SmartCloud ® Radio Node - SCRN 200 Hardware Installation Guide Part number: DOC-RN-HW-05 Published: December 2012 2 © 2012 SpiderCloud Wireless, Inc. SpiderCloud and SmartCloud are registered trademarks of SpiderCloud Wireless, Inc. All Rights Reserved. FCC Statements Warning: In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, the SCRN 200 must have a minimum distance of 20 cm from the body during normal operation. Changes or modifications not expressly approved by SpiderCloud Wireless engineering voids the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case, the user will be required to correct the interference at his own expense. SpiderCloud Wireless 2500 Augustine Drive Suite 200 Santa Clara, CA 95054, USA http://www.spidercloud.com Tel: +1 408 567-9165 Email: [email protected] SpiderCloud Wireless, Inc. SmartCloud Radio Node - SCRN 200 Hardware Installation Guide 3 Table of Contents System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Services Provided . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Radio Node System Isometric Top View and Bottom View. . . . . . . . . . . . . . . . . . . . . . . . . . 6 System Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Frequency Bands of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Size and Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Ports and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Antennas. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 PoE+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Select the Radio Node Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Installation and Mount Bracket Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Bracket Mounting and Cabling Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Detaching the Radio Node from the Mount Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Boot Sequence and Services Node Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 SpiderCloud Wireless, Inc. Contents 4 SpiderCloud Wireless, Inc. 5 SmartCloud Radio Node - SCRN 200 Hardware Installation Guide System Overview The SmartCloud ® Radio Node 200 (SCRN 200) is a low-cost, low-power (100mW) base station designed for indoor use. The radio node is 3GPP compliant, supporting Universal Mobile Telecommunications System (UMTS) Release 6 software. The radio node provides enterprises with dedicated coverage and capacity for UMTS services. It is easy to install and connects to the existing enterprise LAN using standard Ethernet cabling. The radio node is managed by the SmartCloud Services Node 8000 (SCSN 8000) access controller. Figure 1 Radio Node Relationship to Enterprise and Carrier Core Networks Services Provided The radio node provides the following services: •Complete enterprise mobility using licensed spectrum •Radio Frequency (RF) self-calibration for autonomous setup, operation, and management •Enhanced networking •Transparent integration into enterprise network environments LAN Intranet DMZ Enterprise Carrier Core DHCP EmailWeb Iur Interface (between Controllers/RNCs) 3G Cipher Uu Int PoE+ Injector SCRN 200s SGSN MSC IPSec Backhaul IPsec SwitchSwitch Firewall Security Gateway SCSN 8000 SCSN 8000 Iu-CS Iu-PS IPsec SmartCloud Radio Node - SCRN 200 Hardware Installation Guide SpiderCloud Wireless, Inc. 6 Radio Node System Isometric Top View and Bottom View The following diagrams display an isometric top and bottom views of the radio node: Figure 2 Radio Node Top View Figure 3 Radio Node Bottom View with Pedestal Base SmartCloud Radio Node - SCRN 200 Hardware Installation Guide SpiderCloud Wireless, Inc. 7 System Specifications Following are the system specifications for the radio node frequency bands of operation, system size, power, environmental requirements, and compliance: Frequency Bands of O…

Text truncated - open the document above for the full version.

Feb 20, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035, USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SpiderCloud Wireless Inc. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): SCRN-200-2, SCRN-200-2E (Band II) We affirm that between SIEMIC and SpiderCloud Wireless Inc., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely,

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 2.0 Feb 20, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: Y47RN200B2 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Part List - Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 2.0 Jan 20, 2012 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: Y47RN200B2 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 days: - User Manual - Internal Photos - The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors.

EUT (SCRN-200-1) - Front View EUT (SCRN-200-1) - Back View EUT (SCRN-200-1) - Top View EUT (SCRN-200-1) - Bottom View EUT (SCRN-200-1) - Right View EUT (SCRN-200-1) - Left View EUT (SCRN-200-1E) - Front View EUT (SCRN-200-1E) - Back View EUT (SCRN-200-1E) - Top View EUT (SCRN-200-1E) - Bottom View EUT (SCRN-200-1E) - Right View EUT (SCRN-200-1E) - Left View Power Supply External Antenna (SPDA17806/2170) Internal Antenna

Label Drawing Label Location SpiderCloud Wireless Inc. FCC ID: Y47RN200B2 IC: 9424A-RN200B2 Model: SCRN-200-2

Label Drawing Label Location SpiderCloud Wireless Inc. FCC ID: Y47RN200B2 IC: 9424A-RN200B2 Model: SCRN-200-2E

EUT –Top- with RF Shield EUT –Top- without RF Shield EUT – bottom

MPE CALCULATION RF Exposure Requirements: 47 CFR §1.1307(b) RF Radiation Exposure Limits: 47 CFR §1.1310 RF Radiation Exposure Guidelines: FCC OST/OET Bulletin Number 65 EUT Frequency Band: 1500 ~100,000MHz Power Density Limit: 1 mW/ cm 2 Equation: S = PG / 4πR 2 or R = √PG / 4πS Where, S = Power Density P = Power Input to Antenna G = Antenna Gain R = distance to the center of radiated antenna ______________________________________________________________________________________________________________________ Band II Conducted power = 726.1059mw, Antenna Gain (numeric) = 1.78 , MPE limit = 1 mW/cm 2 R= 20cm Result The Above Result had shown that the minimum separation distance in order to meet MPE requirement is 0.257 mW/cm 2 .
