User Manual Model: LXHD 2 Customer Support Visit www.looxcie.com/support or call 1-855-LOOXCIE (566-9243) if you need technical support. Register Your Looxcie To receive important product updates, register your Looxcie at www.looxcie.com/support. Join the Looxcie Community •Become a Looxcie Facebook fan at facebook.com/looxcie. •Follow @LooxcieCam on Twitter at twitter.com/looxciecam. •Subscribe to the Looxcie YouTube channel at youtube.com/looxcie. Thank You for Purchasing Looxcie Please read this user manual carefully before using your Looxcie 3 Looxcie Overview USB Port Record Button Instant Clip Button Record Light (Red) Wi-Fi On (Blue) Power On (Green) Power Off MicroSD Slot Battery Contacts Lens 4 Basic Looxcie Controls Instant Clip Button •Press and release to create an Instant Clip. •Press and hold for approximately 2 seconds to create and send an Instant Clip to your instant share favorite. Go to Settings in the Looxcie mobile app to set up instant sharing. Looxcie Controls Power Switch Slide to power on/off. (Shows green when switched on.) Slide to power on Wi-Fi. (Shows blue when switched on.) Record Button Press to start/stop recording. 5 Get Started Setup Your Looxcie •Insert memory card into microSD slot. •Attach battery to camera and lock into place. TIP: Battery is replaceable. Shop at www.looxcie.com/store. Charge Your Looxcie •Make sure camera is fully charged. •Plug USB Cable into camera’s micro-USB port. •Plug USB Cable into computer’s USB port. TIP: Green light stops flashing when charged. Power off camera for faster charge. Push slot to open & close. Attach battery as shown. Charge with microUSB cable included. 6 Download the Apps Download Desktop App •Download LooxcieDesktop utility onto a computer for firmware upgrades. www.looxcie.com/HDapps Download Mobile App •Download Looxcie mobile app onto smartphone or tablet. www.looxcie.com/HDapps Slide power switch towards Wi-Fi symbol. Get Connected Connect Wi-Fi •Slide camera power switch to “Wi-Fi” position. (Switch glows blue.) •Turn on your smartphone or tablet’s Wi-Fi (under Settings). •Select “Looxcie HD” from list of Wi-Fi networks. TIP: Replace cap to maintain weather-resistant seal, if needed. For more help, visit www.looxcie.com/support. 7 Record, Share, Stream Record & Share •Launch Looxcie mobile app on your smartphone or tablet. •Login following instructions on screen. •Tap camera icon and select “Record” to start recording. •Preview video and share clips to friends and family. TIP: Press Instant Clip button on camera to create 30-second “instant replay” clips. Stream Broadcasting •Tap camera icon and select “Broadcast” to start streaming. •Invite friends to a private broadcast or share a public feed on a community channel or Facebook. Viewing •Tap “Videos” to watch broadcasts from your friends. TIP: Login to Facebook to post broadcast notifications on your Facebook wall or newsfeed. 8 FCC Notice to Users FCC: YJ8-LX4 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna •Increase the separation between the equipment and receiver •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected •Consult the dealer or an experienced radio/TV technician for help Users are not permitted to make changes to modify the device in any way. Changes or modifications not expressly approved by Looxcie, Inc. will void the Looxcie Warranty and the user’s authority to operate the equipment. 9 Industry Canada IC: 9087A-LX4 Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. The term “IC” before the certification/registration number only signi- fies that registration was performed based on a Declaration of Conformity indicating that Industry Canada technical specifications were met. It does not imply that Industry Canada approved the equipment. This device complies with RSS210 of Industry Canada. CAUTION: Exposure to Radio Frequency Radiation. The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada limits for the general population. Consult Safety Code 6, obtainable from Health Canada’s website www.hc-sc.ca/rpb. CE Declaration of Conformity This Product is CE marked according to the provisions of the R&TTE Directive (1999/5/EC). Looxcie declares that this Product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. 10 Copyright © 2012 Looxcie, Inc. All rights reserved. Looxcie and the Looxcie logo are trademarks or registered trademarks of Looxcie, Inc. US and international patents pending. For more information, visit www.looxcie.com. Looxcie Model: LXHD Warranty & Safety Information Thank you for purchasing Looxcie. Please read the warranty and safety…
