XZH-C012632026FLUSH MOUNT CEILING LIGHT WITH MOTION SENSOR

USE AND CARE GUIDE FLUSH MOUNT CEILING LIGHT WITH MOTION SENSOR NOTE: Keep your receipt and these instructions for proof of purchase. WARNING: RISK OF ELECTRIC SHOCK. Ensure the electricity to the wires you are working on is shut off. Either remove the fuse or turn off the circuit breaker before removing an existing light fixture or installing the new one. If you are unfamiliar with electrical installations, we recommend you contact a qualified electrician to do the installation. INSTALLATION Select a suitable location that can support the weight of the fixture. Determine the method for mounting the fixture before drilling, based on the type of ceiling. 1. T urn counterclockwise to open the diffuser shade (B) to expose the mounting holes. Customize the color temperature and motion sensor’s detection range of the light. ¤Choose your fa vorite correlated color temperature (CCT) from five options: 2700K, 3000K, 3500K, 4000K, 5000K. The factory setting is 3000K. ¤Motion detection is factory-set to OFF by default. Four sensing modes (5FT, 10FT, 15FT, and OFF) can be adjusted. Once the sensor detects motion, the light will remain on and will automatically turn off if no motion is detected after 5 minutes. STEP 4.STEP 5. AA AA STEP 2.STEP 3. Model # C01263301A C01264301A C01265301A PACKAGE CONTENTS Part Description Quantity A Fixture body1 BDiffuser Shade1 HARDWARE INCLUDED Part Description Quantity AAMounting Screw2 BBWire Connector2 CCTrim Ring1 AA BBCC CC A A & CC B B A A B AA A 2. Install a mounting screw (AA) in each electrical box hole, but do not tighten fully. 3. Connect the hot and neutr al (black and white) wires from the electrical box to the same color wires from the fixture body (A). Cover the wire connections using the wire connectors (BB). Make sure to fasten them well. Cover the wire connectors (BB) with electrical tape for a more secure connection. 4. Position the wir es back inside the electrical box. Make the mounting screw (AA) head cross the large ends of the keyholes on the fixture body (A), slide the base towards the narrow hole, and fasten these screws well. 5. Reinstall the diffuser shade (B) on the fixture body (A). Restore power at the electrical panel. Turn on the light switch to activate the fixture. BB Item # 1015595238 1015595233 1015595241 STEP 1. A B A US Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 | HOMEDEPOT.COM Retain this manual for future use. CARE AND CLEANING CAUTION: Before attempting to clean the tube and luminaire/light fixture, disconnect the power to the fixture by turning the breaker off or removing the fuse from the fuse box. Clean with a soft, dry cloth. Do not use cleaners with chemicals, solvents, or harsh abrasives. Do not use liquid cleaner on the LEDs, LED driver, or wiring. TROUBLESHOOTING Minor problems often can be fixed without the help of an electrician. WARNING: Before doing any work on the fixture, disconnect power to the light fixture. WARNING: Carefully read and understand the information given in this manual before beginning the assembly and installation. Failure to do so could lead to electric shock, fire, or other injuries which could be hazardous or even fatal. • Ensure the electricity to the wires you are working on is shut off. Either remove the fuse or turn off the circuit breaker. NOTICE: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. lf this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • ncrease the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which thereceiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. NOTICE: FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with minimum distance 20cm between the radiator & you body. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARRANTY WHAT IS COVERED The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship for a period of five (5) years from date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If this product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modifications, alterations, neglect, or mishandling. WHAT IS NOT COVERED This warranty shall not apply to any product that is fo…

Text truncated - open the document above for the full version.

CFR 47 §2.911(d)(7) U.S Agent U.S. AGENT LETTER OF ATTESTATION Date: 2026-04-28 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: XZH-C012632026 ETi Solid State Lighting, Inc certifies that, as of the date of the filing of the application, ETi Solid State Lighting, Inc is our designated U.S. agent for service of process for the above referenced FCC ID. ETi Solid State Lighting, Inc accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. ETi Solid State Lighting, Inc accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: ETi Solid State Lighting, Inc Address: 720 Northgate, Parkway Wheeling, IL 60090, Illinois, United States FRN: 0032652737 Tel.: 86-0756-3635627 Email: [email protected] Signed by (printed name):Sean Luo Signature: Applicant: ETi Solid State Lighting, Inc Add: 720 Northgate, Parkway Wheeling, IL 60090, Illinois, United States FRN: 0032652737 Tel.: 86-0756-3635627 Email: [email protected] Signed by (printed name): Sean Luo Signature:

ETi Solid State Lighting, Inc ADD: 720 Northgate, Parkway Wheeling, IL 60090, Illinois, United States TEL: 86-0756-3635627 E-mail: [email protected] CFR 47 §2.911(d)(5)(i)(ii) Attestation Letter Attestation Letter Date: 04/28/2026 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i)(ii) Filing FCC ID: XZH-C012632026 ETi Solid State Lighting, Inc certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. ETi Solid State Lighting, Inc certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. ETi Solid State Lighting, Inc certifies that the equipment does not use Kaspersky's software information. Sincerely, Signature Contact Person: Sean Luo Title: Dept. Manager ETi Solid State Lighting, Inc ADD: 720 Northgate, Parkway Wheeling, IL 60090, Illinois, United States TEL: 86-0756-3635627 E-mail: [email protected]

ETi Solid State Lighting, Inc ADD: 720 Northgate, Parkway Wheeling, IL 60090, Illinois, United States TEL: 86-0756-3635627 E-mail: [email protected] DECLARATION OF SIMILARITY Date: 2026-04-28 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: We, ETi Solid State Lighting, Inc hereby declare that the product: FLUSH MOUNT CEILING LIGHT WITH MOTION SENSOR, FCC ID: XZH-C012632026, model: C01263@##A, C01264@##A, C01265@##A ( The size of model C01263@##A is 7 inch and 11W, The size of model C01264@##A is 11 inch and 14W, The size of model C01265@##A is 15 inch and 18W, The “@” may be one digits 0 thru 9 for CCT different, The “##” may be two digits 00 thru 99 for commercial purpose ) is electrically identical with the model: C01263301A, C01264301A, C01265301A which was tested by Bay Area Compliance Laboratories Corp.(Dongguan). A description of the differences between those models and that are declared similar are as follows: They are the different model name and CCT and Size and power, the rest are the same. Please contact me should there be need for any additional clarification or information. Best Regards, Signature: Printed Name: Sean Luo Title: Dept. Manager

QA-FR-170-B ETi Solid State Lighting, Inc ADD: 720 Northgate, Parkway Wheeling, IL 60090, Illinois, United States TEL: 86-0756-3635627 E-mail: [email protected] FCC Authorization Date: 04/28/2026 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , ETi Solid State Lighting, Inc Hereby authorizes Bay Area Compliance Laboratories Corp.(Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp.(Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Printed Name: Sean Luo Title: Dept. Manager

QA-FR-171-A ETi Solid State Lighting, Inc ADD: 720 Northgate, Parkway Wheeling, IL 60090, Illinois, United States TEL: 86-0756-3635627 E-mail: [email protected] FCC Confidential Authorization Date: 2026-04-28 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: XZH-C012632026 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, (ETi Solid State Lighting, Inc) hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Sean Luo Title: Dept. Manager

Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-EXP Page 1 / 7 EUT EXTERNAL PHOTOS Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-EXP Page 2 / 7 C01263301A Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-EXP Page 3 / 7 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-EXP Page 4 / 7 C01264301A Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-EXP Page 5 / 7 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-EXP Page 6 / 7 C01265301A Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-EXP Page 7 / 7 *****END *****

ETi Solid State Lighting, Inc 5015682 FLUSHMOUNTCEILINGLIGHTWITHMOTIONSENSOR Model number: C01263301A AC 120V, 60Hz, 11WFCC ID: XZH‐C012632026 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. SUITABLE FOR DAMP LOCATIONS SUITABLE FOR OPERATION IN AMBIENT NOT EXCEEDING 45° ETi Solid State Lighting, Inc 5015682 FLUSHMOUNTCEILINGLIGHTWITHMOTIONSENSOR Model number: C01264301A AC 120V, 60Hz, 14WFCC ID: XZH‐C012632026 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. SUITABLE FOR DAMP LOCATIONS SUITABLE FOR OPERATION IN AMBIENT NOT EXCEEDING 45° ETi Solid State Lighting, Inc 5015682 FLUSHMOUNTCEILINGLIGHTWITHMOTIONSENSOR Model number: C01265301A AC 120V, 60Hz, 18WFCC ID: XZH‐C012632026 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. SUITABLE FOR DAMP LOCATIONS SUITABLE FOR OPERATION IN AMBIENT NOT EXCEEDING 45° FCC ID Lable Location

Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 1 / 17 EUT INTERNAL PHOTOS C01263301A Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 2 / 17 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 3 / 17 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 4 / 17 Radar Module Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 5 / 17 Radar Antennas TX RX Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 6 / 17 C01264301A Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 7 / 17 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 8 / 17 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 9 / 17 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 10 / 17 Radar Module Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 11 / 17 Radar Antennas TX RX Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 12 / 17 C01265301A Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 13 / 17 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 14 / 17 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 15 / 17 Radar Module Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 16 / 17 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2602S22967E-RF-INP Page 17 / 17 Radar Antennas *****END ***** TX RX

Report Template Version: FCC-MPE-V1.1 Page 1 of 6 MAXIMUM PERMISSIBLE EXPOSURE EVALUATION REPORT Applicant: ETi Solid State Lighting, Inc Address: 720 Northgate, Parkway Wheeling, IL 60090, Illinois, United States Product Name: FLUSH MOUNT CEILING LIGHT WITH MOTION SENSOR FCC ID: XZH-C012632026 Standard(s): 47 CFR §1.1310, 47 CFR §2.1091, 47 CFR §15.249 Report Number: 2602S22967E-RF-00C Report Date: 2026/4/29 The above device has been tested and found compliant with the requirement of the relevant standards by Bay Area Compliance Laboratories Corp. (Dongguan). Reviewed By: Alice Tan Approved By: Rocky Xiao Title: RF Engineer Title: RF Supervisor Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Note: The information marked ▲ is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with ★.This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. Each test item follows the test standard(s) without deviation. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2602S22967E-RF-00C Report Template Version: FCC-MPE-V1.1 Page 2 of 6 CONTENTS DOCUMENT REVISION HISTORY ................................................................................................ 3 1. GENERAL INFORMATION .......................................................................................................... 4 1.1 GENERAL DESCRIPTION OF EQUIPMENT UNDER TEST .......................................................................... 4 1.2 ACCESSORY INFORMATION ...................................................................................................................... 4 1.3 ANTENNA INFORMATION DETAIL▲: ....................................................................................................... 4 2. RF EXPOSURE EVALUATION (MPE) ........................................................................................ 5 2.1 RF EXPOSURE EVALUATION .................................................................................................................... 5 2.1.1 Applicable Standard ............................................................................................................................................. 5 2.1.2 Calculation formula .............................................................................................................................................. 5 2.1.3 Calculated Data: ................................................................................................................................................... 5 EXHIBIT A - EUT PHOTOGRAPHS ................................................................................................ 6 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2602S22967E-RF-00C Report Template Version: FCC-MPE-V1.1 Page 3 of 6 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 1.0 2602S22967E-RF-00C Original Report 2026/4/29 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2602S22967E-RF-00C Report Template Version: FCC-MPE-V1.1 Page 4 of 6 1. GENERAL INFORMATION 1.1 General Description Of Equipment under Test EUT Name: FLUSH MOUNT CEILING LIGHT WITH MOTION SENSOR EUT Model: C01263301A, C01264301A, C01265301A Multiple Model(s): C01263@##A, C01264@##A, C01265@##A Rated Input Voltage: AC 120V EUT Received Date: 2026/4/3 EUT Received Status: Good Note: Please refer to the declaration letter for more detail, which was provided by manufacturer. 1.2 Accessory Information Accessory Description ManufacturerModelParameters / / / / 1.3 Antenna Information Detail▲: Antenna Type Frequency Range Antenna Gain Patch 24.00~24.25GHz 9dBi The design of compliance with §15.203: Unit uses a permanently attached antenna. Unit uses a unique coupling to the intentional radiator. Unit was professionally installed, and installer shall be responsible for verifying that the correct antenna is employed with the unit. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2602S22967E-RF-00C Report Template Version: FCC-MPE-V1.1 Page 5 of 6 2. RF EXPOSURE EVALUATION (MPE) 2.1 RF Exposure Evaluation 2.1.1 Applicable Standard According to subpart 15.247(i), 15.407(f)and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. 2.1.2 Calculation formula Prediction of power density at the distance of the applicable MPE limit S = PG/4R² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator…
