XTS-FP2Bluetooth LE scanner trigger

FINGER PICK Model Name: Bluetooth LE scanner trigger Quick User Guide INTRODUCTION The purpose of the Finger Pick finger button is to turn on the barcode reader of a Honeywell Android device to be able to read barcodes while holding the device on your wrist. This way you can easily transform your hand held PDA into a wearable PDA. To work it is necessary to install the dedicated Android application. SAFETY INFORMATION ● Only operate the Bluetooth Finger Pick in accordance with its purpose. ● Do not operate or charge this product near any liquid(s). ● Do not use abrasives, thinners, alcohol, solvents or aerosol cleaners that may cause damage to the Bluetooth Finger Pick. ● If the die-cast chassis or other parts are damaged, do not touch the damaged parts. ● This product contains a lithium-polymer rechargeable battery, which is permanently built-in. To dispose of, be sure to comply with the laws and regulations in your country or region. ● Do not charge for longer than the specified time. ● Do not bend or drop the product, or otherwise expose it to strong physical impact. ● Never disassemble or modify the product. ● Do not expose the product to high temperatures, high humidity or direct sunlight. Specification ● Bluetooth LE button ● Operating Temp: -20°C±2°C ~ 50°C±2°C ● Approx. Weight: 20g ● Bluetooth version: Bluetooth V4.0 ● Battery: Li battery ● Battery life: 180 days Federal Communication Commission Interference Statement Model: FP2 FCC ID. : XTS-FP2 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATIONS IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: ( 1 ) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND ( 2 ) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. FCC INFORMATION The Federal Communication Commission Radio Frequency Interference Statement includes the following paragraph: The equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communication. However, there is no grantee that interference will not occur in a particular installation. If this equipment dose cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on , the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. The user should not modify or change this equipment without written approval form Mobility Sound Technology LTD. Modification could void authority to use this equipment. USER MANUAL CHARGING AND BATTERY Charging of the Bluetooth Finger Pick is done via the Type-C USB connector. Use a standard USB connection or charger supporting: 5V - 1A. During charging, the LED shows a solid Red color. When the battery is fully charged, the LED either turns off. If during operation the battery level goes low the LED show a solid Red color to indicate the battery need to be recharged. With a fully charged battery, the expected operational time is above 3 months. POWER ON AND OFF To power ON the Finger Pick you have to press and hold the POWER button for 2 seconds. When powered ON Blue LED flash twice. When powered ON, Finger Pick goes in Pairing Mode for 120 seconds, after Pairing Mode is timeout, Finger Pick goes power off. To turn OFF the device you have to press and hold the power button for 2 seconds until the BLUE LED solid ON, then release power button USE ANDROID APPLICATION 1. Install the application from Google Play Store (recommended for automatic updates). Search “Finger Pick Lexter” on the Play Store from your Honeywell device or scan the QR code below. Alternatively use the URL below or scan the QR code below www.lexter.com/download/honeywell.apk 2. Open the installed application. The name of the app is “Lexter Wearable”. 3. Allow app to access device’s location Pair to Honeywell device 4. Tap on Bluetooth trigger configuration 5. Allow app to turn on the bluetooth (This point only if bluetooth is not enabled) 6. Select your Finger Pick from devices list (you see the MAC ADDRESS) Widget You can add the widget on the home screen to unpair the button easily. Open the app and tap to “Bluetooth unpair shortcut” for add the widget Unpair it is recommended to use the widget as described above. If necessary, you can also unpair by opening the app
Bluetooth trigger configuration
Unpair trigger Important Note If a finger pick is connected to a device, you must first unpair it in order to connect it to another device. It is therefore recommended to use the widget to unpair the device at the end of the work. LED EVENTS LED Power ON Blue LED double flash Power OFF Blue LED solid ON until the power button is released LED FUNCTION Turned off The device is turned off or the battery charging is complete. Blue single flash (every 3 seconds) Finger Pick connected to device Blue fast double flash(every 2 seconds)Pairing Mode Red solid Battery charging or battery low

DATE : 2022-Sep-14 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: XTS-FP2 Product Name: Bluetooth LE scanner trigger Request for Confidentiality Pursuant to Sections §0.457(d) and §0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2022-Sep-14 Agency agreement expiration date: Usually Give 8 - 12 Months Title: General Manage r On behalf of : Mobility Sound Technology Ltd. Telephone: +886-2-2223-2377

HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 39 of 47 8 Photographs of the EUT View of the EUT 1 View of the EUT 2 HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 40 of 47 View of the EUT 3 View of the EUT 4 HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 41 of 47 View of the EUT 5 View of the EUT 6

Label & Location Label location 3 mm 20 mm

HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 42 of 47 Closer V iew of IO port Inside V iew HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 43 of 47 Front View of PCB-1 Rear View of PCB-1 HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 44 of 47 Front View of PCB 2 Rear View of PCB 2 HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 45 of 47 Closer View of BT module Closer View of Printed Antenna HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 46 of 47 View of Battery-1 View of Battery-2 HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 47 of 47 BT Testing Kit(USB Cable) Type C Cable ----------End Of Test Report----------

HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 1 of 47 Te s t i n g L a b o r a t o r y 1163 FCC COMPLIANCE TEST REPORT Technical Statement of Conformity in accordance with FCC Part 15 Subpart C The Product Equipment Under Test ： Bluetooth LE scanner Trigger Model Number ： FP2 Product Series ： N/A Report Number ： HA225149-RA Issue Date ： 15-Sep-2022 is produced by Mobility Sound Technology LTD. 5F, No.100, Jian 1 st Road, ZhongHe Dist., New Taipei City #23585, Taiwan HongAn TECHNOLOGY CO., LTD. HongAn TECHNOLOGY EMC Laboratory NO.15-1, CWEISHUH KENG, CWEIPIN VILLAGE, LINKOU DIST, NEW TAIPEI CITY, TAIWAN, R. O. C. TEL: +886-2-26030362 FAX: +886-2-26019259 E-mail: [email protected] BSMI Registration No.： SL2-IN-E-0023, SL2-A1-E-0023, FCC Designation No.：TW1071, TW1163, TW1136 SL2-IS-E-0023, SL2-R1-E-0023, TAF Accreditation No.：1163 SL2-R2-E-0023, SL2-L1-E-0023 IC assigned Code：11226A-2 VCCI Registration No.： R-12156, C-12329, T-10219, G-10696ISED CAB identifier: TW1163 Caution : This report sets forth our findings solely with respect to the test sample. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment. Please note that the measurement uncertainty are provided for informational purpose only and are not used in determining the Pass/Fail results. This test report shall not be reproduced written approval of HongAn TECHNOLOGY EMC Laboratory. The relevant information of the content of this test report is provided by the customer. For the correctness, appropriateness or completeness of the information provided by the customer, if there is any doubt or error, which will affect the validity of the results of this test report, the laboratory will not be liable Related responsibilities. HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 2 of 47 Contents 1 General Description 7 1.1 Description of EUT 7 1.2 Test Instruments 8 1.3 Auxiliary Equipments 9 1.4 EUT SETUP 9 1.5 Identifying the Final Test Mode 9 1.6 Final Test Mode 10 1.7 Condition of Power Supply 10 1.8 EUT Configuration 10 1.9 Test Methodology 10 1.10 General Test Procedures 10 1.11 Modification 10 1.12 FCC Part 15.205 restricted bands of operations 11 2 Power line Conducted Emission Measurement 12 2.1 Test Instruments 12 2.2 Test Arrangement and Procedure 12 2.3 Limit (§ 15.207) 12 2.4 Test Result 12 3 Radiated Emission Test 15 3.1 Test Instruments 15 3.2 Test Arrangement and Procedure 15 3.3 Limit of Field Strength of Fundamental (§ 15.249) 16 3.4 Limit of Spurious Emission (§ 15.209) 16 3.5 Test Result 16 4 Out of Band Emission Test 27 4.1 Test Instruments 27 4.2 Test Arrangement and Procedure 27 4.3 Limit of Field Strength of Fundamental (§ 15.249(d)) 27 4.4 Test Result 27 5 20 dB Bandwidth 32 5.1 Test Instruments 32 5.2 Test Arrangement and Procedure 32 5.3 Limit 32 5.4 Test Result 32 6 Antenna requirement 36 HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 3 of 47 6.1 Limit (§ 15.203) 36 6.2 Test Result 36 7 Photographs of the Tests 37 7.1 Power line Conducted Emission Test (at Mains Terminals) 37 7.2 Radiated Disturbances Emission Test 38 8 Photographs of the EUT 39 HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 4 of 47 Release control Record Report Version Description Issued Date V00 Original release. 15-Sep-2022 HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 5 of 47 Test Result Certification Applicant ： Mobility Sound Technology LTD. Address of Applicant ： 5F, No.100, Jian 1 st Road, ZhongHe Dist., New Taipei City #23585, Taiwan Manufacturer ： Mobility Sound Technology LTD. Address of Manufacturer ： 5F, No.100, Jian 1 st Road, ZhongHe Dist., New Taipei City #23585, Taiwan Trade Name ： MobilitySound Equipment Under Test ： Bluetooth LE scanner trigger Model Number ： FP2 Product Series ： N/A FCC ID ： XTS-FP2 Filing Type ： Certification Sample Received Date ： 10-Aug-2022 Test Standard ： FCC Part 15 Subpart C §15.249 Deviations from standard test methods & any other specifications : NONE Remark: 1. This report details the results of the test carried out on one sample. 2. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in both ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.203, 15.207, 15.209, 15.249. 3. This report applies to the above sample only and shall not be reproduced in part without written approval of HongAn Technology Co., Ltd. 4. Test Location (HA2): HongAn Technology EMC Laboratory, No.15-1 Cweishuh Keng, Cweipin Village, Linkou Dist., New Taipei City, Taiwan, R.O.C. FCC Designation No.: TW1071, TW1163. 5. Test Location (HA5): HongAn Technology EMC Laboratory, 2F, No.146, Jian Yi Rd., Chung-Ho Dist., New Taipei City, Taiwan, R.O.C. FCC Designation No.: TW1136. Tested by: 2022-09-12 Andrew Lin / ENG. Dept. Staff Approved by: Date: 2022-09-15 Eason Hsieh / Section Manager HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 6 of 47 Summary of Test Result Test Item Applicable Standard Test Result 1 Antenna Requirement FCC part 15 subpart C §203 Compliance 2 Conducted Emission FCC part 15 subpart C §207 Compliance 3 Restricted Band of Operation FCC part 15 subpart C §205 Compliance 4 Radiated Emission FCC part 15 subpart C §209 Compliance 5 Field Strength FCC part 15 subpart C §249(a) Compliance 6 Out of Band Emission FCC part 15 subpart C §249(d) Compliance 7 20dB Bandwidth FCC part 15 subpart C §215(c) Compliance HongAn TECHNOLOGY CO., LTD.…

Text truncated - open the document above for the full version.

HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 37 of 47 7 Photographs of the Tests 7.1 Power line Conducted Emission Test (at Mains Terminals) Front View Rear View HongAn TECHNOLOGY CO., LTD. Report No.: HA225149-RA Report Version：V00 Page 38 of 47 7.2 Radiated Disturbances Emission Test Below 1 GHz (EUT at 0.8m) Above 1 GHz (EUT at 1.5m)
