XZZ-3700WNRSCT WIRELESS 4-PORT WIFI WIRELESS-N ROUTER

3G Mobile Broadband Router User’s Manual Version: 1.0 (April, 2009) COPYRIGHT Copyright ©2008/2009 by this company. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company This company makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove defective following their purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software. Further, this company reserves the right to revise this publication and to make changes from time to time in the contents thereof without obligation to notify any person of such revision or changes. Federal Communication Commission Interference Statement FCC Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio technician for help. FCC Caution This equipment must be installed and operated in accordance with provided instructions and a minimum 20 cm spacing must be provided between computer mounted antenna and person‟s body (excluding extremities of hands, wrist and feet) during wireless modes of operation. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. Federal Communication Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The equipment version marketed in US is restricted to usage of the channels 1-11 only. R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000. Safety This equipment is designed with the utmost care for the safety of those who install and use it. However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to ensure the safe use of the equipment. EU Countries Intended for Use The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the Netherlands, Portugal, Spain, Sweden, and the United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland. EU Countries Not intended for use None. CATALOG CHAPTER I: PRODUCT INFORMATION 1-1 Introduction and safety information 1-2 Safety Information 1-3 System Requirements 1-4 Package Contents 1-5 Familiar with your new 3G Mobile Broadband router CHAPTER II: SYSTEM AND NETWORK SETUP 2-1 Build network connection 2-2 Connecting to 3G Mobile broadband router by web browser 2-2-1 Windows 95/98/Me IP address setup 2-2-2 Windows 2000 IP address setup 2-2-3 Windows XP IP address setup 2-2-4 Windows Vista IP address setup 2-2-5 Router IP address lookup 2-3 Using „Quick Setup‟ 2-3-1 Setup procedure for „3G/3.5G‟ 2-3-2 Setup procedure for „Cable Modem‟ 2-3-3 Setup procedure for „Fixed-IP xDSL‟ 2-3-4 Setup procedure for „PPPoE xDSL‟ 2-3-5 Setup procedure for „PPTP xDSL‟ 2-3-6 Setup procedure for „L2TP xDSL‟ 2-3-7 Setup procedure for „Telstra Big Pond‟ 2-4 Basic Setup 2-4-1 Time zone and time auto-synchronization 2-4-2 Change management password 2-4-3 Remote Management 2-5 Setup Internet Connection (WAN Setup) 2-5-1 Setup procedure for „3G/3.5G‟ 2-5-2 Setup procedure for „Dynamic IP‟ 2-5-3 Setup procedure for „Static IP‟ 2-5-4 Setup procedure for „PPPoE‟ 2-5-5 Setup procedure for „PPTP‟ 2-5-6…

Text truncated - open the document above for the full version.

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C1 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 APPENDIX C. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C2 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C3 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C10 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C11 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C1 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 APPENDIX C. Photographs of EUT label location

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C4 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C5 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C6 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C7 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C8 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C9 OF C11 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 11, 2010 FAX : 886-2-2696-2255

FCC TEST REPORT Report No.: FR8O2829-01AC Page No. : A1 of A3 FCC ID : XZZ-3700WNR Appendix A. Maximum Permissible Exposure FCC TEST REPORT Report No.: FR8O2829-01AC Page No. : A2 of A3 FCC ID : XZZ-3700WNR 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. FCC TEST REPORT Report No.: FR8O2829-01AC Page No. : A3 of A3 FCC ID : XZZ-3700WNR 1.3. Calculated Result and Limit Antenna Type : Dipole Max Conducted Power for IEEE 802.11b/g : 17.20dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 3 1.995262 17.20 52.4807 0.0208

FCC TEST REPORT Report No.: FR8O2829-01AI Page No. : A1 of A3 FCC ID : XZZ-3700WNR Appendix A. Maximum Permissible Exposure FCC TEST REPORT Report No.: FR8O2829-01AI Page No. : A2 of A3 FCC ID : XZZ-3700WNR 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. FCC TEST REPORT Report No.: FR8O2829-01AI Page No. : A3 of A3 FCC ID : XZZ-3700WNR 1.3. Calculated Result and Limit Antenna Type : Dipole Max Conducted Power for IEEE 802.11n : 15.45dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 3 1.995262 15.45 35.0752 0.0139

FCC TEST REPORT Report No.: FR8O2829-01AC SPORTON International Inc. Report Format Version: a FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : SCT Wireless 4-Port WiFi Wireless-N Router Model No. : SCT-3700WNR Brand Name : SCT Wireless Filing Type : New Application Applicant : SCT Wireless 1894 US Hwy 50 East, Bulding 4 Suite 281, Carson City, NV 89701, United States FCC ID : XZZ-3700WNR Manufacturer : Airgoon L.T.D. 110 W 9th St #000 Wilmington, DE 19801 EIN # 27-1362223 Received Date : Dec. 04, 2008 Final Test Date : Dec. 11, 2008 Statement Test result included is only for the 802.11b/g Dipole Antenna part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. 6F, No. 106, Sec. 1, Hsin Tai Wu Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. FCC TEST REPORT Report No.: FR8O2829-01AC SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC ID : XZZ-3700WNR Table of Contents 1 SUMMARY OF THE TEST RESULT ...................................................................................................................... 2 2 GENERAL INFORMATION..................................................................................................................................... 3 2.1 Product Details ........................................................................................................................................................................................ 3 2.2 Accessories ............................................................................................................................................................................................. 3 2.3 Table for Filed Antenna ........................................................................................................................................................................... 3 2.4 Table for Carrier Frequencies ................................................................................................................................................................. 4 2.5 Table for Test Modes .............................................................................................................................................................................. 4 2.6 Table for Testing Locations ..................................................................................................................................................................... 4 2.7 Table for Supporting Units....................................................................................................................................................................... 5 2.8 Table for Parameters of Test Software Setting ....................................................................................................................................... 5 2.9 EUT Operation during Test ..................................................................................................................................................................... 5 2.10 Test Configuration ................................................................................................................................................................................... 6 3 TEST RESULT ........................................................................................................................................................ 8 3.1 AC Power Line Conducted Emissions Measurement.............................................................................................................................. 8 3.2 Maximum Conducted Output Power Measurement .............................................................................................................................. 12 3.3 Power Spectral Density Measurement .................................................................................................................................................. 14 3.4 6dB Spectrum Bandwidth Measurement............................................................................................................................................... 20 3.5 Radiated Emissions Measurement........................................................................................................................................................ 26 3.6 Band Edge and Fundamental Emissions Measurement ....................................................................................................................... 44 3.7 Antenna Requirements.......................................................................................................................................................................... 49 4 LIST OF MEASURING EQUIPMENTS ................................................................................................................. 50 5 TEST LOCATION.................................................................................................................................................. 52 6 TAF CERTIFICATE OF ACCREDITATION .......................................................................................................... 53 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE.................................................................................. A1 ~ A3 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOTOGRAPHS …

Text truncated - open the document above for the full version.

FCC TEST REPORT Report No.: FR8O2829-01AI SPORTON International Inc. Report Format Version: a FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : SCT Wireless 4-Port WiFi Wireless-N Router Model No. : SCT-3700WNR Brand Name : SCT Wireless Filing Type : New Application Applicant : SCT Wireless 1894 US Hwy 50 East, Bulding 4 Suite 281, Carson City, NV 89701, United States FCC ID : XZZ-3700WNR Manufacturer : Airgoon L.T.D. 110 W 9th St #000 Wilmington, DE 19801 EIN # 27-1362223 Received Date : Dec. 04, 2008 Final Test Date : Dec. 12, 2008 Statement Test result included is only for the 802.11n Dipole Antenna part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. 6F, No. 106, Sec. 1, Hsin Tai Wu Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. FCC TEST REPORT Report No.: FR8O2829-01AI SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Jan. 11, 2010 FAX : 886-2-2696-2255 FCC ID : XZZ-3700WNR Table of Contents 1 SUMMARY OF THE TEST RESULT ...................................................................................................................... 2 2 GENERAL INFORMATION..................................................................................................................................... 3 2.1 Product Details ........................................................................................................................................................................................ 3 2.2 Accessories ............................................................................................................................................................................................. 3 2.3 Table for Filed Antenna ........................................................................................................................................................................... 3 2.4 Table for Carrier Frequencies ................................................................................................................................................................. 4 2.5 Table for Test Modes .............................................................................................................................................................................. 5 2.6 Table for Testing Locations ..................................................................................................................................................................... 5 2.7 Table for Supporting Units....................................................................................................................................................................... 5 2.8 Table for Parameters of Test Software Setting ....................................................................................................................................... 6 2.9 EUT Operation during Test ..................................................................................................................................................................... 6 2.10 Test Configuration ................................................................................................................................................................................... 7 3 TEST RESULT ........................................................................................................................................................ 9 3.1 AC Power Line Conducted Emissions Measurement.............................................................................................................................. 9 3.2 Maximum Conducted Output Power Measurement .............................................................................................................................. 13 3.3 Power Spectral Density Measurement .................................................................................................................................................. 16 3.4 6dB Spectrum Bandwidth Measurement............................................................................................................................................... 22 3.5 Radiated Emissions Measurement........................................................................................................................................................ 28 3.6 Band Edge and Fundamental Emissions Measurement ....................................................................................................................... 46 3.7 Antenna Requirements.......................................................................................................................................................................... 51 4 LIST OF MEASURING EQUIPMENTS ................................................................................................................. 52 5 TEST LOCATION.................................................................................................................................................. 54 6 TAF CERTIFICATE OF ACCREDITATION .......................................................................................................... 55 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE.................................................................................. A1 ~ A3 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOTOGRAPHS OF…

Text truncated - open the document above for the full version.

FCC TEST REPORT Report No.: FR8O2829-01AI Page No. : B1 of B6 FCC ID : XZZ-3700WNR Appendix B. Test Photos FCC TEST REPORT Report No.: FR8O2829-01AI Page No. : B2 of B6 FCC ID : XZZ-3700WNR 1 Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW FCC TEST REPORT Report No.: FR8O2829-01AI Page No. : B3 of B6 FCC ID : XZZ-3700WNR SIDE VIEW FCC TEST REPORT Report No.: FR8O2829-01AI Page No. : B4 of B6 FCC ID : XZZ-3700WNR 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz FRONT VIEW REAR VIEW FCC TEST REPORT Report No.: FR8O2829-01AI Page No. : B5 of B6 FCC ID : XZZ-3700WNR For radiated emissions 30MHz~1GHz FRONT VIEW REAR VIEW FCC TEST REPORT Report No.: FR8O2829-01AI Page No. : B6 of B6 FCC ID : XZZ-3700WNR For radiated emissions above 1GHz FRONT VIEW REAR VIEW
