YW2-9701KBZAGGmate with keyboard

MAKING THE MOST SEPARATING 1: PLACE THE ZAGGmate™ VERTICALLY ON A NON-SLIP SURFACE. 2: USING TWO HANDS, PLACE ONE HAND ON EACH SIDE OF THE ZAGGmate, WITH THUMBS SITUATED JUST ABOVE THE 30-PIN CHARGING PORT, OR THE SIDE WITH KEYBOARD CUTOUT. 3: SECURE THE ZAGGmate WITH ONE THUMB AND THE iPAD® WITH YOUR OTHER THUMB. APPLY SLIGHT DOWNWARD PRESSURE TO iPAD AND SEPARATE. 30-PIN CHARGING PORT KEYBOARD CUTOUT POSITIONING 1 1: LIFT HINGE AND LOCK INTO PLACE BY SLIDING TAB BACK INTO LOCKING SLOTS AND APPLYING SLIGHT PRESSURE. 2: PLACE iPAD (EITHER IN PORTRAIT OR LANDSCAPE MODE) INTO CENTRAL GROOVE, AND REST AGAINST RAISED HINGE. CENTRAL GROOVE RAISED HINGE BATTERY ZAGGmate’s LONG-LIFE BATTERY CAN STAY CHARGED FOR A COUPLE OF MONTHS IN STANDBY. WHEN NOT IN USE, TURN OFF THE KEYBOARD TO LENGTHEN BATTERY LIFE. ZAGGmate WILL GO INTO SLEEP MODE IF LEFT ON AND NOT BEING USED; PRESS A KEY AND WAIT A SECOND OR TWO TO BRING IT OUT OF SLEEP MODE. PLEASE NOTE: ZAGGmate IS MADE FROM AIRCRAFT ALUMINUM WITH A HIGH-GRADE FINISH SIMILAR TO THE FINISH ON MANY POPULAR DEVICES. OPTIONAL: A SET OF FOUR RUBBER FEET IS INCLUDED THAT CAN BE PLACED ON EACH CORNER TO HELP PREVENT SCRATCHING ZAGGmate’s HIGH-GRADE FINISH. FOR UNPARALLELED SCRATCH PROTECTION, WE RECOMMEND ZAGG'S invisibleSHIELD® OR ZAGGskins™. THE iPAD’S PERFECT COMPANION w w w . Z A G G . c o m ©2005 - 2010 ZAGG Inc. All Rights Reserved. PATENT PENDING | NASDAQ: ZAGG | MADE IN CHINA iPad® and Apple® are registered trademarks of Apple, Inc. ZAGG, invisibleSHIELD, invisibleSHIELD with design, and ZAGGmate, are trademarks or registered trademarks of ZAGG Inc. OF YOUR NEW COMPANION This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1: This device may not cause harmful interference, and 2: this device must accept any interference received, including interference that may cause undesired operation

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 Wagons Digital Co., Ltd. 2011-12-14 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: YW2-9701KB We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematic Diagram - Circuit Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature KEI YAU LAM/ Marketing Manager E-mail : [email protected] Phone : 852-31176172 Fax : 852-31176172 Address : Flat/Rm.1701, 17/F., Henan Building, 90 Jaffe Road, Wanchai, Hongkong

Wagons Digital Co., Ltd. Date:2011-12-14 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: YW2-9701KB To Whom It May Concern: This letter is to ascertain that Wagons Digital CO., LTD. Product ZAGmate with keyboard, has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Signature KEI YAU LAM/ Marketing Manager E-mail : [email protected] Phone : 852-31176172 Fax : 852-31176172 Address : Flat/Rm.1701, 17/F., Henan Building, 90 Jaffe Road, Wanchai, Hongkong

Report No.: TB-FCC112728 Page: 3 of 9 TB-RF-075-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Report No.: TB-FCC112728 Page: 4 of 9 TB-RF-075-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT

Report No.: TB-FCC112728 Page: 1 of 9 TB-RF-074-1.0 Appendix IID Label FCC ID: YW2-9701KB This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Report No.: TB-FCC112728 Page: 2 of 9 TB-RF-075-1.0 Appendix II ID Label Location FCC ID LOCATION

Report No.: TB-FCC112728 Page: 5 of 9 TB-RF-075-1.0 Appendix IV EUT Internal Photographs Photo 5 Inside of EUT Photo 6 Appearance of PCB Report No.: TB-FCC112728 Page: 6 of 9 TB-RF-075-1.0 Photo 7 Appearance of PCB Photo 8 Appearance of PCB Report No.: TB-FCC112728 Page: 7 of 9 TB-RF-075-1.0 Photo 9 Appearance of PCB Photo 10 Appearance of Battery Antenna

FCC ID : YW2-9701KB (Portable device) According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz) High Frequency(MHz) Center frequency (MHz) 60/f SAR Limitation (mw) 2402 2480 2441 25 Maximum measured transmitter power: Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 1.091 1.87 1.678 Threshold at which no SAR required is 25 mw. Maximum Tx power is 1.678 mw EIRP. Conclusion: No SAR is required. Sincerely, Signature KEI YAU LAM/ Marketing Manager E-mail : [email protected] Phone : 852-31176172 Fax : 852-31176172 Address : Flat/Rm.1701, 17/F., Henan Building, 90 Jaffe Road, Wanchai, Hongkong

Shenzhen Meihua Electronic Technology Co., Ltd. Report No.: TB-FCC112728 Page: 1 of 49 TB-RF-074-1.0 Room 505, East DingXin Bldg., LiuXian Road, XiLi Town, Nanshan, Shenzhen, China Tel: +86 75526292087 Fax: +86 75526751700 FCC Radio Test Report FCC ID: YW2-9701KB Report No. : TB-FCC112728 Applicant : Wagons Digital Co., Ltd. Equipment Under Test (EUT) EUT Name : ZAGGmate with keyboard Model No. : ZMAP9701KB Serial No. : N/A Brand Name : ZAGG Receipt Date : 2011-12-06 Test Date : 2011-12-07 to 2011-12-12 Issue Date : 2011-12-14 Standards : FCC Part 15, Subpart C Test Method : ANSI C63.4:2003 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC requirements Test/Witness Engineer : Approved& Authorized : This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC112728 Page: 2 of 49 TB-RF-074-1.0 Contents CONTENTS.............................................................................................................................................2 1. GENERAL INFORMATION ABOUT EUT.............................................................................4 1.1 Client Information.................................................................................................................4 1.2 General Description of EUT (Equipment Under Test)...................................................4 1.3 Block Diagram Showing the Configuration of System Tested......................................6 1.4 Description of Support Units..............................................................................................6 1.5 Description of Test Mode....................................................................................................7 1.6 Test Facility...........................................................................................................................7 2. TEST SUMMARY.......................................................................................................................8 3. CONDUCTED EMISSION TEST.............................................................................................9 3.1 Test Standard and Limit......................................................................................................9 3.2 Test Setup.............................................................................................................................9 3.3 Test Procedure.....................................................................................................................9 3.4 Test Equipment Used........................................................................................................10 3.5 EUT Operating Mode........................................................................................................10 3.6 Test Data.............................................................................................................................10 4. RADIATED EMISSION TEST................................................................................................13 4.1 Test Standard and Limit....................................................................................................13 4.2 Test Setup...........................................................................................................................14 4.3 Test Procedure...................................................................................................................15 4.4 EUT Operating Condition.................................................................................................15 4.5 Test Equipment..................................................................................................................16 5. RESTRICTED BANDS REQUIREMENT.............................................................................23 5.1 Test Standard and Limit....................................................................................................23 5.2 Test Setup...........................................................................................................................23 5.3 Test Procedure...................................................................................................................23 5.4 EUT Operating Condition.................................................................................................24 5.5 Test Equipment..................................................................................................................24 6. NUMBER OF HOPPING CHANNEL....................................................................................27 6.1 Test Standard and Limit....................................................................................................27 6.2 Test Setup...........................................................................................................................27 6.3 Test Procedure...................................................................................................................27 6.4 EUT Operating Condition.................................................................................................27 6.5 Test Equipment..................................................................................................................27 7. AVERAGE TIME OF OCCUPANCY.....................................................................................29 7.1 Test Standard and Limit....................................................................................................29 7.2 Test Setup...........................................................................................................................29 7.3 Test Procedure....…
