Optical Remote Unit ION™-M7P/7P/85P/19P (ML-Cabinet) Manual MF0145A4A Manual for ION™-M7P/7P/85P/19P (ML-cab) Page 2 Manual ION-M7P-7P-85P-19P MF0145A4A.doc © Copyright 2011 CommScope, Inc. All rights reserved. Andrew Solutions is a trademark of CommScope, Inc. All information contained in this manual has been revised thoroughly. Yet Andrew Solutions accepts no liability for any omissions or faults. Andrew Solutions reserves the right to change all hard- and software characteristics without notice. Names of products mentioned herein are used for identification purposes only and may be trademarks and / or registered trademarks of their respective companies. No parts of this publication may be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronical, mechanical photocopying, recording or otherwise, without prior written permission of the publisher. Andrew Wireless Systems GmbH, 20-October-2011 Page 3 TABLE OF CONTENTS 1. GENERAL 6 1.1. USED ABBREVIATIONS 6 1.2. HEALTH AND SAFETY WARNINGS 7 1.3. ABOUT ANDREW SOLUTIONS 9 1.4. INTERNATIONAL CONTACT ADDRESSES FOR CUSTOMER SUPPORT 10 2. FUNCTIONAL DESCRIPTION 12 2.1. PURPOSE 12 2.2. THE ION™-M7P/7P/85P/19P (INTELLIGENT OPTICAL NETWORK; MMR) 12 3. COMMISSIONING 14 3.1. MECHANICAL INSTALLATION 14 3.1.1. General 14 3.1.2. Wall Mounting of RU 16 3.1.3. Pole Mounting of RU 17 3.2. ELECTRICAL INSTALLATION 19 3.2.1. General 19 3.2.2. Connections 20 3.2.3. Grounding 21 3.3. CONNECTION OF THE ANTENNA CABLES 21 3.4. POWER CONNECTION 22 3.5. OPTICAL-FIBER-CABLE CONNECTION - RULES 23 3.5.1. Protective Plug 25 3.5.2. Protective-Tube Kit 27 3.6. COMMISSIONING 29 4. ALARMS 33 4.1. BITE AND ALARMS 33 4.2. HANDLING OF ALARMS 33 4.3. ALARM STATUS 33 4.4. STATUS LED ALARMS 34 4.5. EXTERNAL ALARM INPUTS AND OUTPUTS 35 Manual for ION™-M4/8/9 EP (ML-cab) Page 4 Manual ION-M7P-7P-85P-19P MF0145A4A.doc 4.6. TROUBLESHOOTING 36 5. MAINTENANCE 37 5.1. GENERAL 37 5.2. REPLACING THE FAN UNIT 38 5.3. CLEANING THE HEAT SINK 39 6. APPENDIX 40 6.1. ILLUSTRATIONS 40 6.2. SPECIFICATIONS 41 6.2.1. Electrical Specifications 41 6.2.2. Mechanical Specifications 41 6.2.3. Environmental and Safety Specifications 41 6.3. SPARE PARTS 42 7. INDEX 43 Page 5 FIGURES AND TABLES figure 3-1 Mounting bracket installation.................................................................... 16 figure 3-2 RU wall mounting ..................................................................................... 16 figure 3-3 Pole-mounting kit, view from different sides ............................................. 17 figure 3-4 Pole-mounting, ML-cabinet, assembly drawing ........................................ 18 figure 3-5 Pole mounting of RU, finished .................................................................. 18 figure 3-6 Connector flange of ION-M7P/7P/85P/19P .............................................. 20 figure 3-7 RS485 connector...................................................................................... 20 figure 3-8 Grounding bolt .......................................................................................... 21 figure 3-9 Grounding bolt, schematic view................................................................ 21 figure 3-10 AC power supply plug............................................................................. 22 figure 3-11 Protective-plug assembly ....................................................................... 25 figure 3-12 Tube-kit installation................................................................................. 28 figure 4-1 Flange connector, 5 poles........................................................................ 35 figure 4-2 Flange connector, 7 poles........................................................................ 35 figure 4-3 Alarm inputs and outputs, standard .......................................................... 36 figure 5-1 Fan unit and heat sink .............................................................................. 38 figure 6-1 Cabinet drawing........................................................................................ 40 table 1-1 List of international contact addresses....................................................... 11 table 3-1 Specified torques ....................................................................................... 15 table 3-2 RS485 connector, pin assignment............................................................. 20 table 4-1 Status LED alarms..................................................................................... 34 Page 6 Manual ION-M7P-7P-85P-19P MF0145A4A.doc 1. GENERAL 1.1. USED ABBREVIATIONS 3GPP 3 rd Generation Partnership Project 4G 4 th Generation ALC Automatic Level Control AMPS American Mobile Phone System or Advanced Mobile Phone System AWS Advanced Wireless Services BBU Battery Backup Unit BCCH Broadcast Control Channel BITE Built-In Test Equipment BTS Base Transceiver Station CDMA Code Division Multiple Access CEPT Conférénce Européenne des Postes et Télécommunications CF Center Frequency CFO Center Frequency Offset CPD Channel Power Detection DL Downlink DoC Declaration of Conformity EDGE Enhanced Data Rates for GSM Evolution ESD Electrostatic Discharge ETS European Telecommunication Standard ETSI European Telecommunication Standards Institute FCC Federal Communications Commission FSK Frequency Shift Keying GSM Global System for Mobile Communication GUI Graphical User Interface I 2 C-Bus Inter Integrated Circuit Bus (Philips) ID No Identification Number IF Intermediate Frequency LMT Local Maintenance Terminal LNA Low-Noise Amplifier LO Local Oscillator LTE Long Term Evolution MIMO Multiple Input Multiple Output MS Mobile Station OMC Operation and Maintenance Center OTRx Optical Transceiver = SRMU (Subrack Master Unit) PCMCIA Personal Computer Modem Communication International Association PCS Personal Communication System PSTN Public Switched Telephone Network R&TTE Radio & Te…

Text truncated - open the document above for the full version.

Optical Remote Unit ION™-M7P/7P/85P/19P (ML-Cabinet) Manual MF0145A4A Manual for ION™-M7P/7P/85P/19P (ML-cab) Page 2 Manual ION-M7P-7P-85P-19P MF0145A4A.doc © Copyright 2011 CommScope, Inc. All rights reserved. Andrew Solutions is a trademark of CommScope, Inc. All information contained in this manual has been revised thoroughly. Yet Andrew Solutions accepts no liability for any omissions or faults. Andrew Solutions reserves the right to change all hard- and software characteristics without notice. Names of products mentioned herein are used for identification purposes only and may be trademarks and / or registered trademarks of their respective companies. No parts of this publication may be reproduced, stored in a retrieval system, transmitted in any form or by any means, electronical, mechanical photocopying, recording or otherwise, without prior written permission of the publisher. Andrew Wireless Systems GmbH, 20-October-2011 Page 3 TABLE OF CONTENTS 1. GENERAL 6 1.1. USED ABBREVIATIONS 6 1.2. HEALTH AND SAFETY WARNINGS 7 1.3. ABOUT ANDREW SOLUTIONS 9 1.4. INTERNATIONAL CONTACT ADDRESSES FOR CUSTOMER SUPPORT 10 2. FUNCTIONAL DESCRIPTION 12 2.1. PURPOSE 12 2.2. THE ION™-M7P/7P/85P/19P (INTELLIGENT OPTICAL NETWORK; MMR) 12 3. COMMISSIONING 14 3.1. MECHANICAL INSTALLATION 14 3.1.1. General 14 3.1.2. Wall Mounting of RU 16 3.1.3. Pole Mounting of RU 17 3.2. ELECTRICAL INSTALLATION 19 3.2.1. General 19 3.2.2. Connections 20 3.2.3. Grounding 21 3.3. CONNECTION OF THE ANTENNA CABLES 21 3.4. POWER CONNECTION 22 3.5. OPTICAL-FIBER-CABLE CONNECTION - RULES 23 3.5.1. Protective Plug 25 3.5.2. Protective-Tube Kit 27 3.6. COMMISSIONING 29 4. ALARMS 33 4.1. BITE AND ALARMS 33 4.2. HANDLING OF ALARMS 33 4.3. ALARM STATUS 33 4.4. STATUS LED ALARMS 34 4.5. EXTERNAL ALARM INPUTS AND OUTPUTS 35 Manual for ION™-M4/8/9 EP (ML-cab) Page 4 Manual ION-M7P-7P-85P-19P MF0145A4A.doc 4.6. TROUBLESHOOTING 36 5. MAINTENANCE 37 5.1. GENERAL 37 5.2. REPLACING THE FAN UNIT 38 5.3. CLEANING THE HEAT SINK 39 6. APPENDIX 40 6.1. ILLUSTRATIONS 40 6.2. SPECIFICATIONS 41 6.2.1. Electrical Specifications 41 6.2.2. Mechanical Specifications 41 6.2.3. Environmental and Safety Specifications 41 6.3. SPARE PARTS 42 7. INDEX 43 Page 5 FIGURES AND TABLES figure 3-1 Mounting bracket installation.................................................................... 16 figure 3-2 RU wall mounting ..................................................................................... 16 figure 3-3 Pole-mounting kit, view from different sides ............................................. 17 figure 3-4 Pole-mounting, ML-cabinet, assembly drawing ........................................ 18 figure 3-5 Pole mounting of RU, finished .................................................................. 18 figure 3-6 Connector flange of ION-M7P/7P/85P/19P .............................................. 20 figure 3-7 RS485 connector...................................................................................... 20 figure 3-8 Grounding bolt .......................................................................................... 21 figure 3-9 Grounding bolt, schematic view................................................................ 21 figure 3-10 AC power supply plug............................................................................. 22 figure 3-11 Protective-plug assembly ....................................................................... 25 figure 3-12 Tube-kit installation................................................................................. 28 figure 4-1 Flange connector, 5 poles........................................................................ 35 figure 4-2 Flange connector, 7 poles........................................................................ 35 figure 4-3 Alarm inputs and outputs, standard .......................................................... 36 figure 5-1 Fan unit and heat sink .............................................................................. 38 figure 6-1 Cabinet drawing........................................................................................ 40 table 1-1 List of international contact addresses....................................................... 11 table 3-1 Specified torques ....................................................................................... 15 table 3-2 RS485 connector, pin assignment............................................................. 20 table 4-1 Status LED alarms..................................................................................... 34 Page 6 Manual ION-M7P-7P-85P-19P MF0145A4A.doc 1. GENERAL 1.1. USED ABBREVIATIONS 3GPP 3 rd Generation Partnership Project 4G 4 th Generation ALC Automatic Level Control AMPS American Mobile Phone System or Advanced Mobile Phone System AWS Advanced Wireless Services BBU Battery Backup Unit BCCH Broadcast Control Channel BITE Built-In Test Equipment BTS Base Transceiver Station CDMA Code Division Multiple Access CEPT Conférénce Européenne des Postes et Télécommunications CF Center Frequency CFO Center Frequency Offset CPD Channel Power Detection DL Downlink DoC Declaration of Conformity EDGE Enhanced Data Rates for GSM Evolution ESD Electrostatic Discharge ETS European Telecommunication Standard ETSI European Telecommunication Standards Institute FCC Federal Communications Commission FSK Frequency Shift Keying GSM Global System for Mobile Communication GUI Graphical User Interface I 2 C-Bus Inter Integrated Circuit Bus (Philips) ID No Identification Number IF Intermediate Frequency LMT Local Maintenance Terminal LNA Low-Noise Amplifier LO Local Oscillator LTE Long Term Evolution MIMO Multiple Input Multiple Output MS Mobile Station OMC Operation and Maintenance Center OTRx Optical Transceiver = SRMU (Subrack Master Unit) PCMCIA Personal Computer Modem Communication International Association PCS Personal Communication System PSTN Public Switched Telephone Network R&TTE Radio & Te…

Text truncated - open the document above for the full version.

Installation instruction The Remote and the Master Unit has to be mounted by a professional/ special trained installer.

Installation instruction The Remote and the Master Unit has to be mounted by a professional/ special trained installer.

External Photos

External Photos

Label Location 6,5cm 11,5cm

Label Location 6,5cm 11,5cm

Internal Photos 7542238-01 7543140-00 7601520-00

Internal Photos 7542238-01 7543140-00 7601520-00

RF Exposure Info / MPE Sample Calculation Model: ION‐M7P/7P/85P/19P FCC‐ID: XS5‐M778519P The ION‐M7P/7P/85P/19P is a LTE MIMO, 850 MHz, and1900 MHz CDMA/WCDMA multi‐ operator Remote Unit with various Extension Units. It is used in conjunction with a Master Unit in the ION optical distribution system. This system transports multiple LTE channels, a 850 MHz, and a 1900 MHz wideband signal simultaneously, providing a cost‐effective solution for distributing capacity from one or more base stations. The ION‐M7P/7P/85P/19P transports signals on the RF layer in a very inexpensive manner. This means that multiple operators and multiple technologies are moved simultaneously from a cluster of base stations to a remote location over the same fiber. The ION optical distribution system is a coverage solution for dense urban areas, tunnels, subway, airports, convention centers, high‐rise buildings and other locations where physical structures increase path loss. It has been specifically designed to reduce zoning problems and to provide homogeneous coverage. The compact, mechanical design is specifically architected to mount inside of poles or along side structures in such a way that it has a minimal visual impact. The ION‐M7P/7P/85P/19P is available in single (SISO) or multi‐channel (MIMO) configuration supporting 700 MHz, LTE, 850 MHz, and 1900 MHz in parallel. It has been specifically tested and optimized for LTE, OFDM, CDMA, and WCDMA signals. The ION is easily set‐up and supervised via a graphical user interface (GUI). Remote Units can be commissioned through the use of built‐in test equipment. An auto‐levelling function compensates for the optical link loss making installation easy and quick. The entire system may be monitored remotely via an Andrew OMC. This platform uses SNMP protocol and is compliant to X.733 standard. The specific device generally will be professionally installed. Hereby the gain of the finally installed antenna(s), cable attenuation and antenna height will be defined site specific at the time of licensing with the appropriate FCC Bureau(s). The maximum permissible exposure limit is defined in 47 CFR 1.1310 (B). Limits for General Population / Uncontrolled Exposures Frequency Range (MHz) Power Density (mW/cm 2 ) 300 – 1500 f/1500 1550 – 100,000 1 The EUT operates in the 3 frequency bands: 700, 850 and 1900 MHz. The worst case limit for Power Density is for the lowest frequency. The lowest frequency is 728 MHz. The max measured conducted output power is 43.0 dBm (20 W) at the all frequency paths. The maximum permitted level is to be calculated using general equation: S = P*G/4πR 2 P = 40W; G = antenna‐cable attenuation to be defined (numeric gain); π = 3,1416 The min separation distance between the antenna and any human body is to be calculated (solving for R in cm) with the final actual antenna gain/cable attenuation where the limit of 1mW/cm 2 is kept. Example: For f = 728 MHz (0.485 mW/cm 2 and P=43 dBm) and a gain = 12 dBi the calculated distance is R = 2.277 m. Frequency [MHz] Max Power out [dBm] Antenna gain f.E. [dBi] Distance [m] 728 43 12 2.277 728 43 9 1.612 869 43 12 2.084 869 43 9 1.476 1930 43 12 1.586 1930 43 9 1.123 The antenna(s) used with device must be fixed‐mounted on permanent structures with a distance to any human body to comply with the RF Exposure limit.

RF Exposure Info / MPE Sample Calculation Model: ION‐M7P/7P/85P/19P FCC‐ID: XS5‐M778519P The ION‐M7P/7P/85P/19P is a LTE MIMO, 850 MHz, and1900 MHz CDMA/WCDMA multi‐ operator Remote Unit with various Extension Units. It is used in conjunction with a Master Unit in the ION optical distribution system. This system transports multiple LTE channels, a 850 MHz, and a 1900 MHz wideband signal simultaneously, providing a cost‐effective solution for distributing capacity from one or more base stations. The ION‐M7P/7P/85P/19P transports signals on the RF layer in a very inexpensive manner. This means that multiple operators and multiple technologies are moved simultaneously from a cluster of base stations to a remote location over the same fiber. The ION optical distribution system is a coverage solution for dense urban areas, tunnels, subway, airports, convention centers, high‐rise buildings and other locations where physical structures increase path loss. It has been specifically designed to reduce zoning problems and to provide homogeneous coverage. The compact, mechanical design is specifically architected to mount inside of poles or along side structures in such a way that it has a minimal visual impact. The ION‐M7P/7P/85P/19P is available in single (SISO) or multi‐channel (MIMO) configuration supporting 700 MHz, LTE, 850 MHz, and 1900 MHz in parallel. It has been specifically tested and optimized for LTE, OFDM, CDMA, and WCDMA signals. The ION is easily set‐up and supervised via a graphical user interface (GUI). Remote Units can be commissioned through the use of built‐in test equipment. An auto‐levelling function compensates for the optical link loss making installation easy and quick. The entire system may be monitored remotely via an Andrew OMC. This platform uses SNMP protocol and is compliant to X.733 standard. The specific device generally will be professionally installed. Hereby the gain of the finally installed antenna(s), cable attenuation and antenna height will be defined site specific at the time of licensing with the appropriate FCC Bureau(s). The maximum permissible exposure limit is defined in 47 CFR 1.1310 (B). S = power density limit [W/m] P = power [W] R = distance [m] 2 4 n nn n R GP S   => n nn n S GP R 4  (to calculate the distance at one frequency) If we have more bands, than we have to calculated as a percentage: The additional of the terms have to be lower than 1. We are looking for a distance of ensures that the formula is satisfied. n RRRR... 321 1 4 ... 444 2 3 2 33 2 2 22 1 2 11  n nn SR GP SR GP SR GP SR GP  R S GP S GP S GP S GP R S GP S GP S GP S GP n nn n nn     4 ... 444 4 ... 444 3 33 2 22 1 11 2 3 33 2 22 1 11 With n nn n S GP R 4  => n nn n S GP R 4 2  1 4 .... 4 44 1.... 2 3 2 3 33 2 2 2 22 1 2 1 11 ln 3 3 2 2 1 1   n n nn n cacalcalcal S R GP S R GP S R GP S R GP S S S S S S S S   RRRRR n  22 3 2 2 2 1 ... What you have to do for calculate the minimum distance were the power density limit is met: 1) If you have one path, you have to put you special values in the following formula. n nn n S GP R 4  (Distance for one carrier) Limits for General Population / Uncontrolled Exposures Frequency Range (MHz) Power Density (mW/cm 2 ) 300 – 1500 S = f/1500 1550 – 100,000 S = 1 2) If you have more than one path, you must add the individual terms quadratic. n nn n S GP R 4  (Distance for individual carrier) RRRRR n  22 3 2 2 2 1 ... (See previous page) For example: The EUT operates in the 4 frequency bands: 728‐746, 746‐757, 869‐894 and 1850‐1915 MHz. The max measured conducted output power is 43.0 dBm (20 W) at the all frequency paths. Calculation for every path with maximum possible antenna gain and without cable loss: Frequency [MHz] Max Power out [dBm] Max. possible Antenna gain, without cable loss [dBi] Max. Distance [m] 728 43 19.15 5.1865 747 43 19.15 5.1201 869 43 16.15 3.3607 1930 43 19.15 3.6132 The worst case would be if all bands were active: RRRRR n  22 3 2 2 2 1 ... R all > 8.801 m (see previous page for formula) For more accurate calculation, the cable loss and actual antenna gain have to be included in the finally system. The antenna(s) used with device must be fixed‐mounted on permanent structures with a distance to any human body to comply with the RF Exposure limit.

Test Site: FCC Test Site No.: 96997 IC OATS No.: IC3475A-1 The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-11-250-V01.00 Page 1 of 34 Date of issue: 20.10.11 Signature: Issue-No.: 01 Author: Tom Zahlmann Test engineer Date of delivery: 17.10.11 Checked: Thomas Vogel Deputy head of EMC Test dates: 14.10.11 – 18.10.11 Pages: 34 ECL-EMC Test Report No.: 11-250 Equipment under test: ION-M7P/7P/85P/19P 2x 700MHz path FCC ID: XS5-M778519P IC ID: 2237E-M778519P Type of test: FCC 47 CFR Part 27 Subpart H, F: 2011 Miscellaneous Wireless Communication Services IC RSS-131:2003 Zone Enhancers for the Land Mobile Service Measurement Procedures: 47 CFR Parts 2:2011 (Frequency Allocations and Radio Treaty Matters; General Rules and Regulations), Part 27:2011 (Miscellaneous Wireless Communication Services), ANSI/TIA-603-C:2004, Land Mobile FM or PM Communications Equipment Measurement and Performance Standards IC-GEN:2007 General Requirements and Information for the Certification of Radiocommunication Equipment Test result: Passed Test Report No.: 11-250 FCC ID: XS5-M778519P IC ID: 2237E-M778519P The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-11-250-V01.00 Page 2 of 34 Manufacturer: ANDREW Wireless Systems GmbH Industriering 10 D-86675 Buchdorf Tel.: +49 (0)9099 69 0 Fax: +49 (0)9099 69 140 Test Location: TEMPTON Service Plus GmbH European Compliance Laboratory (ECL) Thurn-und-Taxis-Straße 18 D-90411 Nürnberg Tel.: +49 (0) 911 59835 0 Fax: +49 (0) 911 59835 90 General: The purpose of this report is to show compliance to the FCC regulations for devices operating under Part 27 of the Code of Federal Regulations title 47. This report informs about the results of the EMC tests, it only refers to the equipment under test. No part of this report may be reproduced in any form, without written permission. Test Report No.: 11-250 FCC ID: XS5-M778519P IC ID: 2237E-M778519P The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-11-250-V01.00 Page 3 of 34 Table of contents 1 TEST RESULTS SUMMARY .................................................................................................................5 2 EQUIPMENT UNDER TEST (E.U.T.) ....................................................................................................6 2.1 DESCRIPTION....................................................................................................................................6 2.1.1 DOWNLINK.................................................................................................................................6 2.1.2 UPLINK......................................................................................................................................6 2.1.3 DESCRIPTION OF EUT ................................................................................................................6 2.1.4 SYSTEM DIAGRAM OF EUT .........................................................................................................7 2.1.5 BLOCK DIAGRAM OF MEASUREMENT REFERENCE POINTS..............................................................7 3 TEST SITE (ANDREW BUCHDORF) ....................................................................................................8 3.1 TEST ENVIRONMENT..........................................................................................................................8 3.2 TEST EQUIPMENT..............................................................................................................................8 3.3 INPUT AND OUTPUT LOSSES...............................................................................................................8 3.4 MEASUREMENT UNCERTAINTY............................................................................................................8 4 TEST SITE (TEMPTON) ........................................................................................................................8 5 RF POWER OUT: §27.50, §2.1046; RSS-131, RSS-GEN ....................................................................9 5.1 LIMIT.................................................................................................................................................9 5.2 TEST METHOD.................................................................................................................................10 5.3 TEST RESULTS................................................................................................................................10 5.3.1 DOWNLINK...............................................................................................................................10 5.3.1.1 LTE 728 – 746MHz, MIMO.............................................................................................11 5.3.1.2 LTE 746 – 757MHz, MIMO.............................................................................................11 5.3.2 UPLINK....................................................................................................................................12 5.4 SUMMARY TEST RESULT...................................................................................................................12 6 OCCUPIED BANDWIDTH: §90.210, §2.1049; RSS-GEN...................................................................13 6.1 LIMIT...............................................................................................................................................13 6.2 TEST METHOD.................................................................................................................................13 6.3 TEST RESULTS................................................................................................................................13 6.3.1 DOWNLINK........................…

Text truncated - open the document above for the full version.

Test Site: FCC Test Site No.: 96997 IC OATS No.: IC3475A-1 The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-11-250-V01.00 Page 1 of 34 Date of issue: 20.10.11 Signature: Issue-No.: 01 Author: Tom Zahlmann Test engineer Date of delivery: 17.10.11 Checked: Thomas Vogel Deputy head of EMC Test dates: 14.10.11 – 18.10.11 Pages: 34 ECL-EMC Test Report No.: 11-250 Equipment under test: ION-M7P/7P/85P/19P 2x 700MHz path FCC ID: XS5-M778519P IC ID: 2237E-M778519P Type of test: FCC 47 CFR Part 27 Subpart H, F: 2011 Miscellaneous Wireless Communication Services IC RSS-131:2003 Zone Enhancers for the Land Mobile Service Measurement Procedures: 47 CFR Parts 2:2011 (Frequency Allocations and Radio Treaty Matters; General Rules and Regulations), Part 27:2011 (Miscellaneous Wireless Communication Services), ANSI/TIA-603-C:2004, Land Mobile FM or PM Communications Equipment Measurement and Performance Standards IC-GEN:2007 General Requirements and Information for the Certification of Radiocommunication Equipment Test result: Passed Test Report No.: 11-250 FCC ID: XS5-M778519P IC ID: 2237E-M778519P The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-11-250-V01.00 Page 2 of 34 Manufacturer: ANDREW Wireless Systems GmbH Industriering 10 D-86675 Buchdorf Tel.: +49 (0)9099 69 0 Fax: +49 (0)9099 69 140 Test Location: TEMPTON Service Plus GmbH European Compliance Laboratory (ECL) Thurn-und-Taxis-Straße 18 D-90411 Nürnberg Tel.: +49 (0) 911 59835 0 Fax: +49 (0) 911 59835 90 General: The purpose of this report is to show compliance to the FCC regulations for devices operating under Part 27 of the Code of Federal Regulations title 47. This report informs about the results of the EMC tests, it only refers to the equipment under test. No part of this report may be reproduced in any form, without written permission. Test Report No.: 11-250 FCC ID: XS5-M778519P IC ID: 2237E-M778519P The test report shall not be reproduced except in full without the written approval of the testing laboratory. ECL-EMC-TR-11-250-V01.00 Page 3 of 34 Table of contents 1 TEST RESULTS SUMMARY .................................................................................................................5 2 EQUIPMENT UNDER TEST (E.U.T.) ....................................................................................................6 2.1 DESCRIPTION....................................................................................................................................6 2.1.1 DOWNLINK.................................................................................................................................6 2.1.2 UPLINK......................................................................................................................................6 2.1.3 DESCRIPTION OF EUT ................................................................................................................6 2.1.4 SYSTEM DIAGRAM OF EUT .........................................................................................................7 2.1.5 BLOCK DIAGRAM OF MEASUREMENT REFERENCE POINTS..............................................................7 3 TEST SITE (ANDREW BUCHDORF) ....................................................................................................8 3.1 TEST ENVIRONMENT..........................................................................................................................8 3.2 TEST EQUIPMENT..............................................................................................................................8 3.3 INPUT AND OUTPUT LOSSES...............................................................................................................8 3.4 MEASUREMENT…
