CommScope ERA ® UAP2 with Copper Interface Installation Guide Release P/N M0203AA, DRAFT Rev C 31 Aug 2023 DRAFT: CONFIDENTIAL Copyright Statement Copyright statement for DAS and Small Cell documents. Copyright © 2023 CommScope, All rights reserved. THIS DOCUMENT HAS BEEN DEVELOPED BY COMMSCOPE, AND IS INTENDED FOR THE USE OF ITS CUSTOMERS AND CUSTOMER SUPPORT PERSONNEL. THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS. THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR COMMSCOPE SALES REPRESENTATIVE FOR A COPY. DRAFT: CONFIDENTIAL CommScope ERA ® UAP2 with Copper Interface Installation Guide , Release P/N M0203AA, DRAFT Rev C2 Document Revision History This is the third release of the UAP2 with Copper Interface Installation Guide. This release ■revises Table 3: Maximum Power Output by Frequency (page 12) ■added 2 new points in Powering on a Copper UAP2 (page 32). DRAFT: CONFIDENTIAL CommScope ERA ® UAP2 with Copper Interface Installation Guide , Release P/N M0203AA, DRAFT Rev C3 Contents Copyright Statement...........................................................................................................................2 Document Revision History.................................................................................................................3 Chapter 1. Document Overview..........................................................................................................6 Document Cautions and Notes.............................................................................................................6 Abbreviations Used in this Guide..........................................................................................................7 Safely Working with ERA Hardware......................................................................................................8 Health and Safety Precautions........................................................................................................8 Property Damage Warnings............................................................................................................8 General Installation Safety Requirements...................................................................................... 9 Guard Against Damage from Electro-Static Discharge....................................................................9 Compliance..................................................................................................................................... 9 Equipment Symbols Used / Compliance.......................................................................................11 Maximum Output Power Levels....................................................................................................12 Chapter 2. Copper UAP2 Overview....................................................................................................13 UAP2 Accessories and Options........................................................................................................... 13 Mounting Kits............................................................................................................................... 13 Chapter 3. Plan And Prepare for a Copper UAP2 Installation............................................................. 14 Maximum Number of UAP2s Supported in an ERA System................................................................14 UAP2 Dimensions............................................................................................................................... 15 Unpack and Inspect the UAP2 and Accessories..................................................................................15 Obtain the Required Materials........................................................................................................... 16 Rules for Using Cat6A Cables and Connectors....................................................................................16 Chapter 4. Mount the Copper UAP2..................................................................................................18 General Mounting Cautions................................................................................................................18 Mounting a UAP2 on a Ceiling............................................................................................................ 18 Mounting a UAP2 on a Wall................................................................................................................24 Chapter 5. Connect a Copper UAP2 to a Classic CAN OR TEN............................................................. 31 Chapter 6. Powering on a Copper UAP2 ............................................................................................32 DRAFT: CONFIDENTIAL CommScope ERA ® UAP2 with Copper Interface Installation Guide , Release P/N M0203AA, DRAFT Rev C4 Chapter 7. CAT6A Specifications and Testing Requirements...............................................................33 Contacting CommScope....................................................................................................................35 DAS and Small Cell Technical Support.................................................................................................35 Telephone Helplines..................................................................................................................... 35 Online Support........................................................…

Text truncated - open the document above for the full version.

CommScope ERA ® UAP2 with Fiber Interface Installation Guide Release P/N M0203AB, DRAFT Rev D 31 Aug 2023 DRAFT: CONFIDENTIAL Copyright Statement Copyright statement for DAS and Small Cell documents. Copyright © 2023 CommScope, All rights reserved. THIS DOCUMENT HAS BEEN DEVELOPED BY COMMSCOPE, AND IS INTENDED FOR THE USE OF ITS CUSTOMERS AND CUSTOMER SUPPORT PERSONNEL. THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS. THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR COMMSCOPE SALES REPRESENTATIVE FOR A COPY. DRAFT: CONFIDENTIAL CommScope ERA ® UAP2 with Fiber Interface Installation Guide , Release P/N M0203AB, DRAFT Rev D2 Document Revision History This is the fourth release of the UAP2 with Fiber Interface Installation Guide. This release ■revises Table 3: Maximum Power Output by Frequency (page 12) ■added 2 new points in Powering on a Fiber UAP2 (page 39). DRAFT: CONFIDENTIAL CommScope ERA ® UAP2 with Fiber Interface Installation Guide , Release P/N M0203AB, DRAFT Rev D3 Contents Copyright Statement...........................................................................................................................2 Document Revision History.................................................................................................................3 Chapter 1. Document Overview..........................................................................................................6 Document Cautions and Notes.............................................................................................................6 Abbreviations Used in this Guide..........................................................................................................7 Safely Working with ERA Hardware......................................................................................................8 Health and Safety Precautions........................................................................................................8 Property Damage Warnings............................................................................................................8 General Installation Safety Requirements...................................................................................... 9 Guard Against Damage from Electro-Static Discharge....................................................................9 Compliance................................................................................................................................... 10 Equipment Symbols Used / Compliance.......................................................................................11 Maximum Output Power Levels....................................................................................................12 Chapter 2. Fiber UAP2 ......................................................................................................................14 Overview.............................................................................................................................................14 UAP2 Accessories and Options........................................................................................................... 15 Mounting and Power Kits............................................................................................................. 15 SFP+ Modules............................................................................................................................... 15 Chapter 3. Plan and Prepare For A Fiber UAP2 Installation................................................................18 Determine the Power Consumption of the UAP2...............................................................................18 UAP2 Dimensions............................................................................................................................... 18 Unpack and Inspect the UAP2 and Accessories..................................................................................19 Obtain the Required Materials........................................................................................................... 19 Chapter 4. Mount the Fiber UAP2..................................................................................................... 20 General Mounting Cautions................................................................................................................20 Mounting a UAP2 with an AC/DC Power Supply Kit........................................................................... 20 Attach the Power Supply to the UAP2.......................................................................................... 20 Mounting a UAP2 with a Hybrid Splice Kit..........................................................................................21 Assembling and Wiring the Hybrid Fiber Splice Box.....................................................................21 Mounting a UAP2 on a Ceiling............................................................................................................ 29 Mounting a UAP2 on a Wall................................................................................................................34 DRAFT: CONFIDENTIAL CommScope ERA ® UAP2 with Fiber Interface Installation Guide , Release P/N M0203AB, DRAFT Rev D4 Connect the Fiber UAP2 to a Classic CAN or TEN............................................................................... 38 Chapter 5. Powering on a Fiber UAP2................…

Text truncated - open the document above for the full version.

Andrew Wireless Systems GmbH Industriering 10 86675 Buchdorf Germany Covered Equipment Certification Attestation Letter 9/25/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: XS5-RML2BDOD Andrew Wireless Systems GmbH (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Andrew Wireless Systems GmbH (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Cecka Jiri Title: Manager Quality Company Name: Andrew Wireless Systems GmbH Date: 9/25/2023

* the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter September 26, 2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: XS5-RML2BDOD Per section 2.911 (d) (7) of the FCC rules, Andrew Wireless Systems GmbH (“the applicant”), FRN: 0019152750, certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: CommScope Technologies LLC Physical U.S. Company Address: 900 Chelmsford Street Lowell, MA 01851 Agent name: Zachary Johnson Agent Email Address: [email protected] FRN: 0033464595 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: Cecka Jiri Printed name: Zachary Johnson Title: Manager Quality Title: Regulatory Engineer Company Name: Andrew Wireless Systems Company Name: CommScope Technologies LLC Date: September 25, 2023 Date: September 20, 2023

Andrew Wireless Systems GmbH Industriering 10 86675 Buchdorf Germany WARNING LABELING ATTESTATION LETTER FCC ID: XS5-RML2BDOD To whom it may concern, Warning label messages will be also shown in online and point-of-sale marketing materials and on outside packaging of device (per KDB 935210 D02) Warning labelling information: For Industrial Signal Boosters WARNING. This is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express consent of an FCC Licensee to operate this device. Unauthorized use may result in significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation. For Class B signal boosters WARNING. This is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express consent of an FCC Licensee to operate this device. You MUST register Class B signal boosters (as defined in 47 CFR 90.219) online at www.fcc.gov/signal- boosters/registration. Unauthorized use may result in significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation. Label will appear: - on the product itself as label - on the packaging as label - in the manual - in the data sheet - in sales brochures - in all other electronic media where customer has access Part 90 Class B Signal Booster Registration https://signalboosters.fcc.gov/signal-boosters/ Sincerely, Printed name: Cecka Jiri Title: Manager Quality Company Name: Andrew Wireless Systems Date: 10/16/2023

Andrew Wireless Systems GmbH Industriering 10 86675 Buchdorf Germany Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: XS5-RML2BDOD AUTHORITY TO ACT AS AGENT - FCC On our behalf, I appoint Nemko North America, Inc., to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti- Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko North America Inc., still resides still resides with us. Sincerely, Printed name: Cecka Jiri Title: Manager Quality Company Name: Andrew Wireless Systems GmbH Date: 9/25/2023

Andrew Wireless Systems GmbH Industriering 10 86675 Buchdorf Germany Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: XS5-RML2BDOD Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request permanent confidential treatment of exhibits identified as such in the table below and request they are permanently withheld from public review based on the documents containing trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. We also request short-term confidentiality on certain exhibits until the intended date of marketing as outlined below. We request the exhibits be withheld from public view for a period of 180 days. We attest marketing of the product will only commence after the period of short-term confidentiality expires, or if marketing is to commence before the requested number of days listed above, the grantee will inform Nemko to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. Exhibit Type of Confidentiality Requested Block Diagrams ☒ Permanent ☐ Short Term External Photos ------------------ ☐ Short Term Internal Photos ☐ Permanent* ☒ Short Term Operation Description ☒ Permanent ☐ Short Term Parts List & Placement/BOM ☒ Permanent ☐ Short Term Tune-Up Procedure ☒ Permanent ☐ Short Term Schematic Diagrams ☒ Permanent ☐ Short Term Test Setup Photos ------------------ ☐ Short Term User’s Manual ☐ Permanent* ☒ Short Term The asterisked items (*) require further information to be provided in this justification letter before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. Note: any documents held under the Short-Term confidentiality will automatically become public after the requested time if an appropriate extension request has not been received. Any exhibits (i.e., schematic diagrams) that may have already been requested to have “Permanent” confidentiality as shown above need not be repeated under Short-Term confidentiality request. Sincerely, Printed name: Cecka Jiri Title: Manager Quality Company Name: Andrew Wireless Systems GmbH Date: 9/25/2023

Radio Module 34T (DoD) – External picture 7855848-xx and 7855849-xx TOP View BOTTOM View Connector side view Rear side View (text as example) Left and Right side view

RM 34T – Radio Module 7855848-00, 7855849-00- Label picture Accreditation Label dimension Accreditation Label Picture Accreditation Label Position Accreditation Label dimension Accreditation Label picture Accreditation Label position

RM 34T – Assembled PCB 7855726-00- Internal picture

Manufacturer: Andrew Wireless Systems Name: Oscar Frau Product: Radio Module L2 DOD Title: Project Handler FCC ID: XS5-RML2BDOD Signature: MPE limits (§1.1310) Mode Frequency Duty Cycle Power Tolerance Antenna Peak Gain 5 EIRP 1,4 EIRP Distance PD 2 PD Limit 3 Margin PD/PD Limit Worst PD/PD values to be considered MHz % dBm dB dBi dBm mW cm mW/cm^2 mW/cm^2 dB LTE DoD Band 3452.5 100 24,1 1 4,3 32,4 (+3dB) 1738 20 0,345 72 1,000 4,61 0,34572 0,34572 1 EIRP = ( Power dBm + Antenna Gain dBi ) + 10 x Log ( Duty Cycle % / 100 ) 2 PD = EIRP / (4πD 2 ) 3 CFR 47 Part 1, §1.1310(e), table 1 4 +3dB considering MIMO mode 5 See Operational Description

This test report shall not be partially reproduced without the prior written consent of Nemko S.p.A. The phase of sampling of equipment under testis carried out by the customer. Results indicated in this report refer exclusively to the tested samples and apply to the sample as received. This Test Report, when bearing the Nemko name and logo is only valid when issued by a Nemko laboratory or by a laboratory having agreement with Nemko. Doc. No. TRF001 Rev. 1 Date 2022-10-31 C h o o s e S c a n d i n a v i a n t r u s t RADIO TEST REPORT – REP013856 Type of assessment: Final product testing Applicant: Product: Andrew Wireless Systems Industriering 10, Buchdorf 86675 Germany ERA L2 Radio Module Model: Model variant(s): Radio Module L2 DOD -- FCC ID: IC Registration number: XS5-RML2BDOD -- Specifications:  FCC 47 CFR Part 27 Date of issue: July 21, 2023 P. Barbieri Tested by Signature D. Guarnone Reviewed by Signature Report reference ID: REP013856 Page 2 of 120 Lab locations Company name Nemko Spa Address Via del Carroccio, 4 City Biassono Province MB Postal code 20853 Country Italy Telephone +39 039 220 12 01 Facsimile +39 039 220 12 21 Website www.nemko.com Site number 682159 Limits of responsibility Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Spa ISO/IEC 17025 accreditation. Copyright notification Nemko Spa authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Spa accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. Report reference ID: REP013856 Page 3 of 120 Table of Contents Table of Contents ......................................................................................................................................................................................................... 3 Report summary ................................................................................................................................................................................. 4 1.1 Test specifications .................................................................................................................................................................................................... 4 1.2 Test methods ............................................................................................................................................................................................................ 4 1.3 Exclusions ................................................................................................................................................................................................................. 4 1.4 Statement of compliance .......................................................................................................................................................................................... 4 1.5 Test report revision history ....................................................................................................................................................................................... 4 Engineering considerations ................................................................................................................................................................. 5 2.1 Modifications incorporated in the EUT for compliance ............................................................................................................................................ 5 2.2 Technical judgment .................................................................................................................................................................................................. 5 2.3 Deviations from laboratory tests procedures ........................................................................................................................................................... 5 Test conditions ................................................................................................................................................................................... 6 3.1 Atmospheric conditions ............................................................................................................................................................................................ 6 3.2 Power supply range .................................................................................................................................................................................................. 6 Measurement uncertainty .................................................................................................................................................................. 7 4.1 Uncertainty of measurement ................................................................................................................................................................................... 7 Information provided by the applicant ................................................................................................................................................ 8 5.1 Disclaimer ................................................................................................................................................................................................................. 8 5.2 Applicant/Manufacture .........................................................…

Text truncated - open the document above for the full version.

Section 8 Testing data Test name Out-of-band/out-of-block emissions conducted measurements Specification 935210 D05 Indus Booster Basic Meas v01r04 (3.6.2) Report reference ID: REP013856 Page 69 of 120 Test data, continued Figure 8.5-15: Antenna port 2 single carrier lower block edge with input signal at AGC threshold Section 8 Testing data Test name Out-of-band/out-of-block emissions conducted measurements Specification 935210 D05 Indus Booster Basic Meas v01r04 (3.6.2) Report reference ID: REP013856 Page 70 of 120 Test data, continued Figure 8.5-16: Antenna port 2 single carrier lower block edge with input signal at AGC threshold +3 dB Section 8 Testing data Test name Spurious emissions conducted measurements Specification 935210 D05 Indus Booster Basic Meas v01r04 (3.6.3) Report reference ID: REP013856 Page 71 of 120 8.6 Spurious emissions conducted measurements 8.6.1 References, definitions and limits FCC §27.53(n): 3.45 GHz Service. The following emission limits apply to stations transmitting in the 3450–3550 MHz band: For base station operations in the 3450–3550 MHz band, the conducted power of any emission outside the licensee's authorized bandwidth shall not exceed −13 dBm/MHz. Compliance with the provisions of this paragraph (n)(1) is based on the use of measurement instrumentation employing a resolution bandwidth of 1 megahertz or greater. However, in the 1 megahertz bands immediately outside and adjacent to the licensee's frequency block, a resolution bandwidth of at least one percent of the emission bandwidth of the fundamental emission of the transmitter may be employed, but limited to a maximum of 200 kHz. The emission bandwidth is defined as the width of the signal between two points, one below the carrier center frequency and one above the carrier center frequency, outside of which all emissions are attenuated at least 26 dB below the transmitter power. Notwithstanding the channel edge requirement of −13 dBm per megahertz, for base station operations in the 3450–3550 MHz band, the conducted power of any emission below 3440 MHz or above 3560 MHz shall not exceed −25 dBm/MHz, and the conducted power of emissions below 3430 MHz or above 3570 MHz shall not exceed −40 dBm/MHz. For mobile operations in the 3450–3550 MHz band, the conducted power of any emission outside the licensee's authorized bandwidth shall not exceed −13 dBm/MHz. Compliance with this paragraph (n)(2) is based on the use of measurement instrumentation employing a resolution bandwidth of 1 megahertz or greater. However, in the 1 megahertz bands immediately outside and adjacent to the licensee's frequency block, a resolution bandwidth of at leas…
