XU8TEW753DAPN600 High Power Dual Band PoE Access Point

TRENDNET, Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Sep 12, 2013
Application Purpose: Original Equipment
Date of Application: Sep 12, 2013
Equipment Note: N600 High Power Dual Band PoE Access Point
Frequency Range: 5745.00000000 - 5825.00000000
Company: TRENDNET, Inc.
Country: United States

Documents & Files

Select a file to view

ID Label/Location Info

Internal Photos

↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

2006/8/16 v1.0 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Note: The country code selection is for non-US model only and is not available to all US model. Per FCC regulation, all WiFi product marketed in US must fixed to US operation channels only.

Users Manual

TEW-753DAP User’s Guide © Copyright 2013 TRENDnet. All rights reserved. a TEW-753DAP User’s GuideTable of Contents © Copyright 2013 TRENDnet. All rights reserved. b Table of Contents Product Overview ��1 Package Contents ��1 Features ��1 Front Panel ��2 Mounting Holes ��2 Connectors ��2 Product Pre-set Information ��3 Mounting Accessories ��3 Hardware Installation ��4 Mount on Wall or Ceiling ��4 Mount on T-Bar ��4 Wireless Performance Considerations ��5 Operation Modes ��5 Access Point ��5 WDS Bridge ��5 WDS AP ��5 Universal Repeater��5 Application Diagram ��6 System configuration ��7 System Management and Default Settings ��7 Log-in System Management for the First Time ��7 Setup Wizard ��9 Status ��10 System ��13 Wireless ��16 Management ��24 Federal Communication Commission Interference Statement ��32 Europe – EU Declaration of Conformity ��33 RoHS ��33 Limited Warranty ��35 TEW-753DAP User’s GuideProduct Overview © Copyright 2013 TRENDnet. All rights reserved. 1 Product Overview Package Contents TEW-753DAP package includes: • TEW-753DAP • Multi-Language Quick Installation Guide • CD-ROM ( User’s Guide) • Network cable (1.5 m/5 ft.) • Power adapter (12 V, 1.25 A) If any package contents are missing or damaged, please contact the retail store, online retailer, or reseller/distributor from which the product was purchased. TEW-753DAP Features TRENDnet’s N600 Dual Band PoE Access Point, model TEW-753DAP, is a feature rich business class access point with proven concurrent 300 Mbps dual band wireless technology. A variety of installation scenarios are supported with Access Point, WDS AP, WDS Bridge, and Repeater modes. Save installation time and costs with PoE. Quick Setup Get up and running in minutes with the intuitive guided setup Low Profile Off white low profile smoke detector shape blends into most environments Power over Ethernet (PoE) Save installation time and costs with a PoE (Optional power port for non-PoE installations) LED Control Disable diagnostic LEDs to further reduce visual attention Concurrent Dual Band Proven concurrent 300 Mbps dual band wireless n Gigabit Port Gigabit port maintains high performance connection to network Wireless Coverage Increased coverage with MIMO technology Backward Compatible Compatible older wireless g devices TEW-753DAP User’s GuideProduct Overview © Copyright 2013 TRENDnet. All rights reserved. 2 Operation Modes Independently set each band to Access Point, WDS AP, WDS Bridge, or Repeater mode IPv6 IPv6 support AP Scan Integrated wireless scan function helps optimize wireless setup SSIDs Up to 8 SSIDs per band (16 total) with isolation support Traffic Shaping Allocate bandwidth to each wireless SSID System Logs Eight system logs aid network troubleshooting Spanning Tree Configurable spanning tree controls SNMP Extend network monitoring to this device with SNMP support Encrypted Wireless Support for encryption up to WPA2 VLAN Management Up to eight SSIDs per band with VLAN management support Network Access Create MAC filter tables to reduce network access risk • Concurrent dual band 300 Mbps* wireless N • Create up to 8 SSIDs per band • No need to install the device near a power source with PoE installation • Manage traffic shaping per SSID • Off-white low profile housing blends into environment • IPv6 support • Off-white housing blends into environment • 3-year limited warranty *Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions. TEW-753DAP User’s GuideProduct Overview © Copyright 2013 TRENDnet. All rights reserved. 3 Front Panel Wireless Network Power Mounting Holes Connectors DC Power 12V DC 1.25A (Optional) Gigabit PoE Port Mounting holes Kensington security slot Reset …

Text truncated - open the document above for the full version.

Attestation Statements

TRENDNET, Inc. 20675 Manhattan Place, Torrance, CA 90501 Date:2013/09/11 FCC ID: XU8TEW753DAP Declaration for no non-US channel operation We, TRENDNET, Inc. declare that the device does not support any non-US channels in all the operational mode(s) for the following product. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------- TRENDNET, Inc. Wen Tsai / Sr. Product Manager TEL : 310-961-5500 E-mail: [email protected]

Cover Letter(s)

TRENDNET, Inc. 20675 Manhattan Place, Torrance, CA 90501 Date: 2013/07/22 FCC ID: XU8TEW753DAP Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ----------------------------------------------------- TRENDNET, Inc. Wen Tsai / Sr. Product Manager TEL : 310-961-5500 E-mail: [email protected]

Cover Letter(s)

TRENDNET, Inc. 20675 Manhattan Place, Torrance, CA 90501 Date: 2013/07/22 AGENCY AUTHORIZATION LETTER We, the undersigned TRENDNET, Inc. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15 and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ----------------------------------------------------- TRENDNET, Inc. Wen Tsai / Sr. Product Manager TEL : 310-961-5500 E-mail: [email protected]

External Photos

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

Internal Photos

Page 4 Page 5 Page 6 Page 7 Page 8

Operational Description

FCC ID: XU8TEW753DAP Report No.: RF 130701C06 Operational Description This device is a N600 High Power Dual Band PoE Access Point, which operates in both 2.4GHz and 5GHz bands; the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by the 12Vdc from AC Adapter or 48Vdc from POE. The antenna is Embedded antenna with UFL connector. The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

RF Exposure Info

Report No.: SA120618C25O 1 of 6 Report Format Version 5.0.0 Reference No.: 130701C06 RF EXPOSURE REPORT REPORT NO.: SA120618C25O MODEL NO.: TEW-753DAP FCC ID: XU8TEW753DAP RECEIVED: Jun. 18, 2012 TESTED: Aug. 11 ~ Aug. 17, 2012 ISSUED: Aug. 13, 2013 PREPARED BY: TRENDNET, Inc. ADDRESS: 20675 Manhattan Place, Torrance, CA 90501, USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-com pliance to the specification. Report No.: SA120618C25O 2 of 6 Report Format Version 5.0.0 Reference No.: 130701C06 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................................ 3 1. CERTIFICATION ............................................................................................................. 4 2. RF EXPOSURE ............................................................................................................... 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ......................................... 5 2.2 MPE CALCULATION FORMULA .................................................................................... 5 2.3 CLASSIFICATION ........................................................................................................... 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER .................................. 6 Report No.: SA120618C25O 3 of 6 Report Format Version 5.0.0 Reference No.: 130701C06 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA120618C25O Original release Aug. 13, 2013 Report No.: SA120618C25O 4 of 6 Report Format Version 5.0.0 Reference No.: 130701C06 1. CERTIFICATION PRODUCT: N600 High Power Dual Band PoE Access Point MODEL NO.: TEW-753DAP BRAND: TRENDnet APPLICANT: TRENDNET, Inc. TESTED: Aug. 11 ~ Aug. 17, 2012 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (model: TEW-753DAP) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Aug. 13, 2013 Pettie Chen / Senior Specialist APPROVED BY : , DATE :Aug. 13, 2013 Ken Liu / Senior Manager Report No.: SA120618C25O 5 of 6 Report Format Version 5.0.0 Reference No.: 130701C06 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA120618C25O 6 of 6 Report Format Version 5.0.0 Reference No.: 130701C06 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) MODULATION MODE MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 802.11b 21.41 3 20 0.055 1 802.11g 25.77 3 20 0.150 1 802.11n (20MHz) 27.48 3 20 0.222 1 802.11n (40MHz) 24.61 3 20 0.115 1 5180-5240 802.11a 13.72 4 20 0.012 1 802.11n (20MHz) 14.60 4 20 0.014 1 802.11n (40MHz) 16.68 4 20 0.023 1 5745-5825 802.11a 27.35 4 20 0.271 1 802.11n (20MHz) 26.98 4 20 0.249 1 802.11n (40MHz) 26.83 4 20 0.241 1 CONCULSION: Both of the WLAN 2.4G & 5.0G can transmit simultaneously, the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density 1. WLAN 2.4G + WLAN 5.0G = 0.222 + 0.271 = 0.493 Therefore, the maximum calculation of this situation is 0.493, which is less than the “1” limit.

Test Report

Report No.: RF120618C25O 1 of 95 Report Format Version 5.2.0 Reference No.: 120618C25, 121204C20, 130701C06 FCC TEST REPORT (15.247) REPORT NO.: RF120618C25O MODEL NO.: TEW-753DAP FCC ID: XU8TEW753DAP RECEIVED: Jun. 18, 2012 TESTED: Aug. 11 ~ Aug. 17, 2012 (For all tests except Power Spectral Density) Aug. 10, 2013 (For Power Spectral Density) ISSUED: Aug. 13, 2013 PREPARED BY: TRENDNET, Inc. ADDRESS: 20675 Manhattan Place, Torrance, CA 90501, USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120618C25O 2 of 95 Report Format Version 5.2.0 Reference No.: 120618C25, 121204C20, 130701C06 TABLE OF CONTENTS RELEASE CONTROL RECORD ......................................................................................... 5 1. CERTIFICATION ...................................................................................................... 6 2. SUMMARY OF TEST RESULTS ............................................................................. 7 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 7 3. GENERAL INFORMATION ...................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ........................................................................ 8 3.2 DESCRIPTION OF TEST MODES ........................................................................ 10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ......................... 11 3.3 DESCRIPTION OF SUPPORT UNITS .................................................................. 16 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 17 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 19 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND) ............................................ 20 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 20 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ............. 20 4.1.2 TEST INSTRUMENTS .......................................................................................... 21 4.1.3 TEST PROCEDURES ........................................................................................... 22 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 22 4.1.5 TEST SETUP ........................................................................................................ 23 4.1.6 EUT OPERATING CONDITIONS .......................................................................... 23 4.1.7 TEST RESULTS .................................................................................................... 24 4.2 CONDUCTED EMISSION MEASUREMENT ........................................................ 38 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT...................................... 38 4.2.2 TEST INSTRUMENTS .......................................................................................... 38 4.2.3 TEST PROCEDURES ........................................................................................... 39 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 39 4.2.5 TEST SETUP ........................................................................................................ 39 4.2.6 EUT OPERATING CONDITIONS .......................................................................... 39 4.2.7 TEST RESULTS .................................................................................................... 40 4.3 6dB BANDWIDTH MEASUREMENT .................................................................... 44 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .................................................. 44 4.3.2 TEST SETUP ........................................................................................................ 44 4.3.3 TEST INSTRUMENTS .......................................................................................... 44 4.3.4 TEST PROCEDURE ............................................................................................. 44 4.3.5 DEVIATION FROM TEST STANDARD ................................................................. 44 4.3.6 EUT OPERATING CONDITIONS .......................................................................... …

Text truncated - open the document above for the full version.

Test Report

Report No.: RF120618C25O-1 1 of 49 Report Format Version 5.2.0 Reference No.: 120618C25, 121204C20, 130701C06 FCC TEST REPORT (15.407) REPORT NO.: RF120618C25O-1 MODEL NO.: TEW-753DAP FCC ID: XU8TEW753DAP RECEIVED: Jun. 18, 2012 TESTED: Aug. 11 ~ Aug. 17, 2012 (For all tests except Peak Power Excursion and Peak Power Spectral Density) Aug. 10, 2013 (For Peak Power Excursion and Peak Power Spectral Density) ISSUED: Aug. 13, 2013 PREPARED BY: TRENDNET, Inc. ADDRESS: 20675 Manhattan Place, Torrance, CA 90501, USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120618C25O-1 2 of 49 Report Format Version 5.2.0 Reference No.: 120618C25, 121204C20, 130701C06 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................................. 4 1. CERTIFICATION .................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................................ 6 2.1 MEASUREMENT UNCERTAINTY ......................................................................................... 6 3. GENERAL INFORMATION ..................................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ....................................................................................... 7 3.2 DESCRIPTION OF TEST MODES ......................................................................................... 8 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................................ 9 3.3 DUTY CYCLE OF TEST SIGNAL ........................................................................................ 11 3.4 DESCRIPTION OF SUPPORT UNITS ................................................................................. 11 3.4.1 CONFIGURATION OF SYSTEM UNDER TEST .................................................................. 12 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS ...................................................... 14 4. TEST TYPES AND RESULTS .............................................................................................. 15 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .............................................. 15 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ........................... 15 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS ....................... 15 4.1.3 TEST INSTRUMENTS ......................................................................................................... 16 4.1.4 TEST PROCEDURES .......................................................................................................... 17 4.1.5 DEVIATION FROM TEST STANDARD ................................................................................ 17 4.1.6 TEST SETUP ........................................................................................................................ 18 4.1.7 EUT OPERATING CONDITION ........................................................................................... 18 4.1.8 TEST RESULTS ................................................................................................................... 19 4.2 CONDUCTED EMISSION MEASUREMENT ....................................................................... 29 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................................... 29 4.2.2 TEST INSTRUMENTS ......................................................................................................... 29 4.2.3 TEST PROCEDURES .......................................................................................................... 30 4.2.4 DEVIATION FROM TEST STANDARD ................................................................................ 30 4.2.5 TEST SETUP ........................................................................................................................ 30 4.2.6 EUT OPERATING CONDITIONS ......................................................................................... 30 4.2.7 TEST RESULTS ................................................................................................................... 31 4.3 PEAK TRANSMIT POWER MEASUREMENT ............…

Text truncated - open the document above for the full version.

Test Setup Photos

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Test Mode A) 2 CONDUCTED EMISSION TEST (Test Mode B) 3 CONDUCTED EMISSION TEST (Test Mode C) 4 CONDUCTED EMISSION TEST (Test Mode D) 5 RA…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Wen Tsai(Sr. Product Manager)

[email protected]310-961-5500Fax: 310-961-5511

Test Firm

Bureau Veritas CPS (H.K.) Ltd., Taoyuan BranchRichard Chen

[email protected]+886-3-2600884Fax: +886-3-2115834

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	5.75 GHz - 5.83 GHz	544.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is the maximum combined conducted output power. End users and installers must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines.
