YNE-12357Z-Wave Light Controller

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: YNE-12357 FCC Rule Part: 15.249 ACS Report Number: 10-0107.W03.11.A Manufacturer: Kichler Lighting Model: 12357BK, 12357WH Manual WIRELESS DIMMER SETUP NOTE: • Steps in this section will allow user to setup controllers to work in unison on separate runs. • In order for 2 or more switches to work in unison, a network needs to be created and then the controllers need to be associated (linked) together. • Connect each controller to separate light bars powered by different power supplies. Power must be on. • Error is indicated by 10 dim blinks in succession. • Success is indicated by 2 bright blinks in succession. Add an under cabinet controller to network (slave controller add) On the first controller: 1. Press & release recessed RESET button. (The first controller light bar will blink 2 times) 2. Press & hold '+' button for until first controller light bar blinks 2 times. (Hold for hold approx. 2 seconds) On the second controller: 1. Press & release recessed RESET button. (The second controller light bar will blink 2 times) 2. Press & hold both '+' button and '-' button until both the first controller light bar and second controller light bar blinks 2 times. (Hold for approx. 2 seconds) Repeat steps for additional controllers. Take note of which controller was the first controller in above steps. This controller is now the master controller in the network, and is the only one that can add/remove other controllers to the network. Any additional controllers will be slave controllers. Create association (Link) under cabinet controller On the master controller: 1. Press & hold both '+' and '-' buttons until the master LED light bar blink 2 times (hold approx. 2 seconds) 2. Press & release '+' button to put controller into ASSOCIATION ADD MODE (lights will blink twice). On the second controller: 1. Press and release '+' button. Both master and second controller will blink 2 times. Repeat steps for additional link associations. The 'associated' controllers will now track (work in synchronization) with each other. SPECIAL CASE SET-UP: IN-LINE SYNCHRONIZATION • When two or more controllers need to be connected to the same set of LED lights, it will be necessary to follow these steps below for all slave controllers: • Follow all instructions for "WIRELESS DIMMER SETUP" first. 1. Press and hold the recessed RESET button until the attached lights blink 2 times. (Hold approx. 2 seconds) 2. Press the '-' button. (Lights will turn ON) DIMMER MODULE INSTALLATION INSTRUCTIONS Before Installing: All installations should comply with National and local electrical codes. If you have any doubts concerning installation contact a qualified, licensed electrician. NOTE: Read all instructions thoroughly before starting installation. The Kichler ® dimming module can be directly mounted to a Kichler LED KCL fixture OR simply in-line using a Kichler LED interconnect cable. NOTE: • The dimmer switch module can be connected between any fixtures or at either end of a connected run of fixtures. • For use only with Kichler LED 24VDC Class 2, 5 AMP MAX Cabinet Lighting fixtures and accessories. DIRECTLY TO FIXTURES 1) Align connector on end of dimmer module with connector on end of existing fixture. 2) Push dimmer module to existing fixture until the fixture and the dimmer module are flush and connectors snap together. 3) Drive pre-installed screws into mounting surface until fixture is secure. If screws are difficult to install, remove screws, mark holes, and drill 1/16” pilot holes. (See Fig. 3) NOTE: DO NOT OVER TIGHTEN SCREWS. IN-LINE USING INTERCONNECT CABLES 1) Determine location for dimmer module in run. 2) Select proper length interconnect cable P/N 12341 (9”), 12342 (14”), 12343 (21”) or 12345 (10’). 3) Drive pre-installed screws into mounting surface until fixture is secure. If screws are difficult to install, remove screws, mark holes, and drill 1/16” pilot holes. NOTE: DO NOT OVER TIGHTEN SCREWS. 4) Hold interconnect cable to mounting surface and determine best path for cable. If interconnect cable is being run from cabinet to cabinet a notch such as a “V” could be cut in cabinet side panels to help keep cable out of sight. NOTE: Interconnect cable is UL rated CL2. Installer should check with local building codes to determine if CL2 wire is allowed to run through floors, walls and ceilings. (See Fig. 4) 5) Peel backing off retaining clip(s) and affix to desired location(s). Surface should be as clean as possible. Drive pre-installed screw into the cabinet surface to secure the retaining clip to the surface. (See Fig. 5) 6) Slip Cable into clip(s) and snap closed. DIMMER CONTROL Turn OFF lights Turn ON lights: Momentary press of '+' button shall return to last dimmed level. : Momentary press of '-' button enable 0% brightness. Dim Up lights: Press and Hold '+" Button shall enable DIM UP to be selected. Dim Down lights: Press and Hold '-" Button shall enable DIM DOWN to be selected. ADDITIONAL WIRELESS DIMMER PROGRAMMING OPTIONS: Remove association (Link) to under cabinet controller: On the first controller: 1. Press and hold the '+' and '-' buttons for until controller blinks 2 times. (hold for approx. 2 seconds) 2. Press & release '-' button. On the second controller: 1. Press & release '-' button. (Controller will blink 2 times) Remove under cabinet controller from network: On the master controller: 1. Press & release recessed RESET button. (Master LED light bars will blink 2 times) 2. Press & hold '-' until the master lights blink 2 times (hold approx. 2 seconds). On the second controller: 1. Press & release recessed RESET button. (Second controller LED light bars will blink 2 times) 2. Press & hold both '+' and '-' until the master lights and slave controller lights blink 2 times. (hold approx. 2 seconds) Remove In-line Synchronization: 1. Press & hold the recessed RESET button on controller until a…

Text truncated - open the document above for the full version.

Advanced Compliance Solutions – 5015 B.U. Bowman Drive, Buford, GA 30518 Phone: (770) 831-8048 Fax: (770) 831-8598 January 25, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Kichler Lighting respectfully requests confidentiality of certain materials provided with the submission of the 12357BK and 12357WH under FCC ID: YNE-12357 in accordance with FCC Regulations 0.459. The confidentiality request applies to the following exhibits: 10-0107.W03.11.A – Schematics.pdf 10-0107.W03.11.A – System Block Diagram.pdf 10-0107.W03.11.A – Theory of Operation.pdf The 12357BK and 12357WH have been developed at considerable effort and expense by Kitchler Lighting. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company’s business advantage. I appreciate your assistance in this matter. Sincerely, Sam Wismer Vice President, Technology Agent

5015 B. U. Bowman Dr. Buford, GA 30518 January 28, 2011 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: YNE-12357 To Whom It May Concern: The following application is submitted on behalf of our client, Kichler Lighting, for evaluation of their models 12357BK and 12357WH for certification under FCC Part 15.249. Models 12357BK and 12357WH are electrically identical and differ only in color or the exterior enclosure. Only model 12357BK was evaluated for the purpose of demonstrating compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: YNE-12357 FCC Rule Part: 15.249 ACS Report Number: 10-0107.W03.11.A Manufacturer: Kichler Lighting Model: 12357BK, 12357WH External Photos Model(s): 12357BK, 12357WH FCC ID: YNE-12357 ACS Report: 10-0107.W03.11.A Advanced Compliance Solutions Page 2 Figure 1: Front View Figure 2: Back View Model(s): 12357BK, 12357WH FCC ID: YNE-12357 ACS Report: 10-0107.W03.11.A Advanced Compliance Solutions Page 3 Figure 3: Side View Figure 4: Side View

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: YNE-12357 FCC Rule Part: 15.249 ACS Report Number: 10-0107.W03.11.A Manufacturer: Kichler Lighting Model: 12357BK, 12357WH Label Information 3.0076.20 2.3960.69 .230 5.84 .115 2.93 4X .255 [6.47] .100 [25.4] .120 [3.04] FONT: ARIAL, BOLD CHARACTER HEIGHT: .093" SCREEN PRINT MARKINGS FOR PL114331BK PRINT COLOR WHITE FOR PL114331WH RPINT COLOR BLACK ENG DENOTES A INSPECTION ITEM xx NOTES: 1. MATERIAL:POLYCARBONATE TEIJIN L-1225Y, UL FILE NUMBER E50075 2. COLOR: FOR PL114331BK COLOR IS BLACK FOR PL114331WH COLOR IS WHITE 3. WALL THICKNESS .070 [1.7] 4. DRAFT: 0.5 5. FINISHES: COSMETIC SURFACE: MOLD-TECH MT 11000 (0.0004" DEEP) 6. SEE 3D CAD FILE FOR DIMENSIONS NOT SHOWN AND TOOL BUILD INFORMATION. 7. THIS COMPONENT IS TO BE RoHS COMPLIANT. D C B ARELEASED FOR PRODUCTION5/24/10LP LP REVREVISION RECORDDATEREV BYCHK BYECO TITLE - B PART NO. EXP NO. NOTICE: ANY DESIGN OR OTHER INFORMATION HEREON DEVELOPED BY THIS COMPANY IS CONFIDENTIAL MATERIAL AND EXCLUSIVE PROPERTY OF THE L.D. KICHLER CO. DISCLOSURE OR REPRODUCTION REQUIRES THE WRITTEN CONSENT OF THE L.D. KICHLER CO. DRAWN IN PROJECTION THIRD ANGLE TOLERANCES (EXCEPT AS NOTED) DIMENSION IN [ ] OR ( ) IS FOR REF. ONLY "mm" DIMENSION INDICATED IN [ ] DECIMAL ±.005 ±.010 ±.015 ±.031 .XXX .XX .X NONE ANGULAR DATE ± 1/2° CHECKED BY LPTJT FRACTIONAL DRAWN BY ± 1/32 LP SCALE APPROVED BY FULL PL114331BK/WH HOUSING LOWER REV. REV. 3/8/10 TM A R 3.0076.20 2.3960.69 .230 5.84 .115 2.93 4X .255 [6.47] .100 [25.4] .120 [3.04] FONT: ARIAL, BOLD CHARACTER HEIGHT: .093" SCREEN PRINT MARKINGS FOR PL114331BK PRINT COLOR WHITE FOR PL114331WH RPINT COLOR BLACK ENG DENOTES A INSPECTION ITEM xx NOTES: 1. MATERIAL:POLYCARBONATE TEIJIN L-1225Y, UL FILE NUMBER E50075 2. COLOR: FOR PL114331BK COLOR IS BLACK FOR PL114331WH COLOR IS WHITE 3. WALL THICKNESS .070 [1.7] 4. DRAFT: 0.5 5. FINISHES: COSMETIC SURFACE: MOLD-TECH MT 11000 (0.0004" DEEP) 6. SEE 3D CAD FILE FOR DIMENSIONS NOT SHOWN AND TOOL BUILD INFORMATION. 7. THIS COMPONENT IS TO BE RoHS COMPLIANT. D C B ARELEASED FOR PRODUCTION5/24/10LP LP REVREVISION RECORDDATEREV BYCHK BYECO TITLE - B PART NO. EXP NO. NOTICE: ANY DESIGN OR OTHER INFORMATION HEREON DEVELOPED BY THIS COMPANY IS CONFIDENTIAL MATERIAL AND EXCLUSIVE PROPERTY OF THE L.D. KICHLER CO. DISCLOSURE OR REPRODUCTION REQUIRES THE WRITTEN CONSENT OF THE L.D. KICHLER CO. DRAWN IN PROJECTION THIRD ANGLE TOLERANCES (EXCEPT AS NOTED) DIMENSION IN [ ] OR ( ) IS FOR REF. ONLY "mm" DIMENSION INDICATED IN [ ] DECIMAL ±.005 ±.010 ±.015 ±.031 .XXX .XX .X NONE ANGULAR DATE ± 1/2° CHECKED BY LPTJT FRACTIONAL DRAWN BY ± 1/32 LP SCALE APPROVED BY FULL PL114331BK/WH HOUSING LOWER REV. REV. 3/8/10 TM A R

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: YNE-12357 FCC Rule Part: 15.249 ACS Report Number: 10-0107.W03.11.A Manufacturer: Kichler Lighting Model: 12357BK, 12357WH Internal Photos Model(s): 12357BK, 12357WH FCC ID: YNE-12357 ACS Report: 10-0107.W03.11.A Advanced Compliance Solutions Page 2 Figure 1: PCB - Front Figure 2: PCB - Back

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: YNE-12357 FCC Rule Part: 15.249 ACS Report Number: 10-0107.W03.11.A Manufacturer: Kichler Lighting Model: 12357BK, 12357WH Test Begin Date: July 15, 2010 Test End Date: July 28, 2010 Report Issue Date: January 24, 2011 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 18 pages Model: 12357BK, 12357WH FCC ID: YNE-12357 ACS Report: 10-0107.W03.11.A Advanced Compliance Solutions Page 2 TABLE OF CONTENTS 1.0 GENERAL.............................................................................................................................................................3 1.1 PURPOSE.....................................................................................................................................................3 1.2 PRODUCT DESCRIPTION..............................................................................................................................3 1.3 TEST METHODOLOGY AND CONSIDERATIONS............................................................................................3 2.0 TEST FACILITIES................................................................................................................................................4 2.1 LOCATION............................................................................................................................................................4 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS..................................................................4 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION...............................................................................................5 2.3.1 Semi-Anechoic Chamber Test Site.....................................................................................................5 2.3.2 Open Area Tests Site (OATS)...............................................................................................................6 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION...........................................................................................7 3.0 APPLICABLE STANDARD REFERENCES....................................................................................................7 4.0 LIST OF TEST EQUIPMENT.............................................................................................................................8 5.0 SUPPORT EQUIPMENT.....................................................................................................................................9 6.0 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAMS..........................................................................9 7.0 SUMMARY OF TESTS.....................................................................................................................................10 7.1 ANTENNA REQUIREMENT – FCC: SECTION 15.203........................................................................................10 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: SECTION 15.207 IC: RSS-GEN 7.2.4.................................10 7.2.1 Test Methodology.................................................................................................................................10 7.2.2 Test Results............................................................................................................................................10 7.3 UNINTENTIONAL RADIATED EMISSIONS – FCC: SECTION 15.109 IC: RSS-210 2.5....................................12 7.3.1 Test Methodology.................................................................................................................................12 7.3.2 Test Results............................................................................................................................................12 7.4 OCCUPIED BANDWIDTH – FCC: SECTION 15.215 IC: RSS-GEN 4.6.1........................................................13 7.4.1 Test Methodology.................................................................................................................................13 7.4.2 Test Results............................................................................................................................................13 7.5 FUNDAMENTAL FIELD STRENGTH – FCC: SECTION 15.249(A) IC: RSS-210 A2.9(A).................................15 7.5.1 Test Methodology.................................................................................................................................15 7.5.2 Test Results............................................................................................................................................15 7.6 BAND-EDGE COMPLIANCE AND SPURIOUS EMISSIONS – FCC: SECTION 15.249 IC: RSS-210 A2.9........15 7.6.1 Band-Edge Compliance – FCC: Section 15.249(d) IC: RSS-210 A2.9(b).................................15 7.6.1.1 Test Methodology............................................................................................................................................ 15 7.6.1.2 Test Results...................................................................................................................................................... 15 7.6.2 Radiated Spurious Emissions – FCC: Section 15.249(a) & (d), (c); IC:RSS-210 A2.9(a) & (b)..........................................................................................................................................…

Text truncated - open the document above for the full version.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: YNE-12357 FCC Rule Part: 15.249 ACS Report Number: 10-0107.W03.11.A Manufacturer: Kichler Lighting Model: 12357BK, 12357WH Test Setup Photos Model(s): 12357BK, 12357WH FCC ID: YNE-12357 ACS Report: 10-0107.W03.11.A Advanced Compliance Solutions Page 2 Figure 1: Conducted Emissions Figure 2: Conducted Emissions Model(s): 12357BK, 12357WH FCC ID: YNE-12357 ACS Report: 10-0107.W03.11.A Advanced Compliance Solutions Page 3 Figure 3: Radiated Emissions Figure 4: Radiated Emissions Model(s): 12357BK, 12357WH FCC ID: YNE-12357 ACS Report: 10-0107.W03.11.A Advanced Compliance Solutions Page 4 Figure 5: Radiated Emissions
