YJ8-LX1BT 2.1+ EDR Headset with Video Camera

Get Started Charge Looxcie Fully charge Looxcie before use. The Looxcie Indicator light will flash green while charging and remain green when fully charged. Charge by Plugging into a Power Outlet Plug the USB Power Adapter into a power outlet1. Plug the USB Cable into the USB Socket on the USB 2. Power Adapter Plug the USB Cable into the Micro USB Connector 3. on Looxcie, pushing firmly to establish a complete connection Charge by Plugging into a PC Plug the USB Cable into the USB Socket on your PC1. Plug the USB Cable into the Micro USB Connector 2. on Looxcie, pushing firmly to establish a complete connection Download the Looxcie App You must use the Looxcie App to view, edit, and share your Looxcie moments. The Looxcie App turns your smartphone into a controller so you can: Use your smartphone as a viewfinder • Review stored video and clips• Edit and create video clips of various lengths• Share clips via Facebook, YouTube, and more• Download the Looxcie App Turn on your smartphone1. Open the web browser and link to 2. www.looxcie.com/m Follow instructions to download and install the App on your 3. smartphone Visit www.looxcie.com to register and learn more about all the ways you can use the Looxcie App to capture and share all of your important Looxcie moments. Pair Looxcie to Your Smartphone You must pair Looxcie to your Bluetooth ® -enabled smartphone. The first time you turn on Looxcie, it automatically enters pairing mode. Pair Looxcie to Smartphone Press the Power/Call button on Looxcie for three seconds1. Confirm that the green Indicator light and the red Video On light are flashing, indicating pairing mode is active2. Turn on phone’s Bluetooth3. ® feature (“Settings/Tools” on most phones) Select “Looxcie” when phone displays “Search for Devices” results4. When the pairing is successful, the red Video On light will turn off and the green Indicator 5. light will flash more slowly See your phone’s user guide for more information on connecting to Bluetooth6. ® devices Pair Looxcie Manually If Looxcie does not automatically enter pairing mode or you want to pair an additional smartphone with your camcorder, you’ll need to pair it manually. Simultaneously hold and press the Volume and Power/Call buttons until the green 1. Indicator light and red Video On light start flashing If prompted for PIN or passkey, enter “0000”2. Be there. Charge Looxcie Download the Looxcie App Pair Looxcie to Your Smartphone Operate Looxcie as a Camcorder Operate Looxcie as a Bluetooth ® Headset Adjust the Fit of Looxcie Review Looxcie Controls Adjust the Fit of Looxcie Choose Your Earbud Looxcie comes with a medium earbud installed on the earbud post. If it does not fit securely and comfortably, replace it with the small or large earbuds provided. Gently pull the earbud off the earbud post to remove 1. Press the new earbud firmly on the post 2. Adjust Bendable Earloop Decide whether you’ll wear Looxcie on your right or left ear; turn 1. the 180° Rotating Earpiece to wear it on your left ear Put the Bendable Earloop around your ear 2. — it will hold its shape and keep the camcorder stable Twist and shape it until it fits comfortably and securely3. Note: Don’t hesitate to exert pressure on the earloop as you twist and turn it. It’s designed to withstand extensive twisting and turning. Operate Looxcie as a Bluetooth ® Headset Looxcie is more than a wearable camcorder; it’s also a Bluetooth ® headset you can use to make and receive calls once you’ve paired it with your smartphone. To use Looxcie as a Bluetooth ® headset, loop it over your ear and press the Power/Call button to turn it on. Headset Controls Answer a CallEnd a CallMake a CallRedialChange the Volume Press the Power/ Call button Press the Power/ Call button or use your phone Enter a phone number on your phone and press “Send” — the call will transfer to Looxcie Press and hold the Volume button Click the Volume button repeatedly until you reach the desired volume Review Looxcie Controls For more information, visit www.looxcie.com. Create Instant Clips Looxcie stores more than five hours of video. Press and release the Instant Clip button to save a clip of the • last thirty seconds Press and hold the Instant Clip button for three seconds to • create and immediately share a thirty-second clip with a pre-designated recipient (requires setup of Instant Share recipients in Looxcie App) Create longer clips by running the Looxcie App on your • smartphone — you can view, edit, and create clips of any length from stored video Share Looxcie Moments Once you create a clip, use your smartphone to email or post it to social media sites. Visit www.looxcie.com for more information on how to use the Looxcie App to save and share your Looxcie moments. Designed in Silicon Valley. ©2010 Looxcie, Inc. All rights reserved. US and international patents pending. Looxcie is a registered trademark of Looxcie, Inc. All other trademarks are the property of their respective owners. Bendable Earloop Video Button Micro USB Connector Camcorder Boom 180° Rotating Earpiece Indicator Light (Green) Instant Clip Button Video On Light (Red) Volume Button Operate Looxcie as a Camcorder Video Looxcie Moments Turn on Looxcie (Indicator light will flash green) 1. Press the Video button (Video On light will glow red)2. Launch the Looxcie App on your smartphone3. Look at viewfinder on phone to confirm video is level4. If not level, rotate camcorder boom and twist and bend earloop until Looxcie is 5. filming level at your line of sight Join the action! (Looxcie will video everything you see)6. Press the Video button to stop filming7. Note: For best results, use the viewfinder on your phone to confirm that you’re videoing what you see.

Specifications, Safety, and Warranty Information Welcome Thank you for purchasing Looxcie. Please read the specifications, safety, and warranty information in this document before you use Looxcie. Register Looxcie To access online support forums and receive up-to-date product information, please register your Looxcie at www.looxcie.com/support. Get Assistance Online Support Visit www.looxcie.com to get answers to your questions. Browse our comprehensive knowledge base, interact with Looxcie users via community forums, or submit questions to our technical support experts. Phone Support Get phone support by calling 1-(888) 7-LOOXCIE Monday through Friday, 9 am to 5 pm Pacific Time. Product Specifications Weight: less than 28 g (1 oz) Video HVGA video resolution 4 GB on-board storage f 2.8 lens Auto high color and light correction 5+ hours video storage 4+ hours record time MP4 video files Battery 365mAh lithium polymer battery UL/CSA-approved power supply Headset Bluetooth Class 2 Bluetooth V2.1 + EDR Hands Free Profile (HFP 1.5) Dual silicon MEMS microphones DSP-based noise cancellation 6+ hours talk time Range to 33 feet USB Micro USB connector USB 2.0 mass storage compatibility Limited Warranty Hardware Warranty Coverage Looxcie, Inc. (1196 Borregas Ave, Suite 200, Sunnyvale, CA 94089), warrants the Looxcie video device (“Product”) to be free of material defects (subject to the terms set forth below) for a period of one (1) year from the date of purchase (“Warranty Period”). This Warranty specifically excludes any Looxcie software applica- tions which are subject to separate End User License Agreements and any software embodied in the hardware. During the Warranty Period, Looxcie will repair or replace (at Looxcie’s discretion) this Product or any defective parts (“Warranty Service”) at no charge (other than applicable incidental charges). Replacement Product may be new or refurbished/recertified at Looxcie’s discretion. If repair or replacement is not commercially practical or cannot be timely made, Looxcie may choose to refund the purchase price paid for the affected Product. Call Looxcie support at 1-(888) 7-LOOXCIE for instructions regarding obtaining Warranty Service. If Looxcie provides service under Warranty, the terms of the Warranty and applicable provisions of law will cover defects in materials and workmanship that arise during the remaining Warranty or 90 days after service, whichever provides longer coverage. If service is provided outside of Warranty, Looxcie warrants that the replacement will be free from defects in materials and workmanship for 90 days from the replacement ship date. This Warranty is only valid for the original purchaser with the original purchase receipt and will automatically terminate prior to expiration if this Product is sold or otherwise transferred to another party. The Warranty provided by Looxcie in this statement applies only to Products purchased for use, and not for resale. It does not apply to open box purchases, which are sold “as is” and without any Warranty. Specifically exempt from Warranty are limited-life consumable components subject to normal wear and tear, such as earbuds, batteries, and other accessories. This Warranty does not cover cosmetic damage or damage due to misuse, abuse, negligence, acts of nature, accidents, disassembling, or modification of or to any part of the Product. This Warranty excludes damages resulting from actions not Looxcie’s fault and damages resulting from the use of non-Looxcie products. This Warranty does not cover lost data, files, clips, or video. This Warranty does not cover damage due to improper operation, maintenance, or installation, or attempted repair by anyone other than Looxcie or a Looxcie dealer authorized to do Looxcie Warranty work. Any unauthorized repairs will void this Warranty. WARRANTY IS EXCLUSIVE REMEDY OF CONSUMER. ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS EXPRESS WARRANTY. IN NO EVENT SHALL LOOXCIE BE LIABLE, WHETHER IN CONTRACT OR TORT, FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGES OF ANY KIND OR LOSS OF INFORMATION ARISING OUT OF OR IN CONNECTION WITH THE USE OR INABILITY TO USE THE PRODUCT(S), TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW. This Warranty applies only to purchases made in the U.S. and Canada. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS WHICH VARY FROM LOCATION TO LOCATION. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF DIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OR IMPLIED WARRANTIES, SO THE ABOVE EXCLUSIONS MAY NOT APPLY TO YOU. YOU MAY HAVE OTHER LEGAL (STATUTORY) RIGHTS UNDER YOUR APPLICABLE NATIONAL OR LOCAL LAWS. FCC Notice to Users FCC: YJ8-LX1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must not accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions may cause harmful interference to radio communications. However, there is no guarantee that interfer- ence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • R…

Text truncated - open the document above for the full version.

Certification and Safety Approvals FCC Notice To Users This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by Looxcie, Inc. will void the user’s authority to operate the equipment. Industry Canada Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference that may cause undesired operation of the device. The term “IC:” before the certification/registration number only signifies that registration was performed based on a Declaration of Conformity indicating that Industry Canada technical specifications were met. It does not imply that Industry Canada approved the equipment. CE This product is CE marked according to the provisions of the R&TTE Directive (99/5/EC). Hereby, GN A/S, declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Limited Warranty Hardware Warranty Coverage Looxcie, Inc., warrants this product to be free of defects in materials and workmanship (subject to the terms set forth below) for a period of one (1) year from the date of purchase (“Warranty Period”). During the Warranty Period, Looxcie will repair or replace (at Looxcie’s discretion) this product or any defective parts (“Warranty Service”). Replacement product may be new or refurbished/recertified. If repair or replacement is not commercially practical or cannot be timely made, Looxcie may choose to refund to you the purchase price paid for the affected product. If Looxcie provides service under warranty, the terms of the warranty and applicable provisions of law will cover defects in materials and workmanship that arise during the remaining warranty or 90 days after service, whichever provides longer coverage for you. If service is provided outside of warranty, Looxcie warrants that the replacement will be free from defects in materials and workmanship for 90 days from the replacement ship date. This warranty is only valid for the original purchaser with the original purchase receipt and will automatically terminate prior to expiration if this product is sold or otherwise transferred to another party. The warranty provided by Looxcie in this statement applies only to products purchased for use, and not for resale. It does not apply to open box purchases, which are sold “as is” and without any warranty. Specifically exempt from warranty are limited-life consumable components subject to normal wear and tear, such as microphone windscreens, ear cushions, modular plugs, ear tips, decorative finishes, batteries, and other accessories. This Warranty does not cover cosmetic damage or damage due to misuse, abuse, negligence, Acts of Nature, accident, disassembling or modification of, or to any part of, the product. This Warranty does not cover damage due to improper operation, maintenance or installation, or attempted repair by anyone other than Looxcie or a Looxcie dealer which is authorized to do Looxcie warranty work. Any unauthorized repairs will void this warranty. This warranty gives you specific legal rights. You may have other rights which vary from location to location. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or implied warranties, so the above exclusions may not apply to you. This warranty does not affect your legal (statutory) rights under your applicable national or local laws. Looxcie Support Register at Looxcie By registering at Looxcie.com, you not only enable us to provide you with important and up to date information about your product, you are also automatically registered to access all of our online support resources, including our community forums! Finding Answers Find answers to your questions at Looxcie.com. Browse our comprehensive knowledgebase, interact with your fellow Looxcie users in our community forums or submit a question directly to our technical support experts. Phone Support Still stuck? While we are confident that most of your questions can be answered quickly and immediately at Looxcie.com, we don’t stop there. Feel free to give us a call Monday through Friday from 9am to 5pm Pacific time at 1-(888)7-LOOXCIE. We are here to answer any of your questions. We’d love to hear from you!

PROPOSED FCC/IC ID LABEL AND LOCATION FCC /IC Label Location LOOXCIE FCC ID: YJ8-LX1 IC: 9087A-LX1 Mdl: LX1

FCC CFR47 PART 15 SUBPART B ICES-003 ISSUE 4 TEST REPORT FOR BT 2.1 + EDR HEADSET WITH VIDEO CAMERA MODEL NUMBER: LX1 FCC ID: YJ8-LX1 IC: 9087A-LX1 REPORT NUMBER: 10U13339-2, Revision B ISSUE DATE: AUGUST 30, 2010 Prepared for LOOXCIE, INC. 1196 BORREGAS AVE, SUITE 200 SUNNYVALE, CA 94089, U.S.A. Prepared by COMPLIANCE CERTIFICATION SERVICES 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 10U13339-2B DATE: AUGUST 30, 2010 EUT: BT 2.1 + EDR HEADSET WITH VIDEO CAMERA MODEL: LX1 Page 2 of 28 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issue Date Revisions Revised By --- 08/12/10 Initial Issue F. Ibrahim A 08/25/10 Revised FCC ID per clients request A. Zaffar B 08/30/10 Added radiated and conducted data for second configuration (EUT connected to PC). F. Ibrahim REPORT NO: 10U13339-2B DATE: AUGUST 30, 2010 EUT: BT 2.1 + EDR HEADSET WITH VIDEO CAMERA MODEL: LX1 Page 3 of 28 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS.................................................................................... 4 2. TEST METHODOLOGY ........................................................................................................ 5 3. FACILITIES AND ACCREDITATION.................................................................................... 5 4. CALIBRATION AND UNCERTAINTY .................................................................................. 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................... 5 4.2. SAMPLE CALCULATION.............................................................................................. 5 4.3. MEASUREMENT UNCERTAINTY................................................................................ 5 5. EQUIPMENT UNDER TEST ................................................................................................. 6 5.1. DESCRIPTION OF EUT................................................................................................ 6 5.2. TEST CONFIGURATIONS............................................................................................ 6 5.3. MODE(S) OF OPERATION........................................................................................... 6 5.4. MODIFICATIONS.......................................................................................................... 6 5.5. DETAILS OF TESTED SYSTEM .................................................................................. 7 6. TEST AND MEASUREMENT EQUIPMENT ....................................................................... 10 7. APPLICABLE LIMITS AND TEST RESULTS .................................................................... 11 7.1. RADIATED EMISSIONS ............................................................................................. 11 7.1.1. CONFIGURATION 1 ........................................................................................... 12 7.1.2. CONFIGURATION 2 ........................................................................................... 15 7.2. AC POWER LINE CONDUCTED EMISSIONS ........................................................... 18 7.2.1. CONFIGURATION 1 ........................................................................................... 19 7.2.2. CONFIGURATION 2 ........................................................................................... 22 8. SETUP PHOTOS................................................................................................................. 25 REPORT NO: 10U13339-2B DATE: AUGUST 30, 2010 EUT: BT 2.1 + EDR HEADSET WITH VIDEO CAMERA MODEL: LX1 Page 4 of 28 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: LOOXCIE, INC. 1196 BORREGAS AVE, SUITE 200 SUNNYVALE, CA 94089, U.S.A. EUT DESCRIPTION: BT 2.1 + EDR Headset with video camera MODEL: LX1 SERIAL NUMBER: 02124 DATE TESTED: AUGUST 09-27, 2010 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART B ICES-003 ISSUE 4 Pass Pass Compliance Certification Services, Inc. (CCS) tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by CCS based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by CCS and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by CCS will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, any agency of the Federal Government, or any agency of any government. Approved & Released For CCS By: Tested By: FRANK IBRAHIM TOM CHEN EMC SUPERVISOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 10U13339-2B DATE: AUGUST 30, 2010 EUT: BT 2.1 + EDR HEADSET WITH VIDEO CAMERA MODEL: LX1 Page…

Text truncated - open the document above for the full version.

REPORT NO: 10U13339-2B DATE: AUGUST 30, 2010 EUT: BT 2.1 + EDR HEADSET WITH VIDEO CAMERA MODEL: LX1 Page 25 of 28 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. 8. SETUP PHOTOS DIGITAL DEVICE RADIATED EMISSIONS SETUP CONFIGURATION 1 DIGITAL DEVICE FRONT PHOTO DIGITAL DEVICE BACK PHOTO REPORT NO: 10U13339-2B DATE: AUGUST 30, 2010 EUT: BT 2.1 + EDR HEADSET WITH VIDEO CAMERA MODEL: LX1 Page 26 of 28 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. DIGITAL DEVICE RADIATED EMISSIONS SETUP CONFIGURATION 2 DIGITAL DEVICE FRONT PHOTO DIGITAL DEVICE BACK PHOTO REPORT NO: 10U13339-2B DATE: AUGUST 30, 2010 EUT: BT 2.1 + EDR HEADSET WITH VIDEO CAMERA MODEL: LX1 Page 27 of 28 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP CONFIGURATION 1 LINE CONDUCTED FRONT PHOTO LINE CONDUCTED BACK PHOTO REPORT NO: 10U13339-2B DATE: AUGUST 30, 2010 EUT: BT 2.1 + EDR HEADSET WITH VIDEO CAMERA MODEL: LX1 Page 28 of 28 COMPLIANCE CERTIFICATION SERVICES FORM NO: CCSUP4701C 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP CONFIGURATION 2 END OF REPORT LINE CONDUCTED FRONT PHOTO LINE CONDUCTED BACK PHOTO
