Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
怡迅(珠海)光电科技有限公司 ETI Solid State Lighting (Zhuhai) Ltd. 产 品 说 明 书 Product Instruction Manual 产品名称: LED吊装支架灯 Product Name: LED Shop Light 型号编码Model No.: 55703141 生产商:怡迅(珠海)光电科技有限公司 Manufacturer: ETI Solid State Lighting (Zhuhai) Ltd. 地址:珠海市高新区科技创新海岸中珠南路1号一期2#-2厂房 Address: No.1, Zhongzhu Road South,Science & Technology Innovation Coast, High Tech District, Zhuhai City, Guangdong Prov., China 电话Tel:0756-3390990 传真Fax:0756-3390778 网址Web:www.etissl.com.cn 目录Content 1.产品简介ProductIntroduction‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐--‐‐‐‐‐‐‐‐‐‐3 1.1产品描述ProductDescription ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐---‐‐‐‐‐‐‐3 1.2产品示意图SchematicDiagram‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐----‐‐‐‐‐‐‐‐3 2.产品特性ProductFeature‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4 2.1产品特点Productcharacteristic ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4 2.2技术参数Specification‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐5 2.3配光性能LightDistribution‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐6 3.安装方法Methodofapplication‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4-7 4.维护说明MaintenanceInstruction‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐-----‐‐‐‐‐7 5.环境要求Environmentalrequirement‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐8 6.产品执行标准Productcarriedstandard‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐8 7.包装说明Packageinstruction ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐8 7.1包装规格Packagespecification‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐8 7.2包装清单Packagelist ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐8 1.产品简介Product Introduction 1.1. 产品描述:Product Description 1 外形尺寸Out Size: 1100x110x65mm; 2 外壳:铝型材6063,电源盒:铝,灯罩:PC; Shell:AL6063 , Drive box:AL, lamp cover:PC 3 内置电源; built-in drive with box 4 灯珠:三星2835白光灯珠,SMD 3V 0.5W Samsung-LED-2835 1.2. 产品外形图:Product schematic diagram: 2.产品特性 Product Featuers: 2.1. 产品特点Product characteristics : a.长寿命5万小时以上; Long lifetime (above 50,000hrs) b.高效节能环保; High efficiency, energy saving, environmental friendly c.耐冲击,抗震能力强,无紫外线和红外线辐射; Impact resistant, shock resistant, no UV and IR radiation d.绿色环保,无有害气体排放,使用热量低,安全可靠。 Green Initiative, no harmful gas is emitted, low heat is generated while used, safe and reliable . e.光色纯正,使用过程中无频闪,提供更好的视觉感受,保护人眼视力。 Authentic and pure light color, no flicker, protecting your eyes while providing better visualenjoyment. 2.2 技术参数Specification 项目/单位Item/ 参数Parameter 电气参数Electronicratings 额定整灯功率/WRatedPower/W 50W 额定输入电压/VRatedInputvoltage/V AC120V 额定工作频率/HzFrequency/Hz 50/60Hz 额定电源效率/%RatedPowerefficiency 75% 额定功率因数(PF)RatedPowerFactor 0.9 额定输入电流/ARatedInputcurrent/A 0.34A 额定总谐波失真RatedI‐THD <20% 是否调光 否 光源参数Photometricratings LED类型/数量LEDtype/Qty. Samsung-2835/0.5W/92PCS 整灯光通量 /Lm Lumen 3600 Lm 整灯光效/Lm/WLumenefficiency ≥90 色温/K Temprature/K 4000K 显色指数/Ra CRI 80 光束角BeamAngle ≥120° 物理参数Physicalinformation 材质Material PC+AL 工作温度operatingtemperature 45°C 储存温度storagetemperature ‐30~45°C 防护等级IPrating IP20 灯具规格(L×W×H)/mmLuminairedimension(L×W×H)/mm 1100x110x65 净重/gNetweight 1660 g 设计寿命/hrsLifetime/hrs 50000h 3 安装方法 Installation Instructions 3.1.1将两个挂钩固定在天花板表面,挂钩间距760mm Mount the two fixed on the ceiling surface, hook spacing is 760 mm. 3.1.2将吊链挂到灯体背面的挂孔 Will the hanging hole on the reverse of the chain hoist on the lamp body back. 3.1.3将吊链挂到天花板挂钩上 Will the hanging hole on the reverse of the chain hoist on the lamp body back. 3.1.4重复以上两个步骤,用吊链钩住灯具,并挂到天花板挂钩上完成安装,插上插头通 电即可工作 Repeat the above two steps ,with chain hoist hook lamps and lanterns, and hung from the ceiling hook to complete the installation, plug in electricity work。 3.1.5互联安装 End to end connection 3.1.5.1 产品可以互联安装,从第二台灯具开始,参照以上第1,2,3,4步骤安装。 The fixture can be installed end to end. Starting from the second lamps, with reference to the above steps 1, 2, 3,4 installation. 3.1.5.2 将要互联的第二台灯插头线插到前一台灯的插座上即可,最多互联8台灯具。 Will be the second lamp plug in line connected to the former one desk lamp socket. Most Interconnected eight lamps and lanterns 3.1.6 蓝牙连接操作 Control with Bluetooth 1. Open the Bluetooth on your smart phone. 2. The phone will search for “shoplight A”(Test version name), press “shoplight A” to connect the phone to the light. After connected successfully, the light will sound “The light is connected”. 3. Then open you music APP, choose the songs and start to play. 4. To disconnect the shoplight, hit the “shoplight A” again, after disconnected successfully, it will sound “The phone is disconnected”. Note: Installation Instructions - Provided in accordance with the Sec. Gen. In addition, the following markings shall be provided: 1. Instructions for interconnected unit use shall include at least the following: a) Voltage and current rating of portable luminaire; b) Maximum number of units to be interconnected; and c) Maximum distance between units to be interconnected. 2.Caution that installation not be made on a radiant-heating ceiling, and, for swag-type units, a caution that the hooks are to engage the chain only and not the electric cord shall be included 3. “the unit is intended to be installed directly beneath a ceiling-mounted receptacle, and tha t excess cord should be kept out of the workspace, such as by securing it to one of the support ing chains with a cable tie” 4. the maximum distance to the receptacle is determined by the length of cord provided. FCC STATEMENT Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement, the device can be used in portable exposure condition without restriction. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television…
Text truncated - open the document above for the full version.
ETi Solid State Lighting,lnc Covered Equipment Certification Attestation Letter 1/4/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: XZH-5570312026 ETi Solid State Lighting,lnc (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. ETi Solid State Lighting,lnc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. ETi Solid State Lighting,lnc (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Sean.Luo Title: supervisor Company Name: ETi Solid State Lighting,lnc Date: 1/4/2026
ETi Solid State Lighting,lnc Covered Equipment Certification Attestation Letter 1/4/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: XZH-5570312026 ETi Solid State Lighting,lnc (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. ETi Solid State Lighting,lnc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. ETi Solid State Lighting,lnc (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Sean.Luo Title: supervisor Company Name: ETi Solid State Lighting,lnc Date: 1/4/2026
DATE: 2026.01.04 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Age nt On our behalf, I appoint Dongguan New Testing Centre Co., Ltd; 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with ETI Solid State Lighting,lnc;4873 Thurmon Tanner Pkwy,Flowery Branch, GA 30542,USA (Applicant Name and address) <Signature> Name:Sean.Luo Title: supervisor Applicant Company: ETi Solid State Lighting,lnc
Date 2026.01.04 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name:Sean.Luo Title: supervisor Applicant Company: ETi Solid State Lighting,lnc
DATE 2026.01.04 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: XZH-5570312026 Product Name: Remote control Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description BOM These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name:Sean.Luo Title: supervisor Applicant Company: ETi Solid State Lighting,lnc
Model difference statement Application company: ETI Solid State Lighting,Inc. Address: 720 Northgate Parkway Wheeling,IL60090 Product name: LED Shop Light Trade mark: ETI LIGHTING, Commercial Electric, Hampton Bay, Menards, PATRIOT LIGHTING,Mainstays,Great Value,PROFORMAX FCC ID: XZH-5570312026 Model name: 55703100 55703120 55703140 55703160 55703180 55703101 55703121 55703141 55703161 55703181 55703102 55703122 55703142 55703162 55703182 55703103 55703123 55703143 55703163 55703183 55703104 55703124 55703144 55703164 55703184 55703105 55703125 55703145 55703165 55703185 55703106 55703126 55703146 55703166 55703186 55703107 55703127 55703147 55703167 55703187 55703108 55703128 55703148 55703168 55703188 55703109 55703129 55703149 55703169 55703189 55703110 55703130 55703150 55703170 55703190 55703111 55703131 55703151 55703171 55703191 55703112 55703132 55703152 55703172 55703192 55703113 55703133 55703153 55703173 55703193 55703114 55703134 55703154 55703174 55703194 55703115 55703135 55703155 55703175 55703195 55703116 55703136 55703156 55703176 55703196 55703117 55703137 55703157 55703177 55703197 55703118 55703138 55703158 55703178 55703198 55703119 55703139 55703159 55703179 55703199 All the model are the same except model name and LED color temperature. Sign 2026.01.04
Label and Label Locaion
Internal Photos BT antenna
Page 1 of 2 FCC-ID: XZH-5570312026 RF Exposure evaluation FCC ID: XZH-5570312026 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density Page 2 of 2 FCC-ID: XZH-5570312026 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is - 0.25 dBi for 2.4 GHz Bluetooth, the RF power density can be obtained. For 2.4GHz Bluetooth: Mode Max. Output Power (dBm) Max. Output Power (mW) Antenna Gain (Numeric) Power Density At 20 cm (mW/cm 2 ) Power Density Limit FCC (mW/cm 2 ) Test Results GFSK 3.178 2.0787 0.9441 0.00039 1.0000 PASS π/4DQPSK 5.504 3.5514 0.9441 0.00067 1.0000 PASS 8DPSK 5.634 3.6593 0.9441 0.00069 1.0000 PASS 5. Conclusion The SAR evaluation is not required.
FCC TEST REPORT Report No. ....................................: NTC-ER2511025 Applicant’s name ..........................: ETI Solid State Lighting,lnc Addre ss ........................................: 720 Northgate Parkway Wheeling,IL60090 DONGGUAN NEW TESTING CENTRE CO., LTD ◎Address: 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Tel: +86-769-22212079 Web: http://www.ntc-cert.com E-mail: [email protected] Dongguan New Testing Centre Co., Ltd E-mail: NTC@NTC-CERT. COM 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Page 1 / 79 Report No.:NTCER2511025 TABLE OF CONTENTS Te st Report Declare ................................................................................................................... 3 1. Summary of test results...............................................................................................5 2. General test information ..............................................................................................5 2.1. Description of EUT ......................................................................................................5 2.2. Detail models ..............................................................................................................6 2.3. Block diagram EUT configuration for test.....................................................................6 2.4. Test environment conditions........................................................................................6 2.5. Measurement uncertainty ............................................................................................8 2.6. Test Peripheral List .....................................................................................................8 3. Power Line Conducted Emission Test .........................................................................9 3.1. Test equipment ...........................................................................................................9 3.2. Block diagram of test setup .........................................................................................9 3.3. Power Line Conducted Emission Limits (Class B) .......................................................9 3.4. Test Procedure ......................................................................................................... 10 3.5. Test Result................................................................................................................ 10 4. Radiated emission test .............................................................................................. 13 4.1. Test equipment ......................................................................................................... 13 4.2. Block diagram of test setup ....................................................................................... 14 4.3. Limit .......................................................................................................................... 16 4.4. Test Procedure ......................................................................................................... 17 4.5. Test result ................................................................................................................. 17 5. Maximu m Peak Output Power ................................................................................... 23 5.1. Applied procedures / Limit ......................................................................................... 23 5.2. Test procedure .......................................................................................................... 23 5.3. Deviation from standard ............................................................................................ 23 5.4. Test setup ................................................................................................................. 23 5.5. TEST RESULTS ....................................................................................................... 23 6. BANDWIDT H TEST .................................................................................................. 29 6.1. Applied procedures / Limit ......................................................................................... 29 6.2. Test procedure .......................................................................................................... 29 6.3. Deviation from standard ............................................................................................ 29 6.4. Test setup ................................................................................................................. 29 6.5. Test results ............................................................................................................... 29 Dongguan New Testing Centre Co., Ltd E-mail: NTC@NTC-CERT. COM 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Page 2 / 79 Report No.:NTCER2511025 7. Carrier Frequencies Separated ................................................................................. 35 7.1. Applied procedures / Limit ......................................................................................... 35 7.2. Test procedure .......................................................................................................... 35 7.3. Deviation from standard ............................................................................................ 35 7.4. Test setup ................................................................................................................. 35 7.5. Test results ............................................................................................................... 35 8. Hopping Channel Number .........................................................................…
Text truncated - open the document above for the full version.
TestingReport CustomerName:SHENZHENSHIXINZHONGXINTECHNOLOGY.CO.,LTD ProductName:BTAntenna SampleModel:F-6988 ReferenceStandard:GB/T9410-2008;ANSI/IEEEStd149-1979 IssueDate:2019.07.10 Engineer: Date: Auditor: Date: Approver: Date: 2019.07.10 2019.07.10 2019.07.10 1.GeneralInformation 1 . 1GeneralInformationoftestinginstitutions Name ShenzhenHetuoTechnologyCo.,Ltd. Address Room1202B,BuildingC6,HengfengIndustrialCity,Xixiang,Baoan District,Shenzhen Tel 18665849001 E-mail [email protected] Equipm ent Agilent5071C 1.2Testingprinciple Multi-probe OTA Measurement System AntennaPhoto&Lenght(mm) Brief summary of Procedure 1.3Testequipment Equipment ModelNo.SerialNo.Manufacturer Calibration date Next calibration date 24probe microwave chamber 4*3*3NA2019.05.2SATIMO92019.08.31 Network Analyzer 5071CNA Agilent 1.4Testenvironment Temperature 24C±1.5C Humidity 45%RH Pressure 101kPa 1.5 2019.05.29 2019.08.31 1. SATIMO turn on the Upper Computer Software, Name: VeryView99.exe, Version No.: V1.10; 2. VeryView99 via GPIB (General Purpose Interface Bus) to control the shielding room (darkroom)'s SATIMO; 3. Meanwhiel, GPIB control the Agilent 5071C to read the Antenna data by 24 Probe; 4. Agilent 5071C will analyse the data and generate the result; 5. Agilent 5071C will feedback to VeryView99 software to generate the test report. upper computer software Agilent Darkroom Probe 2.SampleInformation 2.1Clientinformation Name SHENZHENSHIXINZHONGXINTECHNOLOGY.CO.,LTD Address A1,ShajingDonghuanIndustrialZone,Bao'anDistrict,Shenzhen Contacts MaChao Tel 18218809918 E-mail [email protected] 2.2DescriptionofEUT(S) ProductName BTAntenna SampleModel F-6988 AntennaSize 4.6*10.4mm AntennaType PCBantenna SerialNo. / TestItem AntennaGain,Radiationpattern FrequencyRange 2400-2500MHz ReceivedDate 2019.07.08 TestDate 2019.07.10 Remark ThelengthoftheRFcableis50mm Thetestphotos 深圳市合拓科技有限公司 Frequency ID1234567891011 Fre quency (MHz)2400.0 2410.0 2420.0 2430.0 2440.0 2450.0 2460.0 2470.0 2480.0 2490.0 2500.0 Efficienc y (dBi)-6.12-6.19-6.13-6.21-6.11-5.93-5.80-5.59-5.40-5.03-4.75 Gain (dBi)-1.80 -2.22 -1.62 -1.87 -2.01 -1.77 -1.56 -1.48 -1.11 -0.73 -0.25 Efficienc y (%)24.45 24.07 24.35 23.94 24.49 25.55 26.30 27.58 28.81 31.38 33.46 Directivit y (dB)4.32 3.96 4.52 4.34 4.10 4.15 4.24 4.11 4.29 4.30 4.50 Peak Gain Position (Theta)126.00 124.00 124.00 124.00 123.00 119.00 123.00 122.00 126.00 124.00 31.00 Peak Gain Position (Phi)80.00 82.00 80.00 83.00 79.00 76.00 249.00 243.00 78.00 240.00 252.00 Efficienc y ThetaPol (%)6.59 6.62 6.65 6.60 6.86 7.18 7.29 7.55 7.55 8.15 8.58 Efficienc y PhiPol (%)17.86 17.45 17.71 17.33 17.63 18.36 19.01 20.02 21.26 23.23 24.88 U pper Hem. Efficiency (%)13.42 13.21 13.18 12.93 12.82 12.70 12.75 12.96 13.79 15.10 16.41 Lower Hem. Efficienc y (%)11.03 10.86 11.18 11.01 11.67 12.85 13.55 14.62 15.02 16.28 17.05 VER7 T90(H)圆度10.94 11.30 11.56 12.29 11.61 13.99 13.46 15.24 14.72 12.13 10.10 Gain 15de g (dBi) E1(XZ)波瓣宽度61.00 91.00 85.00 93.00 87.00 84.00 85.00 81.00 80.00 84.00 83.00 E1 (XZ)前后比3.91 3.29 3.90 3.39 3.00 2.29 1.77 1.98 2.16 2.64 2.49 E2 (YZ)波瓣宽度37.00 35.00 34.00 35.00 219.00 208.00 160.00 160.00 199.00 57.00 84.00 E2 (YZ)前后比3.61 3.36 3.64 3.20 2.33 2.41 2.32 2.20 2.29 2.32 3.05 最大增益处轴比 (P)1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 仰角10度最差 (大)轴比(P)1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 Hc (XY)波瓣宽度94.00 92.00 96.00 100.00 109.00 112.00 118.00 135.00 119.00 116.00 126.00 Hc (XY)前后比0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 Empty max33.46 min23.94 23.94 33.46 0.00 10.00 20.00 30.00 40.00 50.00 60.00 70.00 80.00 90.00 100.00 2400.02410.02420.02430.02440.02450.02460.02470.02480.02490.02500.0 Efficiency (%)Max-Min -0.25 -2.22 -7.00 -6.00 -5.00 -4.00 -3.00 -2.00 -1.00 0.00 2400.02410.02420.02430.02440.02450.02460.02470.02480.02490.02500.0 0.00 10.00 20.00 30.00 40.00 50.00 60.00 70.00 80.00 90.00 100.00 2400.02410.02420.02430.02440.02450.02460.02470.02480.02490.02500.0 Efficiency ThetaPol (%)Efficiency PhiPol (%) 0.00 10.00 20.00 30.00 40.00 50.00 60.00 70.00 80.00 90.00 100.00 2400.02410.02420.02430.02440.02450.02460.02470.02480.02490.02500.0 Upper Hem. Efficiency (%)Lower Hem. Efficiency (%) Test data 2400.0MHz H+V, Eff: 24.5%Back View2400.0MHz Total(E1-XZ), Max= -2.65dBi2400.0MHz Total(E2-YZ), Max= -2.52dBiTotal(H-XY), Max= -3.15dBi, CirD=10.94 -1.8 -3.64 -5.48 -7.32 -9.17 -11.01 -12.85 -14.69 -16.53 -18.38 -20.22 -22.06 -23.9 -25.75 -27.59 -29.43 -31.27 -33.11 2410.0MHz H+V, Eff: 24.1%Back View2410.0MHz Total(E1-XZ), Max= -3.21dBi2410.0MHz Total(E2-YZ), Max= -2.61dBiTotal(H-XY), Max= -3.23dBi, CirD=11.30 -2.22 -4.07 -5.91 -7.75 -9.59 -11.44 -13.28 -15.12 -16.96 -18.8 -20.65 -22.49 -24.33 -26.17 -28.01 -29.86 -31.7 -33.54 2420.0MHz H+V, Eff: 24.4%Back View2420.0MHz Total(E1-XZ), Max= -3.23dBi2420.0MHz Total(E2-YZ), Max= -2.25dBiTotal(H-XY), Max= -2.70dBi, CirD=11.56 -1.62 -3.46 -5.3 -7.15 -8.99 -10.83 -12.67 -14.51 -16.36 -18.2 -20.04 -21.88 -23.72 -25.57 -27.41 -29.25 -31.09 -32.93 2430.0MHz H+V, Eff: 23.9%Back View2430.0MHz Total(E1-XZ), Max= -3.56dBi2430.0MHz Total(E2-YZ), Max= -2.30dBiTotal(H-XY), Max= -2.53dBi, CirD=12.29 -1.87 -3.71 -5.55 -7.39 -9.24 -11.08 -12.92 -14.76 -16.6 -18.45 -20.29 -22.13 -23.97 -25.81 -27.66 -29.5 -31.34 -33.18 2440.0MHz H+V, Eff: 24.5%Back View2440.0MHz Total(E1-XZ), Max= -3.56dBi2440.0MHz Total(E2-YZ), Max= -2.54dBiTotal(H-XY), Max= -2.65dBi, CirD=11.61 -2.01 -3.85 -5.69 -7.53 -9.38 -11.22 -13.06 -14.9 -16.74 -18.59 -20.43 -22.27 -24.11 -25.95 -27.8 -29.64 -31.48 -33.32 2450.0MHz H+V, Eff: 25.5%Back View2450.0MHz Total(E1-XZ), Max= -3.97dBi2450.0MHz Total(E2-YZ), Max= -2.08dBiTotal(H-XY), Max= -2.55dBi, CirD=13.99 -1.77 -3.62 -5.46 -7.3 -9.14 -10.99 -12.83 -14.67 -16.51 -18.35 -20.2 -22.04 -23.88 -25.72 -27.56 -29.41 -31.25 -33.09 2460.0MHz H+V, Eff: 26.3%Back View2460.0MHz Total(E1-XZ), Max= -4.06dBi2460.0MHz Total(E2-YZ), Max= -1.85dBiTotal(H-XY), Max= -2.41dBi, CirD=13.46 -1.56 -3.41 -5.25 -7.09 -8.93 -10.77 -12.6…
Text truncated - open the document above for the full version.
Photos of power line conducted emission test Photos of radiated emission test 30MHz – 1GHz Photos of radiated emission test Above 1GHz
720 Northgate Parkway Wheeling, IL 60090 · Wheeling, Illinois · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 50 W |

Remote control
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Shoplight audio lighting
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Motion Sensor
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Motion Sensor
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
FLUSH MOUNT CEILING LIGHT WITH MOTION SENSOR
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
