XZH-K668-B-CWRemote control

User Manual 1. ALL-OFF:The main switch for the fan and the lights. 2. Light switch: Short press: Fan on and off; Long press for 3 seconds: Match the code. 3. Fan speed Settings 1 to 6 Regulation: Fan speed adjustment. 4. silent mode: The buzzer switch is in the on position,There is a prompt sound [beep] in the state. 5. Comfortable Breeze Mode: There is a gentle wind mode. 6. Fan motor reversal: Control the fan to reverse. 7. The fan is rotating forward: Control the fan to rotate forward. 8. 1 hour Automatically turn off the fan: Set for one hour and the time will end Turn off the fan function after the beam. 9. 4 hour Automatically turn off the fan: Set for four hour and the time will end Turn off the fan function after the beam. 10. Dimming (brightening):Increase brightness. 11. Dimming (darkening): Lower the brightness. 12. Color temperature +: Increase the color temperature. 13. Color temperature -: Reduce the color temperature. 14. Key combination 1: Press the "Comfort Breeze" button and the "1H" button simultaneously. 15. Key combination 2: Press the "Comfort Breeze" button and the "4H" button simultaneously. FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference, including interference that may cause undesired operation of the device. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation, If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.

ETi Solid State Lighting, Inc Covered Equipment Certification Attestation Letter 9/8/2026 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: XZH-K668-B-CW ETi Solid State Lighting, Inc (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. ETi Solid State Lighting, Inc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. ETi Solid State Lighting, Inc (“the applicant”) certifies that the equipment for which authorization issought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity oranti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Sean Luo Title: Supervisor Company Name: ETi Solid State Lighting, Inc Date: 9/8/2026

ETi Solid State Lighting, Inc * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter September 8, 2026 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: XZH-K668-B-CW Per section 2.911(d)(7) of the FCC rules, ETi Solid State Lighting, Inc (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: ETi Solid State Lighting，lnc Physical U.S. Company Address: 720 Northgate Parkway Wheeling, IL 60090 Agent name: Sean.Luo Agent Email Address: [email protected] ,[email protected] FRN: 0032652737 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: Sean.Luo Printed name: Sean.Luo Title: supervisor Title: supervisor Company Name: ETi Solid State Lighting，lnc Company Name: ETi Solid State Lighting，lnc Date: September 8, 2026 Date: September 8, 2026 FRN Code: 0032652737 FRN Code: 0032652737

ETi Solid State Lighting, Inc September 15, 2026 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: XZH-K668-B-CW Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request permanent confidential treatment of exhibits identified as such in the table below and request they are permanently withheld from public review based on the documents containing trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. Exhibit Type of Confidentiality Requested Block Diagrams ☒ Permanent ☐ Short Term External Photos ------------------ ☐ Short Term Internal Photos ☐ Permanent* ☐ Short Term Operation Description ☒ Permanent ☐ Short Term Parts List & Placement/BOM ☒ Permanent ☐ Short Term Tune-Up Procedure ☐ Permanent ☐ Short Term Schematic Diagrams ☒ Permanent ☐ Short Term Test Setup Photos ------------------ ☐ Short Term User’s Manual ☐ Permanent* ☐ Short Term The asterisked items (*) require further information to be provided in this justification letter before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. Note: any documents held under the Short-Term confidentiality will automatically become public after the requested time if an appropriate extension request has not been received. Any exhibits (i.e., schematic diagrams) that may have already been requested to have “Permanent” confidentiality as shown above need not be repeated under Short-Term confidentiality request. Sincerely, Signed: Printed name: Sean Luo Title: Supervisor Company Name: ETi Solid State Lighting, Inc

Family Certification Attestation Letter 日期:2026.7.13 Nemko Canada Inc 303 River Road Ottawa K1V 1H2 Canada Company Name: FCC ID: XZH-K668-B-CW Models: K668-B-CW;K668-B-DT We hereby request Family Certification for the above mentioned Models based on them being electrically identical. The above-mentioned models are exactly the same in terms of circuit diagrams and structure. The only difference lies in the number of buttons on the casing., therefore the test performed on the model K668- B-CW. Signed: Printed name: Sean Luo Title: supervisor Date: 2026.9.8

Label and Label Location Remote control Model: K668-B-CW FCC ID:XZH-K668-B-CW

Internal Photos Antenna

RF Exposure evaluation According to 447498 D04 Interim General RF Exposure Guidance v01 2.1.2 1-mW Test Exemption Per §1.1307(b)(3)(i)(A), a single RF source is exempt RF device (from the requirement to show data demonstrating compliance to RF exposure limits, as previously mentioned) if the available maximum time- averaged power is no more than 1 mW, regardless of separation distance. eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 73.75dBμV/m @3m Antenna gain=0dBi So EIRP=73.75-95.2=-21.45dBm 10^-21.45=0.0072 mW<1 mW Then SAR evaluation is not required

Page 1 / 28 No.:NTC-ER2508023 FCC TEST REPORT Report No. ....................................... : NTC-ER2608045 Applicant’s name ........................... : ETI Solid State Lighting,lnc Address ........................................... : 4873 Thurmon Tanner Pkwy，Flowery Branch, GA 30542， USA DONGGUAN NEW TESTING CENTRE CO., LTD ◎Address: 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Tel: +86-769-22212079 Web: http://www.ntc-cert.com E-mail: [email protected] Page 1 / 28 No.: NTC-ER2608045 TABLE OF CONTENTS 1. SUMMARY ........................................................................................................................................ 4 Test Standards ...................................................................................................................................... 4 Test Description .................................................................................................................................... 4 2. Test Facility ...................................................................................................................................... 5 2.1 Statement of the measurement uncertainty ......................................................................................... 5 3. GENERAL INFORMATION ................................................................................................................... 6 Environmental conditions ..................................................................................................................... 6 General Description of EUT................................................................................................................... 6 Detail Models ........................................................................................................................................ 6 Related Submittal(s) / Grant (s) ............................................................................................................ 6 Modifications ........................................................................................................................................ 6 Equipments Used During The Test ........................................................................................................ 7 4. TEST CONDITIONS AND RESULTS ....................................................................................................... 8 Conducted Emission (AC Main)............................................................................................................. 8 Radiated Emission ................................................................................................................................. 9 20dB Bandwidth .................................................................................................................................. 19 Deactivation Time ............................................................................................................................... 20 Antenna Requirement ........................................................................................................................ 21 5. Test Setup Photos of the EUT .......................................................................................................... 22 6. External and Internal Photos of the EUT .......................................................................................... 23 Dongguan New Testing Centre Co., Ltd E-mail： [email protected] 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Page 2 / 28 No.:NTC-ER2608045 TEST REPORT DECLARE Test Standard Used: FCC Rules and Regulations Part 15 Subpart C 15.231, ANSI C63.10:2020. We Declare: The equipment described above is tested by Dongguan New Testing Centre Co., Ltd and in the configuration tested the equipment complied with the standards specified above. The test results are contained in this test report and Dongguan New Testing Centre Co., Ltd is assumed of full responsibility for the accuracy and completeness of these tests. After test and evaluation, our opinion is that the equipment provided for test compliance with the requirement of the above FCC standards. FCC ID : XZH- K668-B-CW Applicant : ETI Solid State Lighting,lnc Address : 4873 Thurmon Tanner Pkwy，Flowery Branch, GA 30542，USA Equipment under Test : Remote control Model/Type reference : K668-B-CW List Model(s) K668-B-CW;K668-B-DT Trade Mark : ETI LIGHTING,Commercial Electric,Hampton Bay,Menards,PATRIOT LIGHTING，Mainstays,Great Value,Proformax,D&H,AURA Manufacturer : ETI Solid State Lighting (Zhuhai) Ltd Address : No.1, Zhongzhu Road South,Science & Technology Innovation Coast, High Tech District, Zhuhai City, Guangdong Prov., China Manufacturer : NVC VIETNAM TECHNOLOGY AND LIGHTING COMPANY LIMITED Address : PLOT CN9-6, YEN PHONG INDUSTRIAL ZONE (EXPANSION PHASE), YEN TRUNG COMMUNE, YEN PHONG DISTRICT, BAC NINH PROVINCE Test Laboratory : Dongguan New Testing Centre Co., Ltd CAB identifier : CN1264 Address : 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Dongguan New Testing Centre Co., Ltd E-mail： [email protected] 1F & 3F, No. 1 the 1st North Industry Road Songshan Lake Science & Technology Park Dongguan, People’s Republic of China 523808 Page 3 / 28 No.:NTC-ER2608045 Report No.: NTC-ER2608045 Date of Test: Aug.17,2026 to Aug.17,2026 Date of Report: Sept.08,2026 Prepared By: Approved By: ___________________ ______________________ Taylor Chen/Engineer Dave Gao/LAB Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan New Testing Centre Co., Ltd ** Modified History ** Version Description Issued Data Report No. Remark Version 1.0 Initial Test Report Release 2026-09…

Text truncated - open the document above for the full version.

42.10 mm 61.70 mm 62.55 mm 2.59 mm 1.Manufacturer:Shenzhen Live Electronics Co., Ltd. 2.Manufacturer Address:Room 901, Building 3, Phase I, Zone B, Baoneng Science and Technology Park (South Area), Qinghu Industrial Zone, Gangtou Community, Bantian Subdistrict, Longgang District, Shenzhen. 3.Antenna Model name: ZSJ-2122-01 4.Antenna Type: PCB Antenna 5.Antenna Gain: 0dBi 6.Operation frequency: 433.92MHz

Photos of radiated emission test 30MHz – 1GHz Photos of radiated emission test Above 1GHz
