XU8GLM300Wireless N module

TRENDNET, Inc.
Wireless N module - FCC ID XU8GLM300 - TRENDNET, Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Sep 26, 2012
Application Purpose
Original Equipment
Date of Application
Sep 26, 2012
Equipment Note
Wireless N module
Frequency Range
2412.00000000 - 2462.00000000
Company
TRENDNET, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

ALPHA Proprietary and Confidential Information Product User Manual Model Number: GLM-300 Wireless N module User Manual Introduction This module is the wireless networking device based on 802.11b/g technology and compatible for interoperability with 802.11n devices. This device provides up to 150Mbps transfer rate in the wireless network and let users access the Internet resource, sharing file, and email quickly and your wireless communications are protected by up to WPA2 encryption, so your data stays secure. The extremely small design makes it easy to install into new or existing wireless device and lets you to connect wirelessly to your network. It gives you the ability to roam at home or in the office without wires. Features Compatible with IEEE 802.11b/g and 802.11n Standard for 2.4GHz Wireless SoC solution combines 802.11n draft compliant 1T1R MAC/BBP/RF Up to 150Mbps High-Speed PHY transfer rate on the wireless LAN interface Works with All Existing Network Infrastructure. Compatible with Wi-Fi Wireless Products and Services. Capable of 64/128-Bit WEP, 256bit WPA and WPA2 Encryption One I-PEX Connectors for External Antenna Rich hardware interfaces (SPI/I2S/I2C/UART) to enable many possible applications. Support IEEE 802.3 full duplex flow control Support USB host mode System Hardware Processor : Ralink RT-3050 Single Chip SoC 320MHz CPU CLK MIPS 24KEc 320MHz with 32KB I cache/16KB D cache Embedded 1Tx1R 2.4G CMOS RF Chipset maximum consumption 1.45W 802.11n 1T1R MAC/BBP 1 port 10/100Mbps PHY 16 bit 106MHz SDRAM Support 16 bit NOR FLASH (up-to 8 Mbytes) SDRAM: 32M Byte (16Mx16) Flash ROM: 4M Byte (2Mx16) 3.3V DC switching type power adapter Interface : 1x 10/100 Base-T LAN port Other interface : UART , JTAG, GPIOs, WPS button, reset button Power Requirement: Operating Voltage: 3.3V DC System Software STANDARDS IEEE 802.11b/g IEEE 802.11n draft 2.0 IEEE 802.3 IEEE 802.3u System use Linux 2.6. WIRELESS SECURITY WEP (64/128 bit) 4 WPA / WPA2 QOS- WMM, WMM Power Save 22c;!2:/:eCn! 22h;!35/6eCn! 913/22o!)31NI{*;!35/3eCn! 913/22o!)51NI{*;!35/3eCn! Output power: Physical dimensions & Environmental Dimensions: 46mm(L) x 40mm(W) x 5.6mm(H) Operation Temperature: 0к~40к ( 32л to 104л) PIN Description TBD PCB Dimension PCBA dimension : TBD mm(W) x mm(H) PCB dimenstion: 46mm(L) ------END------ 5 * Recommend operating under the condition of good airflow Storage Temperature: -25к~55к (-13л to 131л) Humidity: 5%~95% non-condensing. * Environmental factors may affect actual range Safety and Emission (Base on region and customer’s request) EMI: FCC class B, CE lass B Safety: UL, TUV EMI: FCC 15C/ FCC MPE/ NCC LP0002 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: XU8GLM300”. T he grantee's FCC ID can be used only when all FCC compliance requirements are met. Manual Information To the End User The OEM integrator has to be aware not to provide informatio…

Text truncated - open the document above for the full version.

Attestation Statements

TRENDnet, Inc 20675 Manhattan Place, Torrance, CA 90501 U.S.A. TEL: (310) 961-5500 5474; FAX: (310) 961-5511 Declaration for no non‐US channel operation September 19, 2012 We, TRENDnet, Inc declare that the device does not support any non-US channels in all the operational mode(s) for the following product. FCC ID: XU8GLM300 If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Wen Tsai / Sr. Product Manager TRENDnet, Inc. Tel: (310) 961-5500 5474 Fax:(310) 961-5511 e-mail: [email protected]

Attestation Statements

TRENDnet, Inc 20675 Manhattan Place, Torrance, CA 90501 U.S.A. Declaration Letter We, TRENDnet, Inc declare the wireless module with FCC ID listed below does not have standard PCI-E interface. It is part of the wireless camera and it does not function without a specific test board. We do not provide instruction on how to remove the wireless module in the user’s guide and we will not sell the module by itself. FCC ID: XU8GLM300 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, __________________________________ Wen Tsai / Sr. Product Manager TRENDnet, Inc. Tel: (310) 961-5500 5474 Fax:(310) 961-5511 e-mail: [email protected] 2012/9/19

Cover Letter(s)

TRENDnet, Inc 20675 Manhattan Place, Torrance, CA 90501 U.S.A. Date:2012-9-19 AUTHORIZATION LETTER To whom it may concern: We, the undersigned TRENDnet, Inc hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15C and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------ Wen Tsai / Sr. Product Manager TRENDnet, Inc. Tel.: (310) 961-5500 5474 Fax.: (310) 961-5511 E-mail: [email protected]

Cover Letter(s)

FCC ID: XU8GLM300 Report No.: RF 990928E01A Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch September 25, 2012 Dear Application Examiner, TRENDnet, Inc, device: a Wireless N module, FCC ID: XU8GLM300 would like to have your authorization as a modular device. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data input. It is integrated in chip RT3050. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is RT3050. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: XU8GLM300 Report No.: RF 990928E01A 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, signature Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

External Photos

Report No.: 990928E01A 1 of 5 Reference No.: 120823E01, 120110E14 CONSTRUCTION PHOTOS OF EUT EUT with antenna Report No.: 990928E01A 2 of 5 Reference No.: 120823E01, 120110E14 Report No.: 990928E01A 3 of 5 Reference No.: 120823E01, 120110E14

ID Label/Location Info

Label drawing and location Label size: 40mm*17mm. (L*W) FCC ID : XU8GLM300 Label Here

Internal Photos

Report No.: 990928E01A 4 of 5 Reference No.: 120823E01, 120110E14 Report No.: 990928E01A 5 of 5 Reference No.: 120823E01, 120110E14

Operational Description

FCC ID: XU8GLM300 Report No.: RF 990928E01A Operational Description This device is a Wireless N module, which operates in 2.4GHz band, the maximum data rate could be up to 150Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 150Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 3.3Vdc from the host equipment. The antenna is Dipole with SMA Straight Plug Reverse connector. The other instruction, please have a look at the users manual.

RF Exposure Info

Report No.: SA990928E01A 1 of 6 Report Format Version 5.0.0 Reference No.: 120823E01Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 RF EXPOSURE REPORT REPORT NO.: SA990928E01A MODEL NO.: GLM-300 FCC ID: XU8GLM300 RECEIVED: Aug. 23, 2012 TESTED: Sep. 04, 2012 ISSUED: Sep. 20, 2012 APPLICANT: TRENDnet, Inc ADDRESS: 20675 Manhattan Place, Torrance, CA 90501 U.S.A. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA990928E01A 2 of 6 Report Format Version 5.0.0 Reference No.: 120823E01Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 6 Report No.: SA990928E01A 3 of 6 Report Format Version 5.0.0 Reference No.: 120823E01Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA990928E01A Original release Sep. 20, 2012 Report No.: SA990928E01A 4 of 6 Report Format Version 5.0.0 Reference No.: 120823E01Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 1. CERTIFICATION PRODUCT: Wireless N module BRAND NAME: TRENDnet MODEL NO.: GLM-300 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: TRENDnet, Inc TESTED DATE: Sep. 04, 2012 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: GLM-300) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Sep. 20, 2011 ( Lori Chung, Specialist ) APPROVED BY : , DATE: Sep. 20, 2011 ( May Chen, Deputy Manager ) Report No.: SA990928E01A 5 of 6 Report Format Version 5.0.0 Reference No.: 120823E01Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA990928E01A 6 of 6 Report Format Version 5.0.0 Reference No.: 120823E01Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 165.959 2.00 20 0.05233 1.00 Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] Effective Legacy Gain (dBi) = 4.39 --- END ---

Test Report

Report No.: RF990928E01A 1 of 53 Report Format Version 5.0.0 Reference No.: 120823E01, 120110E14 FCC TEST REPORT REPORT NO.: RF990928E01A MODEL NO.: GLM-300 FCC ID: XU8GLM300 RECEIVED: Aug. 23, 2012 TESTED: Aug. 28 to Sep. 04, 2012 ISSUED: Sep. 20, 2012 APPLICANT: TRENDnet, Inc ADDRESS: 20675 Manhattan Place, Torrance, CA 90501 U.S.A. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF990928E01A 2 of 53 Report Format Version 5.0.0 Reference No.: 120823E01, 120110E14 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 7 3. GENERAL INFORMATION ..................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 8 3.2 DESCRIPTION OF TEST MODES ....................................................................... 10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................. 15 3.5 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 15 4. TEST TYPES AND RESULTS .............................................................................. 16 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 16 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 16 4.1.2 TEST INSTRUMENTS .......................................................................................... 16 4.1.3 TEST PROCEDURES .......................................................................................... 17 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 17 4.1.5 TEST SETUP ....................................................................................................... 18 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 18 4.1.7 TEST RESULTS ................................................................................................... 19 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 21 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 21 4.2.2 TEST INSTRUMENTS .......................................................................................... 22 4.2.3 TEST PROCEDURES .......................................................................................... 24 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 24 4.2.5 TEST SETUP ....................................................................................................... 25 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 25 4.2.7 TEST RESULTS ................................................................................................... 26 4.3 6dB BANDWIDTH MEASUREMENT .................................................................... 39 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .................................................. 39 4.3.2 TEST INSTRUMENTS .......................................................................................... 39 4.3.3 TEST PROCEDURE ............................................................................................. 39 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 39 4.3.5 TEST SETUP ....................................................................................................... 39 4.3.6 EUT OPERATING CONDITIONS ..........................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Wen Tsai(Sr. Product Manager)
[email protected]310-961-5500Fax: 310-961-5511

Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchHank Chung
[email protected]886-3-593-5343

81-1, Lu Laio Keng, 9th Ling, Wu Lung Tsuen, Chiun · Hsinchu Hsien · Taiwan

Non-Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchCeline Chou
[email protected]886-3-3183232

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen
[email protected]886-3-3183232Fax: 886 3 2115834

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz166.00 mW
Modular Type
Single Modular Approval
Confidentiality
Long Term
Grant Notes
Output power listed is conducted. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter.
