YA7-ATVT1240Vehicle telematics

AK1 User Manual Revision: 05 Revision Date: 2012/06/25 ATrack Technology Inc. 3F., No. 88, Sec. 1, Neihu Rd., Neihu Dist., Taipei City 11493, Taiwan (R.O.C.) Tel: +886-2-27975852 Fax: +886-2-27974030 http://www.atrack.com.tw Confidential Document © ATrack Technology Inc. All Rights Reserved. Page 2 of 16 Contents 1. Notification .............................................................................................................................. 3 1.1. Disclaimer .................................................................................................................................... 3 1.2. Copyright ...................................................................................................................................... 3 1.3. Warning ........................................................................................................................................ 3 2. Hardware ................................................................................................................................. 4 2.1. Package Content ......................................................................................................................... 4 2.2. SIM Card Installation .................................................................................................................... 4 2.3. Power I/O Connector ................................................................................................................... 5 2.4. Serial Port Connector ................................................................................................................... 6 2.5. GPS Antenna ............................................................................................................................... 7 2.6. LED Indicators ............................................................................................................................. 8 3. Configuration .......................................................................................................................... 9 3.1. Connect device to HyperTerminal ................................................................................................ 9 3.2. Connect the device to the remote server ................................................................................... 13 4. Firmware Upgrade ............................................................................................................... 14 5. Appendix ................................................................................................................................ 15 5.1. Hardware Specification .............................................................................................................. 15 5.2. FCC Regulations: ....................................................................................................................... 16 Confidential Document © ATrack Technology Inc. All Rights Reserved. Page 3 of 16 1 1 . . N N o o t t i i f f i i c c a a t t i i o o n n 1 1 . . 1 1 . . D D i i s s c c l l a a i i m m e e r r This document, and all other related products, such as device, firmware, and software, is developed by ATrack Technology Inc. thoroughly. At the time of release, it is most compatible with specified firmware version. Due to the functionalities of the devices are being developed and improved from time to time, the change in the protocol, specification, and firmware functions are subjects to change without notice. ATrack Technology Inc. is obligated to modify all the documentation without the limitation of time frame. A change notice shall be released to ATrack Technology Inc. customers upon the completion of document modification. ATrack Technology Inc. products are not intended to be used as life support or rescue equipments. ATrack Technology Inc. is not liable for any loss or injury caused by using or referencing to any products. Any possible means of using or integrating ATrack Technology Inc. products shall be avoided. 1 1 . . 2 2 . . C C o o p p y y r r i i g g h h t t ATrack Technology Inc. holds all parts of intellectual rights applicable in the copyright laws in all the countries. Any or all parts of this document shall not be exposed to non-authorized party without any form of approval from ATrack Technology Inc. Any forms, including but not limited to oral, copy, or internet sharing, of releasing or exposing information to an unauthorized party shall be prohibited. ATrack Technology Inc. reserves the rights of litigation in the violation of such copyright laws. 1 1 . . 3 3 . . W W a a r r n n i i n n g g Connecting the wire inputs can be hazardous to both the installer and your vehicle’s electrical system if not done by an experienced installer. This document assumes you are aware of the inherent dangers of working in and around a vehicle and have a working understanding of electricity. Confidential Document © ATrack Technology Inc. All Rights Reserved. Page 4 of 16 2 2 . . H H a a r r d d w w a a r r e e 2 2 . . 1 1 . . P P a a c c k k a a g g e e C C o o n n t t e e n n t t Each package contains the following device/accessories: • Device * 1 (one of the devices below) AK1 • GPS Antenna * 1 for AT1EONLY • Serial Cable * 1 • Power/IO Cable * 1 2 2 . . 2 2 . . S S I I M M C C a a r r d d I I n n s s t t a a l l l l a a t t i i o o n n The AK1 supported 1.8V/3V universal SIM card which provided by worldwide GSM operators. Unscrew the SIM cover on the button of the AK1 device for SIM card installation. Confidential Document © ATrack Technology Inc. All Rights Reserved. Page 5 of 16 2 2 . . 3 3 . . P P o o w w e e r r I I / / O O C C o o n n n n e e c c t t o o r r The following figure shows power I/O connector and its pin number of AK1 The following table shows its function of power I/O connector Power I/O Connector Pin# Function Color Designation Note 1 Main power input Red PWR DC 9V~40V input 2 Power ground Black GND 3 ACC Input Yellow A…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 3F., No. 88, Sec. 1, Neihu Rd., Neihu Dist., Taipei 11493, Taiwan October 7, 2013 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ATrack Technology Inc. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Vehicle telematics / YA7-ATVT1240 We affirm that between SIEMIC and ATrack Technology Inc., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, _____________________ Daniel Lee / Vice President Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Tel: +886 3 318 3232 #1857

1 CONSTRUCTION PHOTOS OF EUT 2 3 4 5

AK1 Label

2 3 4 5 6 7

Report No.: SA130912C02A 1 of 6 Report Format Version 5.0.0 Reference No.: 131007C19 RF EXPOSURE REPORT REPORT NO.: SA130912C02A MODEL NO.: AK1 FCC ID: YA7-ATVT1240 RECEIVED: Oct. 07, 2013 ISSUED: Oct. 09, 2013 APPLICANT: ATrack Technology Inc. ADDRESS: 3F., No. 88, Sec. 1, Neihu Rd., Neihu Dist., Taipei City 11493 Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA130912C02A 2 of 6 Report Format Version 5.0.0 Reference No.: 131007C19 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION .............................................................................................. 4 2. RF EXPOSURE ................................................................................................ 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ............................ 5 2.2 MPE CALCULATION FORMULA ....................................................................... 5 2.3 CLASSIFICATION .............................................................................................. 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ..................... 6 Report No.: SA130912C02A 3 of 6 Report Format Version 5.0.0 Reference No.: 131007C19 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA130912C02A Original release Oct. 09, 2013 Report No.: SA130912C02A 4 of 6 Report Format Version 5.0.0 Reference No.: 131007C19 1. CERTIFICATION PRODUCT: Vehicle telematics MODEL: AK1 BRAND: ATrack APPLICANT: ATrack Technology Inc. TEST SAMPLE: Identical Prototype STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: AK1) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE : Oct. 09, 2013 Gina Liu / Specialist APPROVED BY : , DATE : Oct. 09, 2013 Gordon Lin / Assistant Manager Report No.: SA130912C02A 5 of 6 Report Format Version 5.0.0 Reference No.: 131007C19 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA130912C02A 6 of 6 Report Format Version 5.0.0 Reference No.: 131007C19 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER Frequency Band (MHz) Operating Mode Maximum Conducted (dBm) Antenna Gain (dBi) E.I.R.P. (mW) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Burst Avg. Power Time Avg. Power GSM850 GPRS8 35 26 0 398.11 0.079 0.55 GSM1900 GPRS8 32 23 0 199.53 0.040 1

Report No.: RF130912C02 1 of 29 Report Format Version 5.0.0 FCC TEST REPORT (PART 22) REPORT NO.: RF130912C02 MODEL NO.: AK1 FCC ID: YA7-ATVT1240 RECEIVED: Sep. 12, 2013 TESTED: Sep. 25, 2013 ISSUED: Sep. 27, 2013 APPLICANT: ATrack Technology Inc. ADDRESS: 3F., No. 88, Sec. 1, Neihu Rd., Neihu Dist., Taipei City 11493 Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF130912C02 2 of 29 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................. 4 1 CERTIFICATION ........................................................................................................ 5 2 SUMMARY OF TEST RESULTS ................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY .................................................................. 6 2.2 TEST SITE AND INSTRUMENTS .................................................................. 7 3 GENERAL INFORMATION ......................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ............................................................... 8 3.2 CONFIGURATION OF SYSTEM UNDER TEST ............................................. 9 3.3 DESCRIPTION OF SUPPORT UNITS ........................................................... 9 3.4 TEST ITEM AND TEST CONFIGURATION ...................................................10 3.5 EUT OPERATING CONDITIONS .................................................................. 11 3.6 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................ 11 4 TEST TYPES AND RESULTS................................................................................... 12 4.1 OUTPUT POWER MEASUREMENT .............................................................12 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT ..........................................12 4.1.2 TEST PROCEDURES ...................................................................................12 4.1.3 TEST SETUP ................................................................................................13 4.1.4 TEST RESULTS ............................................................................................14 4.2 FREQUENCY STABILITY MEASUREMENT .................................................15 4.2.1 LIMITS OF FREQUENCY STABILITY MEASUREMENT ...............................15 4.2.2 TEST PROCEDURE .....................................................................................15 4.2.3 TEST SETUP ................................................................................................15 4.2.4 TEST RESULTS ............................................................................................16 4.3 OCCUPIED BANDWIDTH MEASUREMENT ................................................17 4.3.1 TEST PROCEDURES ...................................................................................17 4.3.2 TEST SETUP ................................................................................................17 4.3.3 TEST RESULTS ............................................................................................18 4.4 BAND EDGE MEASUREMENT.....................................................................19 4.4.1 LIMITS OF BAND EDGE MEASUREMENT ..................................................19 4.4.2 TEST SETUP ................................................................................................19 4.4.3 TEST PROCEDURES ...................................................................................19 4.4.4 TEST RESULTS ............................................................................................20 4.5 CONDUCTED SPURIOUS EMISSIONS .......................................................21 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT .........21 4.5.2 TEST PROCEDURE .....................................................................................21 4.5.3 TEST SETUP ................................................................................................21 4.5.4 TEST RESULTS ............................................................................................22 4.6 RADIATED EMISSION MEASUREMENT......................................................23 4.6.1 LIMIT…

Text truncated - open the document above for the full version.

Report No.: RF130912C02-1 1 of 31 Report Format Version 5.0.0 FCC TEST REPORT (PART 24) REPORT NO.: RF130912C02-1 MODEL NO.: AK1 FCC ID: YA7-ATVT1240 RECEIVED: Sep. 12, 2013 TESTED: Sep. 25, 2013 ISSUED: Sep. 27, 2013 APPLICANT: ATrack Technology Inc. ADDRESS: 3F., No. 88, Sec. 1, Neihu Rd., Neihu Dist., Taipei City 11493 Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF130912C02-1 2 of 31 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................. 4 1 CERTIFICATION ........................................................................................................ 5 2 SUMMARY OF TEST RESULTS ................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY .................................................................. 6 2.2 TEST SITE AND INSTRUMENTS .................................................................. 7 3 GENERAL INFORMATION ......................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ............................................................... 8 3.2 CONFIGURATION OF SYSTEM UNDER TEST ............................................. 9 3.3 DESCRIPTION OF SUPPORT UNITS ........................................................... 9 3.4 TEST ITEM AND TEST CONFIGURATION ...................................................10 3.5 EUT OPERATING CONDITIONS .................................................................. 11 3.6 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................ 11 4 TEST TYPES AND RESULTS................................................................................... 12 4.1 OUTPUT POWER MEASUREMENT .............................................................12 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT ..........................................12 4.1.2 TEST PROCEDURES ...................................................................................12 4.1.3 TEST SETUP ................................................................................................13 4.1.4 TEST RESULTS ............................................................................................14 4.2 FREQUENCY STABILITY MEASUREMENT .................................................15 4.2.1 LIMITS OF FREQUENCY STABILITY MEASUREMENT ...............................15 4.2.2 TEST PROCEDURE .....................................................................................15 4.2.3 TEST SETUP ................................................................................................15 4.2.4 TEST RESULTS ............................................................................................16 4.3 OCCUPIED BANDWIDTH MEASUREMENT ................................................17 4.3.1 TEST PROCEDURES ...................................................................................17 4.3.2 TEST SETUP ................................................................................................17 4.3.3 TEST RESULTS ............................................................................................18 4.4 PEAK TO AVERAGE RATIO .........................................................................19 4.4.1 LIMITS OF PEAK TO AVERAGE RATIO MEASUREMENT ...........................19 4.4.2 TEST SETUP ................................................................................................19 4.4.3 TEST PROCEDURES ...................................................................................19 4.4.4 TEST RESULTS ............................................................................................20 4.5 BAND EDGE MEASUREMENT.....................................................................21 4.5.1 LIMITS OF BAND EDGE MEASUREMENT ..................................................21 4.5.2 TEST SETUP ................................................................................................21 4.5.3 TEST PROCEDURES ...................................................................................21 4.5.4 TEST RESULTS ............................................................................................22 4.6 CONDUCTED SPURIOUS EMISSIONS .........................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST 2 ERP POWER TEST
