 12 2.2. THE ION-M17HP/19HP (INTELLIGENT OPTICAL NETWORK; MMR) 12 3. COMMISSIONING 15 3.1. MECHANICAL INSTALLATION 15 3.1.1. General 15 3.1.2. Wall Mounting of RU 17 3.1.3. Pole Mounting of RU 18 3.2. ELECTRICAL INSTALLATION 20 3.2.1. General 20 3.2.2. Connections 21 3.2.3. Grounding 22 3.3. CONNECTION OF THE ANTENNA CABLES 23 3.4. POWER CONNECTION 23 3.5. OPTICAL-FIBRE-CABLE CONNECTION - RULES 24 3.5.1. Protective Plug 27 3.5.2. Protective-Tube Kit 29 3.6. COMMISSIONING 31 4. ALARMS 35 4.1. BITE AND ALARMS 35 4.2. HANDLING OF ALARMS 35 4.3. ALARM STATUS 35 4.4. STATUS LED ALARMS 36 4.5. EXTERNAL ALARM INPUTS AND OUTPUTS 37 Manual for ION™-M17HP/19HP (ML-cab) Page 4 Manual ION-M17HP-19HP MF0143AXA.doc 4.6. TROUBLESHOOTING 38 5. MAINTENANCE 39 5.1. GENERAL 39 5.2. REPLACING THE FAN UNIT 40 5.3. CLEANING THE HEAT SINK 41 6. APPENDIX 42 6.1. ILLUSTRATIONS 42 6.2. SPECIFICATIONS 43 6.2.1. Electrical Specifications 43 6.2.2. Mechanical Specifications 43 6.2.3. Environmental and Safety Specifications 43 6.3. SPARE PARTS 44 7. INDEX 45 Page 5 FIGURES AND TABLES figure 3-1 Mounting bracket installation ....................................................................17 figure 3-2 RU wall mounting .....................................................................................17 figure 3-3 Pole-mounting kit, view from different sides .............................................18 figure 3-4 Pole-mount ing, ML-cabinet, assembly drawing ........................................19 figure 3-5 Pole mounting of RU, finished ..................................................................19 figure 3-6 Connector flange of ION-M17HP/19HP....................................................21 figure 3-7 RS485 connector ......................................................................................22 figure 3-8 Grounding bolt..........................................................................................22 figure 3-9 Grounding bolt, schematic view ................................................................22 figure 3-10 AC power supply plug.............................................................................23 figure 3-11 Protective-plug assembly .......................................................................27 figure 3-12 Tube-kit installation .................................................................................30 figure 4-1 Flange connector, 5 poles........................................................................37 figure 4-2 Flange connector, 7 poles ........................................................................37 figure 4-3 Alarm inputs and outputs, standard ..........................................................38 figure 5-1 Fan unit and heat sink..............................................................................40 figure 6-1 Cabinet drawing........................................................................................42 table 1-1 List of international contact addresses.......................................................11 table 3-1 Specified torques.......................................................................................16 table 3-2 RS485 connector, pin assignment .............................................................22 table 4-1 Status LED alarms .....................................................................................36 Manual for ION™-M17HP/19HP (ML-cab) Page 6 Manual ION-M17HP-19HP MF0143AXA.doc 1. GENERAL 1.1. USED ABBREVIATIONS 3GPP 3 rd Generation Partnership Project 4G 4 th Generation ALC Automatic Level Control AMPS American Mobile Phone System or Advanced Mobile Phone System AWS Advanced Wireless Services BBU Battery Backup Unit BCCH Broadcast Control Channel BITE Built-In Test Equipment BTS Base Transceiver Station CDMA Code Division Multiple Access CEPT Conférénce Européenne des Postes et Télécommunications CF Center Frequency CFO Center Frequency Offset CPD Channel Power Detection DL Downlink DoC Declaration of Conformity EDGE Enhanced Data Rates for GSM Evolution ESD Electrostatic Discharge ETS European Telecommunication Standard ETSI European Telecommunication Standards Institute FCC Federal Communications Commission FSK Frequency Shift Keying GSM Global System for Mobile Communication GUI Graphical User Interface I 2 C-Bus Inter Integrated Circuit Bus (Philips) ID No Identification Number IF Intermediate Frequency LMT Local Maintenance Terminal LNA Low-Noise Amplifier LO Local Oscillator LTE Long Term Evolution MIMO Multiple Input Multiple Output MS Mobile Station OMC Operation and Maintenance Center OTRx Optical Transceiver = SRMU (Subrack Master Unit) PCMCIA Personal Computer Modem Communication International Association PCS Personal Communication System PSTN Public Switched Telephone Network R&TTE Radio & Tele…
Text truncated - open the document above for the full version.
Users Manual
Optical Remote Unit ION™-M17HP/19HP (ML-Cabinet) Manual MF0143AXA Manual for ION™-M17HP/19HP (ML-cab) Page 2 Manual ION-M17HP-19HP MF0143AXA.doc © Copyright 2011 CommScope, Inc. All rights reserved. Andrew Solutions is a trademark of CommScope, Inc. All information contained in this manual has been revised thoroughly. Yet Andrew Solutions accepts no liability for any omissions or faults. Andrew Solutions reserves the right to change all hard- and software characteristics without notice. Names of products mentioned herein are used for identification purposes only and may be trademarks and / or registered trademarks of their respective companies. No parts of this publication may be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronical, mechanical photocopying, recording or otherwise, without prior written permission of the publisher. Andrew Wireless Systems GmbH, 20-October-2011 Page 3 TABLE OF CONTENTS 1. GENERAL 6 1.1. USED ABBREVIATIONS 6 1.2. HEALTH AND SAFETY WARNINGS 7 1.3. ABOUT ANDREW SOLUTIONS 9 1.4. INTERNATIONAL CONTACT ADDRESSES FOR CUSTOMER SUPPORT 10 2. FUNCTIONAL DE SCRIPTION 12 2.1. PURPOSE 12 2.2. THE ION-M17HP/19HP (INTELLIGENT OPTICAL NETWORK; MMR) 12 3. COMMISSIONING 15 3.1. MECHANICAL INSTALLATION 15 3.1.1. General 15 3.1.2. Wall Mounting of RU 17 3.1.3. Pole Mounting of RU 18 3.2. ELECTRICAL INSTALLATION 20 3.2.1. General 20 3.2.2. Connections 21 3.2.3. Grounding 22 3.3. CONNECTION OF THE ANTENNA CABLES 23 3.4. POWER CONNECTION 23 3.5. OPTICAL-FIBRE-CABLE CONNECTION - RULES 24 3.5.1. Protective Plug 27 3.5.2. Protective-Tube Kit 29 3.6. COMMISSIONING 31 4. ALARMS 35 4.1. BITE AND ALARMS 35 4.2. HANDLING OF ALARMS 35 4.3. ALARM STATUS 35 4.4. STATUS LED ALARMS 36 4.5. EXTERNAL ALARM INPUTS AND OUTPUTS 37 Manual for ION™-M17HP/19HP (ML-cab) Page 4 Manual ION-M17HP-19HP MF0143AXA.doc 4.6. TROUBLESHOOTING 38 5. MAINTENANCE 39 5.1. GENERAL 39 5.2. REPLACING THE FAN UNIT 40 5.3. CLEANING THE HEAT SINK 41 6. APPENDIX 42 6.1. ILLUSTRATIONS 42 6.2. SPECIFICATIONS 43 6.2.1. Electrical Specifications 43 6.2.2. Mechanical Specifications 43 6.2.3. Environmental and Safety Specifications 43 6.3. SPARE PARTS 44 7. INDEX 45 Page 5 FIGURES AND TABLES figure 3-1 Mounting bracket installation ....................................................................17 figure 3-2 RU wall mounting .....................................................................................17 figure 3-3 Pole-mounting kit, view from different sides .............................................18 figure 3-4 Pole-mount ing, ML-cabinet, assembly drawing ........................................19 figure 3-5 Pole mounting of RU, finished ..................................................................19 figure 3-6 Connector flange of ION-M17HP/19HP....................................................21 figure 3-7 RS485 connector ......................................................................................22 figure 3-8 Grounding bolt..........................................................................................22 figure 3-9 Grounding bolt, schematic view ................................................................22 figure 3-10 AC power supply plug.............................................................................23 figure 3-11 Protective-plug assembly .......................................................................27 figure 3-12 Tube-kit installation .................................................................................30 figure 4-1 Flange connector, 5 poles........................................................................37 figure 4-2 Flange connector, 7 poles ........................................................................37 figure 4-3 Alarm inputs and outputs, standard ..........................................................38 figure 5-1 Fan unit and heat sink..............................................................................40 figure 6-1 Cabinet drawing........................................................................................42 table 1-1 List of international contact addresses.......................................................11 table 3-1 Specified torques.......................................................................................16 table 3-2 RS485 connector, pin assignment .............................................................22 table 4-1 Status LED alarms .....................................................................................36 Manual for ION™-M17HP/19HP (ML-cab) Page 6 Manual ION-M17HP-19HP MF0143AXA.doc 1. GENERAL 1.1. USED ABBREVIATIONS 3GPP 3 rd Generation Partnership Project 4G 4 th Generation ALC Automatic Level Control AMPS American Mobile Phone System or Advanced Mobile Phone System AWS Advanced Wireless Services BBU Battery Backup Unit BCCH Broadcast Control Channel BITE Built-In Test Equipment BTS Base Transceiver Station CDMA Code Division Multiple Access CEPT Conférénce Européenne des Postes et Télécommunications CF Center Frequency CFO Center Frequency Offset CPD Channel Power Detection DL Downlink DoC Declaration of Conformity EDGE Enhanced Data Rates for GSM Evolution ESD Electrostatic Discharge ETS European Telecommunication Standard ETSI European Telecommunication Standards Institute FCC Federal Communications Commission FSK Frequency Shift Keying GSM Global System for Mobile Communication GUI Graphical User Interface I 2 C-Bus Inter Integrated Circuit Bus (Philips) ID No Identification Number IF Intermediate Frequency LMT Local Maintenance Terminal LNA Low-Noise Amplifier LO Local Oscillator LTE Long Term Evolution MIMO Multiple Input Multiple Output MS Mobile Station OMC Operation and Maintenance Center OTRx Optical Transceiver = SRMU (Subrack Master Unit) PCMCIA Personal Computer Modem Communication International Association PCS Personal Communication System PSTN Public Switched Telephone Network R&TTE Radio & Tele…
Text truncated - open the document above for the full version.
Users Manual
Optical Remote Unit ION™-M17HP/19HP (ML-Cabinet) Manual MF0143AXA Manual for ION™-M17HP/19HP (ML-cab) Page 2 Manual ION-M17HP-19HP MF0143AXA.doc © Copyright 2011 CommScope, Inc. All rights reserved. Andrew Solutions is a trademark of CommScope, Inc. All information contained in this manual has been revised thoroughly. Yet Andrew Solutions accepts no liability for any omissions or faults. Andrew Solutions reserves the right to change all hard- and software characteristics without notice. Names of products mentioned herein are used for identification purposes only and may be trademarks and / or registered trademarks of their respective companies. No parts of this publication may be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronical, mechanical photocopying, recording or otherwise, without prior written permission of the publisher. Andrew Wireless Systems GmbH, 20-October-2011 Page 3 TABLE OF CONTENTS 1. GENERAL 6 1.1. USED ABBREVIATIONS 6 1.2. HEALTH AND SAFETY WARNINGS 7 1.3. ABOUT ANDREW SOLUTIONS 9 1.4. INTERNATIONAL CONTACT ADDRESSES FOR CUSTOMER SUPPORT 10 2. FUNCTIONAL DE SCRIPTION 12 2.1. PURPOSE 12 2.2. THE ION-M17HP/19HP (INTELLIGENT OPTICAL NETWORK; MMR) 12 3. COMMISSIONING 15 3.1. MECHANICAL INSTALLATION 15 3.1.1. General 15 3.1.2. Wall Mounting of RU 17 3.1.3. Pole Mounting of RU 18 3.2. ELECTRICAL INSTALLATION 20 3.2.1. General 20 3.2.2. Connections 21 3.2.3. Grounding 22 3.3. CONNECTION OF THE ANTENNA CABLES 23 3.4. POWER CONNECTION 23 3.5. OPTICAL-FIBRE-CABLE CONNECTION - RULES 24 3.5.1. Protective Plug 27 3.5.2. Protective-Tube Kit 29 3.6. COMMISSIONING 31 4. ALARMS 35 4.1. BITE AND ALARMS 35 4.2. HANDLING OF ALARMS 35 4.3. ALARM STATUS 35 4.4. STATUS LED ALARMS 36 4.5. EXTERNAL ALARM INPUTS AND OUTPUTS 37 Manual for ION™-M17HP/19HP (ML-cab) Page 4 Manual ION-M17HP-19HP MF0143AXA.doc 4.6. TROUBLESHOOTING 38 5. MAINTENANCE 39 5.1. GENERAL 39 5.2. REPLACING THE FAN UNIT 40 5.3. CLEANING THE HEAT SINK 41 6. APPENDIX 42 6.1. ILLUSTRATIONS 42 6.2. SPECIFICATIONS 43 6.2.1. Electrical Specifications 43 6.2.2. Mechanical Specifications 43 6.2.3. Environmental and Safety Specifications 43 6.3. SPARE PARTS 44 7. INDEX 45 Page 5 FIGURES AND TABLES figure 3-1 Mounting bracket installation ....................................................................17 figure 3-2 RU wall mounting .....................................................................................17 figure 3-3 Pole-mounting kit, view from different sides .............................................18 figure 3-4 Pole-mount ing, ML-cabinet, assembly drawing ........................................19 figure 3-5 Pole mounting of RU, finished ..................................................................19 figure 3-6 Connector flange of ION-M17HP/19HP....................................................21 figure 3-7 RS485 connector ......................................................................................22 figure 3-8 Grounding bolt..........................................................................................22 figure 3-9 Grounding bolt, schematic view ................................................................22 figure 3-10 AC power supply plug.............................................................................23 figure 3-11 Protective-plug assembly .......................................................................27 figure 3-12 Tube-kit installation .................................................................................30 figure 4-1 Flange connector, 5 poles........................................................................37 figure 4-2 Flange connector, 7 poles ........................................................................37 figure 4-3 Alarm inputs and outputs, standard ..........................................................38 figure 5-1 Fan unit and heat sink..............................................................................40 figure 6-1 Cabinet drawing........................................................................................42 table 1-1 List of international contact addresses.......................................................11 table 3-1 Specified torques.......................................................................................16 table 3-2 RS485 connector, pin assignment .............................................................22 table 4-1 Status LED alarms .....................................................................................36 Manual for ION™-M17HP/19HP (ML-cab) Page 6 Manual ION-M17HP-19HP MF0143AXA.doc 1. GENERAL 1.1. USED ABBREVIATIONS 3GPP 3 rd Generation Partnership Project 4G 4 th Generation ALC Automatic Level Control AMPS American Mobile Phone System or Advanced Mobile Phone System AWS Advanced Wireless Services BBU Battery Backup Unit BCCH Broadcast Control Channel BITE Built-In Test Equipment BTS Base Transceiver Station CDMA Code Division Multiple Access CEPT Conférénce Européenne des Postes et Télécommunications CF Center Frequency CFO Center Frequency Offset CPD Channel Power Detection DL Downlink DoC Declaration of Conformity EDGE Enhanced Data Rates for GSM Evolution ESD Electrostatic Discharge ETS European Telecommunication Standard ETSI European Telecommunication Standards Institute FCC Federal Communications Commission FSK Frequency Shift Keying GSM Global System for Mobile Communication GUI Graphical User Interface I 2 C-Bus Inter Integrated Circuit Bus (Philips) ID No Identification Number IF Intermediate Frequency LMT Local Maintenance Terminal LNA Low-Noise Amplifier LO Local Oscillator LTE Long Term Evolution MIMO Multiple Input Multiple Output MS Mobile Station OMC Operation and Maintenance Center OTRx Optical Transceiver = SRMU (Subrack Master Unit) PCMCIA Personal Computer Modem Communication International Association PCS Personal Communication System PSTN Public Switched Telephone Network R&TTE Radio & Tele…
Text truncated - open the document above for the full version.
External Photos
External Photos
External Photos
External Photos
External Photos
External Photos
External Photos
External Photos
ID Label/Location Info
Label Location
ID Label/Location Info
Label Location
ID Label/Location Info
Label Location
ID Label/Location Info
Label Location
Internal Photos
Internal Photos
Internal Photos
Internal Photos
Internal Photos
Internal Photos
Internal Photos
Internal Photos
RF Exposure Info
RF Exposure Info / MPE Sample Calculation Model: ION‐M17HP/19HP FCC‐ID: XS5‐IONM1719P The ION‐M17HP/19HP is a fiber optic based RF repeater for wireless applications. An RF signal is converted to an optical signal by directly modulating a laser. There is no frequency conversion in this system. The optical signal is converted back to RF at the ION‐M remote unit, amplified and broadcast from an antenna or into a passive RF distribution system, such as radiating cable. The RF gain in the system is maintained at a constant level throughout the system via AGC and the user does not need to adjust the gain of the system. The user would inject an RF signal to produce the appropriate RF output power from the ION‐M remote unit. The receive path will always terminate in an RF source, such as a base station or repeater, and will not be directly connected to any antenna. The specific device generally will be professionally installed. Hereby the gain of the finally installed antenna(s), cable attenuation and antenna height will be defined site specific at the time of licensing with the appropriate FCC Bureau(s). The maximum permissible exposure limit is defined in 47 CFR 1.1310 (B). Limits for General Population / Uncontrolled Exposures Frequency Range (MHz) Power Density (mW/cm 2 ) 1550 – 100,000 1 The EUT operates in the 2 frequency bands: 2100 and 1900 MHz. The limit for Power Density is 1 mW/cm 2 . The max measured conducted output power is 46.0 dBm (40 W) at the 2100 MHz path and 46.0 dBm (40W) at the 1900 MHz path. The maximum permitted level is to be calculated using general equation: S = P*G/4πR 2 P = 40W; G = antenna‐cable attenuation to be defined (numeric gain); π = 3,1416 The min separation distance between the antenna and any human body is to be calculated (solving for R in cm) with the final actual antenna gain/cable attenuation where the limit of 1mW/cm 2 is kept. Example: For f=1930MHz (1 mW/cm 2 and P=46 dBm) and a gain = 9 dBi the calculated distance is R = 1.586 m. The antenna(s) used with device must be fixed‐mounted on permanent structures with a distance to any human body to comply with the RF Exposure limit.
RF Exposure Info
RF Exposure Info / MPE Sample Calculation Model: ION‐M17HP/19HP FCC‐ID: XS5‐IONM1719P The ION‐M17HP/19HP is a fiber optic based RF repeater for wireless applications. An RF signal is converted to an optical signal by directly modulating a laser. There is no frequency conversion in this system. The optical signal is converted back to RF at the ION‐M remote unit, amplified and broadcast from an antenna or into a passive RF distribution system, such as radiating cable. The RF gain in the system is maintained at a constant level throughout the system via AGC and the user does not need to adjust the gain of the system. The user would inject an RF signal to produce the appropriate RF output power from the ION‐M remote unit. The receive path will always terminate in an RF source, such as a base station or repeater, and will not be directly connected to any antenna. The specific device generally will be professionally installed. Hereby the gain of the finally installed antenna(s), cable attenuation and antenna height will be defined site specific at the time of licensing with the appropriate FCC Bureau(s). The maximum permissible exposure limit is defined in 47 CFR 1.1310 (B). Limits for General Population / Uncontrolled Exposures Frequency Range (MHz) Power Density (mW/cm 2 ) 1550 – 100,000 1 The EUT operates in the 2 frequency bands: 2100 and 1900 MHz. The limit for Power Density is 1 mW/cm 2 . The max measured conducted output power is 46.0 dBm (40 W) at the 2100 MHz path and 46.0 dBm (40W) at the 1900 MHz path. The maximum permitted level is to be calculated using general equation: S = P*G/4πR 2 P = 40W; G = antenna‐cable attenuation to be defined (numeric gain); π = 3,1416 The min separation distance between the antenna and any human body is to be calculated (solving for R in cm) with the final actual antenna gain/cable attenuation where the limit of 1mW/cm 2 is kept. Example: For f=1930MHz (1 mW/cm 2 and P=46 dBm) and a gain = 9 dBi the calculated distance is R = 1.586 m. The antenna(s) used with device must be fixed‐mounted on permanent structures with a distance to any human body to comply with the RF Exposure limit.
Test Report
Test Site: FCC Test Site No.: 96997 IC OATS No.: IC3475A-1 The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-11-237-V01.00 Page 1 of 35 Date of issue: 07.10.11 Signature: Issue-No.: 01 Author: T. Zahlmann Test engineer Date of delivery: Checked: M. Lehmann Head of ECL Test dates: 22.09. – 28.09.11 Pages: 35 ECL-EMC Test Report No.: 11-237 Equipment under test: ION-M17HP/19HP 1700MHz Path FCC ID: XS5-IONM1719HP IC ID: 2237E-IONM1719HP Type of test: FCC 47 CFR Part 27 Subpart C: 2011 Miscellaneous Wireless Communication Services IC RSS-131:2003 Zone Enhancers for the Land Mobile Service Measurement Procedures: 47 CFR Parts 2 (Frequency Allocations and Radio Treaty Matters; General Rules and Regulations), Part 27:2011 (Miscellaneous Wireless Communication Services), ANSI/TIA-603-C (2004), Land Mobile FM or PM Communications Equipment Measurement and Performance Standards IC-GEN General Requirements and Information for the Certification of Radiocommunication Equipment Test result: Passed Test Report No.: 11-237 FCC ID: XS5-M1719HP IC ID: 2237E-M1719HP The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-11-237-V01.00 Page 2 of 35 Manufacturer: ANDREW Wireless Systems GmbH Industriering 10 D-86675 Buchdorf Tel.: +49 (0)9099 69 0 Fax: +49 (0)9099 69 140 Test Location: TEMPTON Service Plus GmbH European Compliance Laboratory (ECL) Thurn-und-Taxis-Straße 18 D-9…
Text truncated - open the document above for the full version.
