Y8PFJ16-1Keyless Access with Push-Button Start System

Manual Requirement of FCC / IC Our product (FJ16-1) is one of vehicle parts. Therefore, we will not supply the user’s manual. However, we will ask the vehicle manufacturer to include following statements in the vehicle user’s manual in accordance with FCC and IC requirements. 1. Requirement for User Manual 1.1. FCC Requirement 1.1.1. In accordance with 15.21 of FCC rule, following statement will be included in the user’s manual. 1.1.2. In accordance with requirement of FCC§15.19(a)(3), following statement will be included in the user’s manual. 1.2. IC Requirement 1.2.1. In accordance with requirement of RSS-GEN, following statement will be included in the user’s manual. FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.

FUJI HEAVY INDUSTRIES LTD. Keyless Access with Push-Button Start System FCC ID: Y8PFJ16-1 IC Number: 9490A-FJ161 External Photos (Smart ECU) 1/3 Front Rear FUJI HEAVY INDUSTRIES LTD. Keyless Access with Push-Button Start System FCC ID: Y8PFJ16-1 IC Number: 9490A-FJ161 External Photos (Smart ECU) 2/3 Top Bottom FUJI HEAVY INDUSTRIES LTD. Keyless Access with Push-Button Start System FCC ID: Y8PFJ16-1 IC Number: 9490A-FJ161 External Photos (Smart ECU) 3/3 Right Left Note: The outer appearance may be changed. FUJI HEAVY INDUSTRIES LTD. Keyless Access with Push-Button Start System FCC ID: Y8PFJ16-1 IC Number: 9490A-FJ161 External Photos (Antenna (TYPE1)) Front Rear Top Bottom Right Left Note: The outer appearance may be changed. FUJI HEAVY INDUSTRIES LTD. Keyless Access with Push-Button Start System FCC ID: Y8PFJ16-1 IC Number: 9490A-FJ161 External Photos (Antenna (TYPE2)) Front Rear Top Bottom Right Left Note: The outer appearance may be changed. FUJI HEAVY INDUSTRIES LTD. Keyless Access with Push-Button Start System FCC ID: Y8PFJ16-1 IC Number: 9490A-FJ161 Antenna Connection

10. Mark Note: Compli a Marking king location ance statem g layout, size n and layout ent of marki e and other i t ng will not b indications m This device co Operation is sub device may not c must accept any that may cause u be changed. maybe chan omplies with part 15 bject to the following tw cause harmful interferen y interference received, undesired operation. nged and ad of the FCC Rules. wo conditions: (1) This ce, and (2) this device including interference ded. 18

FUJI HEAVY INDUSTRIES LTD. Keyless Access with Push-Button Start System FCC ID: Y8PFJ16-1 IC Number: 9490A-FJ161 Internal Photos (Smart ECU) Component side Solder side Antenna for Rx Internal P h Pri Note: The outer c hotos (Ante nted Circui case may be enna (TYPE it Board Fro e changed. Keyless 1)) ont View s Access Front Rear Top Bottom FUJI HE s with Pu IC Printed EAVY IND ush-Butt FC C Numbe Circuit Bo DUSTRIE ton Start C ID: Y8 er: 9490A oard Rear Vi ES LTD. System PFJ16-1 A-FJ161 iew FUJI HEAVY INDUSTRIES LTD. Keyless Access with Push-Button Start System FCC ID: Y8PFJ16-1 IC Number: 9490A-FJ161 Internal Photos (Antenna (TYPE2)) Front Rear Top Bottom

Test report No. : 10835051H-B-R1 Page : 2 of 15 Issued date : July 21, 2015 Revised date : September 17, 2015 FCC ID : Y8PFJ16-1 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 REVISION HISTORY Original Test Report No.: 10835051H-B Revision Test report No. Date Page revised Contents - (Original) 10835051H-B July 21, 2015 - - 1 10835051H-B-R1 September 17, 2015 P.5 Update to FCC version 1 10835051H-B-R1 September 17, 2015 P.9 Correction of explanatory note for test position Test report No. : 10835051H-B-R1 Page : 3 of 15 Issued date : July 21, 2015 Revised date : September 17, 2015 FCC ID : Y8PFJ16-1 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 CONTENTS PAGE SECTION 1: Customer information ...................................................................................... 4 SECTION 2: Equipment under test (E.U.T.) ....................................................................... 4 SECTION 3: Test specification, procedures & results ......................................................... 5 SECTION 4: Operation of E.U.T. during testing ................................................................. 7 SECTION 5: Radiated Emission ............................................................................................ 9 APPENDIX 1: Test date ........................................................................................................ 10 Radiated Emission ....................................................................................................................... 10 APPENDIX 2: Test instruments ........................................................................................... 12 APPENDIX 3: Photographs of test setup............................................................................. 13 Radiated Emission ....................................................................................................................... 14 Worst Case Position (Horizontal: X-axis / Vertical: X-axis) ................................................... 15 Test report No. : 10835051H-B-R1 Page : 4 of 15 Issued date : July 21, 2015 Revised date : September 17, 2015 FCC ID : Y8PFJ16-1 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 SECTION 1: Customer information Company Name : FUJI HEAVY INDUSTRIES LTD. Address : 1-1, Subaru-cho, ota-shi, Gunma-ken, 373-8555, Japan Telephone Number : +81-276-26-3064 Facsimile Number : +81-276-26-3069 Contact Person : Yuji Kobayashi SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : Keyless Access with Push-Button Start System Model No. : FJ16-1 Serial No. : Refer to Section 4, Clause 4.2 Rating : DC12.0 V Receipt Date of Sample : June 11, 2015 Country of Mass-production : United States of America and Japan Condition of EUT : Production prototype (Not for Sale: This sample is equivalent to mass-produced items.) Modification of EUT : No Modification by the test lab 2.2 Product description Model No: FJ16-1 (referred to as the EUT in this report) is the Smart system. General Specification Clock frequencies in the system : 4.000 MHz (CPU) Radio Specification [Transmitter] *4) Radio Type : Transmitter Frequency of Operation : 134.2 kHz Oscillator Frequency : 4.2944 MHz Type of Modulation : OOK (A1D) Oscillation circuit : Crystal Power Supply : DC 12.0 V Antenna : Antenna (TYPE 1) (*1) (*3) / (TYPE 2) (*2) *1: Maximum number of this antenna is 2. *2: Maximum number of this antenna is 4. Antenna Specification : Ferrite antenna coil [Receiver] Radio Type : Receiver Frequency of Operation : 433.92 MHz Oscillator frequency : 52.9025 MHz (Crystal) Type of Modulation : FSK Type of receiving system : Super-heterodyne Power Supply : DC 5.0 V Antenna Type : Internal antenna (Inverted F antenna) *3) The Antenna (TYPE 1) of this system has variations of model 1 and model 2. The difference of these variations is only the outer shell, and the test was performed with the representative model 1. *4) The test of transmitter part was performed separately from this test report, and the conformability is confirmed. Test report No. : 10835051H-B-R1 Page : 5 of 15 Issued date : July 21, 2015 Revised date : September 17, 2015 FCC ID : Y8PFJ16-1 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 SECTION 3: Test specification, procedures & results 3.1 Test specification Test specification : FCC Part 15 Subpart B: 2015, final revised on September 8, 2015 Title : FCC 47CFR Part15 Radio Frequency Device Subpart B Unintentional Radiators * The revision on September 8, 2015 does not affect the test specification applied to the EUT. 3.2 Procedures and results Item Test Procedure Limits Deviation Worst margin Result Conducted emission FCC: ANSI C63.4: 2009 7. AC powerline conducted emission measurements FCC: Part 15 Subpart B 15.107(a) N/A *1) N/A N/A IC: RSS-Gen 8.8 IC: RSS-Gen 8.8 Radiated emission FCC: ANSI C63.4: 2009 8. Radiated emission measurements FCC: Part 15 Subpart B 15.109(a) N/A 15.2 dB 1735.680 MHz Horizontal, PK Complied IC: RSS-Gen 7 IC: RSS-Gen 7.1.2 *Note: UL Japan, Inc’s EMI Work Procedure 13-EM-W0420. *1) The test is not applicable since the EUT is not the device that is designed to be connected to the public utility (AC) power line. 3.3 Addition to standard No addition, exclusion nor deviation has been made from the standard. 3.4 Uncertainty EMI The following uncertainties have been calculated to provide a confidence level of 95 % using a coverage factor k = 2 Test room (semi- anechoic chamber) Radiated emission (3 m*)(+dB) (1 m*)(+dB) (0.5 m*)(+dB) 9 kHz - 30 MHz 30 MHz - 300 MHz 300 MHz - 1 GHz 1 GHz - 10 GHz 10 GHz - 18 GHz 18 GHz - 26.5 GHz 26.5 GHz - 40 …
