YNKPG731HouseParty Portable Wireless

HouseParty ® Portable Wireless User Manual | Manuel d’utilisation Manual del usuario Thank you for buying the GEAR4 HouseParty Portable Wireless, an app-enhanced home speaker for iPod touch, iPhone and iPad that also works with a wide variety of Bluetooth devices. Please read this manual before use and retain it for future reference. Merci d’avoir choisi le système GEAR4 HouseParty Portable Wireless, un haut-parleur domestique avec une app pour iPod touch, iPhone et iPad qui fonctionne aussi avec une grande variété de périphériques Bluetooth. Veillez à lire attentivement ce manuel d’utilisation avant de l’utiliser et conservez-le pour vous y reporter par la suite. Gracias por la compra de HouseParty Portable Wireless de GEAR4, un altoparlante doméstico con mejora mediante aplicación para iPod touch, iPhone e iPad que también funciona con una amplia gama de dispositivos Bluetooth. Lee este manual antes de usar el producto y consérvalo para futuras consultas. open Title: GEAR4 PG731US HouseParty Portable Wireless Date: 5 December 2012 Version: US V1.3 - 1428 Artwork Owner: [email protected] Finished Dimensions: Height: 124mm Width: 124mm N30346 V1.3 - US - 1428 FCC ID: YNKPG731 IC: 8846A-PG731 Made in ChinaFabriqué en Chine Le mot Bluetooth ® et les logos sont des marques déposées de Bluetooth SIG inc., et toute utilisation de ces marques par Disruptive ltée est en vertu d’une licence. Model / Modèle : PG731 Power adapter / Adaptateur d’alimentation : S032BU1200250 Input / Entrée : 100V-240V ~50/60Hz 900mA Output / Sortie : 12V / 2.5A The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Disruptive Ltd. is under license. 7132 20 2GEAR4 | HouseParty Portable Wireless | User Manual HouseParty Portable Wireless Please read before use. Product features: ■Wireless universal portable speaker ■Ultimate Bluetooth audio with aptX ® and AAC ■Rechargeable lithium-ion battery ■Customisable power management ■USB port for charging mobile devices ■Line-in port for use with other music players ■Up to 12 hours’ battery life* Getting started: ■Plug the power cable into the back of the unit and then into the mains supply. ■Charge your battery for 24 hours to calibrate and get the best performance. ■To activate the speaker, press the POWER button (). Note: When pairing your iPod touch, iPhone or iPad to HouseParty Portable Wireless for the first time, your device will display a notification that your accessory requires an application. Tap OK to go to the App Store download page and proceed to install the free SmartLink Wireless app. To connect your handset with HouseParty Portable Wireless using Bluetooth: ■The unit should be on, the power indicator blue. ■Ensure that the Bluetooth () LED is fast flashing (if slow flashing press Bluetooth () button for 6 seconds until a beep is heard). ■If using an iPhone/iPad go to Settings > General > Bluetooth. Ensure Bluetooth () is turned on. ‘HPP Wireless’ should appear in the list of devices. Select to pair. ■If using an Android device go to Menu > Settings > Wireless & Networks. Ensure Bluetooth () is turned on. Select Bluetooth Settings > Scan for Devices. ‘HPP Wireless’ should appear in the list of devices. Select to pair. ■Your handset should now be paired and your audio applications operate through your HouseParty Portable Wireless. ■To connect additional devices follow the above process again. *Wireless app-enhanced features require GEAR4 SmartLink app for iPhone 4S, iPhone 4, iPhone 3GS, iPod touch (3rd and 4th generation only), iPad (3rd generation), iPad 2 or iPad with iOS 5.0 or higher. Bluetooth connectivity requires iOS 5.0 or higher. Bluetooth range up to 20m, depending on line of sight. App screens correct at time of print. Extended power mode will deliver lower volume output. 3 GEAR4 | HouseParty Portable Wireless | User Manual To reconnect your paired handset to HouseParty Portable Wireless using Bluetooth: ■If your handset was the last device to be connected this will happen automatically. ■Otherwise, press the Bluetooth () button. The Bluetooth () LED should go out. Open your list of paired devices on your handset and select to connect. Note: Only one device can be connected to the speaker at any given time. Wireless app-enhanced for iOS devices: Smarter than your average speaker, free app available from the App Store; ■Use your iPod touch, iPhone or iPad to control the speaker, wirelessly. Simply pair your device with the speaker via Bluetooth and launch the SmartLink Wireless app. ■Stream music wirelessly from the iPod touch, iPhone or iPad in your hand over Bluetooth. You can do this from the music library on your device or through the SmartLink Wireless app. ■Power Management controls let you switch to different power modes to save battery life. A battery indicator tells you the state of charge of the battery. ■The Equaliser controls allow you to optimise the speaker to your choice of music. Charging: ■To charge your device, please make sure your power supply is connected to the speaker. ■Use the USB charge port to charge your personal electronic devices. This is compatible with most Smartphones, Tablets or MP3 players with 1.5A charging. ■Charging your HouseParty Portable Wireless from empty will take about 4 hours, longer if other items are connected. To change to AUX mode: ■Press and hold the power button () until an audio tone is heard (about 6 seconds). This indicates that the mode change is successful. ■To return to Bluetooth from AUX mode, press and hold the power button () for 6 seconds. For use with other audio devices: ■Make sure that the speaker is in AUX mode. Please see above to change modes. ■Plug one end of a 3.5mm audio cable (not included) into your MP3 or MP4 player and connect the other end into the AUX line-in port at the back of the unit. 4GEAR4 | HouseParty Portable Wireless | User Manual Power and Factory Reset: ■The speaker will enter standby mode from …

Text truncated - open the document above for the full version.

1 Photographs - EUT Constructional Details Test model No.: PG731

1 Photographs - EUT Constructional Details Test model No.: PG731

SGS-CSTC Standards Technical Services Ltd. No. 1 W orkshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM120800451301 Page: 1 of 75 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover page FCC REPORT Application No: SZEM1208004513RF Applicant: Disruptive Ltd. Manufacturer: Disruptive Ltd. Factory: Dong Guan Tai Sing Audio Technology Ltd. Product Name: HouseParty Portable Wireless Model No.(EUT): PG731 FCC ID: YNKPG731 Standards: 47 CFR Part 15, Subpart C (2011) Date of Receipt: 2012-08-10 Date of Test: 2012-08-21 to 2012-08-28 Date of Issue: 2012-11-13 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM120800451301 Page: 2 of 75 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 (2009) PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 (2009) PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(1) ANSI C63.10 (2009) PASS 20dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Carrier Frequencies Separation 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Hopping Channel Number 47 CFR Part 15, Subpart C Section 15.247 (b) ANSI C63.10 (2009) PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15, Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10 (2009) PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS Radiated Spurious emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS Band Edge (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM120800451301 Page: 3 of 75 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. …

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup (Test model No.: PG731) 1.1 Conducted Emission 1.2 Radiated Emission
